2AQZU-18037CEILING FAN REMOTE CONTROL

CEILING FAN REMOTE CONTROL MANUAL LEARNING PROCESS NOTE: The Hand Held Remote Control System is equipped with a learning frequency function which has code combinations to prevent potential interference from other remote units. Step: 1. Install 2pcs DC1.5V/AAA batteries. Within 30 seconds of turning the receiver AC power ON. Press the transmitter’s LEARN button. Step: 2. Hold LEARN button over 5 seconds. Once the receiver has detected the frequency, the ceiling fan would turn on low speed. This will indicate the receiver has learned the frequency that was previously selected on the transmitter. NOTE: After the AC power is on, do not press any other button on the transmitter as doing pairing. Because it might be to cause the procedure to fail. After completing the steps above, you should be able to operate the ceiling fan. If the fan is not responding to the transmitter, please turn the power off to the receiver. And repeat step 1 and 2. NOTE: Remove the battery if not used for long periods of time to prevent damage to the hand held remote. FUNCTIONS OF TRANSMITTER : Press and release instantly to turn on or off ceiling fan and lights. 1. FAN SPEED： 1: Turn on ceiling fan at 1st speed (lowest speed) 2. Turn on ceiling fan at 2nd speed 3. Turn on ceiling fan at 3rd speed 4. Turn on ceiling fan at 4th speed 5. Turn on ceiling fan at 5th speed 6. Turn on ceiling fan at 6th speed (high speed) : Turn off ceiling fan. 2. FAN TIMER: When the fan turned on. 1H ：Setting up that the ceiling fan will turn off after 1 hour automatically. 3H ：Setting up that the ceiling fan will turn off after 3 hours automatically. 6H ：Setting up that the ceiling fan will turn off after 6 hours automatically. 3. :set fan wind direction up or down. 4. -- Natural breeze: Fan speed will modulate to simulate a natural breeze. 5. :Press and turn the light on or off. Press and hold to dim or brighten light to the desired level and release. 6. :Press for multi-color, cool or warm color setting 7. : Press for color-temperature change setting Installation of Transmitter Wall Mount Holder with Two screws. To assure continued FCC compliance: FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. CAUTION: To assure continued FCC compliance: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. FCC ID：2AQZU-18037 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Satellite Electronic(Zhong Shan)Ltd. No.8, Chuang Ye Road, Torch Development Zone, Zhongshan, Guangdong, China Date: 2023-03-27 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2AQZU Satellite Electronic(Zhong Shan)Ltd. certifies that, as of the date of the filing of the application, Orientalindustries Group is our designated U.S. agent for service of process for the above referenced Grantee Code. Satellite Electronic(Zhong Shan)Ltd. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Orientalindustries Group accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced Grantee Code. Designated U.S. Agent Information: Name: Orientalindustries Group FRN: 0033523226 Address: 1639 Clarks Lane,SanchezJoseCA95129,USA Contact Person: Mr. Simon Kang Chen Tel.: (650) 433 6921 Email: [email protected] Sincerely, Signed on behalf of Satellite Electronic(Zhong Shan)Ltd. Signed on behalf of rientalindustries Group Name: sean zheng Name: Mr. Simon Kang Chen Title: Manager Title: President Date: 2023-03-27 Date: 2023-03-27

Satellite Electronic(Zhong Shan)Ltd. No.8, Chuang Ye Road, Torch Development Zone, Zhongshan, Guangdong, China Date: 2023-03-22 FEDERAL COMMUNICATIONS COMMISSION AUTHORIZATION AND EVALUATION DIVISION 7435 OAKLAND MILLS ROAD COLUMBIA, MD 21046 SUBJECT: FCC Application for FCC ID: 2AQZU-18037 Confidentiality Request To whom it may concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. ☒ Block Diagram ☐ Tune-Up Information ☒ Operational Description ☐ Security Information ☒ Schematics ☐ Software Defined Radio (SDR) Information ☐ Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ User Manual ☐ For 45 days, pursuant to Public Notice DA 04-1705. or ☐ For 180 days pursuant to KDB 726920 D01. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signatory [sean zheng, Manager]

Reference No.: WTH23X02030184W Page 2 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTH23X02030184W Page 3 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTH23X02030184W Page 4 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTH23X02030184W Page 5 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTH23X02030184W Page 1 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2AQZU-18037 Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTH23X02030184W Page 6 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 Reference No.: WTH23X02030184W Page 7 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Antenna View

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Satellite Electronic(Zhong shan)Ltd. Address of applicant: No.8, Chuang Ye Road, Torch Development Zone, Zhongshan, Guangdong, China. Manufacturer: Satellite Electronic(Zhong shan)Ltd. Address of manufacturer: No.8, Chuang Ye Road, Torch Development Zone, Zhongshan, Guangdong, China. General Description of EUT: Product Name: CEILING FAN REMOTE CONTROL Trade Name: / Model No.: RMSMTFAN Adding Model(s): / Rated Voltage: DC1.5V*2”AAA” Power Adaptor : / FCC ID: 2AQZU-18037 Equipment Type: Portable device Technical Characteristics of EUT: Frequency Range: 2426MHz Max. Field Strength: 99.94dBuV/m Modulation: GFSK Quantity of Channels: 1 Channel Separation: 2MHz Antenna Type: PCB Antenna Antenna Gain: 2.18dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Max. Field Strength Antenna Gain Output Power Tune-Up Power ERP (MHz) (dBuV/m) (dBi) (dBm) (dBm) (dBm) SRD 2426 99.94 2.18 2.5 3.0 3.03 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2426 B 0.5 3.03 2.01 2.766 0.73 Pass Note: 1. EIRP= E-104.8+20logD; Output Power=EIRP- Antenna Gain; ERP=EIRP-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Ratio 3 Simultaneous Ratio Limit Result Pass/Fail / / / / / / / Result: Pass

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 29 TEST REPORT Reference No. .................... : WTH23X02030184W FCC ID ................................ : 2AQZU-18037 Applicant ........................... : Satellite Electronic(Zhong shan)Ltd. Address.............................. : No.8, Chuang Ye Road, Torch Development Zone, Zhongshan, Guangdong, China. Manufacturer ..................... : The same as Applicant Address.............................. : The same as Applicant Product Name ................... : CEILING FAN REMOTE CONTROL Model No... ......................... : RMSMTFAN Standards .......................... : FCC Part 15.249 Date of Receipt sample .... : 2023-02-24 Date of Test........................ : 2023-02-24 to 2023-03-02 Date of Issue ..................... : 2023-03-02 Test Report Form No. ....... : WTX_Part 15_249W Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTH23X02030184W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 29 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .........................................................................4 1.2 TEST STANDARDS .................................................................................................................................................5 1.3 TEST METHODOLOGY ...........................................................................................................................................5 1.4 TEST FACILITY ......................................................................................................................................................5 1.5 EUT SETUP AND TEST MODE ..............................................................................................................................6 1.6 MEASUREMENT UNCERTAINTY .............................................................................................................................7 1.7 TEST EQUIPMENT LIST AND DETAILS ...................................................................................................................8 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 11 3. ANTENNA REQUIREMENTS .............................................................................................................................. 12 3.1 STANDARD APPLICABLE ..................................................................................................................................... 12 3.2 TEST RESULT ...................................................................................................................................................... 12 4. RADIATED EMISSIONS ....................................................................................................................................... 13 4.1 STANDARD APPLICABLE ..................................................................................................................................... 13 4.2 TEST PROCEDURE .............................................................................................................................................. 13 4.3 CORRECTED AMPLITUDE & MARGIN CALCULATION ........................................................................................... 16 4.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 16 5. OUT OF BAND EMISSIONS ................................................................................................................................ 20 5.1 STANDARD APPLICABLE ..................................................................................................................................... 20 5.2 TEST PROCEDURE .............................................................................................................................................. 20 5.3 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 20 6. EMISSION BANDWIDTH ...................................................................................................................................... 24 6.1 STANDARD APPLICABLE ..................................................................................................................................... 24 6.2 TEST PROCEDURE .............................................................................................................................................. 24 6.3 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 24 7. DUTY CYCLE ......................................................................................................................................................... 26 7.1 STANDARD APPLICABLE ..................................................................................................................................... 26 7.2 TEST PROCEDURE .....................................................................…

Text truncated - open the document above for the full version.

Reference No.: WTH23X02030184W Page 8 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Radiation Emission Test Setup (Below 30MHz) Radiation Emission Test Setup (30MHz to 1GHz) Reference No.: WTH23X02030184W Page 9 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Radiation Emission Test Setup (1GHz to 18GHz) Radiation Emission Test Setup (Above 18GHz) Reference No.: WTH23X02030184W Page 10 of 10 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ***** END OF REPORT *****
