2AR2STAT2569True wireless headphones

User manual Register your product and get support at www.philips.com/support Headphones 2000 Series TAT2569 1 Important Safety Instructions 2 Hearing Safety 2 General information 2 2 Your open ear wireless earpieces 3 What is in the box 3 Other devices 3 Overview of your open ear wireless earpieces 4 3 Get started 5 Charge the battery 5 How to wear 5 Pair the earpieces with your 6 Pair the earpieces with another Bluetooth device 6 4 Use your earpieces 7 Connect the earpieces to your Bluetooth device 7 P 7 Manage your calls and music 7 Voice assistant 8 Earpieces LED indicator status 8 Charging case LED indicator status 8 5 Reset the earpieces 9 6 Technical data 9 7 Notice 10 Declaration of conformity 10 Dispose of your old product and battery 10 Remove the integrated battery 10 Compliance with EMF 11 Environmental information 11 Notice of compliance 11 8 Trademarks 13 9 Fr equently asked questions 14 Contents EN2 1 Important Safety Instructions Hearing Safety Danger • To avoid hearing damage, limit the time you use earpieces at high volume and set the volume to a safe level. The louder the volume, the shorter the safe listening time is. Be sure to observe the following guidelines when using your earpieces. • Listen at reasonable volumes for reasonable periods of time. • Be careful not to adjust the volume continuously upwards as your hearing adapts. • Do not turn up the volume so high that you can’t hear what’s around you. • You should use caution or temporarily discontinue use in potentially hazardous situations. • Excessive sound pressure from earpieces and headphones can cause hearing loss. • Using earpieces with both ears covered while driving is not recommended and may be illegal in some areas. • For your safety, avoid distractions fr om music or phone calls while in environments. General information To avoid damage or malfunction: CAUTION • Do not expose earpieces to excessive heat. • Do not drop your earpieces. • Earpieces shall not be exposed to dripping or product.) • Do not allow your earpieces to be submerged in water. • Do not charge your earpieces when the connector or socket is wet. • Do not use any cleaning agents containing alcohol, ammonia, benzene or abrasives. • If cleaning is required, use a soft cloth, if necessary dampened with a minimum amount of water or diluted mild soap, to clean the product. • The integrated battery shall not be exposed to • Danger of explosion if batteries are incorrectly replaced. Replace only with the same or equivalent type. • slot cover must be closed. • mechanically crushing or cutting a battery, can result in an explosion. • Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of • A battery subjected to extremely low air pressure that may result in an explosion or the • only by external power source which output shall comply with PS1 (with output capacity less than 15W). Operating and storage temperatures and humidity • Store in a place where the temperature is between -20°C (-4°F) and 50°C (122 °F) with up to 90% relative humidity. • Operate in a place where the temperature is between 0°C (32°F) and 45°C (113 °F) with up to 90% relative humidity. • Battery life may be shorter in high or low temperature conditions. • Replacement of a battery with an incorrect type risks severely damaging the earpieces and the battery (for example, in the case of some lithium battery types). 3EN 2 Your open ear wireless earpieces Congratulations on your purchase, and your product at www.philips.com/support. With these Philips True wireless earpieces you can: • Enjoy convenient wireless handsfree calls • Enjoy and control music wirelessly • Switch between calls and music What is in the box Philips open ear wireless earpieces Philips TAT2569 Type-C charging cable Silicone ear tip covers (f or charging only) Other devices A mobile phone or device (e.g. notebook, tablet, Bluetooth adapters, MP3 players etc) which supports Bluetooth and is compatible with the earpieces. LS Quick Start Guide Warranty 2000 Series TAT2569 EN4 Overview of your open ear wireless earpieces ① Multi-function touch (MFT) ② Speaker ③ Sound hole ④ Charging pogo pin ⑤ LED indicator (battery state or charging state) ⑥ USB-C charging port ④ ⑤ ⑥ 5EN 3 Get started Charge the battery Note • Before you use your earpieces, place them in the charging case and charge the battery for 2 hours for optimum battery capacity and lif etime. • Use only the original USB-C charging cable to avoid any damage. • Finish your call before charging. Connect the earpieces to the charger, the earpieces will turn • If the earpieces are not used for a long time, the rechargeable battery will begin to lose its charge. To avoid this loss, please fully charge the battery at least once every three months. Charging case Plug one end of the USB-C cable into the charging case and the other end into the power source. Tips • The charging case serves as a portable backup battery for charging the earpieces. When the charging case is fully charged, it will fully recharge the earpieces 2 times. Earpieces Put the earphones into the charging compartment and cover the charging compartment • The earphones start charging, and the blue LED indicator light is on • When the earphones are fully charged, the indicator light goes out Tips • Normally, a full charge takes 2 hours (for the earpieces or charging case) by USB cable. How to wear Insert the earpieces 1 Check left or right orientation of the earpieces. 2 Insert the earpieces into the ears achieved. EN6 Pair the earpieces with 1 Make sure that the earpieces are fully 2 Open the charging case cover and turn on the earphones » » The earpieces are now in pairing mode and are ready to pair with a Bluetooth device (e.g. a mobile phone) 3 Turn on the Bluetooth function of your Bluetooth device. 4 Pair the earpieces with your Bluetooth device, ref er to the user manual of your Bluetooth device. Note • any previously conn…

Text truncated - open the document above for the full version.

MMD Hong Kong Holding Limited 120623-17 rev 9 Certification Application Attestation Statements Date: September 25, 2025 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) __ MMD Hong Kong Holding Limited certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ___ MMD Hong Kong Holding Limited ____ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / - is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates – see KDB 986446 Question 5) as an entity producing “covered” equipment. The applicant also certifies that the device does not have cybersecurity and/or anti-virus software produced by Kaspersky Lab, Inc or any of its successors and assignees identified on the covered list installed on the device, nor will it be installed by the applicant at any time after certification. Thank you, By: _______________________ _______ Tomas Guan _______ (Signature 2 ) (Print name) Title: ___ Safety & Approbation Manager ___ On behalf of: __ MMD Hong Kong Holding Limited __ (Company Name) Telephone: ___86-755-36358341 ________ 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: TPV-USA Corp Contact Name: Gcoff Bostwick Street Address: 6525 Carnegie Blvd., Suite #200 Charlotte, NC 28211 City/Province/Zip: NA Telephone No: 980-890-7523 Email: [email protected] FRN #: 0033543315 Th is letter i s t o confirm that we (“t he Designated U.S . Agent) have accepted the responsibility t o act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: September 15, 2025 Signed by (Gcoff Bostwick / Sales Manager): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- rel ated proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: MMD Hong Kong Holding Limited FCC ID: 2AR2STAT2569 FRN #: 0028068138 Contact Name: Tomas Guan Street Address: Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Telephone No: 86-755-36358341 Extension: -- Email: [email protected] Applicant Signature 1 : Date: September 15, 2025 Signed by (Tomas Guan / Safety & Approbation Manager): 1 - Letters must be placed on appropriate letterhead. The signee for the applicant must be one of the following: Applicant (grantee) contact of record in the FCC’s authorization system, or authorized officers or employee of the applicant (grantee).

MMD Hong Kong Holding Limited 050222-17 Authority to Act as Agent Date: September 25, 2025 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: ______ Shenzhen UnionTrust Quality and Technology Co., Ltd.______ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: _____ 12 months___ By: __________________________ ____ Tomas Guan ____ (Signature 1 ) (Print name) Title: __Safety & Approbation Manager ___ On behalf of: ___ MMD Hong Kong Holding Limited __ (Company Name) Telephone: 86-755-36358341 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

MMD Hong Kong Holding Limited Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong 050222-17 Request for Confidentiality Date: September 25, 2025 Subject: Confidentiality Request for: ___2AR2STAT2569 ____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and/or IC RSP-100, Section 12.4, the applicant requests that a part of the subject application(s) be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☐ Short Term --------------------------- External Photos ☐ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☐ Permanent Parts List & Placement/BOM ☐ Short Term ☐ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☐ Short Term --------------------------- Test Setup Photos ☐ Short Term ☐ Permanent * 1 User’s Manual _____ MMD Hong Kong Holding Limited______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Sincerely, By: (Signature/Title 2 ) Safety & Approbation Manager (Print name) Tomas Guan The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

MMD Hong Kong Holding Limited Product Similarity Declaration Product name: True wireless headphones Model name: TAT2569, TAT2569xx/yy (xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination) We (MMD Hong Kong Holding Limited) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name. Signature: Name: Title: Safety & Approbation Manager Place, date Hong Kong

Page 1 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT EXTERNAL PHOTOS EUT Photo EUT Photo Page 2 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 3 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 4 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 5 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 6 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 7 of 7 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo

Model:TAT 2569 Ref No.:TAT 2569BK/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMG2537000001 Model:TAT 2569 Ref No.:TAT 2569WT/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMH2537000001 Model:TAT 2569 Ref No.:TAT 2569WT/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMH2537000001 TAT 2569 WT/37 TAT 2569 BK/37 TAT 2569 DB/37 Model:TAT 2569 Ref No.:TAT 2569 BK/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMG2537000001 Model:TAT 2569 Ref No.:TAT 2569 D B/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMJ2537000001 Model:TAT 2569 Ref No.:TAT 2569D B/37 Input:5.0V 500mA Output:5.0V 35mAx2 Battery Capacity: 3.7V , 400mAh , 1.48Wh FCC ID:2AR2STAT2569 IC:24589 -TAT2569 Made in China SN:AYMJ2537000001 21mm 4.94mm 18mm 10.8mm10.8mm10.8mm 21mm 4.94mm 18mm21mm 4.94mm 18mm

Page 1 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS EUT INTERNAL PHOTOS EUT Photo(Left earbud) EUT Photo(Left earbud) Page 2 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo(Left earbud) EUT Photo(Left earbud) BT Antenna Page 3 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo(Right earbud) EUT Photo(Right earbud) Page 4 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo(Right earbud) EUT Photo(Right earbud) BT Antenna Page 5 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 6 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 7 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo EUT Photo Page 8 of 8 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com EUT Photo

Page 1 of 8 Report No.: 25090119754RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 SAR TEST EXCLUSION EVALUATION REPORT Product Name: True wireless headphones Trade Mark: PHILIPS or Model No. /HVIN: TAT2569 Add. Model No.: TAT2569xx/yy (xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination) Report Number: 25090119754RFC-2 Test Standards: FCC 47 CFR Part 2.1093 RSS-102 Issue 6 FCC ID: 2AR2STAT2569 IC: 24589-TAT2569 Test Result: PASS Date of Issue: September 25, 2025 Prepared for: MMD Hong Kong Holding Limited Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Prepared by: Shenzhen UnionTrust Quality and Technology Co., Ltd. 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China TEL: +86-755-2823 0888 FAX: +86-755-2823 0886 Prepared by: Reviewed by: David Chen Kevin Liang Senior Project Engineer Assistant Manager Approved by: Date: September 25, 2025 Billy Li Technical Director Page 2 of 8 Report No.: 25090119754RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 Version Version No. Date Description V1.0 September 25, 2025 Original Page 3 of 8 Report No.: 25090119754RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 4 1.4 OTHER INFORMATION ......................................................................................................................................... 5 1.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................................... 5 1.6 DEVIATION FROM STANDARDS ............................................................................................................................ 5 1.7 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 5 1.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 5 2. EQUIPMENT LIST .................................................................................................................................................... 5 3. SAR TEST EXCLUSION EVALUATION ................................................................................................................... 6 3.1 REFERENCE DOCUMENTS FOR EVALUATION ........................................................................................................ 6 3.2 EXEMPTION LIMITS FOR ROUTINE EVALUATION – SAR EVALUATION .................................................................... 6 3.2.1 SAR TEST EXCLUSION THRESHOLD ........................................................................................................ 6 3.2.2 TEST PROCEDURE ................................................................................................................................. 7 3.3 MPE CALCULATION RESULTS ............................................................................................................................ 7 3.3.1 FOR BT ................................................................................................................................................. 7 APPENDIX 1 PHOTOS OF TEST SETUP ....................................................................................................................... 8 APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS ................................................................................... 8 Page 4 of 8 Report No.: 25090119754RFC-2 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6th, Baoneng Science and Technology Park, Longhua Street, Longhua District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] http://www.uttlab.com UTTR-RF-RSS102-V1.1 1. GENERAL INFORMATION 1.1 CLIENT INFORMATION Applicant: MMD Hong Kong Holding Limited Address of Applicant: Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong Manufacturer: MMD Hong Kong Holding Limited Address of Manufacturer: Units 1208-11, 12th Floor, C-Bons International Center, 108 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong 1.2 EUT INFORMATION Product Name: True wireless headphones Model No./ HVIN: TAT2569 Add. Model No.: TAT2569xx/yy (xx=AA-ZZ or blank denoted different color; yy=00-99 denoted different country destination) Trade Mark: PHILIPS or DUT Stage: Identical Prototype EUT Supports Function: (Provided by the customer) 2.4 GHz ISM Band: Bluetooth 5.4 Sample Received Date: September 1, 2025 Note: 1. Th…
