2AR3KPLBFK006Smart Fingerprint Padlock

www.prezlock.com User Manual Prezlock Pebble Plus R Email: [email protected] Product details 7 8 Shackle Button LED Fingerprint SensorCylinderType-C Charging port Key x 2 * 1 2 3 4 5 6 7 6 5 2 1 3 4 * Please keep the code number on the key as record. 8 8 Type-C Cable Unlock your Pebble+ Use Limit If you are currently on factory settings, before Master fi ngerprint is registered, any fi ngerprint or skin can open the lock. To unlock by fi ngerprint, place a fi nger on the Fingerprint Sensor. When you see a green LED light, simply pull out the shackle to unlock.To unlock by key, insert the key into the cylinder and turn it clockwise by 90 degrees, then pull out the shackle to unlock.To unlock by App, please open the App and turn on Bluetooth and location as required,then press the lock button and LED fl ashes blue light, pull out the lock shackle to unlock when the LED light turns green. Device operates between -20C to 60C. Exposure to higher or lower temperatures may damage battery or even cause an explosion. Response time may be slower in low temperatures. The lock is designed and certi fi ed with IP65 weatherproof rating. Do not lay fl at the lock allowing water to get into the charging port for a long period of time.When fl ying, only put device on carry-on luggage, not on check-in luggage. If you touch the fi ngerprint sensor and a red light blinks continuously for 5 seconds, it means the lock power is low, please recharge the battery. Speci fi cation Ways to unlock Fingerprint Key or App Lock release time About 0.9 second Weight About 280 grams Working temperature -20C to 60C Dimension Shackle clearance Shackle hole diameter Case and shackle materialNumber of fi ngerprint storage capacityFingerprint detectionSensor lifespanBattery capacity 51 x 100 x 24 mm 23 x 27 mm8 mm Alloy metal / SteelUp to 100360° detection1 million fi ngerprint senses Rechargeable battery of 300mAh Battery lifeChargerUSB PortFull charging time 6 months per charge or about 3,000 unlocks5 V / 1 A Type-CAbout two hours Locking Mechanism Double Ball Bearing Speci fi cation Encompassing Fingerprint Sensor speci fi cation Size 14mm diameter Sensor array 160 x160 Pixels Spatial resolutionFAR ESD +/- 15KV air+/- 8KV contact FRR < 1% < 0.001% 508 DPI Bluetooth version Bluetooth4.0 Operating system iOS 11 or aboveAndroid 6.0 or above Functions of App The app is compatible with iOS Android OS operating systems and connects to the lock via Bluetooth. Users can unlock the lock through the app add fi ngerprints delete fi ngerprints share access with other users to unlock with the App, rename the lock, OTA update fi rmware, and view unlock history. 1. Download and install App 1. For Android users search for "Prezlock" through Google Play. For Apple users, search for "Prezlock" through the APP Store. Or scan the following QR code to download app. 2. Register Account 2.1 For fi rst time user, please click"Create Account" to register an account 2.2 Follow instructions to fi ll in information. 2.3 Log in to the account after successful registration. 2. Add locks 3. Add fi ngerprints 1. Click the “ +” sign in the app. 2. Select the “Pebble Plus”lock picture. 3. Enter Lock Name, then click “Add” 5. Press the lock button, and the LED fl ashes blue light. 6. If the app fails to connect the lock, press the lockbutton again to reconnect . 7. The following prompt indicates that the lock has been successfully added. Click "Cancel" to exit or click"Continue" to add fi ngerprints. 4. Unlock By key ang fi ngerprint 5. Unlock By App Description of function interface Share Access by App Setting Main of APP Restore factory settings IC and FCC Caution Correct To unlock by fi ngerprint, place your fi nger on the Fingerprint Sensor, until you see a green LED light. 1a Pull out the shackle to unlock. To unlock by key, insert the key into the cylinder and turn it clockwise by 90 degrees. 2 Error 1b 5. Pull out the shackle to unlock. 1. Open the APP. 3. If Auto Unlock is off, tap the green unlock icon of the APP (as shown below). If Auto Unlock is on, go to step 4. 4. When the green unlock icon of the APP turns blue, it means to be unlocked. Press step 5 to unlock. Low power reminder and charging If a red light blinks continuously for 5 seconds after the fi ngerprint sensor is touched, it means the lock power is low, please recharge the battery.Do not charge the lock when the charging port is wet.The fi ngerprint sensor light stays red during charging and turns to green when the lock is fully charged.. Charging Fully Charged Dear customerWe value your comment to enhance the user experience.Please write us at [email protected] pertaining to comments, suggestions, or technical issues.For warranty and more detailed information about our products and company, please visit www.prezlock.com ENGINEERED FOR CONVENIENCE Prezlock Prezlock offers a one year limited warranty. Main Menu Add lock Share Access by App Lock opening history Settings Restore factory settings Lock opening history Guest user to share withSharing access to guest users Share Access by App (Share or Remove) Lock opening historysorted by times. Lock opening history sorted by user names. De fi ne / change the name of the lock Add or remove fi ngerprints Firmware update alertTurn Auto Unlock mode on or offTo save or not to save settings Login account query, modify login password, delete account Exit the current login.Tutorials for general use.APP operating language selection.You can choose to hide or show the lock in the APP interface. 1. Click the Remove icon in the App 4. Click "Continue", the lock will be connected to the APP. When the blue fl ashing LED turns to white, the designated lock will be removed, and the lock has been restored to the factory status. Note: All lock opening history and fi ngerprint registrations will be deleted and no longer be retrieved. In order to ensure the designed service life of the lithium battery, please fully charge the lock before fi rst use, and rech…

Text truncated - open the document above for the full version.

C5266091_X8_Ed.1 1/1 LetterofAuthorization InnovaIdeasLimited Company:InnovaIdeasLimited Address:UnitA1,3/FloorBlock4,GoldenDragonIndustrialCenter,182-190TaiLin PaiRoad,KwaiChungNT,HongKong ProductName:SmartFingerprintPadlock ModelNumber:EL-06 FCCIdentifier:2AR3KPLBFK006 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:DavidTsuiDate:2022-12-30 Title: Signatureofapplicant:

C5266091_X10_Ed.2 1/1 InnovaIdeasLimited OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2022-12-30 Subject:RequestforConfidentiality FCCID:2AR3KPLBFK006 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodofdaysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name:DavidTsui Title:

ANT

Page 1 of 2 RF EXPOSURE EVALUATION Product Name : Smart Fingerprint Padlock Model Name : EL-06 Bluetooth Version : BLE Operating frequency : 2402-2480MHz Numbers of Channel : 40 channels For DTS Antenna Type : Integral Antenna Antenna Gain : -8.98dBi Type of Modulation : GFSK Power supply : DC5V Li-ion Battery : 602030 Rated Voltage: 3.7V Capacity:300mAh 1.11Wh Hardware Version : V2.1.1 Software Version : 3.22 Page 2 of 2 Standard Requirement According to § 15.247(i) and § 1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v06, section 4. 3. 1. The 1-g and 10-g SAR test exclusion thresholds for 100MHz to 6GHz at test separation distances ≤ 50mm are determined by: [ (max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[ √f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g SAR extremity SAR, where ⚫ f(GHz) is the RF channel transmit frequency in GHz ⚫ Power and distance are rounded to the nearest mW and mm before calculation ⚫ The result is rounded to one decimal place for comparison. The test exclusions are applicable only when the minimum test separation distance is ≤ 50mm and for transmission frequencies between 100MHz and 6GHz. When the minimum test separation distance is <5mm, a distance of 5mm is applied to determine SAR test exclusion. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (mW) Distance (mm) Calculation results Limit Operating Mode 2402 -0.43 -0.43 ± 1 1.140250 5 0.353441 3 BLE According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature Ronnie Liu EMC Manager Date: 2023-01-09

Page 1 of 54 FCC TEST REPORT FCC ID:2AR3KPLBFK006 Product : Smart Fingerprint Padlock Model Name : EL-06 Brand : Prezlock Report No. : PTC22110600104E-FC01 Prepared for Innova Ideas Limited Unit A1,3/Floor Block4, Golden Dragon Industrial Center,182-190 Tai Lin Pai Road, Kwai Chung NT, Hong Kong Prepared by Precise Testing & Certification Co., Ltd Building 1, No. 6, Tongxin Road, Dongcheng Street, Dongguan, Guangdong, China Report No.: PTC22110600104E-FC01 Page 2 of 54 1 TEST RESULT CERTIFICATION Applicant’s name : Innova Ideas Limited Address : Unit A1,3/Floor Block4, Golden Dragon Industrial Center,182-190 Tai Lin Pai Road, Kwai Chung NT, Hong Kong Manufacture's name : Dongguan Qingxi Kwong Wah Lock Mfy.Co.,Ltd Address : Jin Qiao Industrial Estate, 221Qing Feng Rd,Qingxi, Dongguan Product name : Smart Fingerprint Padlock Model name : EL-06 Standards : FCC CFR47 Part 15 Section 15.247 Test procedure : ANSI C63.10:2013 Test Date : Nov. 16, 2022 to Dec. 05, 2022 Date of Issue : Dec. 30, 2022 Test Result : Pass This device described above has been tested by PTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of PTC, this document may be altered or revised by PTC, personal only, and shall be noted in the revision of the document. Test Engineer: Simon Pu / Engineer Technical Manager: Ronnie Liu / Manager Report No.: PTC22110600104E-FC01 Page 3 of 54 Contents Page 1 TEST RESULT CERTIFICATION .............................................................................................................................. 2 2 TEST SUMMARY ......................................................................................................................................................... 5 2.1 TEST SITE ........................................................................................................................................................... 6 3 GENERAL INFORMATION ..................................................................................................................................... 7 3.1 GENERAL DESCRIPTION OF E.U.T. .................................................................................................................... 7 3.2 CHANNEL LIST .................................................................................................................................................... 8 4 EQUIPMENT DURING TEST .................................................................................................................................. 9 4.1 EQUIPMENTS LIST ............................................................................................................................................ 9 4.2 MEASUREMENT UNCERTAINTY ......................................................................................................................... 11 4.3 DESCRIPTION OF SUPPORT UNITS ................................................................................................................... 12 5 CONDUCTED EMISSION ......................................................................................................................................... 13 5.1 E.U.T. OPERATION ........................................................................................................................................... 13 5.2 EUT SETUP ...................................................................................................................................................... 13 5.3 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................................. 14 5.4 MEASUREMENT PROCEDURE ........................................................................................................................... 14 5.5 CONDUCTED EMISSION LIMIT ........................................................................................................................... 14 5.6 MEASUREMENT DESCRIPTION .......................................................................................................................... 14 5.7 CONDUCTED EMISSION TEST RESULT ............................................................................................................. 14 6 RADIATED SPURIOUS EMISSIONS ..................................................................................................................... 17 6.1 EUT OPERATION .............................................................................................................................................. 17 6.2 TEST SETUP ..................................................................................................................................................... 18 6.3 SPECTRUM ANALYZER SETUP .......................................................................................................................... 19 6.4 TEST PROCEDURE ............................................................................................................................................ 20 6.5 SUMMARY OF TEST RESULTS .......................................................................................................................... 22 7 CONDUCT BAND EDGE AND SPURIOUS EMISSIONS MEASUREMENT ................................................... 29 7.1 TEST PROCEDURE ............................................................................................................................................ 29 7.2 TEST RESULT ................................................................................................................................................... 30 8 6DB BANDWIDTH MEASUREMENT ..................................................................................................................... 37 TEST PROCEDURE ...…

Text truncated - open the document above for the full version.

ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page1of9 TestingReport CustomerName:InnovaIdeasLimited ProductName:SmartfingerprintPadlock SampleModel:EL-06 ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2022.12.23 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page2of9 Version VersionNo.DateDescriptionFormulateApproval A02022.12.23Forthefirsttime,formulateJacksonEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesting.........................................................................6 3.TestResults......................................................................................................................................7 3.1Teststandard.........................................................................................................................7 3.2Testuncertainty.....................................................................................................................7 3.3Testdata................................................................................................................................7 3.3.1Typicalfreespaceefficiencyandgain......................................................................7 3.3.2Typicalfreespaceradiationpattern...........................................................................8 （Thefollowingisblank）................................................................................................................9 ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page3of9 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address 10/FA,LingyunBld,LiufangRd,BaoanDistrict,SZ Tel 13682621346 E-mail [email protected] Equipment AlltheequipmentusedinthereportisfixedinZoneB,WestSideof1/F,Building1, TingweiIndustrialPark,No.6LiufangRoad,Bao'anDistrict,Shenzhen 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page4of9 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date OTATest System RayZone-5000 RFI-LAB-RF -D00 GTS2021.3.152023.3.14 Network Analyzer E5071C RFI-LAB-RF -D01 KEYSIGHT2022.5.132023.5.12 1.4Testenvironment Temperature 23.5°C Humidity 58%RH Pressure 100.19kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page5of9 2.SampleInformation 2.1Clientinformation Name InnovaIdeasLimited Address JinQiaoIndustrialEstate,221QingFengRd,Qingxi,Dongguan Contacts / Tel / E-mail / Manufacturer DongguanQingxiKwongWahLockMfy.Co.,Ltd JinQiaoIndustrialEstate,221QingFengRd,Qingxi,Dongguan 2.2DescriptionofEUT(S) ProductName SmartfingerprintPadlock SampleModel EL-06 AntennaSize / SerialNo. / AntennaType ExternalAntenna TestItem Antennagain;Efficiency;Radiationpattern FrequencyRange 2400-2480MHz ReceivedDate 2022.12.23 TestDate 2022.12.23 Remark ThelengthoftheRFcableis40mm ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page6of9 2.3EUTappearance 2.4EUTsetupphotooffreespaceOTAtesting Planform Frontview ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page7of9 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-1979 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty Antennagain±0.72dB Radiationefficiency±0.72dB 3.3Testdata 3.3.1Typicalfreespaceefficiencyandgain Frequency/MHz 24002410242024302440245024602470248024902500 PeakGain/dBi -11.21-10.93-10.90-10.74-10.40-9.98-9.88-9.81-9.56-9.28-8.92 Efficiency/% 2.963.103.153.343.573.863.964.164.474.604.74 ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page8of9 3.3.2Typicalfreespaceradiationpattern (1)X-ZPlane: (unit：dBi) (2)Y-ZPlane: (unit：dBi) ReportNo.:RFI-LAB-RF-202212-LL26-2 QP030-E41 Page9of9 (3)X-YPlane: (unit：dBi) (4)TypicalFreeSpace3DRadiationPatternat2.45GHz: (unit：dBi) ---------------------------------…

Text truncated - open the document above for the full version.

ConductedEmissions RadiatedEmissions From30MHz-1000MHz TestfrequencyfromAbove1GHz
