Probe Sockets Battery Cover 12 Probe with cable x 2 AAA Battery x 2 This device provides 2 sockets for probes, which enable you to monitor 2 items at same time. If you need another probe besides the one in the standard package, please contact the dealer. WDJ7026 Put in the battery Two AAA size batteries are needed for this device. Make sure they are put in the right direction by following the icons on the unit. Open the battery cover. Put in batteries, noticing the icons that show directions. Lock the battery cover. Download the APP Search the keyword ‘Tuya’ in Appstore or Google Play, or scan the following QR code with your phone. Download and install it for free. Make sure your phone meet the requirements: iPhone 4S, and later models; iPod touch 5th, ipad 3rd generations and later models, all ipad mini; Android devices running version 4.4 or later, with blue-tooth 4.0 module. Manufacturer: Zhejiang Shunkang Technology Industry Co., Ltd. No.2, 3 Lane Fuxiang North Road, Yuyao, Zhejiang, P.R. China Install the probes The device will keep scanning the sockets when its power is switched on, the Probe Indicators will display where probes are plugged in. Then insert the probes into the food, make sure the front tip of the probe is in the center of the food to get accurate temperature. Pair with your phone Keep the bluetooth switch of your phone on. Launch the app, and follow the instructions in the app to pair and activate the device. Press and hold the power button on the device for 3 seconds to power it on. 4 Connected successfully. Once paired the device with your phone, you don’t need to do it again, unless you change to other phones. 1 2 Probe 1 Probe 2 Note:Food probe is a sharp object. Do not stab the probe into the skin or eyes to avoid causing injury. Sharp edges, do not touch This equipment is not suitable for use in locations where children are likely to be present Enjoy your barbecue time Power ON/OFF Temperature History Preference Display Probe Number Current Temperature Target Temperature Timer Choose the food type and preference for the food where each probe is inserted, the app and the device will display its current and target temperature. The user interface of the app may be changed when upgraded. Please follow the instructions in the app. Power ON: Press and hold the power button for 3 seconds. Power OFF: Press and hold the power button for 3 seconds. Auto-off after 8 hours out of connection with phone. When the food is ready, the app and the device will alarm. C/F Setting FCC CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. must not be co-located or operating in conjunction with any other antenna or transmitter.

Label and label location

Uncover view Uncover view Internal view Internal view Mainboard board front view Mainboard board back view Module view Chip of module Bluetooth Antenna

FCC ID: 2AR47-WDJ7026 Prediction of MPE at a given distance 1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) 2. Test Procedure Where: S = power density P = power input to the antenna G = numeric gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the centre of radiation of the antenna FCC ID: 2AR47-WDJ7026 3. Result Maximum peak output power at antenna input terminal: 9.15 (dBm) Maximum peak output power at antenna input terminal: 8.22 (mW) Antenna gain(typical): 2.5 (dBi) Maximum antenna gain: 1.78 (numeric) Prediction distance: 20 (cm) Source Based Time Average Duty Cycle: 100 (%) Prediction frequency: 2480 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 2.91*10 −3 (mW /cm^2) Power density at a given distance is 2.91*10 −3 <1 mW/cm^2
