2AR6E-HK302Bluetooth FM Transmitter

(2).You can adjust the music Volume/Play/Pause/Previous/Nest on mobile phone, or on the device. 7.Switching Music File Sources It can play the music from TF card and device with Bluetooth function, switch the file source between TF card and devices with Bluetooth by short press . 8.Make A Call (1).You can make a call and answer the phone through this device after connected by Bluetooth. Double tap redial the last phone number. (2).Reject call: when a call coming, double press to reject a call. 9.Aux Out The unit support music sources output from TF card music or Phone's Bluetooth music, And the music output to the other device by aux out port. 10.Part Description 160.0mm 60.0mm Product Production Product Features Operation Instructions This device is a car Bluetooth MP3 player, which equipped with profes- sional high performance Bluetooth module and MP3 decoder chip. It can transmit your mobile phones music and TF Card music to car stereo via FM radio signal. It can also be used as a hands free car kit during driving. This devices transmits signal by wireless method, no need to modify anything in car. It can be used both as the music player for entertainment purpose or hands free car kit in safety purpose during driving. 1.Support Bluetooth hands free MIC call,so that people answer the phone safety. 2.Noise and wind suppressed by CVC technology to create full duplex sound quality. 3.Support mobiles A2DP function. Music will be played directly while the device is connected with mobile phone. 4.Mobile phone can be reconnected automatically. 1.Device Power on (1).Device turns on automatically when plug its integrated car charger to car cigarette lighter power. (2).Select a frequency. (3).Turn on car FM stereo and keep the frequency same with the device. 2.Frequency and Volume Adjustment. (1).This device supports 206 transmis- sion frequency point:87.5~108.0MHZ, long press bottom into the Frequency setting mode, then rotate to adjust FM transmission frequency. (2).Rotate to adjust the volume 3.Playing Music from TF card. (1).Insert the TF card into the device, it will automatically detect and play the MP3/WMA/WAV format music in the TF card. This devices is compatible with most of the mobile phones, except a few mobile phone that are not available to use parts of above functions. Product features be upgraded without any notice. /Siri function Short press to on Again short press to off Operation Instruction 1.Power On/Off 2.How to pair mobile? 3.How to play and pause? 4.How to adjust volume? 5.How to select music? 6.How to answer and end a call? 7.Switching mode Shot press , then it will switch between TF card and Bluetooth mode. 8.Siri function Long press the “ ” button, the product wakes up the Siri voice assistant function Plug the device into the cigarette lighter, then turn on the phone Bluetooth, find the HK302 pairing name, click to pair Short press to play Press again to pause Adjust the volume by rotate Press to play next song Press to play previous song Short press to answer an incoming call Short press to end the call Double press to refuse incoming call Double press to redial the last phone No. QC3.0&5V/2.4A CAR CHARGER 1234 5678 5.Support an external TF cad, can play music files in MP3/WMA/WAV format. 6.Integrated car charger of output QC3.0 and 5V/2.4A, it is available for charging hand-held devices in car. (2).Music selection: short press or to select songs. 4.Connect to Bluetooth Devices (1).This devices is equipped with built in Bluetooth chip , it can connect to any other hand-held Bluetooth devices. (2).It will enter pairing mode automati- cally when the devices is powered on . Search this devices with name of "HK302", and connect it. (3).Memory function. It will connect to its memorized paired Bluetooth device automatically once the unit is powered on. 5.Automatic reconnect function When the unit is power, the phone beyond the Bluetooth reception range, or leave the unit for some time {more than 3 minutes}. Then the phone back to the product’s Bluetooth reception range, this time, click any key of the unit, then the phone can be connected automatically. Don’t need to power off and reconnect the unit and the mobile phone. 6.Playing Music from Mobile Phone (1).After connecting mobile phone to the device successfully via Bluetooth, you can play music from mobile phone the device will wirelessly transmit the signal to car stereo. (1) L' appareil ne doit pas produire de brouillage; (2) L' appareil doit accepter tout brouillage radioélectrique subi, même si NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including in…

Text truncated - open the document above for the full version.

HAIKE PLASTIC AND ELECTRONIC CO LTD Block B. Shanghenglang Bai Fuli Industrial, Dalang Street, Long Hua, ShenZhen, China Agent Authorization Company: HAIKE PLASTIC AND ELECTRONIC CO LTD Address: Block B. Shanghenglang Bai Fuli Industrial, Dalang Street, Long Hua, ShenZhen, China Product Name: Bluetooth FM Transmitter Model Number(s): HK302, HK301, HK303, HK305, HK306, HK307, HK308, HK309, HK601, HK602, HK603, HK605, HK606, HK607, HK608, HK609 Product Description: Bluetooth FM Transmitter We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Dec. 11, 2020 Name: Aiken xiong Title: General Manager Company: HAIKE PLASTIC AND ELECTRONIC CO LTD

HAIKE PLASTIC AND ELECTRONIC CO LTD Block B. Shanghenglang Bai Fuli Industrial, Dalang Street, Long Hua, ShenZhen, China Dec. 11, 2020 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AR6E-HK302 Models: HK302, HK301, HK303, HK305, HK306, HK307, HK308, HK309, HK601, HK602, HK603, HK605, HK606, HK607, HK608, HK609 To Whom It May Concern: We, The HAIKE PLASTIC AND ELECTRONIC CO LTD hereby declare that the model : HK301, HK303, HK305, HK306, HK307, HK308, HK309, HK601, HK602, HK603, HK605, HK606, HK607, HK608, HK609 is identical with the model : HK302, except the model name. Except for the different above, no other modification is performed. Sincerely, HAIKE PLASTIC AND ELECTRONIC CO LTD Signature: [Aiken xiong, General Manager]

HAIKE PLASTIC AND ELECTRONIC CO LTD Block B. Shanghenglang Bai Fuli Industrial, Dalang Street, Long Hua, ShenZhen, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Dec. 11, 2020 Subject; Request for Confidentiality FCC ID: 2AR6E-HK302 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Aiken xiong Title: General Manager

External Photos TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT VIEW OF EUT(PORT)-1 VIEW OF EUT(PORT)-2 VIEW OF EUT(PORT)-3

FCC ID Label Location 20mm*10mm FCC ID: 2AR6E-HK302

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 BT Antenna INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 FM Antenna port INTERNAL VIEW OF EUT-6 INTERNAL VIEW OF EUT-7

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Bluetooth FM Transmitter Model Name HK302, HK301, HK303, HK305, HK306, HK307, HK308, HK309, HK601, HK602, HK603, HK605, HK606, HK607, HK608, HK609 FCC ID 2AR6E-HK302 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION P t =0.773dBm=1.19mW The value of the Maximum output power P t is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(1.19mW /5mm) .[√2.441(GHz)]=0.37<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. §15.239 FM Pt= -48.26dBm=0.000015mW The value of the Maximum output power P t is referred to the test report of the CFR47 For frequencies below 100 MHz and test separation distances ≤ 50 mm，the power threshold determined by the following: P max =0.5 * 474 * [1+log(100/f)] mW, where f is MHz For 88.1MHz, P max =250mW. Pt< P max. For 107.9MHz, P = 3 x 5 / 0.1079^0.5 = 45.7 mW P max =45.7mW. Pt< P max. Simultaneous transmission between Bluetooth and FM transmitter: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)]·[√f(GHz)/x] W/kg, for test separation distances ≤ 50 mm; where x = 7.5 for 1-g SAR and x = 18.75 for 10-g SAR. SAR=(0.37+0. 000015)/7.5=0.049W/kg<1.6W/kg 4. CONCLUSION The SAR evaluation is not required.

Page 1 of 63 FCC Test Report Report No.: AGC02180201102FE03 FCC ID : 2AR6E-HK302 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Bluetooth FM Transmitter BRAND NAME : N/A MODEL NAME : HK302, HK301, HK303, HK305, HK306, HK307, HK308, HK309, HK601, HK602, HK603, HK605, HK606, HK607, HK608, HK609 APPLICANT : HAIKE PLASTIC AND ELECTRONIC CO LTD DATE OF ISSUE : Dec. 10,2020 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC02180201102FE03 Page 2 of 63 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 10,2020 Valid Initial Release Report No.: AGC02180201102FE03 Page 3 of 63 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 6 2.3. RECEIVER INPUT BANDWIDTH .............................................................................................................. 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ......................................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR ......................................................... 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 8 2.7. TEST METHODOLOGY ............................................................................................................................. 8 2.8. SPECIAL ACCESSORIES ......................................................................................................................... 8 2.9. EQUIPMENT MODIFICATIONS ................................................................................................................. 8 2.10. ANTENNA REQUIREMENT..................................................................................................................... 8 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 9 4. DESCRIPTION OF TEST MODES ................................................................................................................. 10 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 11 5.1. CONFIGURATION OF EUT SYSTEM ...................................................................................................... 11 5.2. EQUIPMENT USED IN TESTED SYSTEM .............................................................................................. 11 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 11 6. TEST FACILITY .............................................................................................................................................. 12 7. PEAK OUTPUT POWER ................................................................................................................................ 13 7.1. MEASUREMENT PROCEDURE ............................................................................................................. 13 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 13 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................................. 14 8. 20DB BANDWIDTH ........................................................................................................................................ 18 8.1. MEASUREMENT PROCEDURE ............................................................................................................. 18 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 18 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................... 19 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 23 9.1. MEASUREMENT PROCEDURE ............................................................................................................. 23 Report No.: AGC02180201102FE03 Page 4 of 63 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 23 9.3. MEASUREMENT EQUIPMENT USED .................................................................................................... 23 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................................. 23 10. RADIATED EMISSION ................................................................................................................................. 34 10.1. MEASUREMENT PROCEDURE ........................................................................................................... 34 10.2. TEST SETUP ......................................................................................................................................... 36 10.3. LIMITS AND MEASUREMENT RESULT ............................................................................................... 37 10.4. TEST RESULT........................................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: AGC02180201102FE03 Page 41 of 63 EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 5 Antenna Horizontal FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4882.00047.750.1447.8974-26.11 peak 4882.00036.490.1436.6354-17.37 AVG 7323.00040.632.3642.9974-31.01 peak 7323.00033.412.3635.7754-18.23 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 5 Antenna Vertical FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4882.00047.230.1447.3774-26.63 peak 4882.00039.650.1439.7954-14.21 AVG 7323.00041.42.3643.7674-30.24 peak 7323.00033.452.3635.8154-18.19 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type Report No.: AGC02180201102FE03 Page 42 of 63 EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 6 Antenna Horizontal FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4960.00045.890.2246.1174-27.89 peak 4960.00036.470.2236.6954-17.31 AVG 7440.00039.632.6442.2774-31.73 peak 7440.00030.512.6433.1554-20.85 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 6 Antenna Vertical FrequencyMeter ReadingFactorEmission LevelLimitsMargin (MHz)(dBμV)(dB)(dBμV/m)(dBμV/m)(dB) 4960.00045.850.2246.0774-27.93 peak 4960.00035.490.2235.7154-18.29 AVG 7440.00039.632.6442.2774-31.73 peak 7440.00030.872.6433.5154-20.49 AVG Remark: Factor = Antenna Factor + Cable Loss – Pre-amplifier. Value Type RESULT: PASS Note: The amplitude of other spurious emissions from 1G to 25 GHz which are attenuated more than 20 dB below the permissible value need not be reported. Factor = Antenna Factor + Cable loss - Amplifier gain, Margin= Level -Limit. The “Factor” value can be calculated automatically by software of measurement system. All test modes had been tested. The π /4-DQPSK modulation is the worst case and recorded in the report. Report No.: AGC02180201102FE03 Page 43 of 63 TEST RESULT FOR RESTRICTED BANDS REQUIREMENTS EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 4 Antenna Horizontal PK AV RESULT: PASS Report No.: AGC02180201102FE03 Page 44 of 63 EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 4 Antenna Vertical PK AV RESULT: PASS Report No.: AGC02180201102FE03 Page 45 of 63 EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 6 Antenna Horizontal PK AV RESULT: PASS Report No.: AGC02180201102FE03 Page 46 of 63 EUT Bluetooth FM Transmitter Model Name HK302 Temperature 25°C Relative Humidity 55.4% Pressure 960hPa Test Voltage Normal Voltage Test Mode Mode 6 Antenna Vertical PK AV RESULT: PASS Note: The factor had been edited in the “Input Correction” of the Spectrum Analyzer. The π /4-DQPSK modulation is the worst case and recorded in the report. Report No.: AGC02180201102FE03 Page 47 of 63 11. NUMBER OF HOPPING FREQUENCY 11.1. MEASUREMENT PROCEDURE The EUT shall have its hopping function enabled. Use the following spectrum analyzer settings: 1. Span: The frequency band of operation. Depending on the number of channels the device supports, it may be necessary to divide the frequency range of operation across multiple spans, to allow the individual channels to be clearly seen. 2. RBW: To identify clearly the individual channels, set the RBW to less than 30% of the channel spacing or the 20 dB bandwidth, whichever is smaller. 3. VBW ≥ RBW. Sweep: Auto. Detector function: Peak. Trace: Max hold. 4. Allow the trace to stabilize. 11.2. TEST SETUP (BLOCK DIAGRAM OF CONFIGURATION) Same as described in section 8.2 11.3. MEASUREMENT EQUIPMENT USED The same as described in section 6 11.4. LIMITS AND MEASUREMENT RESULT TOTAL NO. OF HOPPING CHANNEL LIMIT (NO. OF CH) MEASUREMENT (NO. OF CH) RESULT >=15 79 PASS TEST PLOT FOR NO. OF TOTAL CHANNELS Note: The GFSK modulation is the worst case and recorded in the report. Report No.: AGC02180201102FE03 Page 48 of 63 12. TIME OF OCCUPANCY (DWELL TIME) 12.1. MEASUREMENT PROCEDURE The EUT shall have its hopping function enabled. Use the following spectrum analyzer settings: 1. Span: Zero span, centered on a hopping channel. 2. RBW shall be≤channel spacing and where possible RBW should be set >> 1 / T, where T is the expected dwell time per channel. 3. Sweep: As necessary to capture the entire dwell time per hopping channel; where possible use a video trigger and trigger delay so that the transmitted signal starts a little to the right of the start of the plot. The trigger level might need slight adjustment to prevent triggering when the system hops on an adjacent channel; a second plot might be needed with a longer sweep time to show two successive hops on a channel. 4. Detector function: Peak. Trace: Max hold. 5. Use the marker-delta function to determine the transmit time per hop. 6. Repeat the measurement using a longer sweep time to determine the number of hops over the period specified in the requirements. The sweep time shall be equal to, or less than, the period specified in the requirements. Determine the number of hops over the sweep time and calculate the total number of hops in the period specified in the requirements, using the following equation: (Number of hops in the period specified in the requirements) = (number of hops o…

Text truncated - open the document above for the full version.

Test Setup Photos RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz CONDUCTED TEST SETUP
