Cooler Master Technology Inc. 7F., No. 398, Xinhu 1st Rd., Neihu Dist., Taipei City114065 Taiwan Date: 02-24-2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AR8X-CMSCBT US Agent – Attestation Statement / Part 2.911(d)(7) Cooler Master Technology Inc.certifies, that as of 02-24-2023, we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AR8X-CMSCBT. Cooler Master Technology Inc., accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Cooler Master Technology Inc. for FCC ID:2AR8X-CMSCBT. Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Cooler Master Technology Inc. Designated Agent: FCC US Agent, LLC Company Representative: Kevin Yang Designated Agent Representative: Tim Payne Signature: Signature:

Cooler Master Technology Inc. 2023-02-20 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for 2AR8X-CMSCBT [Cooler Master Technology Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Kevin Yang Cooler Master Technology Inc. 2023-02-20 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for 2AR8X-CMSCBT [Cooler Master Technology Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Kevin Yang

Cooler Master Technology Inc. 2023-0 1-0 6 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize EMTEK (SHENZHEN) CO., LTD. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Kevin Yang / Cooler Master Peripheral BU LB Date: 2023.01.06 Cooler Master Technology Inc.

Cooler Master Technology Inc. 2023-1 -0 6 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Product Name: Storm Gaming Controller FCC ID: 2AR8X-CMSCBT) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram, Circuit Schematic, Operation Description) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Kevin Yang / Cooler Master Peripheral BU LB Date: 2023 .1.06 Cooler Master Technology Inc.

EUT EXTERNAL PHOTOGRAPHS ----------------The end----------------

东莞市铭冠电子科技有限公司 TOGRAN ELECTRONIC Co., Ltd. 谢玉银 2023/02/02 1:1 1 A0 1/1 TP16A11701R 3040150381 底标 ABCD 5 6 4 3 2 1 DCBA 7 DESCRIPTION +3 DIMENSIONAL TOLERANCE ±0.10 ±0.15 ±0.20 CHANGE BYDATE 101~150 51~100 0~50 +4 +5 ±0.25 ±0.20 ±0.15 ±0.75 ±0.50 ±0.25 APPROVED BY: CHECKED BY: E DRAWN BY: TEXTURESCALE QUANTITY MATERIAL F UNITS VER. SHEET G PART No. DWG No. MODEL 2 3 4 5 6 E FGHIJ LEVEL 1 ENVIRONMENTAL RELATED SUBSTANCES TO BE CONTROLLED SHOULD NEVER BE USED 1 JIH ANGLE'S 3RD. 7 mm 纸箱 单坑 双坑三坑 0~1000 DIM 标签/贴纸类 印刷/镭雕类 彩盒/吸塑类 150<±0.25±0.30 ±1 吊卡/说明书 FINISHED ITEM 1 下盖 3603579AX1 DESCRIPTION QUANTITY NAME PART NO. ITEM 备注： 1.要求符合铭冠以下三大文件： a.《键盘类外观检验标准T-WQ-007/鼠标类外观检验标准 TG-WQ-008/耳机类外观检验标准TG-WQ-005》 b.《键盘&鼠标可靠性试验管理规范TG-WQ-004/耳机 可靠性试验管理规范TG-WQ-006》 c.《TG-HSF-300环保要求》 2.产品须符合本公司环保最新Reach和RoHS等。 3.标注：“ * ”为重点检测尺寸，重点在实际试配。 4.粘合性：以实物粘贴，粘贴时用2kg力压紧， 常温下24小时，无翘边，翘角，起泡） 5.剥离强度：粘合性测试后，用1kg力才能撕下来 其他是正常的铭冠测试标准 条码规则： 第1~10码为产品料号(固定),CMIGSCXBK1 第11码固定为1 (固定) 第12~13码为生产年 (变动值) 第14~15码为生产周 (变动值) 第16~20码为流水号 (变动值) 尺寸：49.9*24.9mm 材质: 50#消银龙过哑膜，黑底灰字 灰色色值为：Pantone cool gary 8C 材质厚度：0.08±0.02mm C=0 M=0 Y=0 K=100 条码码型：CODE128 条码必须扫描正确 SN的数字上下一定要水平居中，左右分布均匀 S/N: CMIGSCXBK1 1 23 05 00001 产品料号 (固定) 固定值年 (变动值) 周 (变动值) 流水码 (变动值) 24.9mm 49.9mm S/N: CMIGSCXBK11230500001 CCAK23LP0050T1 Model: STORM CONTROLLER Rating: 5V 350mA MADE IN CHINA FCC ID: 2AR8X-CMSCBT IC: 24668-CMSCBT

EUT INTERNAL PHOTOGRAPHS Antenna ----------------The end----------------

FCC ID: 2AR8X-CMSCBT According to § 15.247(i) and § 1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: BT DSS: Transmit Frequency (GHz) Mode Max Conducted Power (dBm) tune up maximum power(dBm) Result calculation 1-g SAR 2.402 GFSK 3.02 4 0.779 3 2.441 GFSK 2.67 4 0.785 3 2.480 GFSK 2.3 4 0.791 3 Conclusion: For the max result : 0.797≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Signature: Date: 2023.01.12 NAME AND TITLE (Please print or type): Lisa Wang/Manager COMPANY (Please print or type): Shenzhen EMTEK Co.,Ltd./Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China

Report No. ENS2208310269W00601R Page 1 of 60 Ver.1.0 TEST REPORT Product Name ： Storm Gaming Controller Model Number ： STORM CONTROLLER FCC ID ： 2AR8X-CMSCBT IC ： 24668-CMSCBT Prepared for : Cooler Master Technology Inc. Address : 7F., No. 398, Xinhu 1st Rd., Neihu Dist., Taipei City 114065 , Taiwan Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2208310269W00601R Date(s) of Tests : September 23, 2022 to October 18, 2022 Date of issue : October 20, 2022 $二维码$ Report No. ENS2208310269W00601R Page 2 of 60 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ............................................................................................................. 5 3 SUMMARY OF TEST RESULT .................................................................................................................. 6 4 TEST METHODOLOGY ............................................................................................................................. 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................... 7 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................ 8 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 9 5.1 FACILITIES .................................................................................................................................... 9 5.2 EQUIPMENT.................................................................................................................................. 9 5.3 LABORATORY ACCREDITATIONS AND LISTINGS..................................................................... 9 6 TEST SYSTEM UNCERTAINTY .............................................................................................................. 10 7 SETUP OF EQUIPMENT UNDER TEST ................................................................................................. 11 7.1 RADIO FREQUENCY TEST SETUP 1 ........................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP 2 ........................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................... 13 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ........................................................ 14 7.5 SUPPORT EQUIPMENT ............................................................................................................. 14 8 FREQUENCY HOPPING SYSTEM REQUIREMENTS ............................................................................ 15 8.1 STANDARD APPLICABLE .......................................................................................................... 15 8.2 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................... 15 8.3 EQUAL HOPPING FREQUENCY USE ....................................................................................... 16 8.4 FREQUENCY HOPPING SYSTEM ............................................................................................. 16 9 TEST REQUIREMENTS ........................................................................................................................... 17 9.1 20DB&99% BANDWIDTH ............................................................................................................ 17 9.2 CARRIER FREQUENCY SEPARATION ...................................................................................... 23 9.3 NUMBER OF HOPPING FREQUENCIES ................................................................................... 26 9.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) .................................................................... 28 9.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................... 31 9.6 CONDUCTED SUPRIOUS EMISSION ........................................................................................ 34 9.7 RADIATED SPURIOUS EMISSION ............................................................................................. 42 9.8 CONDUCTED EMISSION TEST ................................................................................................. 57 9.9 ANTENNA APPLICATION ........................................................................................................... 60 Report No. ENS2208310269W00601R Page 3 of 60 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Cooler Master Technology Inc. Address : 7F., No. 398, Xinhu 1st Rd., Neihu Dist., Taipei City 114065 , Taiwan Manufacturer : Dongguan Togran Electronics Technology Co.,Ltd. Address : No. 110, Shidan Mid Rd, Shijie Town, Dongguan City, Guangdong Province, China 523290 EUT : Storm Gaming Controller Model Name : STORM CONTROLLER Trademark : Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS IC RSS-GEN, Issue 5(04-2018)+A1(03-2019)+A2(02-2021) IC RSS-247 Issue 2(02-2017) PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2, Part 15.247, IC RSS-247 Issue 2 and IC RSS-GEN, Issue 5. The…

Text truncated - open the document above for the full version.

TP016A ANTENNA SPECIFICATION Summary ITEM Controller ANT SPEC Model Name Center Frequency Horizontal Vertical 2403MHz 2441MHz 2480MHz 2403MHz 2441MHz 2480MHz -5.78 -5.65 -5.32 -7.3 -4.5 -1.5 MAX. Gain -1.5dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 14mm Antenna Model Name F model Manufacture DONGGUAN SHUO CHUANG ELECTRONICS CO LTD Address: TONGFUWESTROAD,SHIJIETOWN DONGGUAN,GUANGDONG,CHINA Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Frequency (MHz) Gain(dB) Max Min Avg 2403 -5.78 -30.52 -9.78 2441 -5.65 -35.46 -8.65 2480 -5.32 -24.45 -7.32 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Frequency (MHz) Gain(dB) Max Min Avg 2403 -7.2 -24.8 -13.3 2441 -4.5 -27.6 -11.7 2480 -1.5 -29.4 -10.3

TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement 1.2. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz) ----------------The end----------------
