2ARBY-LEHS602SSuperior 6000S Smart Evaporative Humidifier

Questions or Concerns? Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT at [email protected] or at 1-888-726-8520. Superior 6000S Smart Evaporative Humidifier USER MANUAL 2 Table of Contents Package Contents Specifications Safety Information Getting to Know Your Smart Humidifier Controls & Display Getting Started Filling & Refilling Using Your Smart Humidifier Care & Maintenance Troubleshooting Limited Warranty Information Customer Support 2 3 4 6 8 10 11 13 17 21 27 29 Package Contents 1 x Smart Evaporative Humidifier 4 x Wick Filter (Pre-Installed) 1 x Power Adapter 1 x Cleaning Brush 1 x Water Pump 1 x Water Filling Hose 1 x Storage Bag 1 x User Manual 1 x Quick Start Guide 3 Specifications ModelLEH-S602S-WUS Power Supply 24V 1.25A Rated Power30W Water Tank Capacity6 gal / 22.7 L Max Mist Output1,500 mL/h Max Runtime72 hours on low fan speed setting Note: The humidifier may run for a longer or shorter time depending on the environmental temperature and humidity. Noise Level*28–48dB *Noise test conditions: 1.5 m away from humidifier Effective Range 3,000 ft 2 / 279 m 2 Dimensions12.7 x 12.7 x 26.8 in / 32.3 x 32.3 x 68.1 cm Weight13.2 lb / 6 kg Power Adapter Input: 100–240V 50/60Hz 1.0A Max Output: 24V 1.25A Note: To access additional smart functions, download the VeSync app (see page 12). 4 SAFETY INFORMATION • Only use your humidifier as described in this manual. • Do not use without removing the plastic wrap from the wick filters. The humidifier will not filter water and may overheat, causing a fire hazard. • Do not use your humidifier outdoors. • Keep your humidifier away from water, and wet or damp areas. Never place in water or liquid. • Do not use in excessively humid areas. • Keep your humidifier away from heat sources. • Do not use where combustible gases, vapors, metallic dust, aerosol (spray) products, or fumes from industrial oil are present. • Keep 5 ft / 1.5 m away from where oxygen is being administered. • Children should be supervised to ensure that they do not play with the humidifier. • Do not allow children to play with the plastic packaging. Immediately discard the plastic after unwrapping the wick filters. • Do not place anything into any opening on the humidifier. • Children should be supervised to ensure they do not insert fingers or objects into the vent openings. • Do not sit or place heavy objects on the humidifier. • Do not add essential oils, supplemental water treatment liquids, To reduce the risk of fire, electric shock, or other injury, follow all instructions and safety guidelines. General Safety READ AND SAVE THESE INSTRUCTIONS or water filters into the water tank. This will damage the humidifier and cause leaks. • Always unplug your humidifier before servicing (such as changing the filter). • Do not use your humidifier if it is damaged or not working correctly, or if the cord or plug is damaged. Do not try to repair it yourself. Contact Customer Support (see page 29). • WARNING: To reduce the risk of fire or electric shock, do not use this humidifier with any solid-state speed controls (such as a dimmer switch). • Children should not clean or perform maintenance on the humidifier without supervision. • This humidifier is not to be used by persons (including children) with reduced physical, sensory, or mental capacities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. • Not for commercial use. Household use only. 5 Safety Information (cont.) Power Adapter & Cord • Keep the humidifier near the outlet it is plugged into. • Your humidifier’s adapter has a polarized plug (one prong is wider than the other), which fits into a polarized outlet only one way. This is a safety feature to reduce the risk of electric shock. If the plug does not fit, reverse the plug. If it still does not fit, do not use the plug in that outlet. Do not bypass this safety feature. • Never place the adapter near any heat source. • Do not handle the power adapter or plug with wet hands. Keep the plug and power adapter away from liquids. • Do not cover the cord with a rug, carpet, or other covering. Do not place the cord under furniture or appliances. • Keep the cord out of areas where people walk often. Place the cord where it will not be tripped over. • This humidifier is only to be used with the power supply adapter provided with the humidifier. • If the power adapter is damaged, it must be replaced by Arovast Corporation or similarly qualified persons in order to avoid an electric or fire hazard. Please contact Customer Support (see page 29). • This humidifier’s power adapter uses standard North American 120V, 60Hz outlets. If using outside the US or Canada, check for compatibility. SAVE THESE INSTRUCTIONS Arrow pointed to front 6 GETTING TO KNOW YOUR SMART HUMIDIFIER A. Display B. Air Outlet C. Wick Filter Frame D. Humidity Sensor E. Support Frame F. Humidifier Top G. Water Pump H. Water Tank I. Water Level Window J. Wheels K. Handles L. Alignment Sensor M. Power Adapter Input N. Support Frame Inlet A B D M K N S L F C P E G H I J O. Air Inlet P. Wick Filters Q. Water Filling Hose R. Cleaning Brush S. Power Adapter RQ 7 CONTROL PANEL DISPLAY On/Off Button Fan Speed Indicators Fan Speed Button Humidity Mode Button Auto Mode Button Dry Mode Button Wi-Fi ® Indicator Hour Indicator Check Filter Indicator Display Lock Indicator No Water Indicator Humidity Percentage Timer Button Display Off/ Lock Button Sleep Mode/ Reset Filter Button Fan Speed Indicators Low Medium High 8 CONTROLS & DISPLAY On/Off Button • Tap to turn the humidifier on/off. • Press and hold for 5 seconds to pair with the VeSync app. See the in-app instructions for more information. • Press and hold for 15 seconds to reset the humidifier. This will restore the humidifier’s default settings and disconnect it from Wi-Fi ® and the VeSync app (see page 12). Display Lock Button • Press and hold for 3 …

Text truncated - open the document above for the full version.

Internal Photos M/N: LEH-S602S-WUS Internal Photos M/N: LEH-S602S-WUS Antenna Internal Photos M/N: LEH-S602S-WUS

Conducted Test Radiated Test (30-1000 MHz) Radiated Test (Above 1GHz)
