2ARJH-C3Onvis Smart Camera C3

QUICK START GUIDE 1. Insert a pin to press for 10 seconds to reset. The LED blinks red, green and blue aer reset. 2. Make sure your iOS device (iOS 13.2 or later) is connected to a 5GHz or 2.4GHz Wi-Fi. 3. Download and launch the free Onvis Home app from the App Store. Tap ‘skip’ to use HomeKit directly, or log in/sign up an Onvis account for more services. Or use the Apple Home App to set up and control. 4. Tap “+” on the top right corner and scan the HomeKit QR code to set up the device. 5. If the app prompts “Couldn’t add Onvis-XXXXXX”, please reset and re-add the device. Please keep the QR code for future use. 6. Assign the device to a room, name it and use this name to control with Siri. This smart camera can be integrated into your HomeKit scenes and automations. 7. The use of a HomeKit-enable accessory needs the follow permissions: a.Settings>iCloud>iCloud Drive>Turn On b. Sttings>iCloud>Keychain>Turn On c. Settings>Privacy>HomeKit>Onvis Home>Turn On 8. For troubleshooting visit http://www.onvistech.com/page-1717.html Specifications Smart Camera Overview LED Power button Reset button Dear Customer: Your satisfaction with our product and service is of most importance to us. If you encounter any problem in this product, please contact us via this email: [email protected] Search for 'Onvis Smart Home' on Facebook and Instagram, join us and share us with your experience . Facebook Instagram Customer Service 12-month warranty Lifetime technical support Office Copy Warranty Card Office Copy Warranty Card Customer's Name Mr./Miss/Mrs. Customer's Address: Product Model: C3 Serial No.: Retailer's Name & Stamp: Search for "Onvis Smart Home" on Facebook to join us Email: [email protected] www.onvistech.com Search for "Onvis Smart Home" on Facebook to join us Email: [email protected] www.onvistech.com Customer's Name Mr./Miss/Mrs. Customer's Address: Product Model: C3 Serial No.: Retailer's Name & Stamp: Quality certificate Installation Guide 1.This package include: 1.1. Onvis Smart Camera C3 1.3. 4 Screws and 4 expansion tubes 1.2. 1 magnetic mounting plate 1.4. 1pcs reset pin 1.5. 1 power adaptor1.6 1 pcs 2-meters power cord Insert the reset pin into the reset hole and hold for 10 seconds until the LED blinks red, green, blue once. 2. Reset device 3.1. Put C3 on a table or a flat surface. 3. Mounting methods 3.2. Mount C3 on the wall or vertical surface with screws. 3.3 Mount the magnetic plate on an iron part and attach C3 on the magnetic plate. QR-base code Onvis QR code Set up code QR code Note: When QR code scanning is NOT applicable, select the target device (last 6 digits matching the MAC address), and manually input the SETUP code printed on the QR code. Example: Storage: iCloud ( HomeKit Secure Video), Micro card (up to 128G) Resolution: 1080p@30pfs and 720p@30fps (multiple live streamings) CMOS Sensor: Sony IMX Starlight sensor, 2M pixels Wi-Fi: 5GHz and 2.4GHz, 802.11 b/g/n/ac Lens FOV: 134° Night version: Auto IR Cut 2-way audio Adapter: Input 100-240VAC, 50/60Hz, 0.2A; Output 5.0VDC, 1.2A, Type C Dimensions(WxDxH): 4.4x3.4x3.1 inch (112x87x80mm) Operation temperature: 32~104(0~40) Features Works with Apple HomeKit Onvis C3 is compatible with Apple HomeKit. Call out Siri in iOS devices or Apple Watch like, “Hey, Siri, show me the baby Room” to view a live stream wherever you are. Onvis C3 blends in with your Apple gadgets. HomeKit Secure Video Onvis C3 supports HomeKit Secure Video, enabling you to securely store activity detected by your cameras in iCloud. View live and recorded video from your Onvis C3 in the Apple Home app on your iPhone, iPad, or Mac. No Extra Cloud Storage Fee Onvis C3 shoots recordings on events, and stores videos on iCloud for free if an iCloud plan is registered. Once saved, the videos on iCloud can be reviewed and downloaded from the Home App and stored locally in your iOS devices. Onvis C3 supports local storage of up to 128GB in MicroSD card. Seconds Pre-recording and Multiple Live Streamings Onvis C3 keeps 4 seconds recording rolling. It catches every important moments for you. In addition to recording, C3 oers 2 live streamings, allowing you and your life partne to check your home real time. Privacy Secured Onvis C3 protests your privacy with HomeKit Secure Video(HSV). All data is encrypted before uploading to iCloud. The bank-level AES 256-bit encryption and Transport Layer Security (TLS) ensures industry top data security. Easy Setup Power the camera, scan the setup code and the Onvis C3 camera will be set up in seconds. Rich Notifications Receive rich notifications on your iPhone or iPad and play video clips right from the Lock screen when activity is recorded by your Onvis C3. Motion Detection Onvis C3 detects motions by image change. Accidents without human behavior, like a burst of fire, will be recorded. Operating Humidity: 10%~90% RH non-condensing Storage Temperature: -4~158(-20~70) Storage Humidity: 5%~90% RH non-condensing Certifications: FCC, CE, ROHS Restore factory settings Press and hold the reset button for about 10 seconds. When the blue LED indicator blinks slowly, the device has been restored to factory settings. HomeKit Hub Setting An Apple device as HomeKit hub (iPad/Apple TV/HomePod) is necessary to enable remote control and notification. Find instructions: http://www.onvistech.com/page-1718.html FAQ Why did I fail to set up my Onvis Smart Camera C3 to Onvis Home app? 1.Make sure your C3 is powered on and nearby. 2.If you have a dual band router, please connect your phone to the 2.4GHz/5GHz Wi-Fi network. 3. Make sure your accessory’s blue LED blinks slowly, if not, please reset tofactory settings. 4. Select the C3 shown on screen, then scan the setup code which can be found on the device, instruction manual or inner packaging. 5. If the app prompts ”couldn’t add the device” aer your scanning the setup code: (1)delete the current ”Home” in Home Settings and close the app; (2)restore the accessory to factory settin…

Text truncated - open the document above for the full version.

FCCSoftwareConfigurationControlDeclarationRev1.1 ShenzhenChamponTechnologyCo.,Ltd FCCSoftwareConfigurationControlDeclaration Date:May8,2020 FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Attn:OETDept. Product/ModelNumber:OnvisSmartCameraC3/C3 RegardingFCCCountryCodeSelectionguidelinesidentifiedinKDB594280v02r01. “Allapplicationsforequipmentauthorizationfortransmittersthatcanhaveradio parameters,orothertechnicalparameters,reportedtotheCommissionsetbysoftware musthaveanattestationindicatingthatnothirdpartywillhavesoftware,orconfiguration control,toprogramthedeviceoutofcomplianceofthetechnicalrulesunderwhichithas beencertified.” Wedeclarethatnothirdpartywillhavesoftware,orconfigurationcontrol,toprogramthedevice outofcomplianceofthetechnicalrulesunderwhichithasbeencertified. Name:ChengboChenDate:26/04/2020 Title:CEO Signatureofapplicant

ShenzhenChamponTechnologyCo.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/04/26 Subject; Request for Confidentiality FCC ID: 2ARJH-C3 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chengbo Chen Title: CEO

Shenzhen Champon Technology Co., Ltd Letter of Authorization Company: Shenzhen Champon Technology Co., Ltd Address: Room 628, Yiben Bldg.No.1063 Chaguang Road, Nanshan District, Shenzhen Product Name: Onvis Smart Camera C3 Model Number(s): C3 Product Description: Onvis Smart Camera C3 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 26/04/2020 Name:Chengbo Chen Title:CEO Company: Shenzhen Champon Technology Co., Ltd

FCC ID: 2ARJH-C3

Label Location:

Product Name: Onvis Smart Camera C3 Model No.: C3 FCC ID: 2ARJH-C3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2ARJH-C3 ANTAANTB

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID: 2ARJH-C3 EUT Specification EUTOnvis Smart Camera C3 Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.24GHz WLAN: 5.745GHz ~ 5.825GHz Others: 2.402GHz~2.480GHz Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classificationOccupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversitySingle antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power2.4G WiFi: 14.95dBm (0.0313W) 5.1G WiFi: 12.62dBm (0.0183W) 5.8G WiFi:12.90dBm (0.0195W) Antenna gain (Max)2dBi Evaluation appliedMPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500----F/3006 1500-100000----56 (B) Limits for General Population/Uncontrol Exposures 300-1500----F/15006 1500-100000----130 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result 2.4G WiFi ANT A: Operating Mode Channel Frequency (MHz) Measured Power (dBm) Tune up tolerance (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b 241214.9514.95±115.9520.01241 243714.7714.77±115.7720.01191 246214.4814.48±115.4820.01111 802.11g 241213.5513.55±114.5520.00901 243713.3713.37±114.3720.00861 246212.9812.98±113.9820.00791 802.11n (HT20) 241213.3713.37±114.3720.00861 243713.3613.36±114.3620.00861 246212.8612.86±113.8620.00771 802.11n (HT40) 242211.3611.36±112.362 0.0054 1 243711.0911.09±112.0920.00511 245210.8810.88±111.8820.00491 2.4G WiFi ANT B: Operating Mode Channel Frequency (MHz) Measured Power (dBm) Tune up tolerance (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b 241214.7814.78±115.7820.01191 243714.8214.82±115.8220.01201 246214.4714.47±115.4720.01111 802.11g 241213.3813.38±114.3820.00861 243713.2613.26±114.2620.00841 246213.0713.07±114.0720.00801 802.11n (HT20) 241213.3913.39±114.3920.00871 243713.4113.41±114.4120.00871 246212.8312.83±113.8320.00761 802.11n (HT40) 242211.4211.42±112.422 0.0055 1 243710.9310.93±111.9320.00491 245210.4710.47±111.4720.00441 ANT A+ANT B Operating Mode Channel Frequency (MHz) ANT A Power density at 20cm (mW/ cm 2 ) ANT B Power density at 20cm (mW/ cm 2 ) ANT A+ANT B Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11n (HT20) 24120.00860.00870.01731 24370.00860.00870.01731 24620.00770.00760.01531 802.11n (HT40) 24220.00540.00550.01091 24370.00510.00490.01001 24520.00490.00440.00931 5.1G WiFi ANT A: 5.1G WiFi ANT B: Operating Mode Channel Frequency Measured Power Tune up tolerance Max. Tune up Power Antenna Gain Power density at 20cm Power density Limits (mW/cm2 ) (MHz)(dBm)(dBm)(dBm)(dBi)(mW/ cm2 ) 802.11a 518011.9011.90±112.9020.00611 520011.8911.89±112.8920.00611 524012.3712.37±113.3720.00691 802.11n20 518011.5511.55±112.5520.00571 520011.6311.63±112.6320.00581 524012.1412.14±113.1420.00651 802.11ac20 518011.7411.74±112.7420.00591 520012.1412.14±113.1420.00651 524012.4012.40±113.4020.00691 802.11n40 519011.4811.48±112.4820.00561 523012.2512.25±113.2520.00671 802.11ac40 519012.0112.01±113.0120.00631 523012.7112.71±113.7120.00741 802.11ac80 521012.6212.62±113.6220.00731 Operating Mode Channel Frequency Measured Power Tune up tolerance Max. Tune up Power Antenna Gain Power density at 20cm Power density Limits (mW/cm2 ) (MHz)(dBm)(dBm)(dBm)(dBi)(mW/ cm2 ) 802.11a 518011.7611.76±112.7620.00601 520011.7111.71±112.7120.00591 524012.4012.40±113.4020.00691 802.11n20 518011.9511.95±112.9520.00621 520011.9411.94±112.9420.00621 524012.1312.13±113.1320.00651 802.11ac20 518011.5711.57±112.5720.00571 520011.6011.60±112.6020.00571 524012.2812.28±113.2820.00671 802.11n40 519012.0212.02±113.0220.00631 523012.2512.25±113.2520.00671 802.11ac40 519012.0112.01±113.0120.00631 523011.9611.96±112.9620.00621 802.11ac80 521012.5112.51±113.5120.00711 ANT A+ANT B: 5.8G WiFi ANT A: Operating Mode Channel Frequency ANT A Power density at 20cm ANT B Power density at 20cm ANT A+ANT B Power density at 20cm Power density Limits (MHz)(mW/ cm2 )(mW/ cm2 )(mW/ cm2 )(mW/cm2 ) 802.11n20 51800.00570.00620.01191 52000.00580.00620.01201 52400.00650.00650.01301 802.11ac20 51800.00590.00570.01161 52000.00650.00570.01221 52400.00690.00670.01361 802.11n40 51900.00560.00630.01191 52300.00670.00670.01341 802.11ac40 51900.00630.00630.01261 52300.00740.00620.01361 802.11ac80 52100.00730.00710.01441 Operating Mode Channel Frequency Measured Power Tune up tolerance Max. Tune up Power Antenna Gain Power density at 20cm Power density Limits (mW/cm2 ) (MHz)(dBm)(dBm)(dBm)(dBi)(mW/ cm2 ) 802.11a 574512.90 12.90±113.9020.00771 578511.73 11.73±1 12.7320.0059 1 582510.60 10.60±1 11.6020.0046 1 802.11n20 574512.85 12.85±113.8520.00771 578511.93 11.93±1 12.9320.0062 1 582510.52 10.52±1 11.5220.0045 1 802.11ac20 574512.41 12.41±113.4120.00691 578511.74 11.74±1 12.7420.0059 1 582510.71 10.71±1 11.7120.0047 1 802.11n40 575512.35 12.35±113.3520.00681 579511.53 11.53±1 12.5320.0056 1 802.11ac40 575512.19 12.19±1 13.1920.0066 1 579512.00 12.00±113.0020.00631 802.11ac80 577512.11 12.11±1 13.1120.0065 1 5.8G WiFi ANT B: ANT A+ANT B: Note: 2.4G WiFi+5.1G WiFi +5.8G WiFi simultaneous ( worst case ): 0.0173+0.01…

Text truncated - open the document above for the full version.

Report No.: 18220WC00022602FCC ID: 2ARJH-C3Page 1 of 92 Code:AB-RF-05-a FCC Test Report Client Name: Shenzhen Champon Technology Co., Ltd Address: Room 628, Yiben Bldg.No.1063 Chaguang Road, Nanshan District, Shenzhen Product Name: Onvis Smart Camera C3 Date: Apr. 24, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00022602FCC ID: 2ARJH-C3Page 2 of 92 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. List of channels ........................................................................................................................................... 5 1.6. Description Of Test Setup ......................................................................................................................... 6 1.7. Test Equipment List .................................................................................................................................... 7 1.8. Measurement Uncertainty ......................................................................................................................... 8 1.9. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 15 4.1. Test Standard and Limit .......................................................................................................................... 15 4.2. Test Setup .................................................................................................................................................. 15 4.3. Test Procedure .......................................................................................................................................... 16 4.4. Test Data .................................................................................................................................................... 17 5. Maximum Peak Output Power Test .................................................................................................................. 36 5.1. Test Standard and Limit .......................................................................................................................... 36 5.2. Test Setup .................................................................................................................................................. 36 5.3. Test Procedure .......................................................................................................................................... 36 5.4. Test Data .................................................................................................................................................... 36 6. Occupy Bandwidth Test ...................................................................................................................................... 40 6.1. Test Standard ............................................................................................................................................ 40 6.2. Test Setup .................................................................................................................................................. 40 6.3. Test Procedure .......................................................................................................................................... 40 6.4. Test Data .................................................................................................................................................... 40 7. Power Spectral Density Test .............................................................................................................................. 71 7.1. Test Standard and Limit .......................................................................................................................... 71 7.2. Test Setup .................................................................................................................................................. 71 7.3. Test Procedure ....................................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: 18220WC00022603FCC ID: 2ARJH-C3Page 1 of 89 Code:AB-RF-05-a FCC Test Report Client Name: Shenzhen Champon Technology Co., Ltd Address: Room 628, Yiben Bldg.No.1063 Chaguang Road, Nanshan District, Shenzhen Product Name: Onvis Smart Camera C3 Date: Apr. 24, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00022603FCC ID: 2ARJH-C3Page 2 of 89 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. List of channels ........................................................................................................................................... 5 1.6. Description Of Test Setup ......................................................................................................................... 6 1.7. Test Equipment List .................................................................................................................................... 7 1.8. Measurement Uncertainty ......................................................................................................................... 8 1.9. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 15 4.1. Test Standard and Limit .......................................................................................................................... 15 4.2. Test Setup .................................................................................................................................................. 15 4.3. Test Procedure .......................................................................................................................................... 16 4.4. Test Data .................................................................................................................................................... 17 5. Maximum Peak Output Power Test .................................................................................................................. 33 5.1. Test Standard and Limit .......................................................................................................................... 33 5.2. Test Setup .................................................................................................................................................. 33 5.3. Test Procedure .......................................................................................................................................... 33 5.4. Test Data .................................................................................................................................................... 33 6. Occupy Bandwidth Test ...................................................................................................................................... 37 6.1. Test Standard ............................................................................................................................................ 37 6.2. Test Setup .................................................................................................................................................. 37 6.3. Test Procedure .......................................................................................................................................... 37 6.4. Test Data .................................................................................................................................................... 37 7. Power Spectral Density Test .............................................................................................................................. 68 7.1. Test Standard and Limit .......................................................................................................................... 68 7.2. Test Setup .................................................................................................................................................. 68 7.3. Test Procedure ....................................................................................................................................…

Text truncated - open the document above for the full version.

PHOTOSOFTESTSETUP FCC ID: 2ARJH-C3 Photo of Conducted Emission Measurement Photo of Radiation Emission Test
