2ARKNPTCONTROLLER-Lwireless controller

13 Pimax Portal Manual Product Introduction  The Pimax Portal handheld device is a high-performance, highly reliable, portable, fanless, and touch- enabled multi-functional tablet computer product that combines tablet mode, VR mode, and display mode. In addition to the tablet functionality for general entertainment and office computing, it can also be configured with accessories such as magnetic game controllers, wristbands, and VR boxes for combined use.  This product comes with the Android 10 operating system and features a high-performance Qualcomm Snapdragon XR2 processor with 8GB of standard operating memory that cannot be expanded. There are two versions available for storage capacity, 128GB and 256GB, which can be further expanded through a TF card with a maximum capacity of 1TB. The entire device features a sealed, fanless, and ultra-thin design for easy portability.  This product is suitable for meeting the lightweight office and entertainment needs of most people; it is especially suitable for heavy-duty technology gamers who have high requirements for image quality and positioning experience, as well as professionals who require virtual reality technology assistance in their work. PACKAGE CONTENTS  1 x Portal tablet main unit  1 x Magnetic game controller (left)  1 x Magnetic game controller (right)  1 x USB-C charging cable  1 x Handheld VR Kit (optional) 13  1 x View VR headset (optional)   PRECAUTIONS BEFORE USE  This product uses magnetic connection for the controller and the main unit. Please avoid placing your hands or other body parts between the magnetic game controller and the main unit to prevent getting pinched.  Before using the VR mode of this product, please make sure to check the surrounding environment and reserve at least a 2m x 2m space. Before use, make sure that your body feels comfortable and the surrounding environment is safe. Especially when wearing the headset and moving indoors, try to avoid accidents as much as possible.  It is not recommended for children under 12 years old to use the VR mode of this product. Please place the headset accessories (if any) in a place that children cannot reach. Adolescents over 12 years old should use the VR mode under adult supervision to avoid accidents.  Direct exposure of the headset lenses to ultraviolet rays or sunlight may cause permanent screen damage. Please avoid this situation. This type of screen damage is not covered by the warranty.  This product does not have built-in nearsighted adjustment function. Nearsighted users should wear glasses to use and try to avoid scratching or damaging the optical lenses of the headset with nearsighted glasses. It is recommended to pay attention to the protection of optical lenses when using and storing the product to avoid scratches from sharp objects.  When using the VR Kit with the controller (if any), please use the wrist strap to avoid accidents caused by the controller slipping out of your hand.  Long-term use of VR mode may cause slight dizziness or eye fatigue. It is recommended to take appropriate rest to relieve discomfort.     6DOF VR EXPERIENCE (for VR kit only)  It is recommended to prepare a clean and safe experience space that is not less than 2×2 meters; keep the room bright and avoid using it in spaces with only monochrome walls or large reflective surfaces such as glass, mirrors, and spaces with many moving images and objects.  Set up the play area according to the on-screen prompts after turning on the device. This product can track the motion status of the headset and the controllers in the forward, backward, left, right, up, down, and rotation directions. Your body movements in reality will be reflected in real-time in the virtual world. ! WARNING: The virtual safety area reminder function of this product cannot fully guarantee your safety within the set area. Please always pay attention to the safety situation around you. 13 Specifications Operating System Android 10 Processor Qualcomm Snapdragon XR2 Processor, up to 2.84GHz Memory 8GB DDR4 RAM (standard), up to 8GB supported GPU Qualcomm Adreno 650 GPU, frequency up to 587MHz Storage 128GB SSD, up to 256GB Networking WiFi and Bluetooth connectivity Audio Dual speakers, array microphones Display 5.5" display Maximum effective resolution: 3840x2160 Maximum frame rate at maximum resolution: 144 Maximum color depth: 8-bit Brightness: 400 nit Contrast ratio: 1000:1 Touchscreen 5 points touchscreen I/O interface 1 x USB Type-C Size 225mm (length) × 89mm (width) × 14.2mm (thickness) Weight 367g Temperature Operating temperature: 0°C to 45°C with surface airflow Storage temperature: -30°C to 70°C Humidity 95% @ 40°C (non-condensing) Charging 5Vdc 3A / 9Vdc 2A Battery 3960mAh 13 1. Quick Guide 1.1. Setup 1.1.1 Tablet mode  Connect the magnetic controller (left) / magnetic controller (right) to the side of the console as shown in the figure.  Both the controller and the console have magnets, and they will automatically adsorb when the direction is correct and the distance is close.  Please be careful not to place your hands or other body parts between the console and the magnetic controller to avoid pinching. 1.1.2.VR mode  Before using in VR mode, the magnetic controller needs to be removed first.  Insert the Portal console into the View headset, paying attention to the direction. The screen of the Portal console and the lens of the View headset should face the same side.  After insertion, pull up the elastic band and wrap it around the buckle to further secure it. 13 1.2. Charging  Connect the Portal to the charger via a Type-C data cable to charge the console.  The Portal console supports standard USB charging and Qualcomm QC fast charging protocol, with a maximum charging power of 18W.  Magnetically attach the magnetic controller to the sides of the console to charge the controller. 1.3. Power On -To turn on the device, press and hold the power button at the top when it is…

Text truncated - open the document above for the full version.

PimaxTechnology(Shanghai)Co.,Ltd. 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:PimaxTechnology(Shanghai)Co.,Ltd. Address:BuildingA,Building1,3000LongdongAvenue,China(Shanghai)PilotFreeTradeZone 406-CShanghaiP.R.China ProductName:wirelesscontroller FCCID:2ARKNPTCONTROLLER-L Model(s):PortalQLEDController-L,Portalcontroller-L 2.911(d)(5)(i)EquipmentType We,[PimaxTechnology(Shanghai)Co.,Ltd.](“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:JackyangDate:4/29/2023 TitleandCompanyname:QualityManager/PimaxTechnology(Shanghai)Co.,Ltd. NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

PimaxTechnology(Shanghai)Co.,Ltd. 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:PimaxTechnology(Shanghai)Co.,Ltd. Address:BuildingA,Building1,3000LongdongAvenue,China(Shanghai)PilotFreeTradeZone 406-CShanghaiP.R.China ProductName:wirelesscontroller FCCID:2ARKNPTCONTROLLER-L Model(s):PortalQLEDController-L,Portalcontroller-L 2.911(d)(5)(ii)Applicantfiling We,[PimaxTechnology(Shanghai)Co.,Ltd.](“theapplicant”)certifythat,asofthedateofthefiling oftheapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,established pursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:JackyangDate:4/29/2023 TitleandCompanyname:QualityManager/PimaxTechnology(Shanghai)Co.,Ltd. NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

THREESTONESMEDIALLC U.S. AgentLetterof Attestation To: FederalCommunicationsCommission 7435 OaklandMills Road,Columbia,MD 21046,USA Date: 4/29/2023 Ref:AttestationStatement– Part2.911(d)(7)filing FCC ID：2ARKNPTCONTROLLER-L PimaxTechnology(Shanghai)Co., Ltd. (“the applicant”) certifiesthat, as of the date of the filing of the application,THREESTONESMEDIALLC( “the agent ”) is our designatedU.S. agent for service of processfor the abovereferenceFCC ID . The applicantacceptsto maintainan agent for serviceof processin the UnitedStatesforno less than one year after either the granteehas permanently terminatedall marketingand importationof theapplicableequipmentwithin the U.S., or the conclusionof any Commission-relatedadministrativeor judicialproceedinginvolvingthe equipment, whicheveris later. The applicantfurtheracknowledgesit is ourresponsibilityto informthe FCC wheneverthe agent informationchanges. THREESTONESMEDIALLC ("the agent)understandit is the agent'sobligationto acceptservice of processin the UnitedStatesfor mattersrelatedto the applicableequipment,and at the physical U.S. addressand email address. DesignatedU.S. Agent CompanyName: THREESTONESMEDIALLC FRN: 0033401761 GC: 2A99E Address: 1200 BroadwaySt. APT 329, Los Angeles,CA90015 Signature: ContactPerson:Sijie Zhang Tel: +1 267 909 3692Email:[email protected] Applicant CompanyName: PimaxTechnology(Shanghai)Co., Ltd. Addr ess: BuildingA, Building1, 3000 LongdongAvenue,China (Shanghai)Pilot Free Trade Zone 406-CShanghai P.R. China Signature: ContactPerson:Jack yang Tel: +17145819199Email: [email protected]

PimaxTechnology(Shanghai)Co.,Ltd. AgentAuthorization Company:PimaxTechnology(Shanghai)Co.,Ltd. Address:BuildingA,Building1,3000LongdongAvenue,China(Shanghai)PilotFree TradeZone406-CShanghaiP.R.China ProductName:wirelesscontroller ModelNumber(s):PortalQLEDController-L,Portalcontroller-L ProductDescription:wirelesscontroller WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:4/29/2023 Name:Jackyang Title:QualityManager Company:PimaxTechnology(Shanghai)Co.,Ltd.

PimaxTechnology(Shanghai)Co.,Ltd. Familymodelsdeclarationletter. 4/29/2023 We Company:PimaxTechnology(Shanghai)Co.,Ltd. Address:BuildingA,Building1,3000LongdongAvenue,China(Shanghai)PilotFreeTrade Zone406-CShanghaiP.R.China Product:wirelesscontroller ModelName:PortalQLEDController-L FamilyModel:Portalcontroller-L AllthemodelarethesamecircuitandRFmodule,exceptthemodelnamesandlampshadeand/or lampcoloursdifferent. Thanks Sincerely, Signature [Name]Jackyang [Title]QualityManager PimaxTechnology(Shanghai)Co.,Ltd.

PimaxTechnology(Shanghai)Co.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:4/29/2023 Subject;RequestforConfidentiality FCCID:2ARKNPTCONTROLLER-L ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription SOFTWARESECURITYREQUIREMENTSFORU-NIIDEVICES Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:Jackyang Title:QualityManager Email:[email protected]

PimaxTechnology(Shanghai)Co.,Ltd. Date:April29,2023 FCCID:2ARKNPTCONTROLLER-L ModelNumber:PortalQLEDController-L,Portalcontroller-L To: FederalCommunicationCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21048 ToWhomItMayConcern, We,PimaxTechnology(Shanghai)Co.,Ltd.declarethatthisEUT(FCCID: 2ARKNPTCONTROLLER-L)willconductFCCcompliancetesting,the SDOCpartrecognizedtestlab(ShenzhenNTEKTestingTechnologyCo., Ltd.(ShenZhenLab.).1/F,BuildingE,FendaSciencePark,Sanwei Community,XixiangStreetBao’anDistrict,Shenzhen518126P.R.China) Pleasecontactmeifyouhaveanyquestion. Sincerely, (Signed) Name/Title:Jackyang/QualityManager Company:PimaxTechnology(Shanghai)Co.,Ltd. Address:BuildingA,Building1,3000LongdongAvenue,China(Shanghai)PilotFreeTradeZone 406-CShanghaiP.R.China

S221021019038 Model Name: Portal QLED Controller-L ATTACHMENT PHOTOGRAPHS OF EUT Photo1 Photo2 S221021019038 Model Name: Portal QLED Controller-L Photo3 Photo4 S221021019038 Model Name: Portal QLED Controller-L Photo5 Photo6 S221021019038 Model Name: Portal QLED Controller-L Photo7 Photo8 S221021019038 Model Name: Portal QLED Controller-L Photo9 Photo10 S221021019038 Model Name: Portal QLED Controller-L Photo11 Photo12 S221021019038 Model Name: Portal QLED Controller-L Photo13 Photo14 S221021019038 Model Name: Portal QLED Controller-L Photo15 Photo16 S221021019038 Model Name: Portal QLED Controller-L Photo17 Photo18 S221021019038 Model Name: Portal QLED Controller-L Photo19 Photo20 S221021019038 Model Name: Portal QLED Controller-L Photo21 Photo22 S221021019038 Model Name: Portal QLED Controller-L Photo23

Pimax Wireless Controller Model：Portal QLED Controller-L Input：5V⎓0.5A Pimax Technology (Shanghai) Co., Ltd Made In China FCC ID:2ARKNPTCONTROLLER-L LEFT： 20.4*5.1mm labelabe

S221021019038 Model Name: Portal QLED Controller-L Photo24 S221021019038 Model Name: Portal QLED Controller-L Photo25 Photo26 S221021019038 Model Name: Portal QLED Controller-L Photo27 Photo28 S221021019038 Model Name: Portal QLED Controller-L Photo29 Photo30 S221021019038 Model Name: Portal QLED Controller-L Photo31 Photo32 BT ANT S221021019038 Model Name: Portal QLED Controller-L Photo33 Photo34 S221021019038 Model Name: Portal QLED Controller-L Photo35

Page 1 of 7 Report No.: S22102101937003 Report Revision 1.0 FCC Radiofrequency Radiation Exposure Estimation Report In accordance with the requirements of FCC 47 CFR Part 2(2.1093), ANSI/IEEE C95.1-1992 and KDB 447498 D01 Product Name： wireless controller Trademark： Pimax Model Name： Portal QLED Controller-L Serial Model： Portal controller-L Report No.： S22102101937003 FCC ID： 2ARKNPTCONTROLLER-L Prepared for Pimax Technology (Shanghai) Co., Ltd. Building A, Building 1, 3000 Longdong Avenue, China (Shanghai) Pilot Free Trade Zone 406-C Shanghai P.R. China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 7 Report No.: S22102101937003 Report Revision 1.0 TEST RESULT CERTIFICATION Applicant’s name ................. : Pimax Technology (Shanghai) Co., Ltd. Address ................................. : Building A, Building 1, 3000 Longdong Avenue, China (Shanghai) Pilot Free Trade Zone 406-C Shanghai P.R. China Manufacturer's Name .......... : Pimax Technology (Shanghai) Co., Ltd. Address ................................. : Building A, Building 1, 3000 Longdong Avenue, China (Shanghai) Pilot Free Trade Zone 406-C Shanghai P.R. China Factory's Name .................... : Pimax Technology (Rizhao) Co., Ltd. Address ................................. : 3/F, South Zone, A6 workshop, Electronic Industrial Park , Gaoxin 7th Road, Rizhao High-tech Zone, Shandong Province, China Product description Product name ........................ : wireless controller Trademark ............................ : Pimax Model and/or type reference : Portal QLED Controller-L Serial Model ........................... : Portal controller-L Standards ............................. : FCC 47 CFR Part 1(1.1310) FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 KDB 447498 D01 This device described above has been tested by Shenzhen NTEK. Testing has shown that this device is capable of compliance with FCC radiofrequency radiation exposure specified in FCC 47 CFR Part 2(2.1093) and ANSI/IEEE C95.1-1992. The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Date of Test Date (s) of performance of tests ............. : Feb. 20, 2023 ~ Mar. 28, 2023 Date of Issue .......................................... : Apr. 04, 2023 Test Result .............................................. : Pass Prepared By (Test Engineer) : Approved By (Lab Manager) : (Mary Hu) (Alex Li) Page 3 of 7 Report No.: S22102101937003 Report Revision 1.0 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release Apr. 04, 2023 Mary Hu Page 4 of 7 Report No.: S22102101937003 Report Revision 1.0 TABLE OF CONTENTS 1 General Information ................................................................................................................................. 5 1.1 RF Exposure Requirements ....................................................................................................... 5 1.2 EUT Description ......................................................................................................................... 6 1.3 Test specification(s) .................................................................................................................... 6 1.4 Ambient Condition ...................................................................................................................... 6 2 RF Exposure Evaluation .......................................................................................................................... 7 2.1 Operation in BT .......................................................................................................................... 7 Page 5 of 7 Report No.: S22102101937003 Report Revision 1.0 1 General Information 1.1 RF Exposure Requirements Refer to FCC KDB 447498D01, the 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f (GHZ) ] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 6 of 7 Report No.: S22102101937003 Report Revision 1.0 1.2 EUT Description Device Information Product Name wireless controller Trade Name Pimax Model Name Portal QLED Controller-L Serial Model Portal controller-L FCC ID 2ARKNPTCONTROLLER-L Device Phase Identical Prototype Exposure Category General population / Uncontrolled environment Antenna Type FPC Antenna Antenna Gain 1.5dBi Device Operating Configurations Supporting Mode(s) BT Test Modulation BT(GFSK) Operating Frequency Range(s) Band Tx (MHz) Rx (MHz) BT 2402-2480 1.3 Test specification(s) FCC 47 CFR Part 1(1.1310) FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 KDB 447498 D01 General RF Exposure Guidance 1.4 Ambient Condition Ambient temperature 20°C – 24°C Relative Humidity 30% – 70% Page 7 of 7 Report No.: S22102101937003 Report Revision 1.0 2 RF Exposure Evaluation 2.1 Operation in BT Mode Tune-up (dBm) Tune-up (mW) Distance (mm) f (GHz) Calculation Result SAR Exclusion threshold SAR test exclusion Bluetooth 2.50 1.78 5 2.480 0.56 3 Yes NOTE…
