2ARKV-ITRSS120228Commercial Floor Sweeper

Please read the manual carefully before using the product, and keep it properly. Commercial Floor Sweeper Product Manual iMop 3 Content Hardware introduction Safety specification Packing list Product parameters Machine deployment Host About iMop Introduction 14 5 5 6 10 13 14 18 18 20 21 23 36 42 18 20 22 26 37 42 17 Charging pile Preparations Power on Login account Route creation Add tasks Power off Cautions Charging Connect network Map creation Deploy charging pile Start task Operations of machine 43 43 46 45 47 Starting automatic cleaning Manual charging Traveling states Light bar status 4 Daily maintenance Troubleshooting 48 49 50 53 57 60 61 61 62 Clean the dustbin Replace the side brush Clean the shell 48 48 50 52 53 54 58 60 61 Clean the sensor Replace the battery Replace the dust cleaner Replace the roller brush Maintenance frequency Clean the screen Machine storage Power on Route planning Start task Map creation Modifying route Charging Contact us 64 Canada Statement 63 5 About iMop Thank you for choosing iTR iMop commercial floor sweeper, and sincerely hope that iMop can bring you and your company a cleaner, smarter and more convenient working environment in the future. iMop is iTR series commercial floor sweeper,a fully intelligent unmanned machine specially designed for indoor commercial scenarios and dedicated to floor cleaning and maintenance such as sweeping and dust pushing. iMop specializes in cleaning the floor of large- scale properties such as hospitals, supermarkets, office buildings, shopping malls, Etc. And it can work continuously for several hours without driving. Furthermore, iMop can be equipped with different disinfection modules for environmental disinfection in public places, so that one machine can be integrated with multi-functions. Adhering to the consistent design concept “User First” of iTR, the whole machine can be performed with daily maintenance easily, and the key vulnerable parts have been realized the convenient replacement as well as carries out the maintenance, no need additional tools, improve the user's work efficiency greatly. You can conduct real-time management of software operation through APP, and realize one click operation after the first time deployment. You can also release instructions through the whole property management system to complete tasks, which will of great help to reduce staff and increase efficiency, and enter the robot era easily ！ The manual will guide you how to better use our products by providing you all information as comprehensively as possible, which is of great help for you so as to get the optimal product experience. If there is any questions during daily use, please contact with us as soon as possible and we will serve you wholeheartedly. Introduction iMop Product Manual Product Model Weight and volume Movement parameters Obstacle stopping Dimension（L×W×H） Net weight Maximum Speed Maximum working area Standard working width Minimum passing width Climbing angle Maximum cleaning width Maximum operating efficiency Frontal Side iMop 0.77X0.62X0.7m 95KG 20000m 1m/s 2 1.5m 1m 10° 0.93m 3300m 2 /h 10-100cm 5-30cm Product parameters 6 iMop Product Manual 7 Create map Charging Network Screen Battery Motor Max mapping area Max mapping number Manual charging Auto charging WiFi Size Resolution Rated voltage Capacity Charging time Battery run time Rated brush motor power Rated drive motor power 40000m2 100pcs Standard Standard 2.4GHz 8 inches 720P 24V 120AH lithium battery 3-4h Up to 5-6h 2x40W 2x80W iMop Product Manual Motor Lidar Ultrasonic sensor Binocular camera Rated side brush motor power Rated dust collecting motor power Quantity Angle Quantity Maximum detection distance Quantity Detection distance Field of view Volume of roller brush dustbin Volume of Dust collecting dustbin Revolving speed Quantity 2×25W 240W 1 180° 12 30cm 1 300cm 69°×42°（H×V） 1.7L 9.7L 150RPM 4 Sensor Dustbin Side brush 8 iMop Product Manual 9 *Driven by the continuous improvement of products, the product in the manual shall be subject to the actual products. The updating right is reserved by our company. If there is any questions during daily use, please contact with us as soon as possible and we will serve you wholeheartedly. Revolving speed Quantity Working environment Noise level（iTR Lab Data） Roller brush Charging pile Working temperature Working humidity Highest altitude 220RPM 2 100-240VAC,50-60HZ 0°C - 50°C 0％～ 90％rh 3000m 72dB(A) iMop Product Manual 24VD Input Output C Safety specification iMop commercial floor scrubber is only applicable to indoor environment.Before using the product, please read the manual carefully and comply with the following instructions: NOTE：Equipment meeting Class A requirements may not offer adequate protection to broadcast services within a residential environment. The device only uses 2.4G WiFi RF technology. Before using the machine: 1. The operator must read the manual carefully and use the machine according to its instructions. 2. Make sure that the voltage of the power socket is consistent with the input voltage of the charging pile. 3. Before starting the machine, please check whether the emergency stop button is pressed. If pressed, the machine will not be able to perform tasks automatically after startup. 4. Before starting the machine, please check whether all parts of the machine are intact and whether consumables are in normal and available state. 5. Before starting the task of the machine, please make sure it is near the starting point and adjust the front direction of the machine, otherwise the positioning of the machine will be lost directly. 6. Before turning on the machine, please make sure that the lid of the dustbin is closed tightly. 7. If it is used near the suspended environment, including the stairs, please prepare a virtual wall near the stairs and test whether the product can detect the edge of the suspended area without falling. Meanwhile, a protective fence shall be set at the edge o…

Text truncated - open the document above for the full version.

57 iMop Product Manual Hold the connection between brush plate and side brush and use downward force and you can remove side brush; Replace the side brush There are two groups of side brushes, both located at the front and bottom of machine. There are two brush plates under each side brush. 1 Please take out the new brush plate. The brush plate and the side brush are connected by magnetic adsorption. The notch at the top of brush plate corresponds to the convex notch of side brush, and brush plate will automatically adsorb on side brush. 2 Note: Only components sold or recommended by iTR are applicable to iMop. 58 iMop Product Manual Replace the roller brush There are two roller brushes, which are located at the bottom of machine. When you are going to change the roller brush: Firstly, please remove the roller brush cover plate. You are recommended to use an socket head wrench to unscrew the three socket head screws on the roller brush cover plate (screws are located on the right side of roller brush) , and then, the removed will be completed; 1 Please pull out two roller brushes, and then, you can replace them with new ones; 2 59 iMop Product Manual When installing a new roller brush, please insert the end of roller brush with square hole inward into socket of roller brush components, and then, the installation will be completed; Finally, please recover the cover plate of roller brush and screw on the three socket head screws. Please confirm the tightness of socket head screws, and then, the replacement will be completed; 34 You are recommended to wipe and clean with a clean cloth once a week. Clean the shell Please wipe the machine screen with a clean cloth. Note: Machine’s screen is an electronic product. Please keep away from water. Clean the screen 60 iMop Product Manual 61 iMop Product Manual Clean the sensor Lidar: Binocular camera: Ultrasonic sensor: Please gently wipe the lidar with a clean cloth to ensure that the lidar surface is free of dirt. Please gently wipe the binocular camera with a clean cloth to ensure that the surface of the binocular camera is free of dirt. User can selectively wipe the ultrasonic sensor according to the use of the machine. Please gently wipe the ultrasonic sensor with a clean cloth to ensure that the surface of the ultrasonic sensor is free of dirt. Machine storage Replace battery Please store the machine in a dry and cool place. iTR recommends you do not replace the battery by yourself. Please contact iTR after-sales engineer if necessary. Lidar Ultrasonic sensor Binocular camera Decorative lamp beads PartsMaintenance frequencyRecommended replacement frequency Dustbin Dust cleaner Side brush Sensor Roller brush Shell Screen Depends on dirty condition of dustbin Depends on dirty condition of Dust cleaner Depends on wearing situation Depends on dirty condition of sensor Depends on wearing situation Depends on dirty condition of screen Depends on dirty condition of screen / 1-10 months 2-10 months / 1-2 weeks / / Maintenance frequency 62 iMop Product Manual 63 iMop Product Manual Canada Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ou émetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres entre le radiateur et votre corps. 1. This device may not cause interference; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Sales hotline: +86-13958085776 / +86-13567194090 Email: [email protected] Website:www.it-robo.com Serve for other,then get honor IT-ROBOTICS Technology Co., Ltd. Address: Room 203, Main Building of Jieli Building, No.135 of Jichang Road, Shangcheng District, Hangzhou, Zhejiang Tel: +86-0571-87032179 Fax: +86-0571-87837189

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 130 of 160 13. Photos of the EUT Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 131 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 132 of 160 Power Board location

iMop Label location

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 133 of 160 Wireless router location P3310 Module /TX2 location Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 134 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 135 of 160 P3310 Module/TX2 location Power Board Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 136 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 137 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 138 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 139 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 140 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 141 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 142 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 143 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 144 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 145 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 146 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 147 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 148 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 149 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 150 of 160 ANT2 ANT1 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 151 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 152 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 153 of 160 ANT1 ANT2 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 154 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 155 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 156 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 157 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 158 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 159 of 160 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22022208-2E01 Page 160 of 160 END OF REPORT

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 1 of 7 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Hangzhou TaRen Robotics Technology CO., LTD. Address : 3F JieLi Building JiChang Road Shangcheng Hangzhou Zhejiang China Equipment under Test : Commercial Floor Sweeper Model No. : iMop Trade Mark : iTR FCC ID 2ARKV-ITRSS120228 IC : 28428-ITRSS120228 Manufacturer : JiaXing IT-Robotics Technology Co.,Ltd Address : Room 102, Building 13, NO.36 ChangSheng South Road, Economic and Technological Development Zone, Jiaxing Zhejiang China Report No.: DDT-R22022208-2E03 Issued Date: Apr. 08, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 2 of 7 Table of Contents Test report declares.......................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 5 2. RF Exposure Evaluation ................................................................................................ 6 2.1. Requirement ................................................................................................................... 6 2.2. Calculation method ........................................................................................................ 6 2.3. Estimation result ............................................................................................................. 7 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 3 of 7 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R22022208-2E03 Date of Receipt: Mar. 16, 2022 Date of Test: Mar. 16, 2022 ~ Apr. 08, 2022 Prepared By:Approved By: ____________________ ______________________ Sanvin Zheng/EngineerDamon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : Hangzhou TaRen Robotics Technology CO., LTD. Address : 3F JieLi Building JiChang Road Shangcheng Hangzhou Zhejiang China Equipment under Test : Commercial Floor Sweeper Model No. : iMop Trade mark : iTR Manufacturer : JiaXing IT-Robotics Technology Co.,Ltd Address : Room 102, Building 13, NO.36 ChangSheng South Road, Economic and Technological Development Zone, Jiaxing Zhejiang China E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 4 of 7 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Apr. 08, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 5 of 7 1.General Information 1.1. Description of equipment Note: EUT is the abbreviation of equipment under test. Antenna information Ant1 gain Ant2 gain MIMO IEEE 802.11b 5.94 5.94 / IEEE 802.11g 5.94 5.94 / IEEE 802.11n HT20 5.94 5.94 8.95 IEEE 802.11n HT40 5.94 5.94 8.95 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, G-20118 EUT* Name : Commercial Floor Sweeper Model Number : iMop EUT function description : Please reference user manual of this device Power supply : DC powered by a power supply or a built-in 25.2V lithium battery. Radio Technology : IEEE 802.11b/g/n Operation frequency : IEEE 802.11b: 2412 MHz - 2462 MHz IEEE 802.11g: 2412 MHz - 2462 MHz IEEE 802.11n HT20: 2412 MHz - 2462 MHz IEEE 802.11n HT40: 2422 MHz - 2452 MHz Modulation : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Transmitter rate : IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: up to 144.4 Mbps IEEE 802.11n HT40: up to 300 Mbps Antenna Gain : Antenna 1: 5.94 dBi Antenna 2: 5.94 dBi Serial Number : iTRSS 120220110004 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22022208-2E03 Page 6 of 7 2.RF Exposure Evaluation 2.1. Requirement Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device, and below RF Permissible Exposure limi…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 1 of 160 FCC AND ISED CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Hangzhou TaRen Robotics Technology CO., LTD. Address : 3F JieLi Building JiChang Road Shangcheng Hangzhou Zhejiang China Equipment under Test : Commercial Floor Sweeper Model No. : iMop Trade Mark : iTR FCC ID : 2ARKV-ITRSS120228 IC : 28428-ITRSS120228 Manufacturer : JiaXing IT-Robotics Technology Co.,Ltd Address : Room 102, Building 13, NO.36 ChangSheng South Road, Economic and Technological Development Zone, Jiaxing Zhejiang China Report No.: DDT-R22022208-2E01 Issued Date: Apr. 08, 2022 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 2 of 160 Table of Contents Test report declares.......................................................................................................4 1. Summary of Test Results ............................................................................................... 6 2. General Test Information ............................................................................................... 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 7 2.3. Assistant equipment used for test .................................................................................. 8 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Deviations of test standard............................................................................................. 8 2.6. Test environment conditions .......................................................................................... 8 2.7. Test laboratory ............................................................................................................... 9 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment Used During Test ....................................................................................... 10 4. 6 dB Bandwidth and 99% Bandwidth ........................................................................... 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 13 4.5. Original test data .......................................................................................................... 15 5. Conducted Peak Output Power ................................................................................... 32 5.1. Block diagram of test setup .......................................................................................... 32 5.2. Limits ............................................................................................................................ 32 5.3. Test procedure ............................................................................................................. 32 5.4. Test result ..................................................................................................................... 33 6. Power Spectral Density ................................................................................................ 34 6.1. Block diagram of test setup .......................................................................................... 34 6.2. Limits ............................................................................................................................ 34 6.3. Test procedure ............................................................................................................. 34 6.4. Test result ..................................................................................................................... 35 6.5. Original test data .......................................................................................................... 36 7. Band Edge and Spurious Emissions (Conducted) ...................................................... 45 7.1. Block diagram of test setup .......................................................................................... 45 7.2. Limits ............................................................................................................................ 45 7.3. Test procedure ............................................................................................................. 45 7.4. Test result ..................................................................................................................... 46 7.5. original test data ........................................................................................................... 46 8. Radiated Spurious Emissions ...................................................................................... 77 8.1. Block diagram of test setup .......................................................................................... 77 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 3 of 160 8.2. Limit .............................................................................................................................. 78 …

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 44 of 160 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 45 of 160 7. Band Edge and Spurious Emissions (Conducted) 7.1. Block diagram of test setup Same as section 4.1 7.2. Limits In any 100 kHz bandwidth outside the frequency bands in which the spread spectrum intentional radiator in operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power. 7.3. Test procedure (1) Connect EUT’s antenna output to spectrum analyzer by RF cable. (2) Establish a reference level by using the following procedure: Center frequency DTS Channel center frequency RBW: 100 kHz VBW: 300 kHz Span 1.5 times the DTS bandwidth Detector Mode: Peak Sweep time: auto Trace mode Max hold (3) Allow the trace to stabilize, use the peak marker function to determine the maximum peak power level to establish the reference level. (4) Set the spectrum analyzer as follows: RBW: 100 kHz VBW: 300 kHz Span Encompass frequency range to be measured Number of measurement points ≥span/RBW Detector Mode: Peak Sweep time: auto Trace mode Max hold (5) Allow the trace to stabilize, use the peak marker function to determine the maximum amplitude of all unwanted emissions outside of the authorized frequency band Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 46 of 160 7.4. Test result EUT Set Mode CH or Frequency Ant1 Result (dBm) EUT Set Mode CH or Frequency Ant1 Result (dBm) 11b CH1 Pass 11n HT 20 CH1 Pass CH6 Pass CH6 Pass CH11 Pass CH11 Pass 11g CH1 Pass 11n HT 40 CH3 Pass CH6 Pass CH6 Pass CH11 Pass CH9 Pass EUT Set Mode CH or Frequency Ant2 Result (dBm) EUT Set Mode CH or Frequency Ant2 Result (dBm) 11b CH1 Pass 11n HT 20 CH1 Pass CH6 Pass CH6 Pass CH11 Pass CH11 Pass 11g CH1 Pass 11n HT 40 CH3 Pass CH6 Pass CH6 Pass CH11 Pass CH9 Pass 7.5. original test data Band Edge: 11B_Ant1_Low_2412 11B_Ant2_Low_2412 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 47 of 160 11B_Ant1_High_2462 11B_Ant2_High_2462 11G_Ant1_Low_2412 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 48 of 160 11G_Ant2_Low_2412 11G_Ant1_High_2462 11G_Ant2_High_2462 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 49 of 160 11N20MIMO_Ant1_Low_2412 11N20MIMO_Ant2_Low_2412 11N20MIMO_Ant1_High_2462 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 50 of 160 11N20MIMO_Ant2_High_2462 11N40MIMO_Ant1_Low_2422 11N40MIMO_Ant2_Low_2422 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 51 of 160 11N40MIMO_Ant1_High_2452 11N40MIMO_Ant2_High_2452 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 52 of 160 Spurious Emissions: 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 53 of 160 11B_Ant2_2412_0~Reference 11B_Ant2_2412_30~1000 11B_Ant2_2412_1000~26500 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 54 of 160 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 11B_Ant1_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 55 of 160 11B_Ant2_2437_0~Reference 11B_Ant2_2437_30~1000 11B_Ant2_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 56 of 160 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 11B_Ant1_2462_1000~26500 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R22022208-2E01 Page 57 of 160 11B_Ant2_2462_0~Reference 11B_Ant2_2462_30~1000 11B_Ant2_2462_1000~26…

Text truncated - open the document above for the full version.
