2ARN8-SMPVG02VetGuardian animal alert sensor

Structured Monitoring Products Product Management Department USER MANUAL Purpose of the document The purpose of this document is to provide direction and explain how to set up and use VetGuardian. User understands and acknowledges that (i) it is participating in SMP's Early Market Test for the Products, (ii) it is receiving a preliminary version of the Product, and (iii) the Product may not operate properly, may not perform all functions for which it is intended or represented, and may not operate error-free. User agrees to use the Product primarily for purposes of evaluation, agrees to provide SMP with its comments, criticisms, and suggestions for changes with respect to the Product, and agrees to help SMP identify any and all errors or malfunctions in the operation of the Product. For a period of three hundred and sixty-five days (365) days from the date User receives the Products (the ‘Test Period’), User shall keep a written record of the use and results of the Products together with any unusual, unplanned, or extraordinary events observed by User during the Test Period, supported by data, printouts, photos, or other evidence of such events as appropriate. From time to time throughout the Test period, SMP may require additional or modified tests of the Products as may be reasonably requested by SMP. User's personnel shall report each instance of any failure or malfunction of the Products (‘Product Failure’) in full (including, without limitation, description of the application then underway and the specifics of the Product Failure). If any Product Failure results in damage to files or data or if the frequency of Product Failures is excessive under the circumstances, User shall also promptly notify SMP of this fact. Copies of the reports regarding Product Failures shall be forwarded to SMP. Equipment Statements For All Equipment: Changes or modifications not expressly approved by SMP could void the user's authority to operate the equipment.1 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Class B equipment: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit VetGuardian User Manual VetGuardian User Manual Last Modified: May 17, 2022 Author: KB Version 2.23 Page 2 different from that which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device contains an array of SPAD (single photon avalanche diode) detectors, and an integrated 940 nm light source based on an eye-safe Class 1 VCSEL (vertical cavity surface-emitting laser). The laser output is designed to remain within Class 1 laser safety limits under all reasonably foreseeable conditions including single faults in compliance with IEC 60825-1:2014 (third edition). Caution: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure Compliance Information for the Wi-Fi module FCC PART 15 STATEMENTS: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. The end user of this product should be aware that any changes or modifications made to this equipment without the approval of the manufacturer could result in the product not meeting the Class A limits, in which case the FCC could void the user's authority to operate the equipment. Compliance Information for the Wi-Fi module FCC: Contains 2ABCB-RPICM4 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning …

Text truncated - open the document above for the full version.

7/11/2022 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: 2ARN8-SMPVG02 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List / Tune-Up Procedure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Michelle Branum, CKC CS for Vikram Ramprakash, Structured Monitoring Products.

Regarding test report inquiry regarding secondary transmit frequency shown in plots just below the declared transmit frequency of 5870 MHz. Reply from Lab: The lower frequency is not related to this 5870 MHz transmitter device. The device operates on a single channel at 5870 MHz, but the onboard certified Wi-Fi module can simultaneously transmit and can be seen in the graph. An MPE report has been submitted to cover the RF Exposure of the simultaneous transmission

F2P27463 Page 1 of 5 20220707 PHOTOGRAPHS: EXTERNAL Structured Monitoring Products – FCC ID: 2ARN8-SMPVG01 Model SMPVG02 Front Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 2 of 5 20220707 Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 3 of 5 20220707 Rear Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 4 of 5 20220707 Side Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 5 of 5 20220707 Top Bottom

Label Placement Label Placement Last Modified: 7/1/22 Author: SMP Version 2.5 Page 1/1 Label to placed inside sunken area.

F2P27463 Page 1 of 5 20220521 PHOTOGRAPHS: INTERNAL Structured Monitoring Products – FCC ID: 2ARN8-SMPVG02 Radar Board Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 2 of 5 20220711 Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 3 of 5 20220711 PCB Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 4 of 5 20220711 Order Number: F2P27463 Client: Structured Monitoring Products Model: SMPVG02 F2P27463 Page 5 of 5 20220711 Back

042216 Report Number: F2P27463-02E Page 1 of 8 Issue Date: 2022-07-14 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com CERTIFICATION TEST REPORT Manufacturer: Structured Monitoring Products 151 Innovation Way, Suite 210 Elyria, Ohio 44035 USA United States of America Applicant: Same as above Product Description: Heart rate and respiratory rate measurement device for animals. Model: SMPVG02* – Version 2.5 *Denotes actual model tested where models SMPVG02 and SMPVG03 are identical except for a different label for the unit name for branding purposes. FCC ID: 2ARN8-SMPVG02 Testing Commenced: 2022-04-26 Testing Ended: 2022-04-26 Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards: • KDB447498 • FCC Part 1.1310 Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 2 of 8 Issue Date: 2022-07-14 Evaluation Conducted by: Julius Chiller, EMC/Wireless Engineer Report Reviewed by: Ken Littell, Vice President of EMC F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 3 of 8 Issue Date: 2022-07-14 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 4 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 5 3 ENGINEERING STATEMENT 6 4 EUT INFORMATION AND DATA 7 5 RF EXPOSURE FOR DEVICE >20cm FROM HUMAN 8 Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 4 of 8 Issue Date: 2022-07-14 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to KDB558074. 1.4 Document History Document Number Description Issue Date Approved By F2P27463-02E First Issue 2022-07-14 K. Littell Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 5 of 8 Issue Date: 2022-07-14 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results RF Exposure for Device >20cm from Human KDB447498 FCC Part 1.1310 Complies Modifications Made to the Equipment None Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 6 of 8 Issue Date: 2022-07-14 3 ENGINEERING STATEMENT This report has been prepared on behalf of Structured Monitoring Products, Inc. to provide documentation for the testing described herein. This equipment has been tested and found to comply with FCC Rule Part 1.1310 and KDB447498. The test results found in this test report relate only to the item(s) tested. Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 7 of 8 Issue Date: 2022-07-14 4 EUT INFORMATION AND DATA 4.1 Equipment Under Test: Product: Heart Monitor Model: SMPVG02* – Version 2.5 Serial No.: 1 Firmware: 2.5 Hardware: D FCC ID: 2ARN8-SMPVG02 FCC ID of Approved WiFi module is 2ABCB-RPICM4 *Denotes actual model tested where models SMPVG02 and SMPVG03 are identical except for a different label for the unit name for branding purposes. 4.2 Trade Name: Structured Monitoring Products 4.3 Power Supply: 12VDC from AC Supply 4.4 Applicable Rules: • KDB447498 • FCC Part 1.1310 4.5 Antenna: Integral Antenna of Radar Transmitter, 0dBi Gain WiFi Antenna for 2.4GHz transmission, 3.5dBi Gain WiFi Antenna for 5GHz transmission, 2.3dBi Gain 4.6 Accessories: CUI AC Adaptor ESTA120100UDC-P5P-SZ Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 042216 Report Number: F2P27463-02E Page 8 of 8 Issue Date: 2022-07-14 5 RF EXPOSURE FOR DEVICE >20cm FROM HUMAN 5.1 Requirements: Distance used is 20cm Limit: 1mW/cm 2 Formula used for result: E.I.R.P. 4 π R 2 Results: E.I.R.P. of Radar transmission = 0.10165 mW 0.10165mW at the 5870 MHz single channel. 0.10165mW = 0.10165mW = 0.00002mW/cm2 4 π R 2 5026.55 The highest E.I.R.P. of the WiFi as reported in the authorization for the WiFi module in the 5170 – 5825 MHz range = 112.2 mW 112.2mW = 112.2mW = 0.0223mW/cm2 4 π R 2 5026.55 0.00002mW/cm2 = Ratio of 0.00002 1mW/cm 2 0.0223mW/cm2 = Ratio of 0.0223 1mW/cm 2 The combined MPE of WiFi and Radar is Ratio of 0.00002 + 0.0223 = 0.02232

060818 Report Number: F2P27463-01E Page 1 of 40 Issue Date: 2022-08-12 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com CERTIFICATION TEST REPORT Manufacturer: Structured Monitoring Products 151 Innovation Way, Suite 210 Elyria, Ohio 44035 USA United States of America Applicant: Same as Above Product Name: Heart Monitor Product Description: Heart rate and respiratory rate measurement device for animals. Operating Voltage/Freq. of EUT During Testing: 12VDC from AC supply Model: SMPVG02* – Version 2.5 *Denotes actual model tested where models SMPVG02 and SMPVG03 are identical except for a different label for the unit name for branding purposes. FCC ID: 2ARN8-SMPVG02 Testing Commenced: 2022-04-26 Testing Ended: 2022-08-12 Summary of Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications and/or manufacturer’s statement. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards:  FCC Part 15 Subpart C, Section 15.249  FCC Part 15 Subpart C, Section 15.215(c) – Additional provisions to the general radiated emission limitations  FCC15.207 - Conducted Limits  FCC Part 15 Subpart A, Section 15.31(e) – Measurement Standards Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 2 of 40 Issue Date: 2022-08-12 Evaluation Conducted by: Julius Chiller, EMC/Wireless Engineer Report Reviewed by: Ken Littell, Vice President of EMC F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 3 of 40 Issue Date: 2022-08-12 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 4 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 7 3 TABLE OF MEASURED RESULTS 8 4 ENGINEERING STATEMENT 9 5 EUT INFORMATION AND DATA 10 6 LIST OF MEASUREMENT INSTRUMENTATION 11 7 OCCUPIED BANDWIDH 12 8 FIELD STRENGTH OF EMISSIONS 15 9 VOLTAGE VARIATIONS 27 10 CONDUCTED EMISSIONS 31 11 PHOTOGRAPHS - TEST SETUPS 36 Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 4 of 40 Issue Date: 2022-08-12 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to the 2013 version of ANSI C63.10 and recommended FCC procedure of measurement under Section 15.249. A list of the measurement equipment can be found in Section 6. Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 5 of 40 Issue Date: 2022-08-12 1.3 Uncertainty Budget: The uncertainty in EMC measurements arises from several factors which affect the results, some associated with environmental conditions in the measurement room, the test equipment being used, and the measurement techniques adopted. The measurement uncertainty budgets detailed below are calculated from the test and calibration data and are expressed with a 95% confidence factor using a coverage factor of k=2. The Uncertainty for a laboratory is referred to as Ulab. For Radiated and Conducted Emissions, the Expanded Uncertainty is compared to the Ucispr values to determine if a specific margin is required to deem compliance. Ulab Ucispr If Ulab is less than or equal to Ucispr, then: • compliance is deemed to occur if no measured disturbance exceeds the disturbance limit; • non-compliance is deemed to occur if any measured disturbance exceeds the disturbance limit. If Ulab is greater than Ucispr in table 1, then: • compliance is deemed to occur if no measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit; • non-compliance is deemed to occur if any measured disturbance, increased by (Ulab – Ucispr), exceeds the disturbance limit. Note: Only measurements listed in the tables above that relate to tests included in this Test Report are applicable. Measurement Range Combined Uncertainty Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 2.54 5.07dB Radiated Emissions <1 GHz @ 10m 2.55 5.09dB Radiated Emissions 1 GHz to 2.7 GHz 1.81 3.62dB Radiated Emissions 2.7 GHz to 18 GHz 1.55 3.10dB AC Power Line Conducted Emissions, 150kHz to 30 MHz 1.38 2.76dB AC Power Line Conducted Emissions, 9kHz to 150kHz 1.66 3.32dB Measurement Range Expanded Uncertainty Radiated Emissions <1 GHz @ 3m 5.2dB Radiated Emissions <1 GHz @ 10m 5.2dB Radiated Emissions 1 GHz to 2.7 GHz Under Consideration Radiated Emissions 2.7 GHz to 18 GHz Under Consideration AC Power Line Conducted Emissions, 150kHz to 30 MHz 3.6dB AC Power Line Conducted Emissions, 9kHz to 150kHz 4.0dB Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 6 of 40 Issue Date: 2022-08-12 1.4 Document History: Document Number Description Issue Date Approved By F2P27463-01E First Issue 2022-08-12 K. Littell Order Number: F2P27463 Applicant: Structured Monitoring Products Model: SMPVG02 – Version 2.5 060818 Report Number: F2P27463-01E Page 7 of 40 Issue Date: 2022-08-12 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results Spurious Emissions CFR 47 Part 15.209 Complies -20dB Occupied Bandwidth CFR 47 Part 15.215(c) Complies Field Strength of Emissions CFR 47 Pa…
