2ARNG-KBRR1XTKobotix Real Racer First Person View (FPV) RC Car

page 1 WHAT’S INCLUDED 8+ 1 x INSTRUCTION MANUAL 1 x REAL RACER™ 1 x CONTROLLER 1 x LiPo BATTERY CHARGING CABLE 1 x RECHARGEABLE LiPo BATTERY PACK 1 x FPV HEADSET INTRODUCTION Thank you for purchasing KOBOTIX ® REAL RACER™! Get ready to race! The future of RC racing has arrived. REAL RACER™ puts you in the drivers seat. Follow the instructions in the manual and you will be up and racing in no time! CAUTION: HAIR ENTANGLEMENT Tie back and cover hair and secure loose clothing prior to play. WARNING: CHOKING HAZARD This product is not suitable for children under 3 years because of small parts. TM INSTRUCTION MANUAL page 2 1 12 3 2 4 A B 1. (A) Press the button at the bottom of the Controller handle to release the Battery Cartridge. (B) Insert 4 x AAA batteries (not included). Ensure that the positive and negative polarities match the illustration inside the Battery Cartridge. 2. Slide the Battery Cartridge back into the Controller until it *clicks* into place. 1. Lay the REAL RACER™ Car down so that the Battery Compartment faces upwards. 2. Using a Phillips screwdriver (not included), remove the screw on the Battery Compartment Cover. 3. Connect the battery connectors together and insert the Rechargeable LiPo Battery Pack (included) into the Battery Compartment. 4. Replace the Battery Compartment Cover and tighten screw using the screwdriver. Do not over-tighten. POWERING REAL RACER™ INSTALLING THE LiPo BATTERY PACK REPLACING BATTERIES IN THE CONTROLLER page 3 1 3 2 1. Plug the charging cable into a powered USB outlet such as a PC or mobile phone charger. The LED will glow GREEN when connected to a USB outlet. 3. When the LiPo battery is fully charged, the charging cable LED will glow GREEN. Charging time for a fully discharged battery is approximately 60 minutes. 2. Plug the battery connector into the connector on the charging cable. The LED on the charging cable will glow RED to indicate charging in progress. In extremely rare circumstances, there may be a risk of a battery leaking fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Non-rechargeable batteries are NOT to be recharged. • Rechargeable LiPo batteries are to be removed from the product before charging. • Rechargeable LiPo batteries are only to be charged under adult supervision. • You MUST charge the LiPo battery in a safe area away from any flammable materials. • NEVER charge the battery unattended at any time. When charging the battery, remain in constant observation of the battery to monitor the process and react immediately to any potential problems. • DO NOT expose batteries to extreme heat or fire, batteries may leak or explode. • DO NOT short-circut the supply terminals. • DO NOT drop or subject to strong impact. • DO NOT allow the battery to get wet. • Only charge the battery with the included battery charging cable. • Dispose of batteries properly. BATTERY SAFETY PRECAUTIONS CHARGING THE LiPo BATTERY PACK BATTERY INFORMATION page 4 A. B. C. A. Camera B. Power Toggle C. Battery Compartment ABOUT THE REAL RACER™ CAR TRANSMISSION RANGE: Approximately 30 metres (98.4 feet) MAX SPEED: 20 km/h (12.4 mph) CAMERA: HD 720p 30 FPS CONNECTIVITY CONTROL LINK: 2.4 GHz RF VIDEO LINK: Wi-Fi 802.11n (2.4 GHz) 1. Standard RC Racing experience without the app and headset. Your Real Racer™ is ready to go as soon as the batteries are installed and both the Real Racer™ Car and Controller is powered on. 2. With the Real Racer™ App, experience the driver’s view and access the various features of your Real Racer™. 3. For a fully immersive Driver’s view RC experience - activate the Real Racer™ App, turn on the Headset function and strap on the FPV Headset. USING THE REAL RACER™ CAR MANY WAYS TO DRIVE TECHNICAL INFORMATION page 5 A. B. E. F. G. H. I. K. L. J. D. A. Capture Video B. Steering Wheel C. Throttle D. Pistol Grip E. Battery Cartridge Release F. Steering Rate SIDE VIEW TOP VIEW G. Take Picture H. Bind I. Steering Trim J. Throttle Rate K. AUX L. Power Button DRIVING REAL RACER™ ABOUT THE CONTROLLER ATTACHING THE STEERING WHEEL Place the hexagonal Steering Column (located on the underside of the Steering Wheel) against the hexagonal hole on the right side of the Controller and slowly rotate. The Steering Wheel will automatically attach to the Controller once correct alignment has been achieved. Lightly press Steering Wheel into place. C. page 6 234 A. B. A. Release Button B. Capacitive Touch Button C. Optical Distance Dial D. Focal Adjustment Dial E. Phone Compartment F. Optical Lens G. Adjustable Headstrap D. G. F.F. E. C. Note: The FPV Headset is designed for devices between 4.7” - 6.2”. 1. Connect REAL RACER™ to your device, launch the REAL RACER™ App and activate the HEADSET Mode. 2. Open the Phone Compartment on your headset and insert your phone with the screen facing the optical lens. Close the compartment and make sure that it is securely locked. 3. Wear the headset and adjust straps to make sure it fits your head securely and comfortably. 4. Adjust the optical lens’ until you see clearly. The Optical Distance Dial on top adjusts optical spacing and the Focal Adjustment Dials on both sides adjust focus. 5. You are now in the driver’s seat. Pick up the Controller and you are ready to race! ABOUT THE FPV HEADSET WEARING THE FPV HEADSET THE FPV HEADSET page 7 DEVICE LIST kobotix.com/devices SAFETY PRECAUTIONS: • Keep hands, hair and loose clothing away from the wheels when power switch is turned ON. • Keep all chemicals, small parts and anything electrical out of the reach of children. • Keep moving parts clean. • Keep parts dry. • Always let parts cool after use before touching. • Turn off controller and vehicle when not in use. • Remove battery(s) from controller when not in use. • Parental guidance is recommended. • Users should keep strict accordance with the instruction manual while operating the product. • The product must only be used with the recommended controller. BATTERY SAFETY …

Text truncated - open the document above for the full version.

The Product Workshop Limited TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.07.02 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, The Product Workshop Limited hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Martyn Kay Signature:

The Product Workshop Limited TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.07.02 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR Product Name : Kobotix Real Racer First Person View (FPV) RC Car Model Name: KBRR10T FCC ID: 2ARNG-KBRR1XT To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Martyn Kay Signature:

Page 1 of 3 Report No.: STS2002003 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: KBRR10T Photo 1 Photo 2 Page 2 of 3 Report No.: STS2002003 Photo 3 Photo 4 Page 3 of 3 Report No.: STS2002003 Photo 5 Photo 6

Label

Page 1 of 3 Report No.: STS2002003 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: KBRR10T Photo 1 Photo 2 Page 2 of 3 Report No.: STS2002003 Photo 3 Photo 4 2.4G SRD Antenna Page 3 of 3 Report No.: STS2002003 Photo 5 Photo 6

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2002003W06 Issued for The Product Workshop Limited Unit 1303A, Henley Industrial Centre, 9-15 Bute Street, Mong Kok, Kowloon, Hong Kong Product Name: Kobotix Real Racer First Person View (FPV) RC Car Brand Name: KOBOTIX Model Name: KBRR10T Series Model: N/A FCC ID: 2ARNG-KBRR1XT IC: 24571-KBRR1XT Test Standard: FCC Part 15.249 RSS 210 Issue 9 S T L A B S Page 2 of 37 Report No.: STS2002003W06 TEST RESULT CERTIFICATION Applicant’s Name ................. : The Product Workshop Limited Address .................................. : Unit 1303A, Henley Industrial Centre, 9-15 Bute Street, Mong Kok, Kowloon, Hong Kong Manufacture's Name ............ : The Product Workshop Limited Address .................................. : Unit 1303A, Henley Industrial Centre, 9-15 Bute Street, Mong Kok, Kowloon, Hong Kong Product Description Product Name ........................ : Kobotix Real Racer First Person View (FPV) RC Car Brand Name ......................... : KOBOTIX Model Name ........................... : KBRR10T Series Model .......................... : N/A Test Standards ...................... : FCC Part15.249 RSS 210 Issue 9 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC/IC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................ : Date of receipt of test item ..... : 18 Feb. 2020 Date of performance of tests .. : 18 Feb. 2020 ~ 26 May 2020 Date of Issue .......................... : 26 May 2020 Test Result .............................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Vita Li) Page 3 of 37 Report No.: STS2002003W06 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 RADIATED EMISSION MEASUREMENT 14 4. BANDWIDTH TEST 32 4.1 TEST PROCEDURE 32 4.2 TEST SETUP 32 4.3 EUT OPERATION CONDITIONS 32 4.4 TEST RESULTS 33 5. ANTENNA REQUIREMENT 35 5.1 STANDARD REQUIREMENT 35 5.2 EUT ANTENNA 35 6. FREQUENCY STABILITY 36 6.1 LIMITS 36 6.2 TEST PROCEDURE 36 6.3 TEST RESULT 36 Page 4 of 37 Report No.: STS2002003W06 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 26 May 2020 STS2002003W06 ALL Initial Issue Page 5 of 37 Report No.: STS2002003W06 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.249 , Subpart C RSS 210 Issue 9 Standard Section Test Item Judgment Remark 15.207 RSS-Gen Issue 5 Conducted Emission N/A -- 15.203 RSS-Gen Issue 5 Antenna Requirement Pass -- 15.249 RSS 210 Issue 9 (B.10) Radiated Spurious Emission Pass -- 15.205 Radiated Band Edge Emission Pass -- 15.249 RSS-Gen Issue 5 Occupied Bandwidth Pass -- RSS-Gen Issue 5 Frequency Stability PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 6 of 37 Report No.: STS2002003W06 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 7 of 37 Report No.: STS2002003W06 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Kobotix Real Racer First Person View (FPV) RC Car Trade Name KOBOTIX Model Name KBRR10T Series Model N/A Model Difference N/A Product Description The EUT is a Kobotix Real Racer First Person View (FPV) RC Car Operation Frequency: 2402 MHz – 2481 MHz Modulation Type: GFSK Antenna Designation: Copper Pipe Antenna Gain(Peak): 0 dBi Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Power Rating Input: DC 6V (4 x 1.5V AAA) Hardware version number Ver1.0 Software version number Ver1.0 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Page 8 of 37 Report No.: STS2002003W06 2. Frequency list Channel Frequency Channel FrequencyChannel Frequency Channel Frequency 1 2402 21 2422 41 2442 61 2462 2 2403…
