2AROI-KF27Remote Control Car

Remote Control Car KF27 KF27 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction.

SHANTOU KAISHENGFENG TOYS CO., LTD. Covered Equipment Certification Attestation Letter 6/29/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AROI-KF27 SHANTOU KAISHENGFENG TOYS CO., LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. SHANTOU KAISHENGFENG TOYS CO., LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. SHANTOU KAISHENGFENG TOYS CO., LTD. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Kevin Chen Title: Manager Company Name: SHANTOU KAISHENGFENG TOYS CO., LTD. Date: 6/29/2026

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¶VREOLJDWLRQWRDFFHSWVHUYLFHRISURFHVVLQ WKH8QLWHG6WDWHVIRUPDWWHUVUHODWHGWRWKHDSSOLFDEOHHTXLSPHQWDQGDWWKHSK\VLFDO86DGGUHVVDQGH PDLORIWKHGHVLJQDWHGDJHQWOLVWHGDERYH :H6+$1728.$,6+(1*)(1*72<6&2/7'!DQG3LFXV$GYLVRUV86//&!DFNQRZOHGJHWKH DSSOLFDQW¶VDFFHSWDQFHRILWVREOLJDWLRQWRPDLQWDLQDQDJHQWIRUVHUYLFHRISURFHVVLQWKH8QLWHG6WDWHVIRU QROHVVWKDQRQH\HDUDIWHUHLWKHUWKHJUDQWHHKDVSHUPDQHQWO\WHUPLQDWHGDOOPDUNHWLQJDQGLPSRUWDWLRQ RIWKHDSSOLFDEOHHTXLSPHQWZLWKLQWKH86RUWKHFRQFOXVLRQRIDQ\&RPPLVVLRQUHODWHGDGPLQLVWUDWLYH RUMXGLFLDOSURFHHGLQJLQYROYLQJWKHHTXLSPHQWZKLFKHYHULVODWHU 6LJQDWXUH $SSOLFDQW 6+$1728.$,6+(1*)(1*72<6&2/7' 1DPH 3ULQWHG .HYLQ&KHQ 7LWOH0DQDJHU  86GHVLJQDWHGDJHQW 3LFXV $GYLVRUV 86 //& 1DPH 3ULQWHG ,YDQ:DQJ 7LWOH &(2 6LJQDWXUH

SHANTOU KAISHENGFENG TOYS CO., LTD. DATE: 6/29/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with SHANTOU KAISHENGFENG TOYS CO., LTD. (6B, WEST MEIXIN AVENUE, FENGXIANG STREET, CHENGHAI, SHANTOU, China) <Signature> Name: Kevin Chen Title: Manager Applicant Company: SHANTOU KAISHENGFENG TOYS CO., LTD.

Date: 6/29/2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Kevin Chen Title: Manager Company: SHANTOU KAISHENGFENG TOYS CO., LTD.

Date: 6/29/2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AROI-KF27 Product Name: Remote Control Car Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Kevin Chen Title: Manager Company: SHANTOU KAISHENGFENG TOYS CO., LTD.

SHANTOU KAISHENGFENG TOYS CO., LTD. 6B, WEST MEIXIN AVENUE, FENGXIANG STREET, CHENGHAI, SHANTOU, China Date: 2026/6/29 Dear Sir/Madam, We, SHANTOU KAISHENGFENG TOYS CO., LTD., Hereby declares the following statement, PCB board, circuit, structure and internal of these model(s) are the same, Only model name and appearance color are different for these model: FCC ID: 2AROI-KF27 Product name: Remote Control Car Model no.: KF27, KF27MAX, KF27PRO, KF2627 Sincerely, Name/Title： Kevin Chen / Manager Company: SHANTOU KAISHENGFENG TOYS CO., LTD. Address: 6B, WEST MEIXIN AVENUE, FENGXIANG STREET, CHENGHAI, SHANTOU, China Phone: 0754-85827556 Fax: N/A E-Mail: [email protected]

Report No.: TZ0035260550PH02 Page 1 of 7 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0035260550PH02 Page 2 of 7 External Photo 3 External Photo 4 Report No.: TZ0035260550PH02 Page 3 of 7 External Photo 5 External Photo 6 Report No.: TZ0035260550PH02 Page 4 of 7 External Photo 7 External Photo 8 Report No.: TZ0035260550PH02 Page 5 of 7 External Photo 9 External Photo 10 Report No.: TZ0035260550PH02 Page 6 of 7 External Photo 11 External Photo 12 Report No.: TZ0035260550PH02 Page 7 of 7 External Photo 13

The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: 2AROI-KF27

Report No.: TZ0035260550PH03 Page 1 of 3 Internal Photographs of EUT Internal Photo 1 Internal Photo 2 Report No.: TZ0035260550PH03 Page 2 of 3 Internal Photo 3 Internal Photo 4 SRD antenna Report No.: TZ0035260550PH03 Page 3 of 3 Internal Photo 5 Internal Photo 6

FCC ID: 2AROI-KF27 Page 1 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). FCC ID: 2AROI-KF27 Page 2 of 2 This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Results RF Exposure at Separation distance (cm): 0.5 Mode Antenna Frequency [MHz] Conducted Power [dBm] Manufacturing tolerance Antenna Gain [dBi] Max of ERP and Conducted Power including Tune Up SAR- based exemption threshold Pth [mW] Target Power [dBm] Tolerance ±[dB] [dBm] [mW] BLE_1M Ant1 2405 1.03 0.5 1 0.17 1.5 1.41 2.78 BLE_1M Ant1 2440 1.33 1 1 0.17 2 1.58 2.75 BLE_1M Ant1 2475 0.96 0.5 1 0.17 1.5 1.41 2.72 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The Maximum Erp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 1 of 23 Appendix Test Data for SRD (Conducted Measurement) Product Name: Remote Control Car Trade Mark: / Test Model: KF27 FCC ID: 2AROI-KF27 Environmental Conditions Temperature: 23.5°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Max Zhang NOTE N/A Appendix A: DTS Bandwidth Test Result Test Mode Antenna Frequency [MHz] DTS BW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict SRD Ant1 2405 0.588 2404.748 2405.336 0.5 PASS SRD Ant1 2440 0.580 2439.756 2440.336 0.5 PASS SRD Ant1 2475 0.580 2474.756 2475.336 0.5 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 2 of 23 Test Graphs SRD-Ant1-2405-PASS SRD-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 3 of 23 SRD-Ant1-2475-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 4 of 23 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict SRD Ant1 2405 1.0930 2404.4986 2405.5916 --- --- SRD Ant1 2440 1.0921 2439.4987 2440.5908 --- --- SRD Ant1 2475 1.1020 2474.4881 2475.5901 --- --- Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 5 of 23 Test Graphs SRD-Ant1-2405 SRD-Ant1-2440 Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 6 of 23 SRD-Ant1-2475 Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 7 of 23 Appendix C: Maximum peak conducted output power Test Result Peak Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict SRD Ant1 2405 1.03 ≤30 PASS SRD Ant1 2440 1.33 ≤30 PASS SRD Ant1 2475 0.96 ≤30 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 8 of 23 Test Graphs Peak SRD-Ant1-2405-PASS SRD-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 9 of 23 SRD-Ant1-2475-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 10 of 23 Appendix D: Maximum peak power spectral density Test Result Test Mode Antenna Frequency [MHz] Result [dBm/3kHz] Limit [dBm/3kHz] Verdict SRD Ant1 2405 -5.55 ≤8.00 PASS SRD Ant1 2440 -5.53 ≤8.00 PASS SRD Ant1 2475 -5.80 ≤8.00 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 11 of 23 Test Graphs SRD-Ant1-2405-PASS SRD-Ant1-2440-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 12 of 23 SRD-Ant1-2475-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 13 of 23 Appendix E: Band edge measurements Test Result Test Mode Antenna Ch. Name Frequency [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict SRD Ant1 Low 2405 -1.04 -44.07 ≤-21.04 PASS SRD Ant1 High 2475 -1.46 -46.73 ≤-21.46 PASS Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 14 of 23 Test Graphs SRD-Ant1-2405-PASS SRD-Ant1-2475-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 15 of 23 Appendix F: Conducted Spurious Emission Test Result Test Mode Antenna Frequency [MHz] Freq. Range [MHz] Ref. Level [dBm] Result [dBm] Limit [dBm] Verdict SRD Ant1 2405 0~Reference -1.38 -1.38 --- PASS SRD Ant1 2405 30~1000 -1.38 -59.17 ≤-21.38 PASS SRD Ant1 2405 1000~26500 -1.38 -33.56 ≤-21.38 PASS SRD Ant1 2440 0~Reference -1.07 -1.07 --- PASS SRD Ant1 2440 30~1000 -1.07 -54.63 ≤-21.07 PASS SRD Ant1 2440 1000~26500 -1.07 -35.42 ≤-21.07 PASS SRD Ant1 2475 0~Reference -1.29 -1.29 --- PASS SRD Ant1 2475 30~1000 -1.29 -55.91 ≤-21.29 PASS SRD Ant1 2475 1000~26500 -1.29 -35.75 ≤-21.29 PASS 1. Note: offset(dB) in Reference test plots = cable loss(dB) + attenuator factor(dB); For spurious emissions plots from 30MHz to 26.5GHz, the cable loss and attenuator factors have been set in the 'Input Correction' of the Spectrum Analyzer during the test. Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 16 of 23 Test Graphs SRD-Ant1-2405-0~Reference-PASS SRD-Ant1-2405-30~1000-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 17 of 23 SRD-Ant1-2405-1000~26500-PASS SRD-Ant1-2440-0~Reference-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 18 of 23 SRD-Ant1-2440-30~1000-PASS SRD-Ant1-2440-1000~26500-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 19 of 23 SRD-Ant1-2475-0~Reference-PASS SRD-Ant1-2475-30~1000-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 20 of 23 SRD-Ant1-2475-1000~26500-PASS Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 21 of 23 Appendix G: Duty Cycle Test Result Test Mode Antenna Frequency [MHz] ON Time [ms] Period [ms] Duty Cycle [%] Duty Cycle Factor [dB] SRD Ant1 2405 0.18 0.29 62.07 2.07 SRD Ant1 2440 0.17 0.28 60.71 2.17 SRD Ant1 2475 0.17 0.28 60.71 2.17 Note: offset(dB) = cable loss(dB) + attenuator factor(dB) Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 22 of 23 Test Graphs NTNV-SRD-Ant1-2405 NTNV-SRD-Ant1-2440 Appendix Test Data of the Report No.: TZ0035260550FRF12 Page 23 of 23 NTNV-SRD-Ant1-2475

Report No.: TZ0035260550FRF12 Page 1 of 30 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0035260550FRF12 Product Name : Remote Control Car Model/Type reference : KF27, KF27MAX, KF27PRO, KF2627 FCC ID : 2AROI-KF27 Prepared for : SHANTOU KAISHENGFENG TOYS CO., LTD. 6B, WEST MEIXIN AVENUE, FENGXIANG STREET, CHENGHAI, SHANTOU, China Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 15C, ANSI C63.10-2020 + Cor.1-2023 Date of Test : 2026-05-18 ~ 2026-06-10 Date of Issue : 2026-06-11 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0035260550FRF12 Page 2 of 30 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-06-11 Valid Initial release Report No.: TZ0035260550FRF12 Page 3 of 30 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ....................................................... 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. EUT configuration ................................................................................................................... 5 1.5. Description of Test Facility .................................................................................................... 5 1.6. Statement of the Measurement Uncertainty ......................................................................... 6 1.7. Measurement Uncertainty ...................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 6 1.9. Frequency of Channels .......................................................................................................... 6 2. T E S T M E T H O D O L O G Y ............................................................ 8 2.1. EUT Configuration .................................................................................................................. 8 2.2. EUT Exercise ........................................................................................................................... 8 2.3. Test Sample ............................................................................................................................. 8 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 9 3.1. Justification ............................................................................................................................. 9 3.2. EUT Exercise Software ........................................................................................................... 9 3.3. Special Accessories ............................................................................................................... 9 3.4. Block Diagram/Schematics .................................................................................................... 9 3.5. Equipment Modifications ....................................................................................................... 9 3.6. Test Setup ................................................................................................................................ 9 4. S U M M A R Y O F T E S T R E S U L T S ............................................... 10 5. T E S T R E S U L T .................................................................... 11 5.1. On Time and Duty Cycle ....................................................................................................... 11 5.2. Maximum Peak Conducted Output Power Measurement ................................................. 12 5.3. Power Spectral Density Measurement ................................................................................ 13 5.4. 6 dB Spectrum Bandwidth and Occupied Channel Bandwidth Measurement ............... 14 5.5. Radiated Emissions Measurement ...................................................................................... 15 5.6. Conducted Spurious Emissions and Band Edges Test .................................................... 23 5.8. Band-edge measurements for radiated emissions ........................................................... 25 5.9. Antenna Requirements ......................................................................................................... 28 6. L I S T O F M E A S U R I N G E Q U I P M E N T ......................................... 29 7. T E S T S E T U P P H O T O G R A P H S O F E U T ..................................... 30 8. E X T E R I O R P H O T O G R A P H S O F E U T ........................................ 30 9. I N T E R I O R P H O T O G R A P H S O F E U T ........................................ 30 Report No.: TZ0035260550FRF12 Page 4 of 30 1. G E N E R A L I N F O R M A T I O N 1.1. Client Information Applicant : SHANTOU KAISHENGFENG TOYS CO., LTD. Address : 6B, WEST MEIXIN AVENUE, FEN…

Text truncated - open the document above for the full version.

深圳市利信辉电子有限公司 Shenzhen Lixinhui Electronics Co., Ltd. 天线规格承认书 Antenna Specification for Approval 客户名称 Customer Name： XX电子 产品名称： Product Name： 2.4G天线 全长35mm白色 客户型号： Product Name: 产品料号： Part NO.: C10-35-2.5 制 表： Write By： 周 敏 日 期：Issued Date: 2019-08-05 地址：深圳市宝安区福永街道凤凰凤业１路３号 Address：No. 3, Fenghuang Fengye 1st Road, Fuyong Subdistrict, Bao'an District, Shenzhen City 工程R&D Dept 采购Business Dept 承认 Approved By 利 信 辉 Product Specification A.Electrical Characteristics Frequency 2400MHz ~2500MHz VSWR <3.0 Efficiency >30% Impedance 50 Ohm Polarization Line Gain 0.17dBi B.Material & Mechanical Characteristics Material of Radiator Cu Cable Type 1.0 19P Connector Type : NO Dimension C.Environmental Operation Temperature - 30 °C ~ + 80 °C Storage Temperature - 30 °C ~ + 85 °C Test Equipment & Conditions 1． Network Analyzers : Agilent 8753D 5071B 2． Communications Test Set: Agilent E5515C 3． 3D Chamber Test System Effiency &Gain Effiency &Gain 2.40 -0.00 2.440 0.12 2.48 0.17 Radiation Pattern:

Report No.: TZ0035260550PH01 Page 1 of 2 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz Report No.: TZ0035260550PH01 Page 2 of 2 RF Conducted Test
