2ART9-ELLIQ3P0SElliQ

Hey there, I can't wait to finally meet you! ElliQ User Manual Let's get started. ElliQ User Manual Table of Contents Safety Information.......................................................6 Introduction................................................................10 Getting Started...........................................................12 Set Up..........................................................................16 Connect to WiFi...........................................................18 Communicating with ElliQ.........................................20 What Can ElliQ Do?.....................................................26 Troubleshooting.........................................................34 FAQs.............................................................................36 © Intuition Robotics, Printed January 2024. ElliQ User Manual 76 Safety Information Safety Information Warning Before using ElliQ, please read all the safety information provided below and retain documentation for future reference. Failure to comply with these safety guidelines may cause fire, electric shock, or other injuries. Treatment Treat ElliQ with caution. The product is made of plastic and glass and includes sensitive built-in electrical components. Place your ElliQ on a stable work surface that allows sufficient airflow. ElliQ may be damaged if it falls, burns, perforates, or if it comes into contact with liquids, oils, or lotions. Do not use a damaged ElliQ – for example, with a cracked screen – as this may cause injury. Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. Recommended use, storage, and transportation temperature of ElliQ is 50 to 95°F. Power ElliQ must only be connected to the power socket by the power cord that came with the product. Other power supplies may not comply with the required safety regulations. Using such power supplies can put the user at risk of injury and even death. Using damaged power supplies or cables, can cause fire, shock, or injury to the user, or damage ElliQ or other property. When using the power cord included in the package to power your ElliQ, make sure that the charging cable is fully inserted into the device before plugging the power supply into an electrical outlet. To reduce the chances of overheating or heat-related injuries, always maintain proper ventilation around your ElliQ and its power supply and be careful when you turn them on. Exposure to fluids Keep your ElliQ and power cable away from liquid sources, such as beverages, oils, creams, sinks, baths, showers, etc. Technical Specs Model number: ElliQ 3.0S Input Power: 12V DC 5A Working Temperature: 50 to 95°F (10 to 35°C) Working Altitude: not more than 6,500 ft. ElliQ User Manual 98 Safety Information FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 8 inches between the radiator and your body. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a separate circuit from the one to which the receiver is linked. • Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Company Name: Intuition Robotics Address: 2345 Yale St. Palo Alto, CA 94306 Phone number: (844) 944-3554 RF exposure statement This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and operated with a minimum distance of 8 inches between the radiator and any part of your body. Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5 de la norme RSS-102. Il doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et toute partie de votre corps. IC WARNING This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le bro…

Text truncated - open the document above for the full version.

Reference No.: WTX23X10233365W001/002/003/004/005 Page 2 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Reference No.: WTX23X10233365W001/002/003/004/005 Page 3 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 3 EUT View 4 Reference No.: WTX23X10233365W001/002/003/004/005 Page 4 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 5 EUT View 6 Reference No.: WTX23X10233365W001/002/003/004/005 Page 5 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT View 7

Reference No.: WTX23X10233365W001/002/003/004/005 Page 1 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn ANNEX EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: The label shall be securely affixed to a permanently attached part of the device, in a location where it is visible or easily accessible to the user, and shall not be readily detachable. The label shall be sufficiently durable to remain fully legible and intact on the device in all normal conditions of use throughout the device’s expected lifetime. Proposed Label Location on EUT FCC ID Label Location

Reference No.: WTX23X10233365W001/002/003/004/005 Page 6 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 Reference No.: WTX23X10233365W001/002/003/004/005 Page 7 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 3 EUT Housing and Board View 4 Reference No.: WTX23X10233365W001/002/003/004/005 Page 8 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn EUT Housing and Board View 5 Solder Board-Component View 1 Reference No.: WTX23X10233365W001/002/003/004/005 Page 9 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 2 Solder Board-Component View 3 Reference No.: WTX23X10233365W001/002/003/004/005 Page 10 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 4 Solder Board-Component View 5 Reference No.: WTX23X10233365W001/002/003/004/005 Page 11 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 6 Solder Board-Component View 7 Reference No.: WTX23X10233365W001/002/003/004/005 Page 12 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 8 Solder Board-Component View 9

Reference No.: WTX23X10233365W001/002/003/004/005 Page 13 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 10 Solder Board-Component View 11 Reference No.: WTX23X10233365W001/002/003/004/005 Page 14 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 12 Solder Board-Component View 13 Reference No.: WTX23X10233365W001/002/003/004/005 Page 15 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 14 Solder Board-Component View 15 Reference No.: WTX23X10233365W001/002/003/004/005 Page 16 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Solder Board-Component View 16 Solder Board-Component View 17 Reference No.: WTX23X10233365W001/002/003/004/005 Page 17 of 20 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Antenna View WIFI/BT Antenna

1. RF Exposure Requirements 1.1 General Information Client Information Applicant: Intuition Robotics Address of applicant: Hayezira 3 St. Ramat-Gan, Israel Manufacturer: Intuition Robotics Address of manufacturer: Hayezira 3 St. Ramat-Gan, Israel General Description of EUT: Product Name: ElliQ Trade Name: ElliQ Model No.: ElliQ 3.0S Adding Model(s): / Rated Voltage: DC12V Battery Capacity: / Power Adapter: MOEDLl:NBS65A120500M3 INPUT:AC100-240V~ 50/60Hz, 1.5A OUTPUT:DC12V,5A FCC ID: 2ART9-ELLIQ3P0S Equipment Type: Mobile device Technical Characteristics of EUT: Bluetooth(BLE mode) Bluetooth Version: V5.0 (BLE mode) Frequency Range: 2402-2480MHz RF Output Power: 7.85dBm (Conducted) Data Rate: 1Mbps Modulation: GFSK Quantity of Channels: 40 Channel Separation: 2MHz Type of Antenna: FPC Antenna Antenna Gain: 2.19dBi Bluetooth(BR/EDR mode) Bluetooth Version: V5.0 (BR/EDR mode) Frequency Range: 2402-2480MHz RF Output Power: 11.80dBm (Conducted) Data Rate: 1Mbps, 2Mbps, 3Mbps Modulation: GFSK, π/4 DQPSK, 8DPSK Quantity of Channels: 79 Channel Separation: 1MHz Type of Antenna: FPC Antenna Antenna Gain: 2.19dBi Wi-Fi(2.4G) Support Standards: 802.11b, 802.11g, 802.11n Frequency Range: 2412-2462MHz for 802.11b/g/n(HT20) 2422-2452MHz for 802.11n(HT40) RF Output Power: 19.16dBm (Conducted) Type of Modulation: CCK, OFDM, QPSK, BPSK, 16QAM, 64QAM Quantity of Channels: 11 for 802.11b/g/n(HT20); 7 for 802.11n(HT40) Channel Separation: 5MHz Type of Antenna: FPC Antenna Antenna Gain: 2.19dBi Wi-Fi(5G) Support Standards: 802.11a, 802.11n(HT20), 802.11n-HT40, 802.11ac-VHT20, 802.11ac-VHT40,802.11ac-VHT80 Frequency Range: 5180-5240MHz, 5260-5320MHz 5500-5700MHz, 5745-5825MHz Max. RF Output Power: 15.51dBm (Conducted) Type of Modulation: QPSK, 16QAM, 64QAM,256QAM Type of Antenna: FPC Antenna Antenna Gain: 2.97dBi 1.2 RF Exposure Exemption According to §1.1307(b)(3) and KDB 447498 D04 Interim General RF Exposure Guidance v01, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Option A: FCC Rule Part 1.1307 (b)(3)(i)(A):The available maximum time-averaged power is no more than 1mW, regardless of separation distance. Option B: FCC Rule Part 1.1307 (b)(3)(i)(B): The available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold P th (mW) described in the following formula. P th is given by: Option C: FCC Rule Part 1.1307 (b)(3)(i)(C): The minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. R must be at least λ/2π, where λ is the free-space operating wavelength in meters. Single RF Sources Subject to Routine Environmental Evaluation RF Source frequency (MHz) Threshold ERP (watts) 0.3-1.34 1,920 R 2 1.34-30 3,450 R 2 /f 2 30-300 3.83 R 2 300-1,500 0.0128 R 2 f 1,500-100,000 19.2R 2 For Multiple RF sources: FCC Rule Part 1.1307(b)(3)(ii): (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averaging period, in which case they may be treated as a single source (separation is not required). (B) In the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation. 1.3 Calculated Result Radio Access Technology Prediction Frequency Output Power Antenna Gain Duty Cycle Tune-Up Time-Averaged Power ERP (MHz) (dBm) (dBi) (%) (dBm) (dBm) Bluetooth 2402 11.80 2.19 100 12.00 12.04 Wi-Fi(2.4G) 2412 19.16 2.19 100 20.00 20.04 Wi-Fi(5G) 5180 15.51 2.97 100 16.00 16.82 Frequency Option Min. Distance Max. Power Exposure Limit Ratio Result (MHz) (cm) (dBm) (mW) (mW) Pass/Fail 2402 C 20.00 12.04 16.00 768.00 0.02 Pass 2412 C 20.00 20.04 100.93 768.00 0.13 Pass 5180 C 20.00 16.82 48.08 768.00 0.06 Pass Note: 1. Time-Averaged Power=Output Power * Duty Cycle; ERP= Time-Averaged Power+ Antenna gain-2.15dB 2. Option A, B and C refers as clause 1.2. 3. For option B, Max (time-averaged power, effective radiated power (ERP)) converts to Max. Power. For option C, ERP converts to Max. Power; 4. For option B, P th (mW) converts to Exposure Limit (mW); For option C, ERP (W) converts to Exposure Limit (mW). 5. Ratio= Tune-Up ERP (mW)/ Exposure Limit (mW) Mode for Simultaneous Multi-band Transmission: Radio Access Technology Ratio 1 Ratio 2 Simultaneous Ratio Limit Result Pass/Fail -- -- -- -- -- -- Note: BT and Wi-Fi can’t transmit at the same time. Result: Pass

深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 1 承 认 书 SPECIFICATION FOR APPROVAL 客户名称 CUSTOMER NAME: 创维电器（Skyworth Electric Appliances） 产品名称 PRODUCT NAME: E8天线（E8 antenna） 客户料号 CUSTOMER P/N: MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKED BY: Yan peihao APPROVED BY: Fen juan DATE: 2023.12.1 地址:深圳市宝安区28区大宝路金富来大厦A座401-407 Address: Room 401-407, Building A, Jinfulai Building, Dabao Road, District 28, Bao'an District, Shenzhen 电话telephone: 0755-27728733 传真fax: 0755-27805416 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 2 Contents Item Description 1. .............................................测试仪器及环境(Testing instruments and environment) 2. ........................................................................... 匹配电路(matching circuit) 3. ............................................................................整机图片(Whole machine image) 4. ......................................................................环境处理(environmental treatment) 5. ........................................................................天线 S11，ReturnLoss，Smith圆图 (Environmental processing antenna S11, ReturnLoss, Smith circle diagram 6. .................................................................................天线增益(Antenna gain) 7. .......................................................................有源测试数据(Active testing data) 8. .........................................................................................苹果图(Apple chart) 9. ..............................................................................线样图(Line sample diagram) 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 3 1 . 测试仪器及环境: CTIA 743暗室，8960/5515C，手机背向放置 离标准 喇叭天线4米转台处 1 Testing instrument and environment: CTIA 743 darkroom, 8960/5515C, with the phone placed backwards at a turntable 4 meters away from the standard speaker antenna 2、匹配电路matching circuit 匹配电路有更改。 Matching circuit has been modified 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 5 5. 天线 S11，ReturnLoss，Smith圆图 Antenna S11, ReturnLoss, Smith Circle Diagram 6.天线增益Antenna gain 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 6 7.有源测试数据Active testing data 天线类型Antenna type 天线材质：FPC天线 天线类型：PIFA Antenna material: FPC Antenna type: PIFA 8.苹果图Apple chart 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 7 深圳通诚无限科技有限公司 Shenzhen Tongcheng infinite Technology Co., Ltd 2023-12-8 17:25:35 8 9.线样图Line sample diagram

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 64 TEST REPORT Reference No. ....................: WTX23X10233365W004 FCC ID ............................... .: 2ART9-ELLIQ3P0S Applicant .......................... .: Intuition Robotics Address ............................ .: Hayezira 3 St. Ramat-Gan, Israel Manufacturer .................... .: The same as Applicant Address ............................ .: The same as Applicant Product Name .................. .: ElliQ Model No... ........................ .: ElliQ 3.0S Standards ......................... .: FCC Part 15.247 Date of Receipt sample ... .: 2023-10-31 Date of Test....................... .: 2023-10-31 to 2023-11-28 Date of Issue .................... .: 2023-11-28 Test Report Form No. ...... . : WTX_Part 15_247W Test Result ........................ .: Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Mike Shi Silin Chen Reference No.: WTX23X10233365W004 Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 64 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................... 5 1.2 TEST STANDARDS ................................................................................................................................................. 6 1.3 TEST METHODOLOGY ........................................................................................................................................... 6 1.4 TEST FACILITY ...................................................................................................................................................... 6 1.5 EUT SETUP AND TEST MODE .............................................................................................................................. 7 1.6 MEASUREMENT UNCERTAINTY ............................................................................................................................. 9 1.7 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................. 10 2. SUMMARY OF TEST RESULTS ......................................................................................................................... 13 3. ANTENNA REQUIREMENT ................................................................................................................................. 14 3.1 STANDARD APPLICABLE ..................................................................................................................................... 14 3.2 EVALUATION INFORMATION ................................................................................................................................ 14 4. FREQUENCY HOPPING SYSTEM REQUIREMENTS .................................................................................... 15 4.1 STANDARD APPLICABLE ..................................................................................................................................... 15 4.2 FREQUENCY HOPPING SYSTEM ......................................................................................................................... 15 4.3 EUT PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ............................................................................... 16 5. QUANTITY OF HOPPING CHANNELS AND CHANNEL SEPARATION .................................................... 17 5.1 STANDARD APPLICABLE ..................................................................................................................................... 17 5.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 17 5.3 TEST PROCEDURE .............................................................................................................................................. 17 5.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 18 6. DWELL TIME OF HOPPING CHANNEL ........................................................................................................... 19 6.1 STANDARD APPLICABLE ..................................................................................................................................... 19 6.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................................... 19 6.3 TEST PROCEDURE .............................................................................................................................................. 19 6.4 SUMMARY OF TEST RESULTS/PLOTS ................................................................................................................. 20 7. 20DB BANDWIDTH ............................................................................................................................................... 21 7.1 STANDARD APPLICABLE ..................................................................................................................................... 21 7.2 TEST SETUP BLOCK DIAGRAM .........................................................................................…
