2ARTZ-860AAction Camera

MAINTENANCE Underwater Usage Notes This camera are splash, water, and dust resistant and were tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of 10 meters up to 30 minutes). Splash, water, and dust resistance are not permanent conditions and resistance might decrease as a result of normal wear. In order to ensure the waterproof performance of the camera, please carefully refer to the operation and maintenance precautions as following. The machine is not waterproof due to improper operation and improper maintenance, which is not covered by the warranty. 1. Make sure to check whether the silicone pads on the waterproof cover is clean before using underwater. Otherwise it will affect the camera's waterproof ability, and a single hair or sand will cause leakage! 2. Make sure to check whether the silicone pad on the battery waterproof cover is intact,Damage to the silicone pad will cause water leakage! 3. Make sure that the battery waterproof cover is tightly closed before using underwater. If not,the camera will not be waterproof. 4. Avoid jumping into water a high speed with camera. Otherwise, the impact may result in water water leakage. 5. DO NOT use the camera in a hot spring or expose the product directly to high temperatures over 40°C. High temperature may cause deformation of the waterproof seal on the camera body and lose its waterproof function. 6. Keep it safe from falling and dropping. Falling and drop will cause damage to the watertight seal on the camera body and the camera is not waterproof. 7. The microphone and speaker's hole on the camera has built in waterproof material. DO NOT remove the waterproof material or poke the holes.Otherwise, the camera will no longer be waterproof. 8. Clean the camera with clean water after using underwater. Allow it to dry naturally before using again. 9. This camera is not waterproof unless the battery cover are closed. CAUTIONS  This is a 4K action camera, It is normal for the housing to exert heat under use.  Don’t expose the product directly to high temperatures over 45 °C.  Please properly protect well the lens and screen of camera after using.  Keep it safe from falling and dropping.  Keep it distance from any strong magnetic interference objects like electrical machine to avoid strong radio waves that might be damaging the product and affect the sound or image quality.  In case of overheating, unwanted smoke from the device, unplug it immediately from the power outlet to prevent hazardous fire.  Keep it safety from children while on charging.  Stored the device in a cool, dry and dust free location.  Do not modify the camera it in any way,if the camera has been detached,the warranty will be void. OVERVIEW OF CAMERA The camera is an all-weather action camera, equipped with 6-axis gyroscope EIS technology, which can take clear 20MP photos and capture stable videos at 4k/60fps. This camera adopting watertight seal and a hydrophobic coating on the camera body, which can reach IP68 waterproof level. This action camera is weatherproof and distinct to unlock all the filming scenarios and ease your vlogging experience. Its IPX8 water-resistant design can protect the action camera from rain, snow and water splashing. 1. Lens 2. Speaker 3. Internal Microphone 4. Shutter Button / Select Button 5. Front Screen 6. Battery Waterproof Cover 7. Indicator 8. Power Button / Mode Button 9. Touch Screen  Button Operation Instructions  Power Button / Mode Button: Press and hold seconds to power on/off. Press shortly to switch between Video Mode and Photo Mode.  Shutter Button: Press shortly to start/stop recording video. Press shortly to shoot photos. Press and hold seconds to switch between front and rear screens. Notes:  You can't switch screens during recording or in Setting Mode.  Front and rear screens cannot work at the same time. GETTING STARTED Welcome to your new camera. To capture video and photos, you need a micro SD card (sold separately).  STORAGE/MICRO CARDS We strongly recommend to use the branded memory cards purchased from regular channels for maximum reliability and stability during recording and in high vibration activities. • UHS-III rating at least for 4K Video resolution (at least 60MB/S or above read and writing speed) • Capacity up to 128GB (FAT32) The bigger memory may have an effect on the compatibility with the camera. Notes:  Please format the micro SD,micro SDHC and micro SDXC memory card on the camera before using.  Please insert the memory card in correct way . if not , the card slot maybe damage by the wrong way.  To keep your micro SD card in good condition, reformat it on a regular basis.  Reformatting erases all of your content, so be sure to offload your photos and videos first.  Don’t place your Micro SD card near strong magnetic objects to avoid data error or loss.  FAT32 format memory card stops recording when the storage of each file is over 4GB and starts to record again on a new file.  POWERING ON+ OFF  To Power On: Press and hold the Power button for seconds. The camera beeps while the camera status light is on. When information appears on the LCD display or the camera status screen, your camera is on.  To Power Off: Press and hold the Mode button for three seconds. OVERVIEW OF SHOOTING MODES There are 6 shooting modes: Video Mode, Photo Mode, Burst Photo Mode, Time Lapse Video Mode,Time Lapse Photo Mode and Prerecord Mode.  Video Mode Video Mode is the default mode when you turn on the camera. In Video Mode,press Shutter button, the camera start recording video,press Shutter button again to stop recording video.  Photo Mode Press Mode button once to switch to Photo Mode after you turn on camera. In Photo Mode, press Shutter button, the camera takes a photo. In Video Mode or Photo Mode, quickly slide from right to left or slide from left to right on the touch screen to switch between Video Mode and Photo Mode.  Burst Photo Mode Bu…

Text truncated - open the document above for the full version.

DLKElectronicLimited 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:DLKElectronicLimited Address:Floor5,B4Building,FenghuanggangThirdIndustrialPark,Xixiang,Baoan District,Shenzhen,China ProductName:ActionCamera FCCID:2ARTZ-860A Model(s):860A,860Q,860M,860A,860X,860N,860D,860L,860K,880Q,880M,880A,880X, 880N,880D,880L,880K 2.911(d)(5)(i)EquipmentType We,DLKElectronicLimited(“theapplicant”)certifythattheequipmentforwhichauthorizationis soughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:JasonChanDate:2023.11.02 TitleandCompanyname:N/A/DLKElectronicLimited NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

DLKElectronicLimited 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:DLKElectronicLimited Address:Floor5,B4Building,FenghuanggangThirdIndustrialPark,Xixiang,Baoan District,Shenzhen,China ProductName:ActionCamera FCCID:2ARTZ-860A Model(s):860A,860Q,860M,860A,860X,860N,860D,860L,860K,880Q,880M,880A,880X, 880N,880D,880L,880K 2.911(d)(5)(ii)Applicantfiling We,DLKElectronicLimited(“theapplicant”)certifythat,asofthedateofthefilingoftheapplication, theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,establishedpursuantto§1.50002 ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:JasonChanDate:2023.11.02 TitleandCompanyname:N/A/DLKElectronicLimited NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

DLKElectronicLimited AgentAuthorization Company:DLKElectronicLimited Address:Floor5,B4Building,FenghuanggangThirdIndustrialPark,Xixiang,Baoan District,Shenzhen,China ProductName:ActionCamera ModelNumber(s):860A,860Q,860M,860A,860X,860N,860D,860L,860K,880Q, 880M,880A,880X,880N,880D,880L,880K ProductDescription:ActionCamera WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2023.11.02 Name:JasonChan Title:N/A Company:DLKElectronicLimited

DLKElectronicLimited OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2023.11.02 Subject;RequestforConfidentiality FCCID:2ARTZ-860A ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:JasonChan Title:N/A

DLKElectronicLimited ModelDifference Productdescription:ActionCamera Modelname:860A,860Q,860M,860A,860X,860N,860D,860L,860K,880Q,880M,880A, 880X,880N,880D,880L,880K TradeName:N/A Onlythemodelnameisdifferent. Regards Sincerely Client’ssignature: Client’sname/title:JasonChan/Manager Contactinformation/address:Floor5,B4Building,FenghuanggangThirdIndustrial Park,Xixiang,BaoanDistrict,ShenzhenCity,China.

EUT PHOTO(External Photos)

Label & label location 20mm*10mm FCC ID:2ARTZ-860A Label location

EUT PHOTO(Internal Photos) WIFI ANT BT ANT ※※※※※ END OF REPORT ※※※※※

FCC ID:2ARTZ-860A RF Exposure Evaluation According to KDB 447498 D01 General RF Exposure Guidance v06 and part 2.1093， Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, For 2.4G WIFI Mode Max Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit 802.11b 7.43 5.53 2462 5 1.74 3.0 802.11g 6.52 4.49 2462 5 1.41 3.0 802.11n20 5.33 3.41 2462 5 1.07 3.0 802.11n40 4.30 2.69 2452 5 0.84 3.0 For BT Mode Max Power(dBm) Max Power(mW) Frequency(MHz) Min. distance(mm) Calc. thresholds limit GFSK 3.074 2.03 2441 5 0.63 3.0 π/4-DQPSK 3.855 2.43 2441 5 0.76 3.0 8-DPSK 4.411 2.76 2441 5 0.86 3.0 Note: The 2.4G WIFI and BT are can not transmitting at the same time. So a SAR test is not required
