2ARUDTSR12.0 TCL Roku TV Wireless Soundbar

Quick Star t Guide TSR1 2.0 TCLRoku TV Wireless Soundbar 1 Register Your Product Enjoy exclusive benefits with registration: Text a photo of t he camera icon to 71403 Or register online at register.tcl.com Need help? Visit photoregister.com/help or text HELP to 71403 TCL395 Text to Register Expedited support and serviceInsider tips on your soundbar Exclusive offers and promotionsVerification of ownership *Only Available to U.S. Customers Register your TCL · Roku TV Wireless Soundbar to receive the latest news on product releases, promotional offers, and more!* 2 What's in the box Make sure you read all the safety information before you use this product. Safety instructions QSG Quick Start GuideSafety leaflet Warranty card Warranty cardWall mount template Soundbar main unit AC power cord Wall mount bracket x 2Wall bracket screw x 2Wall anchor x 2Wall mounting screw x 2 • Short press for restart. • Long press for about 10 seconds for factory reset. Soundbar main unit AC input power connector Reset button 3a Overview LED light: Indicates Product State RESET RESET AC~IN 3b Soundbar LED Light Product StateColorLED Expression Solid White Powered On Looking for Roku TV™ Setup (waiting) Booting up Ready Software Update Restart Factory Reset Setup (working) Working / Busy Blinking Blink 3 times, then solid moving to a slow blink Solid moving to a slow blink > 2" T V T V 3 2 5 6 30.4" The ideal place to position the Soundbar is centered underneath your TV. 4 Wall mount your Soundbar 4a Place your Soundbar 1 4b T V Required tools: • Place the supplied wall mount template on the wall. Make sure the wall mount template is at least 2 inches below the center of the TV. • Use a level to make sure the wall mount te mplate is positione d accurate ly . • Use the tape to stick the wall mount template firmly on the wall. • Mark on the wall using each marking on the template through the mounting holes. • Take away the wall mount template. • Drill a screw hole at each marking on the wall . we also recommend moving the Soundbar as close to the edge of the stand as possible, for better sound. • Unscrew the screws from the back of the soundbar and set them aside for potential use in the future. 4b 789 Wall mount your Soundbar Required tools: • Insert the supplied wall anchors into 2 screw holes on the wall. • Insert the supplied wall bracket screws through the wall brackets into the wall anchors. • Fix and tighten the wall bracket screws on the wall. Required tools: • 10 11 Tighten the supplied wall mounting screws into the screw holes in the back of the Soundbar main unit. Wall mount your Soundbar • Hang the Soundbar main unit on the wall mount brackets. 4b 12 12 • Power up your Soundbar. • Press and hold on your Roku remote for 5 seconds to open the setup menu. 5 Connect to your Roku TV What you’ll need: Let’s get started: 1 • Roku TV connected to the internet. • Your Roku TV remote. T V T V 2 AC IN RESET • Follow the on-screen setup. Choose Wireless soundbar and select Continue to begin the pairing process. 5 Connect to Your TV 3 T V TCL · Roku TV | Searching for devices Searching for wireless soundbar TCL · Roku TV | Updating soundbar Updating soundbar TCL · Roku TV | Fast TV Start TCL · Roku TV | Select all devices to set up Continue Continue Remote Wireless soundbar Subwoofer Wireless speakers 0% Fast TV Start has been enabled on your TV! With Fast TV Start, even if your display is off you can: ·Listen to music ·Use voice commands to wake up your TV ·Stream via Bluettoth When you see the Bluetooth pairing screen, go to your smartphone, tablet, or computer and follow the next several steps. Select Settings, followed by Remotes & devices. • Press the Home button on your Roku remote. You can stream music from your mobile device via Bluetooth. • Select Pair Bluetooth device. 6 Pair with your Bluetooth device • • • > Select your Roku device from the list of available devices > Wait a moment for your Bluetooth device to scan for devices and discover your Roku TV. > Pairing is successful. Make sure your ROKU Wireless Sound Bar is connected to your TV before you start. (refer to 5) Once it's been paired, you can reconnect any time by choosing the Roku TV from the list of Bluetooth devices on your smart phone, tablet, etc. A Bluetooth device (phone, tablet, etc.) only needs to follow the pairing process once. Open Bluetooth settings on your smartphone, tablet, or computer. Roku TV Search Streaming Channels Settings Roku | Remotes & devices Bluetooth devices Setup Set up a new device Pair Bluetooth device Remotes Roku | Remotes & devices Bluetooth devicesMy phone(Connected) Setup Set up a new device Pair Bluetooth device Remotes Bluetooth BLUETOOTH OTHER NETWORK Roku TV T V Searching Roku | Bluetooth pairing To pair a Bluetooth device with your Roku TV: 1. Go to your device's Bluetooth settings 2. Select 'Roku TV' to pair FAQ All technology names mentioned are the trademarks or registered trademarks of their respective companies. • Press the Home button on your Roku remote. • Settings > System > Power. • Follow the on-screen setup to turn off Standby LED. How to turn off the LED light of Sound Bar on your Roku TV? • While streaming video or music, press . • Select Sound Settings. • Turn on the settings you want. How to use sound settings? Does this Soundbar work with any TV? No, the Soundbar and other Roku wireless devices are mutually exclusive. No, the Soundbar is only compatible with Roku TV. Does this Soundbar work with other Roku wireless devices at the same time? TSR1_NA_USA_QSG_V0.7 Copyright © 2021 TCL. All rights reserved. support.tclusa.com support.tclcanada.com or Roku and Roku TV are the trademarks or registered trademarks of Roku, Inc. English The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The e…

Text truncated - open the document above for the full version.

TCL Entertainment Solutions Limited I, the signer, Ada shi The difference between the following products just lies in the model , the other is the same. Product name :2.0 TCL·Roku TV Wireless Soundbar FCC ID: 2ARUDTSR1 Model Number: TSR1 Additional Model: TS120,TS1204,TDS1204,TS1204K, TDS1204K.FS1204,OS1204,AltoR1,Alto R, ***1204, TS7204,TS720,TDS7204,TS7204K,TDS7204K.FS7204,OS7204,AltoR7,*** 7204 (“*” can be any alphanumeric character including blank for marketing differences) Signature: Name:Ada shi Title: engineer Company: TCL Entertainment Solutions Limited

1/1 Co m Add scie Prod Mod TSR TDS *** 4,Al (“*” diffe FCC We a 0819 abov Any beha We d Carm relat to d carri same Na m Title Si gn mpany:TC dress: 7/F ence park, duct Nam del Numb R1,TS120, S1204K.FS 1204, TS ltoR7,*** ” can be a erences) C Identifie authorize L 93 Bellater ve named e individual alf and tak declare tha me, s/n, 0 ted to the discuss any ied out by e effect as me:Ada shi e: Enginee nature of L Enterta F, buildin , SHATIN, me:2.0 TCL er: ,TS1204,T S1204,OS 7204,TS7 *7204 any alpha er:2ARUD LGAI Tech rra, Spain, equipment within LGA ke action on at authoriz 08193 Bel approval p y issues c y LGAI Te s acts of ou i er applican t Letter o ainment S ng 22E, 2 , N.T. ,Ho L·Roku TV TDS1204, S1204,Alt 720,TDS7 anumeric DTSR1 nolo gical C , to act o t. AI Technol n the appli ze LGAI Te laterra, Sp project to concerning echnologica ur own. t: of Auth Solutions 22 science ong Kong V Wireles ,TS1204K oR1,Alto 204,TS72 character Center S.A on our beh logical Cen cation. echnologica pain, is a the Feder the app r al Center S horizati Limited e park ea china ss Soundb K, R, 204K,TDS r includin ., Ronda d half on all nter S.A. is al Center S llowed to al Commu oval appli c S.A. on ou Date:7/ C ion ast avenu bar S7204K.FS ng blank f de la Font d matters c s authorize S.A., Ronda forward nication C cation. An ur behalf /28/2021 C5266091_X8 ueHong K S7204,OS for marke del Carme, concerning d to act on a de la Fon all inform ommissio n ny and all shall hav e 8_Ed.1 Kong S720 eting , s/n, g the n our nt del ation n and acts e the

1/1 Offic Fed e 7435 Colum Date Subj e FCC To W Purs u (47C attac Abo v cons discl o comp It is corr e docu equip Sinc e Signa Nam Title: e of Engine eral Commu 5 Oakland M mbia, MD 2 : 7/28/2021 ect: Reques ID: 2ARUDT Whom It May uant to th CFR0.457, 0 chment(s) a ve mentione idered as osure of ab petitor an u our under s espondent d uments and pment auth erely, ature: e:Adashi : Engineer T eering Techn nications Co Mills Road 21046 1 st for Confid TSR1 y Concern, he provisio 0.459), we as confident Exhibits ID Label/Loca Attestation St External Photo Block Diagram Schematics Test Report Test Setup Ph User’s Manua Internal Photo Parts List / Tu RF Exposure I Operational D Cover Letter(s SDR Software ed docume proprietar y bove docum nfair advan standing th during cert those infor orization is TCL Entertai nology ommission dentiality ns of Sec t are reques tial docume ation tatement os m hotos l os une Up Info Description s) e / Security Inf nt contains y informatio ments migh ntage in the hat all mea tification rev rmation wil issued. nment Sol u tions 0.457 sting the C nt from pub Lon Co n fo s detailed s on in oper ht be harm market. surement t view proce l be availab utions Limite 7 and 0.4 Commission blic disclosu g-Term nfidentiality S C No No No No No No system and ration of th mful to our test reports ess cannot ble for publ C5 ed 59 of Co m to withho ure. Short-Term Confidentiality No No No No No equipment he equipm company s, FCC ID la be granted ic review o 266091_X10 mmission's old the follo y t descriptio ent. The p and would abel format d as confid nce the gr a 0_Ed.1 rules owing n are public give t and ential ant of

1/1 Date Fede Auth 7435 Colu Attn Prod TSR TDS *** 4,Al (“*” diffe Re ga “All radio set b softw the t We pro g been Si gn Nam Title: FC e: 7/28/202 eral Comm horization a 5 Oakland umbia, MD : OET D e duct/ Mod R1,TS120, S1204K.FS 1204, TS ltoR7,*** ” can be a erences) arding FCC application o paramet by software ware, or co technical r declare th gram the d n certified. ature of a p e:Adashi : Engineer T CC Softw 21 unications and Evalua Mills Road 21046 ept. del Numb ,TS1204,T S1204,OS 7204,TS7 *7204 any alpha C Country C ns for equ ers, or oth e must hav onfiguratio ules under at no third device out pplicant： TCL Entertai ware Confi Commissi ation Divisio ber: TDS1204, S1204,Alt 720,TDS7 anumeric Code Selec uipment a her technic ve an attes on control, r which it h d party wi of compli a nment Solu iguration on on ,TS1204K oR1,Alto 204,TS7 2 character ction guide authorizatio cal parame station ind to progra has been ce ll have sof ance of the utions Limite Control D K, R, 204K,TDS r includin elines ident on for tra eters, repo dicating tha am the dev ertified.” ftware, or e technical C5 ed Declaratio S7204K.FS ng blank f tified in KD nsmitters orted to th at no third vice out of configurat rules und 266091_X13 on S7204,OS for marke DB 594280. that can he Commi party will f complianc tion contro er which it 3_Ed.1 S720 eting . have ssion have ce of ol, to t has

External Photos M/N: TSR1 External Photos M/N: TSR1 External Photos M/N: TSR1 External Photos M/N: TSR1

变量，直接打印 字体：Arial Regular 大小：6pt 变量 BSSYYWWCRXXXX 编码规则如下： 共13位 条码类型：CODE 128 B = Brand code, 品牌码 (T=TCL, O=Onkyo) SS = Supplier Code, 供应商代码（CM=CMT MI=Minami VT=Vtrek RS=RSR SK=Sky dragon TL=Tonly） YY = Calendar Year , 生产年代码 (21 = 2021, 22 = 2022...etc.) WW = Calendar Week, 生产周代码 (1 = 1周，2 = 2周...etc) C=Version change code，版本变更代码，由0开始，当流水码超过9999，依次变为1,2,3... R = Reserve code，走向代码 R = 1, 对于北美NA区，此代码固定为1 R = 2, 对于欧洲EU区，此代码固定为2 R = 3, 对于澳洲AU区，此代码固定为3 R = 4, 对于巴西BR区，此代码固定为4 R = 5, 对于全球版GL，此代码固定为5 XXXX = Running number, 流水码 (由 0001 – 9999) 。 流水码每周归零一次。同一生产商针对相同区域走向但不同型号的产品，同一周内流水码 按 0001 – 9999顺序依次生成，例： 若同一周内生产3000张TS6110贴纸和1000张TS7010贴纸，则TS6110流水码由0001到3000跳变， TS7010流水码由3001到4000跳变。 BSSYYWWCRXXXX This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3(B)/NMB-3(B). TSR1 2.0 TCL·Roku TV Wireless Soundbar Power Supply: 100-240V~ 50/60Hz Model No.: TSR1 Power Consumption: 30W FCC ID: 2ARUDTSR1IC: 24579-TSR1 TCL North America 1860 Compton Ave, Corona, CA 92881, USA Made in China / Fabriqué en Chine BSSYYWWCRXXXX Press the button RESET at the back of the Soundbar for restart. Press and hold the button RESET for about 10 seconds for factory reset. This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3(B)/NMB-3(B). ATTENTION: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR 贴纸粘贴位置 TSR1 2.0 TCL·Roku TV Wireless Soundbar Power Supply: 100-240V~ 50/60Hz Model No.: TSR1 Power Consumption: 30W FCC ID: 2ARUDTSR1IC: 24579-TSR1 TCL North America 1860 Compton Ave, Corona, CA 92881, USA Made in China / Fabriqué en Chine BSSYYWWCRXXXX Press the button RESET at the back of the Soundbar for restart. Press and hold the button RESET for about 10 seconds for factory reset. This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3(B)/NMB-3(B). ATTENTION: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR

Internal Photos M/N: TSR1 Internal Photos M/N: TSR1 Internal Photos M/N: TSR1 Internal Photos M/N: TSR1 Internal Photos M/N: TSR1 Internal Photos M/N: TSR1 Internal Photos M/N: TSR1

FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 1 of 8 FCC 47 CFR MPE REPORT TCL Entertainment Solutions Limited 2.0 TCL• Roku TV Wireless Soundbar Model Number: TSR1 Additional Model: TS120, TS1204, TDS1204, TS1204K, TDS1204K, FS1204, OS1204, AltoR1, Alto R, ***1204, TS7204, TS720, TDS7204, TS7204K, TDS7204K, FS7204, OS7204, AltoR7, ***7204 (“*” can be any alphanumeric character including blank for marketing differences) FCC ID: 2ARUDTSR1 Prepared for: TCL Entertainment Solutions Limited 7/F, building 22E, 22 science park east avenue Hong Kong science park, SHATIN, N.T. ,Hong Kong China. Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2107155 Date of Test: Jun. 04~Jul. 27, 2021 Date of Report: Jul. 28, 2021 FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 2 of 8 Maximum Permissible Exposure 1. Applicable Standards Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. 1.1. Limits for Maximum Permissible Exposure (MPE) (a) Limits for Occupational/Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-10000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 ,︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-10000 1.o 30 Note: f=frequency in MHz; *Plane-wave equivalent power density FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 3 of 8 1.2. MPE Calculation Method E (V/m) = d G×P×30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d×377 G×P×30 From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 4 of 8 2. Conducted Power Result Bluetooth Antenna Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power (dBm) Antenna gain (dBi)(Linear) GFSK 2480 4.99 3.1550 4±1 2.5 1.778 8-DPSK 2480 1.65 1.4622 1±1 2.5 1.778 BLE 2480 5.24 3.3420 5±1 2.5 1.778 WiFi Antenna 0 Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power (dBm) Antenna gain (dBi)(Linear) IEEE 802.11b 2412 19.10 81.2831 19±1 2.5 1.778 IEEE 802.11g 2412 25.19 330.3695 25±1 2.5 1.778 IEEE 802.11n HT20 2412 24.77 299.9163 24 ±1 2.5 1.778 IEEE 802.11n HT40 2422 25.27 336.5116 25 ±1 2.5 1.778 IEEE 802.11a 5240 13.11 20.4644 13±1 4.11 2.576 IEEE 802.11n HT20 5240 14.96 31.3329 14 ±1 4.11 2.576 IEEE 802.11ac VHT20 5240 14.72 29.6483 14 ±1 4.11 2.576 IEEE 802.11n HT40 5755 14.75 30.4089 14 ±1 4.11 2.576 IEEE 802.11ac VHT40 5755 14.74 24.8886 14 ±1 4.11 2.576 IEEE 802.11ac VHT80 5210 14.97 30.4089 14 ±1 4.11 2.576 FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 5 of 8 WiFi Antenna 1 Mode Frequency (MHz) Peak output power (dBm) Peak output power (mW) Target power (dBm) Antenna gain (dBi)(Linear) IEEE 802.11b 2412 19.01 79.6159 19±1 2.5 1.778 IEEE 802.11g 2412 25.50 354.8134 25±1 2.5 1.778 IEEE 802.11n HT20 2412 24.58 287.0781 24 ±1 2.5 1.778 IEEE 802.11n HT40 2422 24.96 313.3286 24 ±1 2.5 1.778 IEEE 802.11a 5745 13.94 24.7742 13±1 4.11 2.576 IEEE 802.11n HT20 5745 15.88 36.3915 15 ±1 4.11 2.576 IEEE 802.11ac VHT20 5745 15.60 36.3078 15 ±1 4.11 2.576 IEEE 802.11n HT40 5755 16.00 40.0867 16 ±1 4.11 2.576 IEEE 802.11ac VHT40 5755 16.01 39.9945 16 ±1 4.11 2.576 IEEE 802.11ac VHT80 5775 15.87 38.9942 15 ±1 4.11 2.576 FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 6 of 8 Calculated Result and Limit WiFi Antenna 0 Mode Target power (dBm) Antenna gain Power Density (S) (mW/cm 2 ) Limited of Power Density (S) (mW/cm 2 ) Test Result (dBi) (Linear) 2.4G Band GFSK 4.99 2.5 1.7780.0011 1 Complies 8-DPSK 1.65 2.5 1.7780.0005 1 Complies BLE 5.24 2.5 1.7780.0012 1 Complies IEEE 802.11b 19.25 2.5 1.7780.0298 1 Complies IEEE 802.11g 25.19 2.5 1.7780.1169 1 Complies IEEE 802.11n HT20 24.69 2.5 1.7780.1042 1 Complies IEEE 802.11n HT40 25.27 2.5 1.7780.1190 1 Complies 5G Band IEEE 802.11a 13.11 4.11 2.5760.0105 1 Complies IEEE 802.11n HT20 14.96 4.11 2.5760.0161 1 Complies IEEE 802.11ac VHT20 14.72 4.11 2.5760.0152 1 Complies IEEE 802.11n HT40 14.83 4.11 2.5760.0156 1 Complies IEEE 802.11ac VHT40 14.79 4.11 2.5760.0154 1 Complies IEEE 802.11ac VHT80 14.97 4.11 2.5760.0161 1 Complies FCC ID: 2ARUDTSR1 EST Technology Co. ,Ltd Report No. ESTE-R2107155 Page 7 of 8 WiFi Antenna 1 Mode Target power (dBm) Antenna gain Power Density (S) (mW/cm 2 ) Limited of Power Density (S) (mW/cm 2 ) Test Result (dBi) (Linear) 2.4G Band IEEE 802.11b 19.01 2.5 1.7780.0282 1 Complies IEEE 802.11g 25.50 2.5 1.7780.1255 1 Complies IEEE 802.11n HT20 24.58 2.5 1.7780.1016 1 Complies IEEE 802.11n HT40 24.96 2.5 1.7780.1108 1 Complies 5G Band IEEE 802.11a 13.94 4.11 2.5760.0127 1 Complies IEEE 802.11n HT20 15.61 4.11 2.5760.0187 1 Complies IEEE 802.11ac VHT20 15.60 4.11 2.5760.0186 1 Complies IEEE 802.11n HT40 16.03 4.11 2.5760.0205 1 Complies IEEE 802.11ac VHT40 16.02 4.11…

Text truncated - open the document above for the full version.

FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 1 of 119 FCC PART 15E TEST REPORT FOR CERTIFICATION On Behalf of TCL Entertainment Solutions Limited 2.0 TCL• Roku TV Wireless Soundbar Model Number: TSR1 Additional Model: TS120, TS1204, TDS1204, TS1204K, TDS1204K, FS1204, OS1204, AltoR1, Alto R, ***1204, TS7204, TS720, TDS7204, TS7204K, TDS7204K, FS7204, OS7204, AltoR7, ***7204 (“*” can be any alphanumeric character including blank for marketing differences) FCC ID: 2ARUDTSR1 Prepared for: TCL Entertainment Solutions Limited 7/F, building 22E, 22 science park east avenue Hong Kong science park, SHATIN, N.T. ,Hong Kong China. Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2107154 Date of Test: Jun. 04~Jul. 27, 2021 Date of Report: Jul. 28, 2021 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 2 of 119 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION ........................................................................................................................ 3 1. GENERAL INFORMATION ................................................................................................................. 5 1.1. Description of Device (EUT) ........................................................................................................... 5 1.2. The antenna information for EUT .................................................................................................... 6 2. SUMMARY OF TEST ......................................................................................................................... 7 2.1. Summary of test result ...................................................................................................................... 7 2.2. Test Facilities .................................................................................................................................... 8 2.3. Measurement uncertainty for EST Technology Co., Ltd. ................................................................ 9 2.4. Assistant equipment used for test ..................................................................................................... 9 2.5. Block Diagram .................................................................................................................................. 9 2.6. Test Mode ....................................................................................................................................... 10 2.7. Channel List .................................................................................................................................... 12 2.8. Power Setting of Test Software ...................................................................................................... 13 2.9. Duty Cycle of Test Signal .............................................................................................................. 14 2.10. Test Equipment List ....................................................................................................................... 18 3. 6DB BANDWIDTH &26DB BANDWIDTH & 99% OCCUPIED BANDWIDTH ..................................... 20 3.1. Limit ............................................................................................................................................... 20 3.2. Test Setup ....................................................................................................................................... 20 3.3. Spectrum Analyzer Setting ............................................................................................................. 20 3.4. Test Procedure ................................................................................................................................ 21 3.5. Test Result ...................................................................................................................................... 22 3.6. Test Result ...................................................................................................................................... 23 4. MAXIMUM CONDUCTED OUTPUT POWER ..................................................................................... 43 4.1. Limit ............................................................................................................................................... 43 4.2. Test Setup ....................................................................................................................................... 43 4.3. Test Procedure ................................................................................................................................ 43 4.4. Test Result ...................................................................................................................................... 44 5. PEAK POWER SPECTRAL DENSITY ................................................................................................ 46 5.1. Limit ............................................................................................................................................... 46 5.2. Test Setup ....................................................................................................................................... 46 5.3. Spectrum Analyzer Setting ............................................................................................................. 46 5.4. Test Procedure ................................................................................................................................ 46 5.5. Test Result ...................................................................................................................................... 47 6. UNWANTED EMISSIONS AND BAND EDGE ..................................................................................... 61 6.1. Limit ..............................…

Text truncated - open the document above for the full version.

FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 51 of 119 U-NII-1 IEEE 802.11n HT20 5200MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11n HT20 5240MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11ac VHT20 5180MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 52 of 119 U-NII-1 IEEE 802.11ac VHT20 5200MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11ac VHT20 5240MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11n HT40 5190MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 53 of 119 U-NII-1 IEEE 802.11n HT40 5230MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11ac VHT40 5190MHz ANT 1 ANT 2 U-NII-1 IEEE 802.11ac VHT40 5230MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 54 of 119 U-NII-1 IEEE 802.11ac VHT80 5210MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 55 of 119 U-NII-3 IEEE 802.11a 5745MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11a 5785MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11a 5825MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 56 of 119 U-NII-3 IEEE 802.11n HT20 5745MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 57 of 119 U-NII-3 IEEE 802.11n HT20 5785MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11n HT20 5825MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11ac VHT20 5745MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 58 of 119 U-NII-3 IEEE 802.11ac VHT20 5785MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11ac VHT20 5825MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11n HT40 5755MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 59 of 119 U-NII-3 IEEE 802.11n HT40 5795MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11ac VHT40 5755MHz ANT 1 ANT 2 U-NII-3 IEEE 802.11ac VHT40 5795MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 60 of 119 U-NII-3 IEEE 802.11ac VHT80 5775MHz ANT 1 ANT 2 FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 61 of 119 6. UNWANTED EMISSIONS AND BAND EDGE 6.1. Limit The maximum emissions outside of the frequency bands of operation shall be attenuated in accordance with the following limits: (1) For transmitters operating in the 5.15-5.25 GHz band: All emissions outside of the 5.15-5.35 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (2) For transmitters operating in the 5.25-5.35 GHz band: All emissions outside of the 5.15-5.35 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (3) For transmitters operating in the 5.47-5.725 GHz band: All emissions outside of the 5.47-5.725 GHz band shall not exceed an e.i.r.p. of −27 dBm/MHz. (4) For transmitters operating in the 5.725-5.85 GHz band:All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz above or below the band edge, and from 25 MHz above or below the band edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or below the band edge, and from 5 MHz above or below the band edge increasing linearly to a level of 27 dBm/MHz at the band edge. The unwanted emissions which fall in Restricted bands shall not exceed the field strength levels specified in the following table: 15.209 Radiated emission limits Frequency (MHz) Field Strength(μV/m) Distance(m) 0.009-0.490 2400/F(kHz) 300 0.490-1.705 24000/F(kHz) 30 1.705-30 30 30 30-88 100 3 88-216 150 3 216-960 200 3 Above 960 500 3 15.205 Restricted frequency band FCC ID: 2ARUDTSR1 EST Technology Co., Ltd Report No.ESTE-R2107154 Page 62 of 119 Note： 1. dBμV/m=20Log(μV/m) 2. Above 1GHz the formula is used to convert the EIRP to field strength E[dBμV/m] = EIRP[dBm] 20 log (d[m]) + 104.77, where E is field strength and d is distance at which the field strength limit is specified in the applicable requirements. for example,3m field strength(dBμV/m)=EIRP-20log(3)+104.77=EIRP+95.2 6.2. Test Setup FCC ID: …
