2ARWCCWV-0303Coolr Vista

CoolR Group USER MANUAL 1 December 2019 December-16-2019 CoolR Vista CoolR Group USER MANUAL 2 Contents 1.Pre-install Checklist .............................................................................................................................................. 2 2. Physical Installation ............................................................................................................................................. 3 Initiate ................................................................................................................................................................. 3 Identify install position ........................................................................................................................................ 3 Install ................................................................................................................................................................... 3 Provisioning ......................................................................................................................................................... 3 Login .................................................................................................................................................................... 3 3.Device Monitor .................................................................................................................................................... 4 1.From Home screen Expand main menu () ...................................................................................................... 4 2.Select “Device Monitor” from the list. ................................................................................................................. 4 Configuration & Install ............................................................................................................................................ 4 Settings: WIFI Vista Mode Enable/Disable .......................................................................................................... 5 Troubleshooting .................................................................................................................................................. 6 Pre-install Checklist 1. Hardware installation items a. Vista b. Paper or lint free cloth to clean the glass surface 2. For software configuration a. Android phone with Android 4.4 or above and Bluetooth 4.1 or above b. Bluetooth and internet connectivity on the phone c. Ideally GPS should also be on d. Login credentials for the application CoolR Group USER MANUAL 3 Physical Installation Initiate 1. Note down the serial# & MAC address of the vista. 2. Note down the asset (cooler serial/name) & outlet (location/store) details Identify install position 1. Coolr Smart Vista should be placed on inner wall of the Door of the cooler. 2. Ideally, Vista should be placed vertically at center of cooler door on handle side. Install 1. Clean the glass to remove any moisture 2. Stick the device in vertical position inside Cooler with camera facing towards the hinge/inside & Push the device and hold for about 5 second s. Provisioning Login 1. Login to the “Coolr Smart Device” Application from Playstore/App store CoolR Group USER MANUAL 4 Device Monitor 1. From Home screen Expand main menu () 2. Select “Device Monitor” from the list. 3. In device monitor screen, expand options menu on top right () & Select “Start Scan” & wait for scan to show you vista device. Configuration & Install 1. Once you see you vista serial you can connect to it by selecting blue circle next to the serial number. 2. After connecting with vista, expand options menu on top right () & Select “Install” CoolR Group USER MANUAL 5 3. After successful Install the pop-up will appear “Device Installed successfully” 4. You can select the back (Arrow) button to return back to device monitor screen. Settings: WIFI Vista Mode Enable/Disable 1. Navigate to Device Monitor Screen & Reconnect with the Vista device, expand options menu on top right () & Select “Start Scan” & wait for scan to show you vista device. 2. Select the appropriate Device Serial by Selecting the “V” icon to enter onto the Device Details screen. CoolR Group USER MANUAL 6 3. Scroll down till where “Wifi Settings” details have mentioned. - Enable the WIFI Vista Mode - Enter SSID and Password - Select “Send” - Select Save icon. NOTE: - If success, the device sends a ping data to the server and the events data (if any). - After that you can leave the commands from CoolR Portal. Device will connect and send data to server. Troubleshooting Issue: Can’t find application PlayStore/App store You can alternatively download the application from a.https://itunes.apple.com/us/app/coolr-smart-device/id1374366398?ls=1&mt=8 - b.https://play.google.com/store/apps/details?id=com.CoolrSmartDevices&hl=en_US Issue: Can’t find the Device during Install 1. Make sure that phone has BLE 4.1 or higher 2. Make sure your Phone OS is Android 4.4 or higher 3. Make sure Bluetooth and Location Services are ON Issue: Can’t Connect with Device In “Device Monitor 1. From Device Monitor Select “Sync” & wait till scan finishes. 2. Re-attempt to connect again. FCCCaution Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2) thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay causeundesiredoperation. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser'sauthoritytooperatetheequipment. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation. Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference toradiocommunic…

Text truncated - open the document above for the full version.

Coolr Group Inc Agent Authorization Company: Coolr Group Inc Address: 14100 Parke Long Ct, Suite I, Chantilly, VA-20151, United States of America Product Name: Coolr Vista Model Number(s): CWV-0303 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/01/10 Name: Roy Mehta Title: Manager Company: Coolr Group Inc

Coolr Group Inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/01/10 Subject; Request for Confidentiality FCC ID: 2ARWCCWV-0303 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Roy Mehta Title: Manager

External Photos

Size:40*20mm FCC ID: 2ARWCCWV-0303 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Location

Internal Photos WIFI Antenna BT Antenna

Shenzhen BCTC Testing Co., Ltd. FCC ID: 2ARWCCWV-0303 RF EXPOSURE EVALUATION 1. Introduction According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b), a device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 cm is normally maintained between the transmitting antenna and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 cm separation requirement. The limits to be used for MPE evaluation are specified in §1.1310. All unlicensed personal communications service (PCS) devices and unlicensed NII devices shall be subject to the limits for general population/uncontrolled exposure. 2.RF Radiation Exposure Limits According to 47 CFR §1.1310, the criteria listed in below table shall be used to evaluate the environmental impact of human exposure to RF radiation as specified in §1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of §2.1093. Notes: 1. f = frequency in MHz 2. Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided they are made aware of the potential for exposure. 3. General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Shenzhen BCTC Testing Co., Ltd. 3.MPE Assessment Method Calculations can be made to predict RF field strength and power density levels around typical RF sources. For example, in the case of a single radiating antenna, a prediction for power density in the far-field of the antenna can be made by use of the general Equations below. This equation is generally accurate in the far-field of an antenna but will over-predict power density in the near field, where they could be used for making a "worst case" or conservative prediction. Where S = Power Density, unit in mW/cm2 P = Power input to the antenna, unit in mW G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = Distance to the center of radiation of the antenna, unit in cm EIRP = Effective isotropically radiated power 4. MPE Calculation for Standalone Operations Operation Frequency: 802.11a/b/g/n/ac: 2412-2462MHz, 5180-5240MHz, 5745-5825MHz Power density limited: 1mW/ cm 2 Antenna Type: External antenna Antenna gain: 1dBi R=20cm mW=10^(dBm/10) =3.1416 2.4g_wifi Modulation Max conduct ed power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2) 802.11b13.1113±114.0025.121.260.006301 802.11g13.0413±114.0025.121.260.006301 802.11n2011.6911±112.0015.851.260.003971 BLE Modulation Max conduct ed power (dBm) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Antenna Gain Numeric Evaluation result (mW/cm2 ) Power density Limits (mW/cm2) GFSK3.403±14.002.511.260.000631 Conclusion: For the max result : 0.00630≤ 1.0, compliance with FCC's RF Exposure. Summary: Since the ERP (effective radiated power) operated at < 1.5 GHz is less than 1.5 watts and > 1.5 GHz is less than 3 watts, the routine environmental evaluation is not required, and the MPE result calculated for this device complies with the MPE limit as specified in 47 CFR §1.1310.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 55 FCC Part 15C Test Report FCC ID: 2ARWCCWV-0303 Product Name: Coolr Vista Trademark: N/A Model Name : CWV-0303 Prepared For : Coolr Group Inc Address : 14100 Parke Long Ct, Suite I, Chantilly, VA-20151, United States of America Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 30, 2019 – Jan. 08, 2020 Date of Report : Jan. 08, 2020 Report No.: BCTC1912002808-1E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 55 TEST RESULT CERTIFICATION Applicant’s name ............... Coolr Group Inc Address ............................... 14100 Parke Long Ct, Suite I, Chantilly, VA-20151, United States of America Manufacture's Name .......... MOKO Technology Limited Address ............................... 3F, BLD 1, Shenlan Industrial Park, 240 Fuqian Rd, Longhua, Shenzhen, 518109 China Product description Product name ......................... Coolr Vista Trademark ............................... N/A Model and/or type reference ............................ CWV-0303 Standards ........................... FCC Part15.247 ANSI C63.10:2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 55 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 13 3.1.3 DEVIATION FROM TEST STANDARD 13 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 RADIATED EMISSION LIMITS 15 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 16 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.2.8 TEST RESULTS (1GHZ~25GHZ) 21 3.3 RADIATED BAND EMISSION MEASUREMENT 24 3.3.1 TEST REQUIREMENT: 24 3.3.2 TEST PROCEDURE 24 3.3.3 DEVIATION FROM TEST STANDARD 25 3.3.4 TEST SETUP 25 3.3.5 EUT OPERATING CONDITIONS 25 4 . POWER SPECTRAL DENSITY TEST 27 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 55 Table of Contents Page 4.1 APPLIED PROCEDURES / LIMIT 27 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . BANDWIDTH TEST 34 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 5.1.2 DEVIATION FROM STANDARD 34 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 TEST RESULTS 35 6 . PEAK OUTPUT POWER TEST 41 6.1 APPLIED PROCEDURES/LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 43 7.1 APPLICABLE STANDARD 43 7.2 TEST PROCEDURE 43 7.3 DEVIATION FROM STANDARD 43 7.4 TEST SETUP 43 7.5 EUT OPERATION CONDITIONS 43 7.6 TEST RESULT 43 8 . DUTY CYCLE OF TEST SIGNAL 50 8.1 STANDARD REQUIREMENT 50 8.2 FORMULA: 50 9 . ANTENNA REQUIREMENT 53 9.1 STANDARD REQUIREMENT 53 9.2 EUT ANTENNA 53 10 . EUT TEST PHOTO 54 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 55 Table of Contents Page 11 . EUT PHOTO 55 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 55 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (d) Radiated Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Restricted Band of Operation PASS 15.247 (d) Band Edge (Out of Band Emissions) PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 7 of 55 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add. : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately …

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 38 Test Report FCC: 2ARWCCWV-0303 Product Name: Coolr Vista Trademark: N/A Model Name : CWV-0303 Prepared For : Coolr Group Inc Address : 14100 Parke Long Ct, Suite I, Chantilly, VA-20151, United States of America Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 30, 2019 – Jan. 08, 2020 Date of Report : Jan. 08, 2020 Report No.: BCTC1912002808-2E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 38 TEST RESULT CERTIFICATION Applicant’s name ................. : Coolr Group Inc Address ................................. : 14100 Parke Long Ct, Suite I, Chantilly, VA-20151, United States of America Manufacture's Name ............ : MOKO Technology Limited Address ................................. : 3F, BLD 1, Shenlan Industrial Park, 240 Fuqian Rd, Longhua, Shenzhen, 518109 China Product description Product name ........................... : Coolr Vista Trademark ................................. : N/A Model and/or type reference : CWV-0303 Standards ............................. : FCC Part15.247 ANSI C63.10:2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 38 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 12 3.1.3 DEVIATION FROM TEST STANDARD 12 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.3 RADIATED BAND EMISSION MEASUREMENT 22 3.3.1 TEST REQUIREMENT: 22 3.3.2 TEST PROCEDURE 22 3.3.3 DEVIATION FROM TEST STANDARD 22 3.3.4 TEST SETUP 23 3.3.5 EUT OPERATING CONDITIONS 23 4 . POWER SPECTRAL DENSITY TEST 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.1.1 TEST PROCEDURE 25 4.1.2 DEVIATION FROM STANDARD 25 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 38 Table of Contents Page 4.1.3 TEST SETUP 25 4.1.4 EUT OPERATION CONDITIONS 25 4.1.5 TEST RESULTS 26 5 . BANDWIDTH TEST 28 5.1 APPLIED PROCEDURES / LIMIT 28 5.1.1 TEST PROCEDURE 28 5.1.2 DEVIATION FROM STANDARD 28 5.1.3 TEST SETUP 28 5.1.4 EUT OPERATION CONDITIONS 28 5.1.5 TEST RESULTS 29 6 . PEAK OUTPUT POWER TEST 31 6.1 APPLIED PROCEDURES / LIMIT 31 6.1.1 TEST PROCEDURE 31 6.1.2 DEVIATION FROM STANDARD 31 6.1.3 TEST SETUP 31 6.1.4 EUT OPERATION CONDITIONS 31 6.1.5 TEST RESULTS 32 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 33 7.1 APPLICABLE STANDARD 33 7.2 TEST PROCEDURE 33 7.3 DEVIATION FROM STANDARD 33 7.4 TEST SETUP 33 7.5 EUT OPERATION CONDITIONS 33 8 . ANTENNA REQUIREMENT 36 8.1 STANDARD REQUIREMENT 36 8.2 EUT ANTENNA 36 9 . EUT TEST PHOTO 37 10 . EUT PHOTO 38 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 5 of 38 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (d) Radiated Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Restricted Band of Operation PASS 15.247(d) Band Edge (Out of Band Emissions) PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC1912002808-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 6 of 38 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add.: BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 3m camber Radiated spurious emission(30MHz-1GHz) U=4.3dB 2 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 3 3m chamber Radiated spurious emission(18GHz-40GHz) U=3.34dB 4 Conducted Adjacent channel power U=1.38dB 5 Conducted output power uncertainty Above 1G U=1.576dB 6 Conducted output power…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Radiated Measurement Photos
