2AS3P-6005-02Playzoom Walkie Talkie

User Manual Installation the battery 1. Make sure your radio is turned OFF. 2. Remove the battery compartment door. 3. Install the 3 NiMH rechargeable battery or 3 AAA Alkaline batteries into the battery compartment. 4.Replace the battery compartment door. Basic radio operations 1. Press to turn on. 2. Press to enter the channel settings, the channel display pattern starts flashing,with to select. Press PTT to confirm and exit. 3. Press twice to enter the setting. OFF for no code, 01~38 for CTCSS code,39-99 for DCS code. 4. Press for 3 times to enter the Vox function selection. there are OFF,1,2.3 these 3 gear sensitivity optional. 5. Press for 4 times to enter the CALL tone selection function. They are 01 to 10 sounds available. 6. Press for 5 times to enter the key tone selection function, select the button when the ON button will beep a tone, select the OFF button when there is no tone. 7. Press for 6 times to enter the launch end of the tone selection function, with to select. select ON to release the PTT will have a tone, the opposite choice of OFF there is no tone. 8. Press for 7 times and exit can also press PTT to confirm the exit menu. Note It doesn’t has charging function, it can’t be charged directly through charger base and so on , it only can be charged by a NiMH vrechargeable battery. When installing the battery, please pay attention to the corresponding positive and negative placement! 01 V oice Operated T ransmission (V ox) T ransmisson is initiated by speaking into the microphone of the radio instead of the pushing the PTT button. Note: Note Level “N”(OFF)disables VOX Levels 1-3 set thesensitivity of the VOX circuit Use level 1 in quiet environments, and use level 3 in very noisy environments. You can find the appropriate sensitivity level by speaking into the microphone. Scanning Channels Eatures your radio to scan for active channels .when activity is detected, your radio lands (stays) on that channel for 5 seconds. To transmit on that channel ends, your radio continues scannig to other channels. To turn the channel scan ON: 1.Press and hold to enter Scan mode. 2.press or PTT to turn off Scan mode. Note: During scanning , press the key to change the direction of the scan.Safety and General Information 1.If you carry any kind of personal medical device, consult a doctor before use. 2.To avoid the risk of burns, do not use the device if the aerial is damaged in any way. 3.Never use the device in close proximity to a radio to avoid interference. 4.Position the transmitter and antenna at least 5 cm from your mouth. 5.The device cannot be used to contact the emergency services. US:1 CTCSS: 38 + DCS : 61 3xAAA(Not include) FRS:462.5625MHz Up to 2 Km(Open field ) =< 500 mW FM-F3E 12.5 KHZ Techincal specifications Channels Sub-code Battery Frequency Range Transmission Power Modulation Type Channel spacing 02 -30°C~+50°C Warnings RF ENERGY EXPOSURE AND PRODUCT SAFETY GUIDE FOR PORTABLE TWO-WAY RADIOS This two-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. RF energy, which when used improperly, can cause biological damage. All Retevis two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In ad-dition, manufacturers also recommend specific operating instructions to users of two-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. Please refer to the following websites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits: http://www.who.int/en/ Local Government Regulations When two-way radios are used as a consequence of employment, the Local Government Regulations requires users to be fully aware of and able to control their exposure to meet general requirements.Exposure awareness can be facilitated by the use of a product labeldirecting users to specific user awareness information. Your Retevis two-way radio has a RF Exposure Product Label. Also, your Retevis user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Radio License Governments keep the radios in classification, business two-way radios operate on radio frequencies that are regulated by the local radio management departments (FCC, ISED, OFCOM, ANFR, BFTK,Bundesnetzagentur...).To transmit on these frequencies, you are required to have a license issued by them. The detailed classification and the use of your two radios, please contact the local government radio management departments. Use of this radio outside the country where it was intended to be dist-ributed is subject to government regulations and may be prohibited. Unauthorized modification and adjustment Changes or modifications not expressly approved by the party resp-onsible for compliance may void the user’s authority granted by the ocal government radio management departments to operate this radio and should not be made. To comply with the corresponding requirements, transmitter adjustments should be made only by or under the supervision of a person certified as technically qualified to perform transmitter maintenance and repairs in the private land mobile and fixed services as certified by an organization representative of the user of those services. Replacement of any transmitter component (crystal, semiconductor,etc.) not authorized by the local government radio management dep-artments equipment Before using this radio, read this guide which contains important operating instructions for safe usage and RF energy awareness and control for compliance with applicable standards and regulations. 03 04 authorization for this radio could violate the rules. FCC Requirements: This device complies with part 15 of the FCC Ru…
