2AS4ASC-AI08SimCam Baby Pro

This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modi

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-7-9> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AS4ASC-AI08 SC-AI08 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Yan Deng/Assistant Company: Wuhan Simshine Intelligent Technology Co., Ltd Address: Room 1, floor 11, building 4, phase iii and iv,Wuhan creative capital, Mahu village,Hongshan str, Hongshan district,Wuhan China Phone: 027-88756910 Fax: 027-88756910 E-Mail: [email protected]

Wuhan Simshine Intelligent Technology Co., Ltd Room 1, floor 11, building 4, phase iii and iv,Wuhan creative capital, Mahu village,Hongshan str, Hongshan district,Wuhan China Date: 2021-7-9 FCC ID: 2AS4ASC-AI08 Model Number: SC-AI08 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Wuhan Simshine Intelligent Technology Co., Ltd, declare that this EUT (FCC ID: 2AS4ASC-AI08) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Yan Deng/Assistant Company: Wuhan Simshine Intelligent Technology Co., Ltd Address: Room 1, floor 11, building 4, phase iii and iv,Wuhan creative capital, Mahu village,Hongshan str, Hongshan district,Wuhan China Phone: 027-88756910 Fax: 027-88756910 E-Mail: [email protected]

Wuhan Simshine Intelligent Technology Co., Ltd Room 1, floor 11, building 4, phase iii and iv,Wuhan creative capital, Mahu village,Hongshan str, Hongshan district,Wuhan China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-7-9 To whom it may concern: We, Wuhan Simshine Intelligent Technology Co., Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AS4ASC-AI08 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Yan Deng/Assistant Company: Wuhan Simshine Intelligent Technology Co., Ltd Address: Room 1, floor 11, building 4, phase iii and iv,Wuhan creative capital, Mahu village,Hongshan str, Hongshan district,Wuhan China Phone: 027-88756910 Fax: 027-88756910 E-Mail: [email protected]

FCC ID: 2AS4ASC-AI08 External Photos of the EUT Fig.1 Fig.2 FCC ID: 2AS4ASC-AI08 Fig.3 Fig.4 FCC ID: 2AS4ASC-AI08 Fig.5 Fig.6

FCC ID: 2AS4ASC-AI08 Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location SimCam Baby Pro Model No.: SC-AI08 FCC ID : 2AS4ASC-AI08

FCC ID: 2AS4ASC-AI08 Internal Photos of the EUT Fig.1 Fig.2 Antenna FCC ID: 2AS4ASC-AI08 Fig.3 Fig.4 FCC ID: 2AS4ASC-AI08 Fig.5 Fig.6 FCC ID: 2AS4ASC-AI08 Fig.7 Fig.8 FCC ID: 2AS4ASC-AI08 Fig.9 Fig.10 FCC ID: 2AS4ASC-AI08 Fig.11 Fig.12

RF Exposure evaluation FCC ID: 2AS4ASC-AI08 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information L4K1 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Type of antenna: Gain of the antenna (Max.) Frequency range: 2.4GWIFI / FPC ANT 2.0dBi for 2400-2500MHz 5. Manufacturing Tolerance 2.4GWIFI(Peak) Frequency (MHz) B Mode 2412 2437 2462 Target (dBm) 12.0 12.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) G Mode 2412 2437 2462 Target (dBm) 11.0 12.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 Frequency (MHz) N20 Mode 2412 2437 2462 Target (dBm) 12.0 11.0 11.0 Tolerance ± (dB) 1.0 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 2.0dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW 2.4GWIFI 13.0 19.9526 2.0 1.5849 0.0063 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. MPE evaluate distance is 20cm from user manual provide by manufacturer. 7. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20210708011-1-1 2AS4ASC-AI08 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Jul. 08, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Applicant’s name ............................ : Wuhan Simshine Intelligent technology Co., LTD Address ............................................ : Room 1, floor 11, building 4, phase iii and iv, Wuhan creative capital, Mahu village, Hongshan street, Hongshan district, Wuhan,China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: SimCam Baby Pro Trade Mark ....................................... : Manufacturer .................................... : Wuhan Simshine Intelligent technology Co., LTD Model/Type reference....................... : SC-AI08 Listed Models .................................. : N/A Modulation Type ............................... : CCK/DSSS/ OFDM Operation Frequency ........................ : From 2412 - 2462MHz Rating ............................................... : DC 5V From External circuit Result................................................ : PASS Report No.: GTS20210708011-1-1 Page 2 of 40 T E S T R E P O R T Test Report No. : GTS20210708011-1-1 Jul. 08, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test : SimCam Baby Pro Model /Type : SC-AI08 Listed Models : N/A Applicant : Wuhan Simshine Intelligent technology Co., LTD Address : Room 1, floor 11, building 4, phase iii and iv, Wuhan creative capital, Mahu village, Hongshan street, Hongshan district, Wuhan,China Manufacturer : Wuhan Simshine Intelligent technology Co., LTD Address : Room 1, floor 11, building 4, phase iii and iv, Wuhan creative capital, Mahu village, Hongshan street, Hongshan district, Wuhan,China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210708011-1-1 Page 3 of 40 Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M M A R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 5 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Test Description 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D R E S U L T S ........................................... 10 4.1 AC Power Conducted Emission 10 4.2 Radiated Emission 13 4.3 Maximum Peak Conducted Output Power 19 4.4 Power Spectral Density 20 4.5 6dB Bandwidth 23 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 33 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 34 6 P H O T O S O F T H E E U T ........................................................... 35 Report No.: GTS20210708011-1-1 Page 4 of 40 1 T E ST S T ANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission Systems (DTS) ,Frequency Hopping Spread Spectrum System(HFSS), and Hybrid System Devices Operating Under §15.247 of The FCC rules. Report No.: GTS20210708011-1-1 Page 5 of 40 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Jun. 11, 2021 Testing commenced on : Jun. 11, 2021 Testing concluded on : Jul. 08, 2021 2.2 Product Description Product Name: SimCam Baby Pro Model/Type reference: SC-AI08 Power supply: DC 5V From External circuit Adapter(Auxiliary test Provided by the laborator) Mode:EP-TA20CBC Input:AC100-240V-50/60Hz，0.5A Output:DC 5V,2A testing sample ID： GTS20210708011-1-1-1#(Engineer sample), GTS20210708011-1-1-2#(Normal sample) WIFI : Supported type: 802.11b/802.11g/802.11n(H20): Modulation: 802.11b: DSSS 802.11g/802.11n(H20): OFDM Operation frequency: 802…

Text truncated - open the document above for the full version.

FCC ID: 2AS4ASC-AI08 Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2AS4ASC-AI08 Test Setup Photo of Line Conducted Emissions Measurement
