2AS5O-0357369Wireless Charger

035-7369-0 FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. -English:" This device complies with Industry Canada licence-exempt RSS standard( s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." -French:" Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil nedoit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement."

FCC ID: 2AS5O-0357369

Label Location On EUT Label Product Name: Wireless Charger Model No.: 035-7369-0 FCC ID: 2AS5O-0357369 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AS5O-0357369 ANT ANT

China Etech Groups Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: 035-7369-0, CTC-QIS05, E-QI-20630-A FCC ID : 2AS5O-0357369 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: 035-7369 Type of antenna: Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range: 110.1-205KHz Model No. of antenna: 035-7369-0 Type of antenna: Inductive loop coil Antenna Gain of the antenna: 0 dBi Frequency range: 110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road, Baoan District, Shenzhen, China City: Shenzhen ZIP / Postal code: N/A Country: China Place: China Date: 2020-08-14 Signature: version01

Report No.: 18220WC00099002FCC ID: 2AS5O-0357369Page 1 of 14 Code:AB-RF-05-a FCC TEST REPORT Client Name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China Product Name: Wireless Charger Date: Aug. 11, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00099002FCC ID: 2AS5O-0357369Page 2 of 14 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 6 2. Measurement and Result ..................................................................................................................................... 7 2.1. Requirements .............................................................................................................................................. 7 2.2. Test Setup .................................................................................................................................................... 8 2.3. Test Procedure ............................................................................................................................................ 8 2.4. Test Result ................................................................................................................................................... 8 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 8 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 ................................................................................................................................................................ 10 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 11 Report No.: 18220WC00099002FCC ID: 2AS5O-0357369Page 3 of 14 Code:AB-RF-05-a TEST REPORT Applicant: China Etech Groups Ltd Manufacturer: China Etech Groups Ltd Product Name: Wireless Charger Model No.: 035-7369-0, CTC-QIS05, E-QI-20630-A Trade Mark: N.A. Rating(s): Input: DC 5V/3A, 9V/2A Wireless Output1: 5W, 7.5W, 10W Wireless Output2: 5W USB-A Output: DC 5V/1A Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJul. 16, 2020 Date of TestJul. 16~27, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00099002FCC ID: 2AS5O-0357369Page 4 of 14 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Wireless Charger Model No. : 035-7369-0, CTC-QIS05, E-QI-20630-A (Note: All samples are the same except the model name, so we prepare "035-7369-0" for test only.) Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:FSK Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China Manufacturer: China Etech Groups Ltd Address : 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China Factory: China Etech Groups Ltd Address : 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China Report No.: 18220WC00099002FCC ID: 2AS5O-0357369Page 5 of 14 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Manufacturer: Anker Innovations Limited M/N: A2013 Input: 100-240V~50-60Hz Output: 3.6-6.5V 3A/ 6.5-9V2A/ 9-12V1.5A Apple AirPods: Manufacturer: Apple Phone: Manufacturer:SAMSUNG M/N: Galaxy S10+(SM-G9750) 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 24, 2018 3 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 …

Text truncated - open the document above for the full version.

Report No.: 18220WC00099001FCC ID: 2AS5O-0357369Page 1 of 30 Code:AB-RF-05-a FCC TEST REPORT Client Name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China Product Name: Wireless Charger Date: Aug. 11, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00099001FCC ID: 2AS5O-0357369Page 2 of 30 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 15 4.1. Test Standard and Limit .......................................................................................................................... 15 4.2. Test Setup .................................................................................................................................................. 15 4.3. Test Procedure .......................................................................................................................................... 16 4.4. Test Data .................................................................................................................................................... 17 5. Antenna Requirement ......................................................................................................................................... 21 5.1. Test Standard and Requirement ............................................................................................................ 21 5.2. Antenna Connected Construction .......................................................................................................... 21 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 22 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 24 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 28 Report No.: 18220WC00099001FCC ID: 2AS5O-0357369Page 3 of 30 Code:AB-RF-05-a TEST REPORT Applicant: China Etech Groups Ltd Manufacturer: China Etech Groups Ltd Product Name: Wireless Charger Model No.: 035-7369-0, CTC-QIS05, E-QI-20630-A Trade Mark: N.A. Rating(s): Input: DC 5V/3A, 9V/2A Wireless Output1: 5W, 7.5W, 10W Wireless Output2: 5W USB-A Output: DC 5V/1A Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJul. 16, 2020 Date of TestJul. 16~27, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00099001FCC ID: 2AS5O-0357369Page 4 of 30 Code:AB-RF-05-a 1. General Information 1.1. Client Information Applicant: China Etech Groups Ltd A…

Text truncated - open the document above for the full version.

FCC ID: 2AS5O-0357369 Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
