Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
True wireless earbuds with charging case Size: 85*55 mm USING INSTRUTION PACKING LIST SPECIFICATIONS: Congratulations on your True wireless earbuds.These BT earbuds allow you to enjoy your music without wires.Please read this manual before use.NOTICE:1. Keep the product dry; do not place the product in damp places2. Keep out of direct sunlight and high temperatures High temperatures may result in damage3. Keep out of cold temperatures, this will help to avoid internal damage4. Do not disassemble the product5. Avoid dropping the headphones6. Do not continue to charge the headphones over 10 hours7. When charging use the Micro USB charging cord that came with the headphones FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:-Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver.-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.-Consult the dealer or an experienced radio/TV technician for help.The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. 1- Charging case2- On/Off button Charging indicator3- Earbuds True wireless earbuds ×1 ADDITIONAL Frequency range (Hz-KHz) 20Hz – 20 KHz Continuous playing timeCharging timeBattery capacity Earbuds :Battery capacity Charging stationMic function :Pick up function :BT version : 2.5-3 hours5.0yesyes300 mAh30 mAh1.5 hours 7DNHRXWWKHHDUEXGVIURPWKHFKDUJLQJFDVHWKH\ZLOOEHSRZH URQ and pair automatically after the indicator flashing in red /blue color for 4-5 seconds.$FWLYDWH\RXUSDLULQJGHYLFH¶V%7PRGH6HDUFKIRU³09B(% ́DQGVHOHFWLWWRFRQQHFW$IWHUWKHFRQQHFWLRQLVVXFFHVVIXOWKHHDUEXG¶VOLJKWZLOOE HRII 6KRUWSUHVVWRSDXVHSOD\PXVLF3UHVVDQGKROG6WRVZLWFKXSDQGGRZQVRQJV/LVWHQWRRUQRWOLVWHQWRPXVLFFDQVXSSRUWWKUHHFOLFNVWR FDOOEDFN the last phone number.6KRUWSUHVVWRDQVZHUHQGWKHFDOOORQJSUHVV6WRUHMHFW WKHFDOO Precaution (DUEXGVZLOODXWRPDWLFDOO\EHSRZHURIILIWKHUHLVQRRSHUDW LRQLQ minutes after switch on.When the phone is out of distance,earbuds is disconnected.When return to the communication distance, the earbuds will automatically connect to the phone.,IWKHVLQJOHVLGHGHDUEXGVLVFRQQHFWHGWRWKHPRELOHSKRQH WKHWZR earbuds can not be connected.In this case,the mobile phone bluetooth should be turned off,When the dual earbuds light flashes red and blue, double-click one of the earbuds and it can be paired. 1. 2. 3. True wireless earbuds E-BP-19520-A Paring Mode Led light flash in red/blue color Working Low BatteryChargingFull charged The light is offThe red light is offThe red light is onLED light flash red slowly <Press for 3 seconds>Manually switch on and off <Long Press 2 seconds> Reject phone call Switch the next song <click> Answer phone call Interrupt and hang up during call Play/Pause music <Press 3 times>Replay the last call FUNCTION KEYSINDICATOR LIGHT STATUS
- Page 1 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China APPENDIX 1: EUT PHOTO Photo 1 (For model E-BP-19520-A) Photo 2 - Page 2 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 3 Photo 4 - Page 3 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 5 Photo 6 - Page 4 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 7 Photo 8 - Page 5 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 9 Photo 10 - Page 6 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 11 Photo 12 - Page 7 of 7 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 13 ----END OF REPORT----
Lable True Wireless Earbuds Model: E‐BP‐19520‐A Input: 5V‐300mAh Made in China FCC ID: 2AS5O‐19520 Location
- Page 1 of 5 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China APPENDIX 1: EUT PHOTO Photo 1 (For model E-BP-19520-A) Photo 2 - Page 2 of 5 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 3 Photo 4 - Page 3 of 5 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 5 Photo 6 - Page 4 of 5 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 7 Photo 8 - Page 5 of 5 - Report No.: MTi19122605-1E1-1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Photo 9 Photo 10 ----END OF REPORT---- BT Antenna
version01 China Etech Groups Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: E-BP-19520-A FCC ID: 2AS5O-19520 fulfills the req uirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for Internal antenna type(s) described below: Model No. of antenna: N/A Type of antenna: Ceramic Antenna Gain of the antenna: 0.45 dBi Frequency range: 2402~2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road,Baoan, Shenzhen, China City: Shenzhen ZIP / Postal code: N/A Country: China Contact: Paul Huang Date: 3/10/2020 Signature:
RF EXPOSURE REPORT FCC ID: 2AS5O-19520 Date of issue: Jan. 07, 2020 Report Number: MTi19122605-1E2 Sample Description: True Wireless Earbuds Model(s): E-BP-19520-A, N-m 569, N-m 570, EB5555, EB5555-GYA, EB5555-WHA Applicant: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road, Baoan District, Shenzhen, China. Date of Test: Dec. 30, 2019 to Jan. 07, 2020 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 4- Report No.: MTi19122605-1E2 TEST RESULT CERTIFICATION Applicant’s name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road, Baoan District, Shenzhen, China. Manufacture's name: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road, Baoan District, Shenzhen, China. Product name: True Wireless Earbuds Model and/or type reference: E-BP-19520-A Serial Model: N-m 569, N-m 570, EB5555, EB5555-GYA, EB5555-WHA RF Exposure Procedures: KDB 447498 D01 v06 This device described above has been tested by Shenzhen Microtest Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Tested by: Danny Xu Jan. 07, 2020 Reviewed by: Leo Su Jan. 07, 2020 Approved by: Tom Xue Jan. 07, 2020 - Page 3 of 4- Report No.: MTi19122605-1E2 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz c) For frequencies below 100 MHz, the following may be considered for SAR test exclusion (also illustrated in Appendix C): 1) For test separation distances > 50 mm and < 200 mm, the power threshold at the corresponding test separation distance at 100 MHz in step b) is multiplied by [1 + log(100/f(MHz))] 2) For test separation distances ≤ 50 mm, the power threshold determined by the equation in c) 1) for 50 mm and 100 MHz is multiplied by ½ 3) SAR measurement procedures are not established below 100 MHz. - Page 4 of 4- Report No.: MTi19122605-1E2 When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any SAR test results below 100 MHz to be acceptable. 2. SAR Test Exclusion Thresholds We use 5mm as separation distance to calculate. Bluetooth DSS: Transmit Frequenc y (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune- up Result 1g SAR power(dBm) calculation 2.402 GFSK -3.400 (-3±1) -2 0.1956 3 2.441 -2.970 (-3±1) -2 0.1972 3 2.480 -3.342 (-3±1) -2 0.1987 3 2.402 π/4-DQPSK -2.650 (-2±1) -1 0.2462 3 2.441 -2.310 (-2±1) -1 0.2482 3 2.480 -2.700 (-2±1) -1 0.2502 3 Conclusion: For the max result: 0.2502≤ 3.0 for 1g SAR, No SAR is required. ----END OF REPORT----
This test report is valid for the tested samples only. It cannot be reproduced except in full without prior written consent of Shenzhen Microtest Co., Ltd. Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Test Report FCC ID: 2AS5O-19520 Date of issue: Jan. 07, 2020 Report number: MTi19122605-1E1 Sample description: True Wireless Earbuds Model(s): E-BP-19520-A, N-m 569, N-m 570, EB5555, EB5555-GYA, EB5555-WHA Applicant: China Etech Groups Ltd Address: 16/F, Block C, 2nd Phase of Central Avenue, Haihong Industrial Area, Xixiang Road, Baoan District, Shenzhen, China. Date of test: Dec. 30, 2019 to Jan. 07, 2020 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 53 - Report No.: MTi19122605-1E1 Tel:(86-755)88850135 Fax: (86-755) 88850136 Web: http://www.mtitest.com E-mail: [email protected] Address: No.102A & 302A, East Block, Hengfang Industrial Park, Xingye Road, Xixiang, Bao'an District, Shenzhen, Guangdong, China Table of Contents 1 GENERAL INFORMATION ....................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................... 5 1.2 OPERATION CHANNEL LIST .............................................................................................................................................. 5 1.3 TEST CHANNEL LIST ....................................................................................................................................................... 6 1.4 ANCILLARY EQUIPMENT LIST ........................................................................................................................................... 6 1.5 DESCRIPTION OF SUPPORT UNITS .................................................................................................................................... 6 2 SUMMARY OF TEST RESULTS ................................................................................................................................. 7 3 TEST FACILITIES AND ACCREDITATIONS .................................................................................................................. 8 3.1 TEST LABORATORY ........................................................................................................................................................ 8 3.2 ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 3.3 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 8 3.4 TEST SOFTWARE ........................................................................................................................................................... 8 4 EQUIPMENT LIST .................................................................................................................................................. 9 5 TEST RESULT ....................................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT ............................................................................................................................................. 10 5.1.1 Standard requirement ....................................................................................................................................... 10 5.1.2 EUT antenna ..................................................................................................................................................... 10 5.2 PEAK OUTPUT POWER ................................................................................................................................................. 11 5.2.1 Limit .................................................................................................................................................................. 11 5.2.2 Test setup .......................................................................................................................................................... 11 5.2.3 Test procedure ................................................................................................................................................... 11 5.2.4 Test results ........................................................................................................................................................ 11 5.3 CONDUCTED EMISSION ................................................................................................................................................ 16 5.3.1 Limits ................................................................................................................................................................. 16 5.3.2 Test setup .......................................................................................................................................................... 16 5.3.3 Test procedure ................................................................................................................................................... 17 5.3.4 Test results ........................................................................................................................................................ 17 5.4 RADIATED SPURIOUS EMISSION ...................................................................................................................................... 18 5.4.1 Limits .........................................................................................…
Text truncated - open the document above for the full version.
Model: E-BP-19520-A Radiated emission
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 590.00 µW |
