2AS6EIP-WLBG-4CHBLE Scanner

Copyright ⓒ 2021 People & Technology Co., Ltd. All Rights Reserved IP-WLBG-4CH Setting Manual 2 Contents 1. Introduction ---------------------------------------- 2. IP-WLBG-4CH --------------------------------------- 3. Hardware Specification---------------------------- 4. Scanner Install Location ---------------------------- 5. Scanner Installation --------------------------------- 6. How to set up the scanner ------------------------- 7. FAQ -------------------------------------------------- 8. FCC Rules --------------------------------------------- 3 4 5 6 7 8 14 15 Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved ።Purpose This document provides basic guidelines for customers who use products designed by People & Technology. ።Range The scope of this document is to provide software descriptions and general instructions from IP-WLBG-4CH. ።Object This document is intended for customers using People & Technology's IP-WLBG-4CH. ።Question Please contact http://www.pntbiz.co.kr for technical support and documentation errors. 3 Introduction Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved ።Component Description 4 1) IP-WLBG-4CH Scanner Body 2) Antenna (Removable) * If the component is missing or damaged, contact your place of purchase. Please keep the boxes and packaging materials in case of return. IP-BS-US 1) Scanner Body 2) Antenna Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 5 Hardware Specification FeaturesDescription MCU ST STM32F722VE ARM® Cortex® -M7 CPU with FPU Wi-Fi TI CC3235S ARM® Cortex® -M4 Core at 80 MHz MemoryRAM (Up to 256KB) StorageExternal S-Flash Network802.11 a/b/g/n : 2.4GHz and 5GHz BLEScanner + Peripheral (nRF52832 x 4) AntennaBLE x 4 / Wi-Fi x 1 Power USB 2.0 Power ( 5.0 V / 3.0 A) HW / SW VersionV 1.0 / V 1.0 Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved *) Direct current [D.C] symbol : This scanner can be connected to the network anywhere within the range of the wireless network. However, the operating distance of the scanner, the range of wireless connections, may vary significantly depending on the physical arrangement of the scanner. For example, the thickness and number of walls that a wireless signal passes through can limit the scope of the scanner. - It is recommended to be near the WiFi router. - Stay away from potentially interfering devices. - Stay away from solid metal doors or metal surfaces. - Glass, insulated walls, tanks, mirrors, bricks, and concrete can affect radio signals. 6 Scanner Install Location Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved ።Scanner Installation 1. Connect the scanner to the USB DC adapter. 2. Check the LEDs on the scanner. 1. Powered On 2. WiFi (AP) Connected 3. BT Signal Received 4. Data Transmitted 7 ።LED Scenario Scanner Installation Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved Blinking PWR Wi-Fi BT PWR Wi-Fi BT PWR Wi-Fi BT 1. Run the settings app provided. After launching the app, click the button in the lower right corner to search for the scanner. 2. Select the scanner you want to set from the list. 8 How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 3. Enter the PASSWORD you received. 4. Enter PASSWORD and the screen for setting up the scanner will be displayed. 9 How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 5. Click the Search icon on the right side of SSID to start WiFi scanning. 10 How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 6. Select the WiFi you want to connect to from the list. 7. Check the selected WiFi SSID. 11 How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 8. Enter your WiFi password. 12 9. Check the scanner ID. How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 10. Enter the server information to which the scanner will send data. (Default value is WMS server information) 13 How to set up the Scanner Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 11. When the setting is complete, click the " Save " button to finish the setup. 14 Q1. If you USB Scanner not found. A1.Turn off the scanner, power it back up, and try connecting it. It can only be accessed within 30 seconds of the initial power supply. Q2. If you unable to connect to WiFi SSID. A2.Please check your WiFi information and router settings. Q3. If you forgot ID and password. A3.Please contact the place of purchase or head office. Q4. If you want to buy an antenna. A4.Please contact the place of purchase or head office. If you have any questions, please contact http://www.pntbiz.com FAQ Copyright ⓒ 2018 People & Technology Co., Ltd. All Rights Reserved 15 O FCC Compliance Statement(Part 15.19 (3)) This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. O FCC Interference Statement(Part 15.105) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one of the following measures: •Reorient or relocate the…

Text truncated - open the document above for the full version.

People and Technology 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea Date: April 04, 2022 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. UL Verification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Chloe Lee/ Deputy General Manager of KCTL Inc. and hereafter referred to as KCTL to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Chloe Lee/ Deputy General Manager of KCTL Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KCTL as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jinsun Lim, CEO People and Technology

People and Technology 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea CONFIDENTIALITY REQUEST Fed eral Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 April 04, 2022 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, People and Technology requests confidential ity for the foll owing products: FCC ID Number Product Title/Model 2AS6EIP-WLBG-4CH BLE Scanner / IP-WLBG-4CH The following exhibits contain trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our product. This material is not customarily available to the general public and we request that it be withheld from public inspection. We request that the following information submitted be held permanent confidential treatment. Permanent Confidential Request -. Schematics -. Block Diagram -. Operationa l Description -. Antenna specification -. U-NII Device SW Security Statement W e also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give temporary confidentiality of commercially sensitive information prior to product release. Short-Term Confidential Request -. External Photos -. Internal Photos -. Test set-up photo -. User Manual If you have any questions, please feel free to contact me at the address shown below. Sincerely, Ji nsun Lim/ CEO

People and Technology 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea U-NII Clients without radar detection statement TO WHOM IT MAY CONCERN We, People and Technology declare that our product IP-WLBG-4CH`s client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons support ad-hoc peer- to-peer modes. Best Regards. Jinsun Lim/ CEO

People and Technology 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea Tel. +82-70-8650-3640 . WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2AS6EIP-WLBG-4CH Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo-location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: Jinsun Lim / CEO Signature:

This test report shall not be reproduced, except in full, without the written approval External photos of EUT This test report shall not be reproduced, except in full, without the written approval This test report shall not be reproduced, except in full, without the written approval This test report shall not be reproduced, except in full, without the written approval

FCC Label Location Label Here BACK Panel : USB Port (Power IN): Ant Port Model : IP-WLBG-4CHS/N : WG4C020010001Wi-Fi Mac : C0885BF00064Rating : DC 5 V, 3 AManufactured by People and TechnologyMade in KoreaTel : +82-70-8650-3600 BarcodeBarcode FCC Label Drawing 40.2 mm 20.2 mm FCC ID : 2AS6EIP-WLBG-4CH This device complies with p art 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not ca use harmful interference, and (2) this device must accept any interference received, including inter ference that may cause undesired operation.

This test report shall not be reproduced, except in full, without the written approval Internal photos of EUT This test report shall not be reproduced, except in full, without the written approval

This test report shall not be reproduced, except in full, without the written approval * RF Exposure 1. Regulation Regulation This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC rules and Regulations. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Table 1 – Limits for Maximum Permissible Exposure (MPE) Frequency Range (㎒) Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] (A) Limits for Occupational / Controlled Exposure 0.3 ~ 3.0 614 1.63 *100 6 3.0 ~ 30 1842/f 4.89/f *900/f 2 6 30 ~ 300 61.4 0.163 1.0 6 300 ~ 1 500 / / f/300 6 1 500 ~ 15 000 / / 5 6 (B) Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19/f *180/f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density Per the guidance of KDB 680106, the E-field and H-field limits shown in the table above are extended down to 100 ㎑ in Appendix C): 1) For test separation distances > 50 ㎜ and < 200 ㎜, the power threshold at the corresponding test separation distance at 100 ㎒ in step b) is multiplied by [1 + log(100/f(㎒))] 2) For test separation distances ≤ 50 ㎜, the power threshold determined by the equation in c) 1) for 50 ㎜ and 100 ㎒ is multiplied by ½ 3) SAR measurement procedures are not established below 100 ㎒. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any SAR test results below 100 ㎒ to be acceptable. This test report shall not be reproduced, except in full, without the written approval 2. Result MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01 () SPGRRPGS ππ4 4 2 =⇒= S = power density [㎽/㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation is conjunction with any other antenna or transmitter. A minimum separation distance of 20 ㎝ must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. Note. 1. The power density P d (5th column) at a distance of 20 ㎝ calculated from the friis transmission Formula is far below the limit of 1 ㎽/㎠. This test report shall not be reproduced, except in full, without the written approval Calculation Result of RF Exposure Maximum tune-up tolerance (Worst Case) RF Mode Frequency [㎒] Max Tune-up Power [㏈m] Ant Gain [㏈i] Power density at 20 ㎝ [㎽/㎠] Limit [㎽/㎠] BLE_ANT1 BLE (1 Mbps/Packet 37) 2 480 -1.00 2.44 0.000 35 1.00 BLE_ANT2 BLE (1 Mbps/Packet 37) 2 480 -1.00 2.44 0.000 35 1.00 BLE_ANT3 BLE (1 Mbps/Packet 37) 2 480 -1.00 2.44 0.000 35 1.00 BLE_ANT4 BLE (1 Mbps/Packet 37) 2 480 -1.00 2.44 0.000 35 1.00 WLAN 2.4 ㎓ 802.11b (1 Mbps) 2 412 11.00 2.44 0.004 39 1.00 WLAN 5 ㎓ (UNII-1) 802.11a (6 Mbps) 5 200 0.00 2.27 0.000 34 1.00 WLAN 5 ㎓ (UNII-2 A) 802.11a (6 Mbps) 5 260 -1 .00 3.81 0.000 38 1.00 WLAN 5 ㎓ (UNII-2 C) 802.11a (6 Mbps) 5 600 -1 .00 5.20 0.000 52 1.00 WLAN 5 ㎓ (UNII-3) 802.11a (6 Mbps) 5 825 -1 .00 4.24 0.000 42 1.00 Simultaneous Transmission (Worst Case) RF Mode Frequency [㎒] Max Tune-up Power [㏈m] Ant Gain [㏈i] Power density at 20 ㎝ [㎽/㎠] Limit [㎽/㎠] BLE (1 Mbps/Packet 37)_ANT1+2+3+4 + WLAN 5 ㎓ (UNII-1) 802.11a (6 Mbps) 0.001 74 1.00

verify No.686575942735 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (2) of (59) KCTL-TIR001-003/6 KP21-05777 REPORT REVISION HISTORY Date Revision Page No 2022-04-04 Originally issued - 2022-04-20 Updated 6, 43 This report shall not be reproduced except in full, without the written approval of KCTL Inc. This document may be altered or revised by KCTL Inc. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KCTL Inc. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (3) of (59) KCTL-TIR001-003/6 KP21-05777 CONTENTS 1. General information ......................................................................................................4 2. Device information ........................................................................................................4 2.1. Frequency/channel operations................................................................................5 2.2. Duty Cycle Factor ...................................................................................................5 3. Antenna requirement ....................................................................................................6 4. Summary of tests ..........................................................................................................7 5. Measurement uncertainty .............................................................................................8 6. Measurement results explanation example ..................................................................9 7. Test results ................................................................................................................. 10 7.1. Maximum peak output power ................................................................................ 10 7.2. Peak Power Spectral Density ............................................................................... 13 7.3. 6 ㏈ Bandwidth(DTS Channel Bandwidth) .......................................................... 17 7.4. Spurious Emission, Band Edge and Restricted bands .......................................... 21 7.5. Conducted Spurious Emission .............................................................................. 44 8. Measurement equipment ............................................................................................ 59 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (4) of (59) KCTL-TIR001-003/6 KP21-05777 1. General information Client : People and Technology Address : 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea Manufacturer : People and Technology Address : 2rd floor(Samsung-dong, Youngchang Building), 27, Samseong-ro 95-gil, Gangnam-gu, Seoul, Republic of korea Laboratory : KCTL Inc. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 CAB Identifier: KR0040 ISED Number: 8035A KOLAS No.: KT231 2. Device information Equipment under test : BLE Scanner Model : IP-WLBG-4CH Modulation technique : Bluetooth Low Energy _GFSK WIFI(802.11a/b/g/n_HT20)_DSSS, OFDM Number of channels : Bluetooth Low Energy : 40 ch 802.11b/g/n_HT20 : 13 ch UNII-1: 4 ch (20 ㎒) UNII-2A: 4 ch (20 ㎒) UNII-2C: 11 ch (20 ㎒) UNII-3: 5 ch (20 ㎒) Power source : DC 5 V Antenna specification : Monopole Antenna Antenna gain : Bluetooth Low Energy : 2.44 ㏈i 802.11 b/g/n_HT20 : 2.44 ㏈i UNII-1 : 2.27 ㏈i UNII-2A : 3.81 ㏈i UNII-2C : 5.20 ㏈i UNII-3 : 4.24 ㏈i Frequency range : Bluetooth Low Energy : 2 402 ㎒ ~ 2 480 ㎒ 802.11b/g/n_HT20 : 2 412 ㎒ ~ 2 472 ㎒ UNII-1: 5 180 ㎒ ~ 5 240 ㎒ (802.11a) UNII-2A: 5 260 ㎒ ~ 5 320 ㎒ (802.11a) UNII-2C: 5 500 ㎒ ~ 5 720 ㎒ (802.11a) UNII-3: 5 745 ㎒ ~ 5 825 ㎒ (802.11a) Software version : 1.0 Hardware version : 1.0 Test device serial No. : N/A Operation temperature : -20 °C ~ 50 °C KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (5) of (59) KCTL-TIR001-003/6 KP21-05777 2. 1. Frequency/channel operations This device contains the following capabilities: WiFi (802.11a/b/g/n), Bluetooth (BLE) Ch. Frequency (㎒) 00 2 402 . . . . 19 2 440 . . . . 39 2 480 Table 2.1.1. Bluetooth Low Energy 2. 2. Duty Cycle Factor Test mode Period (ms) On time (ms) Duty cycle Duty Cycle Factor (dB) (Linear) (%) 1M Bits/s, 37 Packet (Port 1) 2.224 2.107 0.947 4 94.74 0.23 1M Bits/s, 37 Packet (Port 2) 2.224 2.107 0.947 4 94.74 0.23 1M Bits/s, 37 Packet (Port 3) 2.224 2.107 0.947 4 94.74 0.23 1M Bits/s, 37 Packet (Port 4) 2.224 2.107 0.947 4 94.74 0.23 Notes. 1. Duty cycle (Linear) = Ton time / Period 2. DCF(Duty cycle factor) = 10log(1/duty cycle) 3. DCF is not compensated to average result if the duty cycle is more than 98% KCTL Inc. 65, S…

Text truncated - open the document above for the full version.

KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (33) of (59) KCTL-TIR001-003/6 KP21-05777 Middle Channel Port Frequency Pol. Reading Antenna Factor Amp. + Cable DCF Result Limit Margin [㎒] [V/H] [㏈(㎶)] [㏈] [㏈] [㏈] [㏈(㎶/m)] [㏈(㎶/m)] [㏈] Peak data 1 2 312.13 1) V 67.16 31.79 -45.67 - 53.28 74.00 20.72 2 568.28 V 67.95 32.31 -45.21 - 55.05 74.00 18.95 3 996.17 1) V 63.66 33.40 -52.88 - 44.18 74.00 29.82 4 880.22 1) H 60.63 33.62 -51.54 - 42.71 74.00 31.29 5 999.89 V 63.73 35.20 -50.98 - 47.95 74.00 26.05 7 319.39 1) V 63.00 35.37 -49.78 - 48.59 74.00 25.41 2 2 312.06 1) V 66.61 31.79 -45.67 - 52.73 74.00 21.27 2 568.36 V 68.89 32.31 -45.21 - 55.99 74.00 18.01 4 846.23 1) H 60.92 33.63 -51.55 - 43.00 74.00 31.00 6 000.34 V 64.52 35.20 -50.98 - 48.74 74.00 25.26 7 351.56 1) H 58.52 35.36 -49.78 - 44.10 74.00 29.90 3 3 991.64 1) H 64.88 33.39 -52.87 - 45.40 74.00 28.60 4 880.22 1) V 60.73 33.62 -51.54 - 42.81 74.00 31.19 5 999.44 H 63.64 35.20 -50.98 - 47.86 74.00 26.14 6 538.66 V 61.16 35.32 -49.77 - 46.71 74.00 27.29 7 318.94 1) V 61.72 35.37 -49.78 - 47.31 74.00 26.69 4 2 311.99 1) V 67.62 31.79 -45.67 - 53.74 74.00 20.26 2 376.00 1) V 68.61 31.93 -45.64 - 54.90 74.00 19.10 2 504.14 V 68.96 32.21 -45.34 - 55.83 74.00 18.17 2 568.28 V 70.32 32.31 -45.21 - 57.42 74.00 16.58 3 983.03 1) H 63.39 33.39 -52.87 - 43.91 74.00 30.09 4 147.52 1) H 61.62 33.49 -52.63 - 42.48 74.00 31.52 4 879.77 1) H 65.76 33.62 -51.54 - 47.84 74.00 26.16 5 999.89 V 63.57 35.20 -50.98 - 47.79 74.00 26.21 7 320.75 1) V 60.04 35.37 -49.78 - 45.63 74.00 28.37 Average Data 1 2 312.13 1) V 64.37 31.79 -45.67 0.23 50.72 54.00 3.28 2 2 312.06 1) V 63.07 31.79 -45.67 0.23 49.42 54.00 4.58 3 No spurious emissions were detected within 20 ㏈ of the limit. 4 2 311.99 1) V 64.62 31.79 -45.67 0.23 50.97 54.00 3.03 2 376.00 1) V 66.60 31.93 -45.64 0.23 53.12 54.00 0.88 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (34) of (59) KCTL-TIR001-003/6 KP21-05777 Average Data (Port 1) Average Data (Port 2) Average Data (Port 3) Average Data (Port 4)_2 311 ㎒ Blank Average Data (Port 4) _2 376 ㎒ Blank KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (35) of (59) KCTL-TIR001-003/6 KP21-05777 Horizontal/Vertical for 1 ㎓ ~ 3.5 ㎓ (Port 1) Horizontal/Vertical for 3.5 ㎓ ~ 18 ㎓ (Port 1) Horizontal/Vertical for 1 ㎓ ~ 3.5 ㎓ (Port 2) Horizontal/Vertical for 3.5 ㎓ ~ 18 ㎓ (Port 2) KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (36) of (59) KCTL-TIR001-003/6 KP21-05777 Horizontal/Vertical for 1 ㎓ ~ 3.5 ㎓ (Port 3) Horizontal/Vertical for 3.5 ㎓ ~ 18 ㎓ (Port 3) Horizontal/Vertical for 1 ㎓ ~ 3.5 ㎓ (Port 4) Horizontal/Vertical for 3.5 ㎓ ~ 18 ㎓ (Port 4) KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (37) of (59) KCTL-TIR001-003/6 KP21-05777 High Channel Port Frequency Pol. Reading Antenna Factor Amp. + Cable DCF Result Limit Margin [㎒] [V/H] [㏈(㎶)] [㏈] [㏈] [㏈] [㏈(㎶/m)] [㏈(㎶/m)] [㏈] Peak data 1 2 351.98 1) V 67.36 31.87 -45.65 - 53.58 74.00 20.42 2 608.20 V 68.92 32.37 -45.14 - 56.15 74.00 17.85 2 483.61 1) V 49.10 32.16 -27.20 - 54.06 74.00 19.94 3 985.30 1) H 65.85 33.39 -52.87 - 46.37 74.00 27.63 4 959.97 1) V 61.16 33.61 -51.68 - 43.09 74.00 30.91 5 999.89 V 62.73 35.20 -50.98 - 46.95 74.00 27.05 7 440.38 1) V 61.11 35.32 -49.78 - 46.65 74.00 27.35 2 2 352.06 1) V 67.35 31.87 -45.65 - 53.57 74.00 20.43 2 607.73 V 68.54 32.37 -45.14 - 55.77 74.00 18.23 2 483.66 1) V 52.19 32.16 -27.20 - 57.15 74.00 16.85 3 990.28 1) H 63.87 33.39 -52.87 - 44.39 74.00 29.61 4 959.52 1) V 61.26 33.61 -51.68 - 43.19 74.00 30.81 6 000.80 V 61.74 35.20 -50.98 - 45.96 74.00 28.04 6 551.80 H 60.46 35.32 -49.77 - 46.01 74.00 27.99 7 439.47 1) V 62.11 35.32 -49.78 - 47.65 74.00 26.35 3 2 493.76 1) V 45.26 32.19 -27.23 - 50.22 74.00 23.78 4 939.58 1) H 60.87 33.61 -51.63 - 42.85 74.00 31.15 5 999.89 H 63.18 35.20 -50.98 - 47.40 74.00 26.60 7 439.47 1) V 59.82 35.32 -49.78 - 45.36 74.00 28.64 4 2 352.05 1) V 67.88 31.87 -45.65 - 54.10 74.00 19.90 2 415.86 V 69.10 32.01 -45.58 - 55.53 74.00 18.47 2 543.91 V 68.55 32.27 -45.26 - 55.56 74.00 18.44 2 608.13 V 71.19 32.37 -45.14 - 58.42 74.00 15.58 2 483.52 1) V 50.20 32.16 -27.20 - 55.16 74.00 18.84 4 960.42 1) H 67.76 33.61 -51.68 - 49.69 74.00 24.31 6 000.34 V 63.80 35.20 -50.98 - 48.02 74.00 25.98 7 440.38 1) V 59.98 35.32 -49.78 - 45.52 74.00 28.48 Average Data 1 2 351.98 1) V 64.81 31.87 -45.65 0.23 51.26 54.00 2.74 2 483.61 1) V 35.13 32.16 -27.20 0.23 40.32 54.00 13.68 2 2 352.06 1) V 63.59 31.87 -45.65 0.23 50.04 54.00 3.96 2 483.66 1) V 37.66 32.16 -27.20 0.23 42.85 54.00 11.15 3 No spurious emissions were detected within 20 ㏈ of the limit. 4 2 352.05 1) V 64.93 31.87 -45.65 0.23 51.38 54.00 2.62 2 483.52 1) V 37.83 32.16 -27.20 0.23 43.02 54.00 10.98 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (38) of (59) KCTL-TIR001-003/6 KP21-05777 Average Data (Port 1) Average Data (Port 2) Average Data (Port 3) Average Data (Port 4) Blank KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR22-SRF0042-A Page (39) of (59) KCTL-TIR001-003/6 KP21-05777 Horizontal/Vertical for Band-edge (Port 1) Horizontal/Vertical for Band-edge (Port 1) Horizontal/Vertical for Band-edge (Port 2) Horizontal/Vertical for Band-edge (Port 2) KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gye…
