Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
8800 PREFACE Thank you for purchasing our dual band portable two way radio. This easy-to-use radio will deliver you secure, instant and reliable communications at peak efficiency. Please read this manual carefully before use. The information presented herein will help you to derive maximum performance from your radio. ContentsUnpacking And Checking Equipment Supplied Accessories Note: If you need to know more information about optional accessories. Please contact us. Item Antenna Belt Clip Hand Strap Li-polymer Battery Charger Adaptor User Manual 1 1 1 1 1 1 1 Quantity 01 Carefully unpack the transceiver. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, please contact the carrier or the dealers immediately. Unpacking and Checking Equipment Product Overview Function Keypad Before Use Charging the Battery Pack Charger LED indicator and charging status USB Charging Battery LED Indicator and battery status Preparation Installing/Removing the Antenna Installing/Removing the Belt Clip Installing/Removing the Battery Installing the Optional Speaker/Microphone(or Headset) Status Indication LED Indicator LCD Icons Basic Operations Menu Functions Troubleshooting Care and Cleaning 01 02 03 05 05 05 06 06 07 07 07 07 08 08 08 09 10 13 15 17 Product OverviewFunction Keypad 0302 No.KeyFunction 【MENU】Menu/Enter Key Exit/Delete Key Switch A/B Band in standby mode Press for 2 Seconds to up rapidly Change the Scan direction in scan status 【UP】 Press for 2 Seconds to down rapidly Change the Scan direction in scan status In Standby status: Input frequency in VFO mode Input channel number in Channel mode In Transmitting status: Input DTMF Code in transmitting status 【DOWN】 【Numeric Keypad】 【EXIT】 No.Part NameNo.Part NameNo.Part Name PF1 Key (LAMP Key) PTT-1 PTT-2 PF2 Key (Programmed Key) LED Indicator Antenna Power On/Off Volume Knob LCD Display Function Keypad Numeric Keypad Speaker Microphone FlashlightAccessories Jack Charging Indicator USB Charging Port Battery Contacts Battery Screw Function Keypad 0504 Before Use Charging the Battery Pack Charger LED indicator and charging status Use only the charger and battery specified by the manufacturer. The charger LED indicates the charging progress. 1.As ① shown, Plug the AC adaptor into the AC outlet, and then plug the cable of the AC adaptor into the DC jack located on the back of the charger. 2.As ② shown, Plug the radio into the charger. Make sure the battery terminals are good in contact with charging terminals. 3.The indicator light turns to red, the charging begins. 4.The indicator light turns to green, the charging is completed. LED indication Constant Green Constant Red Constant Green Standby (no-load) Charging Fully charged Charging status 【PF1】 Press PTT-1 key to transmitting A Band LAMP Key, Short press to turn on/off flashlight Long press for emergency alarm 【PTT-1】 Press PTT-2 key to transmitting B Band 【PTT-2】 【PF2】 Short Press: TX Power/Monitor/Scan Long Press: TX Power/Monitor/Scan Default: TX Power Note: PF2 Key can be setup in PC software. No.KeyFunction Preparation Installing/Removing the Antenna Installing/Removing the Battery Screw the antenna into the connector on the top of the transceiver by holding the antenna at its base and turning it clockwise until secure. Note: Turn the antenna counter-clockwise until you can remove it. 1.Attach the belt clip above the correspond- ing holes on the back of the radio, and screw it clockwise with the two supplied screws. 2.Loosen the screws to remove the belt clip. 1.Match the two top grooves of the battery pack on the back of the radio and then push it. 2.Screw it clockwise to install the battery. 3.Unscrew count- er-clockwise to remove the battery. Installing/Removing the Belt Clip 0706 Before Use Constant Red Constant Green Charging Fully Charged USB Charging Battery LED Indicator and battery status 1.Plug the USB charging cable into the charging port on the back of the battery. 2.The indicator light turns to red, the charging begins. 3.The indicator light turns to green, the charging is completed. Use only the USB charging cable specified by the manufacturer. Charger LED can indicate the charging status. LED indicationCharging status PreparationStatus IndicationLCD Icons LED Indicator Radio Status Transmitting Receiving LED glows red LED glows green LED Indicator Installing the Optional Speaker/Microphone(or Headset) Insert the speaker/micro- phone (or headset) plugs into the speaker/micro- phone jacks. 0908 Icon Radio status Signal Strength Level Low Power High Power DTMF activated CTCSS activated Keypad lock function activated. Press 【 * 】 Key for 2 Seconds to unlock the keypad VOX function enabled Narrow Band selected Battery Level indicator A/B Band Direction, Operation frequency Bluetooth programming function activated DCS activated Position: TX frequency = RX frequency + Offset frequency Negative: TX frequency = RX frequency - Offset frequency Dual watch/ dual reception functions activated Basic OperationsBasic Operations 1110 Powering On/Off Turn the 【Power/Volume knob】 clockwise to switch the transceiver power ON till a click is heard. Adjusting the Volume Rotate the 【Power/Volume knob】 to adjust the volume. Turn clockwise to increase the volume and counter-clockwise to decrease the volume. Enter/Exit Menu Short Press 【MENU】 Key to enter menu, and press 【UP/DOWN】 key to select the function. Press 【MENU】 Key to confirm, Press 【EXIT】 to exit. A/B Band Switch In standby, press 【EXIT】 Key to switch A/B Band. Main Band marked with △. Dual PTT Press 【PTT-1】 to transmit in A Band. Press 【PTT-2】 to transmit in B Band. VFO/Channel Switch In standby, long Press 【MENU】 Key to switch between VFO and channel mode. If the channel list does not have a valid channel number, you cannot switch to channel mode. Side Key To program the side key function via program software. Side key f…
Text truncated - open the document above for the full version.
Fujian Senhaix Electronic Technology Co., Ltd Date: 9 July 2020 Federal Communication Commission Authorization and Evaluation Division FCC ID: 2AS7F8800 Subject: Declaration of compliance to the requirements of §15.121 We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory Fujian Senhaix Electronic Technology Co., Ltd Contact person: Donna Wu
Agent Authorization Company: Fujian Senhaix Electronic Technology Co., Ltd Address: No. 7 Zi Hua Road, Jiangnan Hi-tech Industrial Zone, Licheng, Quanzhou, Fujian, China Product Name: Two Way Radio Model Number(s): 8800 Product Description: Two Way Radio We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-06-30 Name: Donna Wu Company: Fujian Senhaix Electronic Technology Co., Ltd
Fujian Senhaix Electronic Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-06-30 Subject; Request for Confidentiality FCC ID: 2AS7F8800 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Fujian Senhaix Electronic Technology Co., Ltd Contact person: Donna Wu
Fujian Senhaix Electronic Technology Co., Ltd Agent Authorization Company: Fujian Senhaix Electronic Technology Co., Ltd Address: No. 7 Zi Hua Road, Jiangnan Hi-tech Industrial Zone, Licheng, Quanzhou, Fujian, China Product Name: Two Way Radio Model Number(s): 8800 Product Description: Two Way Radio We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-06-30 Name: Donna Wu Company: Fujian Senhaix Electronic Technology Co., Ltd
External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT Antenna BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT
FCC ID Label Location FCC ID: 2AS7F8800
Internal Photos OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 OPEN VIEW OF EUT-3 OPEN VIEW OF EUT-4 OPEN VIEW OF EUT-5 OPEN VIEW OF EUT-6 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 INTERNAL VIEW OF EUT-6 INTERNAL VIEW OF EUT-7 INTERNAL VIEW OF EUT-8 INTERNAL VIEW OF EUT-9
Page 1 of 26 FCC ID : 2AS7F8800 PRODUCT DESIGNATION : Two Way Radio BRAND NAME : SenHaiX MODEL NAME : 8800 APPLICANT : Fujian Senhaix Electronic Technology Co., Ltd DATE OF ISSUE : Jun. 30, 2020 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. FCC Test Report Report No.: AGC01120200601FE08 Report No.: AGC01120200601FE08 Page 2 of 26 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Jun. 30, 2020 Valid Initial Release Report No.: AGC01120200601FE08 Page 3 of 26 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ............................................................................................................... 4 2. PRODUCT INFORMATION ........................................................................................................................... 5 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION .............................................................. 6 4. SUPPORT EQUIPMENT LIST ....................................................................................................................... 7 5. SYSTEM DESCRIPTION ............................................................................................................................... 7 6. SUMMARY OF TEST RESULTS ................................................................................................................... 8 7. FCC RADIATED EMISSION TEST ................................................................................................................ 9 7.1. TEST EQUIPMENT OF RADIATED EMISSION .................................................................................. 9 7.2. LIMITS OF RADIATED EMISSION TEST ............................................................................................ 9 7.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ........................................................................... 9 7.4 PROCEDURE OF RADIATED EMISSION TEST ................................................................................ 11 7.5 TEST RESULT OF RADIATED EMISSION TEST .............................................................................. 12 8. CONDUCTED EMISSION TEST .................................................................................................................. 16 8.1 PROVISIONS APPLICABLE ............................................................................................................... 16 8.2 MEASUREMENT PROCEDURE ........................................................................................................ 16 8.3 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 17 8.4 TEST RESULT .................................................................................................................................... 18 9. ANTENNA CONDUCTED POWER FOR RECEIVERS ............................................................................... 20 10. SANNING RECEIVERS AND FREQUENCY CONVERTERS USED WITH SANNING RECEIVERS. ...... 23 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP .......................................................................................... 25 Report No.: AGC01120200601FE08 Page 4 of 26 1. VERIFICATION OF COMPLIANCE Applicant Fujian Senhaix Electronic Technology Co., Ltd Address No. 7 Zi Hua Road, Jiangnan Hi-tech Industrial Zone, Licheng, Quanzhou, Fujian, China Manufacturer Fujian Senhaix Electronic Technology Co., Ltd Address No. 7 Zi Hua Road, Jiangnan Hi-tech Industrial Zone, Licheng, Quanzhou, Fujian, China Factory Fujian Senhaix Electronic Technology Co., Ltd Address No. 7 Zi Hua Road, Jiangnan Hi-tech Industrial Zone, Licheng, Quanzhou, Fujian, China Product Designation Two Way Radio Brand Name SenHaiX Test Model 8800 Hardware Version SHX8800_V05 Software Version Version V1.0 Measurement Procedure ANSI C63.4: 2014 Date of test Jun. 24, 2020~Jun. 30, 2020 Deviation No any deviation from the test method. Condition of Test Sample Normal The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2014. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Prepared By Calvin Liu (Project Engineer) Jun. 30, 2020 Reviewed By Max Zhang (Reviewer) Jun. 30, 2020 Approved By Forrest Lei (Authorized Officer) Jun. 30, 2020 Report No.: AGC01120200601FE08 Page 5 of 26 2. PRODUCT INFORMATION The EUT is a Two Way Radio designed for voice communication. It is designed by way of utilizing the F3E modulation achieves the system operating. A major technical description of EUT is described as following: Communication Type Voice / Tone only Modulation FM RX Frequency Range RX:136 MHz -174 MHz, 400MHz -470MHz Emission Type F3E Antenna Designation Detachable Antenna Type External Antenna Antenna Gain 2.0dBi Power Supply DC 7.4V, 2000mAh by battery Adapter Parameter Input: AC 100-240V 50/60Hz, 0.6A Output: DC 12V 0.5A Charger Parameter Input: DC 12V Output: DC 8.4V 400mA I/O Port Information (Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with Antenna Port 1 0 1 Report No.: AGC01120200601FE08 Page 6 of 26 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION List Of Test Equipment: TEST EQUIPMENT OF CONDUCTED EMISSION TEST Equipment Manufacturer Model S/N Cal. Date Cal. Due TEST RECEIVER R&S ESCI 100096 Jul. 12, 2019 Jul. 11, 2020 AMN/LISN R&S ESH2-Z5 100086 Aug. 22, 2019 Aug. 21, 2020 TEST SOFTWARE FR EZ-EM…
Text truncated - open the document above for the full version.
Test Setup Photos CONDUCTED EMISSION TEST SETUP RADIATED EMISSION TEST SETUP-BELOW 1GHZ RADIATED EMISSION TEST SETUP-ABOVE 1GHZ
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15B | 400 MHz - 470 MHz | - |
