2AS7K-BZ1PXR20Prelude XR Wireless Power Bank

THANK YOU FOR YOUR ORDER! Learn more about BEZALEL and our full line of wireless charging products at bezalel.co. Contact us at [email protected]. V E.1.8 Battery Capacity Wireless Input USB-C Input Wireless Output 1 Wireless Output 2 USB-C Output USB-C Input + Wireless Output 5Vdc/6500mAh, 9Vdc/3600mAh 5V 1A, 9V 1.2A 5V 3A, 9V 2.2A 5W / 7.5W / 10W / 15W 3W 5V 3A, 9V 2.2A USB-C Input : 5V 3A Wireless Output : 5V 3A (15W) Specifications Prelude XR Wireless Power Bank X1 USB-C Cable X1 User Manual X1 Package Contents FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. Safety & Handling Keep wireless charging unit dry and away from liquids. Do not use on wet surfaces. Do not attempt to disassemble or modify charger. Always disconnect power supply before cleaning charger. Keep away from high heat. Use in the temperature range between -5 and 45 degrees Celsius (23 and 113 degrees Fahrenheit). Don't place credit cards, security badges, passports or key fobs between your iPhone and Prelude XR. This may damage magnetic strips or RFID chips in those items. If you have a case that holds any of these sensitive items, remove them before charging or make sure that they aren’t between the back of your device and Prelude XR. Your iPhone or Prelude XR might get slightly warmer while your iPhone charges. To extend the lifespan of your battery, if the battery gets too warm, software might limit charging for up until 80 percent only. If you keep your iPhone in a leather case while charging with your Prelude XR, the case might show imprints from compression of the leather. This is normal. But if you’re concerned about this, we suggest using a non-leather case. 1. 2. 3. 4. 5. 6. 7. 8. 2. Press the Power Button for about a second. Then Power Indicator will light up and Prelude XR is ready for use. 1. Wired Charging Connect the Prelude XR to your phone with a USB-C cable (not included). 0% - 10% 10% - 30% 30% - 100% (blinking) Wired Charging Power Indicator 2. Wireless Charging 2 Press the Power Button for about a second. Then Power Indicator will light up and Prelude XR is ready for use. 1. Gently place your AirPods Case wireless charging area onto Prelude XR Wireless Charging Area 2. 0% - 10% 10% - 30% 30% - 100% (blinking) Wireless Charging Power Indicator 2. 3. Charging Your Device with Prelude XR After the Prelude XR is fully charged, you can use it to charge your wireless or non-wireless devices. Wireless Charging 1 Press the Power Button for about a second. Then Power Indicator will light up and Prelude XR is ready for use. 1. Gently attach Prelude XR Wireless Charging Area 1 onto your iPhone wireless charging area. *When in the Sandwich Charging Mode (Prelude XR wirelessly charges the iPhone while it is being wirelessly charged). Please make sure that Prelude XR has more than 30% battery power (blue light). Only then, the system will charge the iPhone. Wireless charging is in progress. Plug the end of USB-C cable into Prelude XR USB-C port. Plug the other end of the cable into the power adapter (not included). * Use PD2.0/AFC/FCP/SCP/PE1.1 USB adapter for improved and fast recharging experience. *At the same time, you can wireless charge your iPhone. Gently attach Prelude XR Wireless Charging Area 1 onto your iPhone wireless charging area. Wireless Charging 0% - 30% 30% - 99% 100% (breathing) (breathing) Gently attach Prelude XR Wireless Charging Area 2 onto powered Prelude XS Power Adapter (not included). * If the Wireless Charging Area 2 was used for output charging, please turn off Prelude XR (by pressing the Power Button for 3 seconds) before wirelesss charing it with Prelude XS. Charging Prelude XR Fully charge Prelude XR before using for the first time. Wireless Charging 0% - 30% 30% - 99% 100% (breathing) (breathing) Welcome to Prelude XR Press and hold the Power Button for about a second and the Power Indicator will light up. Prelude XR will go into standby mode for 2 minutes. After that, your Prelude XR is ready to go! Prelude XR will automatically turn off if there is no action for 2 minutes or by pressing the Power Button for 3 seconds. If the battery power is too low for output, the Power Indicator will blink red. Please fully charge it. Prelude XR as a Stand The fold-out stand can be unfolded and used as a phone stand. 1 2 0% - 10% 10% - 30% 30% - 100% (blinking) Wireless Charging Area 1 USB-C Port Power Indicator Wireless Charging Area 2 Power Button Fold-Out …

Text truncated - open the document above for the full version.

BEZALEL INC. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Product Name: Prelude XR Wireless Power Bank FCC ID: 2AS7K-BZ1PXR20 Model(s): BZ1PXR20 2.911(d)(5)(i) Equipment Type We, [BEZALEL INC.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Date: 2023.3.22 Title and Company name: Helen Cheng/ Operation Manager NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

BEZALEL INC. 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Product Name: Prelude XR Wireless Power Bank FCC ID: 2AS7K-BZ1PXR20 Model(s): BZ1PXR20 2.911(d)(5)(ii) Applicant filing We, [BEZALEL INC.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Date: 2023.3.22 Title and Company name: Helen Cheng/ Operation Manager NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

BEZALEL INC. 2.911 (d)(7)USA Agent v1.2 Section 2.911(d)(7) USA Agent for Service of Process Company name: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Product Name: Prelude XR Wireless Power Bank FCC ID: 2AS7K-BZ1PXR20 Model(s): BZ1PXR20 2.911(d)(7) USA Designated Agent for Service of Process We, [BEZALEL INC.] (“the applicant”) designate [BEZALEL INC.] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States FRN Number: 0028444271 Contact Name: Helen Cheng Telephone No: +1 424.625.4011 Email: [email protected] Applicant Company name: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States FCC Grantee Code: 2AS7K Contact Name: Helen Cheng Telephone No: +1 424.625.4011 Email: [email protected] BEZALEL INC. 2.911 (d)(7)USA Agent v1.2 Signature: Title: Operation Manager Signature: Title: Operation Manager Date:2023.3.22 Date: 2023.3.22 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

BEZALEL INC. Authorization Company: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Product Name: Prelude XR Wireless Power Bank Model Number(s): BZ1PXR20 Product Description: Prelude XR Wireless Power Bank We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023/03/22 Name: Helen Cheng Title: Operation Manager Company: BEZALEL INC.

BEZALEL INC. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023/03/22 Subject; Request for Confidentiality FCC ID: 2AS7K-BZ1PXR20 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Helen Cheng Title: Operation Manager

External Photos

Size:10*10mm FCC ID: 2AS7K-BZ1PXR20 Label location

Internal Photos Antenna ANT1 Antenna ANT2

Fine Page 1 of 4 线 圈 规 格 书 客 戶： CUSTOMER: 客 戶 料 號： CUST P/N: Y.009.0025 料 號： FINE P/N: G511-6.3UH±10% 单线圈0.08*80*10TS 産 品 型 號： DESC: Φ42.5MMX42.5MMX1.0MM 日 期： DATE: 2021-7-20 版 本： Version: A.0 Fine Page 2 of 4 版本變更履歷 SPECIFICATION 産 品 型 號： Φ20.5x43-6.3uH-0.08x105-6mm-50C 版本 Rev：A.0 客戶CUST: XXX 客户料号CUST P/N: Y.009.0025 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 40.5±1.0 B 20.5±0.5 C Max D 22Max E 5±2 MM F 42.5Max G 5MMref H 2.2 Max I 4.3 ref M J K 注： 1.交叉出线; 2.出线位置缠8mm(ref)宽度高 温胶纸1-2Ts; 3.线圈贴圆形硬磁片带槽，磁 片尺寸42.5±1mm,内孔 4.3mm,厚度为1.0±0.2mm 4.双开槽。 Fine Page 3 of 4 三、绕线参数Winding Specification: NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 漆包线0.08*80P 10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 3.8uH ±20% 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 6.3uH ±10% 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤50mΩ LCZ METER 502B 擬制/日期PREPARED BY/DATE 審核/日期CHECKED BY/DATE

No.：BCTC/RF-EMC-005 Page 1 of 33 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2212689738-1E Applicant: BEZALEL INC. Product Name: Prelude XR Wireless Power Bank Model/Type Ref.: BZ1PXR20 Tested Date: 2022-12-06 to 2023-03-27 Issued Date: 2023-03-27 Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 2 of 33 Edition：A.5 FCC ID: 2AS7K-BZ1PXR20 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Prelude XR Wireless Power Bank Trademark: BEZALEL Model/Type Ref.: BZ1PXR20 Prepared For: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Manufacturer: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-12-06 Sample tested Date: 2022-12-06 to 2023-03-27 Issue Date: 2023-03-27 Report No.: BCTC2212689738-1E Test Standards: FCC Part15.209 ANSI C63.10-2013 Test Results: PASS Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 3 of 33 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 4 2. Test Summary ....................................................................................................... 5 3. Measurement Uncertainty ..................................................................................... 6 4. Product Information And Test Setup ..................................................................... 7 4.1 Product Information ............................................................................................... 7 4.2 Support Equipment ............................................................................................... 7 4.3 Test Setup Configuration ...................................................................................... 8 4.4 Test Mode ............................................................................................................. 8 5. Test Facility And Test Instrument Used ................................................................. 9 5.1 Test Facility ........................................................................................................... 9 5.2 Test Instrument Used ............................................................................................ 9 6. Conducted Emissions .......................................................................................... 11 6.1 Block Diagram Of Test Setup .............................................................................. 11 6.2 Limit .................................................................................................................... 11 6.3 Test Procedure ................................................................................................... 11 6.4 EUT Operating Conditions .................................................................................. 11 6.5 Test Result (Coil ANT 2) ..................................................................................... 12 Coil ANT 1 ................................................................................................................... 14 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test Procedure ................................................................................................... 17 7.4 Test Result .......................................................................................................... 18 8. Bandwidth Test .................................................................................................... 25 9. Antenna Requirements ........................................................................................ 28 10. EUT Photographs ................................................................................................ 29 11. EUT Test Setup Photographs.............................................................................. 30 (Note: N/A Means Not Applicable) Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 4 of 33 Edition：A.5 1. Version Report No. Issue Date Description Approved BCTC2212689738-1E 2023-03-27 Original Valid Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 5 of 33 Edition：A.5 2. Test Summary The Product has been tested according to the following specifications: No. Test Parameter Clause No Results 1 Conducted Emission 15.207 PASS 2 Radiated Emission 15.209 PASS 3 20dB Bandwidth 15.215 PASS 4 Antenna Requirement 15.203 PASS Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 6 of 33 Edition：A.5 3. Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the Product as specified in CISPR 16-4-2. This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. No. Item Uncertainty 1 3m chamber Radiated spurious emission(9kHz-30MHz) U=3.7dB 2 3m chamber Radiated spurious emission(30MHz-1GHz) U=4.3dB 3 3m chamber Radiated spurious emission(1GHz-18GHz) U=4.5dB 4 3m chamber Radiated spurious emission(18GHz-40…

Text truncated - open the document above for the full version.

No.：BCTC/RF-EMC-005 Page 1 of 34 Edition：A.5 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2212689738-2E Applicant: BEZALEL INC. Product Name: Prelude XR Wireless Power Bank Model/Type Ref.: BZ1PXR20 Tested Date: 2022-12-06 to 2023-03-27 Issued Date: 2023-03-27 Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 2 of 34 Edition：A.5 FCC ID: 2AS7K-BZ1PXR20 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Prelude XR Wireless Power Bank Trademark: BEZALEL Model/Type Ref.: BZ1PXR20 Prepared For: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Manufacturer: BEZALEL INC. Address: 3528 Torrance Blvd., Ste. 215, Torrance, CA 90503, United States Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2022-12-06 Sample tested Date: 2022-12-06 to 2023-03-27 Issue Date: 2023-03-27 Report No.: BCTC2212689738-2E Test Standards: FCC CFR 47 part1, 1.1307(b), 1.1310 Test Results: PASS Tested by: Approved by: Brave Zeng/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 3 of 34 Edition：A.5 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 4 2. Product Information ............................................................................................... 5 2.1 Product Information ............................................................................................... 5 2.2 Support Equipment ............................................................................................... 5 2.3 Test Mode ............................................................................................................. 5 3. Test Facility And Test Instrument Used ................................................................. 6 3.1 Test Facility ........................................................................................................... 6 3.2 Test Instrument Used ............................................................................................ 6 4. Method Of Measurement ....................................................................................... 7 4.1 Applicable Standard .............................................................................................. 7 4.2 Block Diagram Of Test Setup ................................................................................ 7 4.3 Limit ...................................................................................................................... 8 4.4 Test Procedure ..................................................................................................... 8 4.5 Equipment Approval Considerations ..................................................................... 9 4.6 E And H Field Strength ....................................................................................... 10 5. Photographs Of Test Set-Up ............................................................................... 22 (Note: N/A Means Not Applicable) Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 4 of 34 Edition：A.5 1. Version Report No. Issue Date Description Approved BCTC2212689738-2E 2023-03-27 Original Valid Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 5 of 34 Edition：A.5 2. Product Information 2.1 Product Information Model/Type Ref.: BZ1PXR20 Model differences: N/A Product Description: Prelude XR Wireless Power Bank Operation Frequency: 115kHz-205kHz Antenna installation: loop coil antenna Ratings: USB-C Input: 5V3A;9V2.2A Input:Wireless:5V/1A,9V1.2A USB-C Output:5V/3A;9V/2.2A Wireless 1: Output:5W,7.5W,10W,15W Wireless 2:3W Hardware Version: N/A Software Version: N/A Cable of Product No. Cable Type Quantity Provider Length (m) Shielded Note 1 -- -- Applicant --- Yes/No With a ferrite ring in mid Detachable 2 -- -- BCTC -- Yes/No -- 2.2 Support Equipment No. Device Type Brand Model Series No. Note 1. Wireless load --- --- --- auxiliary Notes: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 2.3 Test Mode Test Modes 1 Charging +Wireless（5W） Test Modes 2 Wireless Charging 3W Test Modes 3 Wireless Charging 5W Test Modes 4 Wireless Charging 7.5W Test Modes 5 Wireless Charging 10W Test Modes 6 Wireless Charging 15W Test Modes 7 Wireless Charging 5W+ Type-C Output 5V1.25A Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 6 of 34 Edition：A.5 3. Test Facility And Test Instrument Used 3.1 Test Facility All measurement facilities used to collect the measurement data are located at Shenzhen BCTC Testing Co., Ltd. Address:1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China. The site and apparatus are constructed in conformance with the requirements of ANSI C63.4 and CISPR 16-1-1 other equivalent standards. FCC Test Firm Registration Number: 712850 IC Registered No.: 23583 3.2 Test Instrument Used EMF Test Equipment Manufacturer Model# Serial# Last Cal. Next Cal. Electromagnet -ic radiation tester Wavecontrol SMP160 19SN0980 May 26, 2022 May 25, 2023 Electromagne- tic field probe Wavecontrol WP400-3 20WP120082 Sept. 08, 2022 Sept. 07, 2023 Report No.: BCTC2212689738-2E No.：BCTC/RF-EMC-005 Page 7 of 34 Edition：A.5 4. Method Of Measurement 4.1 Applicable Standard According t…

Text truncated - open the document above for the full version.

Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 30 of 33 Edition：A.5 11.EUT Test Setup Photographs Conducted emissions Photo(Coil ANT1) Coil ANT Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 31 of 33 Edition：A.5 Radiated Measurement Photos(Coil ANT2) Report No.: BCTC2212689738-1E No.：BCTC/RF-EMC-005 Page 32 of 33 Edition：A.5
