2ASBN-TWS-10NBluetooth ANC True Wireless Earphones

Bluetooth Connection LED 25% 50% 75% 100% User Manual TWS- 10N Bluetooth ANC True Wireless Earphones 1. 2. 3. 4. 5. 6. 7. 8. Power On/Off As soon as take out earbuds from the charging case, TWS-10N turns on automatically. Put earbuds into the charging case,TWS-10N turns off automatically. (Cannot power On/Off manually) Answer/Hang up/Reject the Call In incoming call, click L or R earbud to answer the phone call. In incoming call, long press 2 seconds on L or R earbud to reject the call. When in calling, double-click L or R earbud to hang up the phone call. Voice assistant Long press 2 seconds L earbud to turn on voice assistant. Play/Pause music When playing music, double-click L or R earbud to play/pause music. Last song/Next song When playing music, three-click L earbud to return to the previous song. When playing music, three-click R earbud to next song. ANC mode In normal mode, hold R earbud for 2 seconds to turn on ANC. Please use the provided charging cable to recharge the earbuds by the charging case. Charging case LED indicator in green when charging. After full recharged, four LED indicator on the charging case are always on. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Wear the right size ear caps for your ears. Adjusting earbuds correctly achieves the best noise reduction performance and sound quality. Avoid prolonged exposure to excessive volume that may cause noise-induced hearing impairment. Turn the volume down before putting on your headphones, then adjust it to the right volume. Don't use headphones while driving or riding your bike Stay away from sharp edges, uneven surfaces, metal parts, and anything that could damage the headphones. Do not modify, repair or remove headphones without professional guidance. Do not use corrosive or volatile liquid to clean the earphone Do not use headphones in dangerous environments. This headphone contains small parts, which may cause choking hazard. Please keep away from children and pets to prevent accidents. Battery warning: *Improper use of the battery may cause fire or chemical burns.The battery may explode in case of damage. *The battery can only be charged using an adapter specially provided for this product. *Please dispose of batteries according to local regulations.Recycle if possible.Do not dispose of batteries as household waste or throw them into a fire, lest they explode. *Please refer to the user manual for instructions on the charging status indicator. LED Light Charging FCC Statement Accessories ResetNotes OperatingOperating BLUETOOTH TWS-10N Left Earphone Right Earphone Left Earphone Right Earphone Using dual earbuds mode After take out "TWS-10N" from the charging case, both of L&R earbuds turn on automatically with voice prompt "Power on". Soon later, L & R earbuds pair automatically, and the R earbud LED indicator blinks in red and green color. Using single earbud mode If you only take out L or R earbud from the charging case, it turns on automatically with voice prompt "Power on", and the LED indicator on L or R earbud will blink in red and green alternately. Connect with your cell phone: When you hear voice prompts "Power on", after connected, R earbud LED indicator will blink red and green alternately. Activate your cell phone Bluetooth and search "TWS-10N". Choose and click "TWS-10N" on mobile phone, then you will hear "connected". Start to enjoy music after you finished the above steps. As soon as you take out TWS-10N from the charging case, long press R earbud 10 seconds till the red LED indicator on R earbud keep blinking 5 times, it means cleared pairing. Put the earbud into the charging case again and then take out both earbuds from the charging case, you can see earbud are in pairing mode with promps “Power on”. After paired, R earbud LED indicator blinks in red and green, then you can start using TWS-10N.

GOLD FINGERS TECHNOLOGY CO.,LTD 2020-01-09 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ASBN-TWS-10N Product Name: Bluetooth ANC True Wireless Earphones Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description • BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Meiling Xu Title: Sourcing Company: GOLD FINGERS TECHNOLOGY CO.,LTD

GOLD FINGERS TECHNOLOGY CO.,LTD 2020-01-09 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongce Testing Lab. / 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with GOLD FINGERS TECHNOLOGY CO.,LTD / 7F, C15 Bldg., Fuyuan Industrial Park, No.598 Zhoushi Rd, Bao'an District, Shenzhen 518126, China (Applicant Name and address) <Signature> Name: Meiling Xu Title: Sourcing Applicant Company: GOLD FINGERS TECHNOLOGY CO., LTD

Page 1 of 11 Appendix B: Photographs of EUT Product: Bluetooth ANC True Wireless Earphones Model: TWS-10N External Photos Page 2 of 11 Page 3 of 11 Page 4 of 11 Page 5 of 11 Page 6 of 11 Left Page 7 of 11 Page 8 of 11 Page 9 of 11 Right Page 10 of 11 Page 11 of 11

Label Artwork and Location Model: TWS-10N Label: Size: L*W=25*8mm FCC ID: 2ASBN-TWS-10N Location

Page 1 of 6 Appendix B: Photographs of EUT Product: Bluetooth ANC True Wireless Earphones Model: TWS-10N Internal Photos Left Page 2 of 6 Page 3 of 6 Page 4 of 6 Right Page 5 of 6 Antenna Page 6 of 6

RF exposure evaluation FCC ID: 2ASBN-TWS-10N §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  For BDR+EDR: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 1.34 1±1 2.00 1.58 5 0.50 3.0  For BLE: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 1.59 1±1 2.00 1.58 5 0.50 3.0 Result: Base on the calculation value, No SAR measurement is required.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2ASBN-TWS-10N Product: Bluetooth ANC True Wireless Earphones Model No.: TWS-10N Additional Model No.: N/A Trade Mark: N/A Report No.: TCT200103E007 Issued Date: Jan. 13, 2020 Issued for: GOLD FINGERS TECHNOLOGY CO., LTD 7F, C15 Bldg., Fuyuan Industrial Park, No.598 Zhoushi Rd, Bao'an District, Shenzhen 518126, China Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT200103E007 Page 2 of 36 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. Emission Bandwidth ........................................................................................... 16 6.5. Power Spectral Density ....................................................................................... 19 6.6. Test Specification ................................................................................................ 19 6.7. Conducted Band Edge and Spurious Emission Measurement ....................... 22 6.8. Radiated Spurious Emission Measurement ...................................................... 25 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT200103E007 Page 3 of 36 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Bluetooth ANC True Wireless Earphones Model No.: TWS-10N Additional Model No.: N/A Trade Mark: N/A Applicant: GOLD FINGERS TECHNOLOGY CO., LTD Address: 7F, C15 Bldg., Fuyuan Industrial Park, No.598 Zhoushi Rd, Bao'an District, Shenzhen 518126, China Manufacturer: GOLD FINGERS TECHNOLOGY CO., LTD Address: 7F, C15 Bldg., Fuyuan Industrial Park, No.598 Zhoushi Rd, Bao'an District, Shenzhen 518126, China Date of Test: Jan. 06, 2020 – Jan. 10, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Jan. 10, 2020 Brave Zeng Reviewed By: Date: Jan. 13, 2020 Beryl Zhao Approved By: Date: Jan. 13, 2020 Tomsin Report No.: TCT200103E007 Page 4 of 36 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.247 (a)(2) PASS Power Spectral Density §15.247 (e) PASS Band Edge §15.247(d) PASS Spurious Emission §15.205/§15.209 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT200103E007 Page 5 of 36 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: Bluetooth ANC True Wireless Earphones Model No.: TWS-10N Additional Model No.: N/A Trade Mark: N/A Bluetooth Version: V5.0 (This report is for BLE) Operation Frequency: 2402MHz~2480MHz Channel Separation: 2MHz Number of Channel: 40 Modulation Technology: GFSK Antenna Type: Ceramic Antenna Antenna Gain: 1.75dBi Power Supply: Rechargeable Li-ion Battery DC 3.7V Operation Frequency each of channel Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz 18 2438…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Bluetooth ANC True Wireless Earphones Model: TWS-10N Radiated Emission Page 2 of 2 Conducted Emission
