1 ClearClick® AM/FM Retro Radio with BT (Model #VR40) Quick Start Guide & User’s Manual 5-Year Warranty & Free USA-Based Tech Support This product comes with a 5-year warranty & free USA tech support from ClearClick®. As a small business, we’re here to serve you! If you have any issues with our product, please contact us at [email protected]. www.ClearClick.tech 2 Register Your Product & Browse Our Products Thank you for your purchase! Make sure you register your product & check out our other unique & easy-to-use technology at: www.ClearClick.tech Safety Precautions 1. Do not disassemble the unit. 2. Do not operate the unit around water or rain. Do not operate the unit around any kind of machines or appliances (other than computers). 3. Turn off and unplug the unit when not in use. 4. Do not allow young children to use this device. Thank You! Thank you for your purchase of the ClearClick® AM/FM Retro Radio! (Model Number VR40) We appreciate your business. At ClearClick®, we try to make our technology as clear to understand and use as possible. But if you get stuck at any point, you qualify for FREE USA-based tech support as a ClearClick® customer. Just email us at: [email protected] (Make sure you explain your issue in detail and tell us that you’re using our ClearClick® AM/FM Retro Radio). Our USA-based tech support team members will normally reply to you within 24-48 business hours.) 3 QUICK START – Listening To AM/FM Radio 1. Plug the power adapter into the back of the radio. Plug the other end into any electrical outlet. 2. Switch the left knob to either “AM” or “FM.” 3. Turn on the radio by turning the VOLUME (ON/OFF) knob clockwise. 4. Use the tuning knob to select your desired radio station. 5. Use the volume control knob to adjust the volume. NOTE: To improve the reception of your radio, adjust the pigtail antenna in the back of the radio. QUICK START – Playing Music via Bluetooth 1. Plug the power adapter into the back of the radio. Plug the other end into any electrical outlet. Turn on the radio with the Volume/On/Off knob. 2. Switch the left knob to “BT.” (Bluetooth mode) The Bluetooth indicator LED will light up blue. 3. On your phone, tablet, or other Bluetooth device, turn on Bluetooth and scan for devices. Connect to the “Vintage Radio” device. 4. Use the volume control knob to adjust the volume. (Note: You may also need to adjust the volume on your phone or tablet.) 4 Radio Diagram 1. Bluetooth indicator LED 2. Function switch knob 3. Tuning knob 4. Power ON/OFF and volume control knob 5. Speaker FCC Warnings Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. 5 www.ClearClick.tech Need Help With Anything? We Are Here To Help! Email Us At: [email protected]

FCC ID: 2ASDT-VR4046 FCC ID: 2ASDT-VR4046 FCC ID: 2ASDT-VR4046

FCCID:2ASDT-VR4046 FCCID:2ASDT-VR4046 BTAnt FCCID:2ASDT-VR4046

RF Exposure evaluation Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v06 FCC Part 2 §2.1091 FCC ID: 2ASDT-VR4046 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 6 3.0 – 30 1842/f 4.89/f (900/f 2 )* 6 30 – 300 61.4 0.163 1.0 6 300 – 1500 / / f/300 6 1500 – 100,000 / / 5 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 30 3.0 – 30 824/f 2.19/f (180/f 2 )* 30 30 – 300 27.5 0.073 0.2 30 300 – 1500 / / f/1500 30 1500 – 100,000 / / 1.0 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used BT antenna is 0dBi, the RF power density can be obtained. EDR Freq. (MHz) Output Power (dBm) Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Output power to antenna (mW) Ant Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW/c m2) Result GFSK 2402 0.836 0±1.0 1 1.259 0 0.00025 1 Pass 2440 -0.208 0±1.0 1 1.259 0 0.00025 1 Pass 2480 -1.564 -1±1.0 0 1.000 0 0.00020 1 Pass π/4DQPSK 2402 0.730 0±1.0 1 1.259 0 0.00025 1 Pass 2440 -0.147 0±1.0 1 1.259 0 0.00025 1 Pass 2480 -1.591 -1±1.0 0 1.000 0 0.00020 1 Pass 8DPSK 2402 0.721 0±1.0 1 1.259 0 0.00025 1 Pass 2440 -0.134 0±1.0 1 1.259 0 0.00025 1 Pass 2480 -1.502 -1±1.0 0 1.000 0 0.00020 1 Pass Note: The estimation distance is 20cm 5. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device.

Project No.: ZKT-210615L2593 Page 1 of 69 FCC TEST REPORT FCC ID:2ASDT-VR4046 Report Number. ............................... : ZKT-210615L2593 Date of Test ....................................... Jun. 03, 2021 to Jun. 15, 2021 Date of issue .................................... : Jun. 16, 2021 Total number of pages ...................... 69 Test Result ..................................... : PASS Testing Laboratory. .......................... : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ............................ : ClearClick Software LLC Address .......................................... : 3006 Teak Place, Fullerton, CA 92835, United States Manufacturer's name ..................... : Shenzhen Jiayinking Technology Holding Company Limited Address .......................................... : A1102, workshop 1, Tianan Digital Innovation Park, No. 524, Qinglin Road, huanggekeng community, Longcheng street, Longgang District, Shenzhen Test specification: Standard .......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-116_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2021-06-16 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................... : VINTAGE RADIO WITH BLUETOOTH Trademark ...................................... : ClearClick Model/Type reference ...................... : RA14087-1, RA16053-1, VR40, VR46 Ratings ............................................. : AC 120V/60Hz Project No.: ZKT-210615L2593 Page 2 of 69 Testing procedure and testing location: Testing Laboratory ..................................... :Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-210615L2593 Page 3 of 69 Table of Contents Page 1. VERSION ............................................................ 5 2. TEST SUMMARY ..................................................... 6 2.1 TEST FACILITY ....................................................... 7 2.2 MEASUREMENT UNCERTAINTY ....................................... 7 3. GENERAL INFORMATION ............................................. 8 3.1 GENERAL DESCRIPTION OF EUT ..................................... 8 3.2 Test Setup Configuration ............................................... 9 3.3 Support Equipment .................................................... 9 3.4 Test Mode .......................................................... 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS ............................. 11 4. EMC EMISSION TEST ................................................ 12 4.1 Conducted emissions ................................................. 12 4.1.1 POWER LINE CONDUCTED EMISSION Limits ........................ 12 4.1.2 TEST PROCEDURE ................................................ 12 4.1.3 DEVIATION FROM TEST STANDARD ................................ 12 4.1.4 TEST SETUP ...................................................... 13 4.1.5 EUT OPERATING CONDITIONS ..................................... 13 4.1.6 Test Result ........................................................ 14 4.2 Radiated emissions .................................................. 15 4.2.1 Radiated Emission Limits ............................................ 16 4.2.2 TEST PROCEDURE ................................................ 16 4.2.3 DEVIATION FROM TEST STANDARD ................................ 17 4.2.4 TEST SETUP ...................................................... 17 4.2.5 EUT OPERATING CONDITIONS ..................................... 18 4.2.6 TEST RESULTS ................................................... 19 5. RADIATED BAND EMISSION MEASUREMENT ......................... 24 5.1 Test Requirement: ................................................... 24 5.2 TEST PROCEDURE ................................................. 24 5.3 DEVIATION FROM TEST STANDARD ................................. 25 5.4 TEST SETUP ....................................................... 25 5.5 EUT OPERATING CONDITIONS ...................................... 25 5.6 TEST RESULT ...................................................... 26 6. CONDUCTED BAND EDGE AND SPURIOUS EMISSION ................. 27 6.1 Limit ................................................................ 27 6.2 Test Setup .......................................................... 27 6.3 Test procedure ...................................................... 27 6.4 DEVIATION FROM STANDARD ....................................... 27 6.5 Test Result .......................................................... 28 7. 20DB BANDWIDTH .................................................. 40 7.1 Test Setup .......................................................... 40 7.2 Limit ................................................................ 40 7.3 Test procedure ...................................................... 40 7.4 DEVIATION FROM STANDARD ...…
