Fine Page 1 of 4 深圳市奥嘉达科技有限公司 承 認 書 SPECIFICATION FOR APPROVAL 客 戶： CUSTOMER: 深圳市奥嘉达科技有限公司 客 戶 料 號： CUST P/N: 松 岛 料 號： FINE P/N: 62*48-9.2UH 单线圈0.08*105P*10TS 産 品 型 號： DESC: 62MMX48MM 日 期： DATE: 2020/04/10 版 本： Version: A.0 擬制 PREPARED BY 審核 CHECKED BY 批准 APPROVED BY 客戶承認 CUSTOMER APPROVE 黄强 张新云 周勇 Fine Page 2 of 4 版本變更履歷 Version Change History 版本 Rev. 變 更 前 Before Change 變 更 後 After Change 更 改 日 期 Change Date 批 准 Approved By A.0 新发行 ---- 2020/04/10 周勇 Fine Page 3 of 4 SPECIFICATION 産 品 型 號： DESC 62x48-9.2uH-0.08x105-40mm 版本 Rev： A.0 客戶CUST: XXX 客户料号CUST P/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATIC DIAGRAM: A 62±1.0 B 48±1.0 C 34±1.0 D 17±1 E 40±2 F 3±2 注： 1.交叉出线; 2.出线位置缠8mm(ref)宽度高 温胶纸1-2Ts; 3.线圈贴椭圆形软 磁片，磁片 尺寸62MMX48MM,内孔 34X17, 三、绕线参数Winding Specification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 Winding Direction 1 S F 丝包线0.08*105P 10Ts CCW 四、电气特性ELECTRICAL CHARACTERISTICS: 温度TEMPERATURE:25±10°C, 湿度RELATIVE HUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TEST FREQUENCY 测试仪器 TEST EQUIPMENTS 1 IND. S-F 4.0uH ±20%单独线圈 100KHz/1.0V LCZ METER 1062B 2 IND. S-F 9.2uH ±10%加磁片 100KHz/1.0V LCZ METER 1062B 3 DCR S-F ≤50.7mΩ 100KHz/1.0V LCZ METER 502B 4 Q S-F ≤47 100KHz/1.0V LCZ METER 502B 擬制/日期PREPARED BY/ D AT E 審核/日期CHECKED BY/ D AT E 张新云2020.4.9 周勇2020.4.9 Fine Page 4 of 4

TRF NO. FCC Page 1 of 4 Report No.: ES200325042W Ver.1.0 EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 TRF NO. FCC Page 2 of 4 Report No.: ES200325042W Ver.1.0 EUT View 3 EUT View 4 TRF NO. FCC Page 3 of 4 Report No.: ES200325042W Ver.1.0 EUT View 5 EUT View 6 TRF NO. FCC Page 4 of 4 Report No.: ES200325042W Ver.1.0 EUT View 7 EUT View 8 ----------------The end----------------

Label and label location

TRF NO. FCC Page 1 of 7 Report No.: ES200325042W Ver.1.0 EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 EUT Housing and Board View 2 TRF NO. FCC Page 2 of 7 Report No.: ES200325042W Ver.1.0 EUT Housing and Board View 3 EUT Housing and Board View 4 TRF NO. FCC Page 3 of 7 Report No.: ES200325042W Ver.1.0 EUT Housing and Board View 5 Solder Board-Component View 1 BLE Ant . TRF NO. FCC Page 4 of 7 Report No.: ES200325042W Ver.1.0 Solder Board-Component View 2 Solder Board-Component View 3 TRF NO. FCC Page 5 of 7 Report No.: ES200325042W Ver.1.0 Solder Board-Component View 4 Solder Board-Component View 5 TRF NO. FCC Page 6 of 7 Report No.: ES200325042W Ver.1.0 Solder Board-Component View 6 Adapter TRF NO. FCC Page 7 of 7 Report No.: ES200325042W Ver.1.0 Wireless coil ----------------The end----------------

FCC ID: 2ASNTTENMINDS-MP2 According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: Channel Freq. (MHz) Max Transmit Power (dBm) Max tune-up power (dBm) Result calculation 1-g SAR DTS 2402 -0.653 0 0.31 3.0 2440 0.120 1 0.39 3.0 2480 0.699 1 0.34 3.0 Conclusion: For the max result : 0.39≤ 3.0 for 1-g SAR extremity SAR, No SAR is required.

Report No.ES200325042W03 Page 1 of 44 Ver.1.0 TEST REPORT Product Name ： Motion Pillow Model Number ： MP2 FCC ID ： 2ASNTTENMINDS-MP2 Prepared for : TENMINDS CO., LTD Address : 1F(Nonhyeon-dong,ConerBuilding),6,Bongeunsa-ro 5-gil, Gangnam-gu, Seoul, South Korea Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES200325042W03 Date(s) of Tests : March 31, 2020 to April 9, 2020 Date of issue : April 10, 2020 $二维码$ Report No.ES200325042W03 Page 2 of 44 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ............................................................................................................. 4 3 SUMMARY OF TEST RESULT .................................................................................................................... 5 4 TEST METHODOLOGY ............................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .................................................................................................. 6 4.3 DESCRIPTION OF TEST MODES ........................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS ...................................................................................................... 8 5.1 FACILITIES............................................................................................................................................... 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................... 8 6 TEST SYSTEM UNCERTAINTY ................................................................................................................. 9 7 SETUP OF EQUIPMENT UNDER TEST .................................................................................................. 10 7.1 RADIO FREQUENCY TEST SETUP 1 ................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP 2 ................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP .............................................................................................. 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ............................................................... 13 7.5 SUPPORT EQUIPMENT......................................................................................................................... 13 8 TEST REQUIREMENTS ............................................................................................................................. 14 8.1 DTS 6DB BANDWIDTH ........................................................................................................................ 14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ......................................................................... 17 8.3 MAXIMUM POWER SPECTRAL DENSITY ........................................................................................ 20 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ....................................... 23 8.5 RADIATED SPURIOUS EMISSION ...................................................................................................... 28 8.6 CONDUCTED EMISSIONS TEST ......................................................................................................... 40 8.7 ANTENNA APPLICATION .................................................................................................................... 43 Report No.ES200325042W03 Page 3 of 44 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : TENMINDS CO., LTD Address : 1F(Nonhyeon-dong,ConerBuilding),6,Bongeunsa-ro 5-gil, Gangnam-gu, Seoul, South Korea Manufacturer : XIAMEN TUWAN INTELLIGENT TECHNOLOGY. CO., LTD Address : Unit 7A3,Tianhu Building B,No.148 Binglang Xili,Siming District,Xiamen, EUT : Motion Pillow Model Name : MP2 Trademark : 10minds Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : March 31, 2020 to April 9, 2020 Prepared by : Sewen Guo /Editor Reviewer : Joe Xia/Editor Approve & Authorized Signer : Lisa Wang/Manager Report No.ES200325042W03 Page 4 of 44 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product Motion Pillow Model Number MP2 Device Type Bluetooth V4.0 Data Rate : 1Mbps for GFSK modulation Modulation: Bluetooth DTS: GFSK Operating Frequency Range: 2402-2480MHz Number of Channels: 40 Channels for Bluetooth DTS; Transmit Power Max: 0.699 dBm Antenna Type: Integral Antenna Antenna Gain: 2.65 dBi; Power supply DC supply: DC 5.0V Adapter supply: Model：P12DUSB050200 Input：100-240V,50/60Hz,0.3A Output：5.0V,2.0A Temperature Range: 0°C ~ +45°C Note: for more details, please refer to the User’s manual of the EUT. Report No.ES200325042W03 Page 5 of 44 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.247(a)(2) DTS (6dB) Bandwidth PA SS 15.247(b)(3) Maximum Peak Conducted Output Power PA SS 15.247(e) Maximum Power Spectra…
