Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Jan 27, 2021
Application Purpose: Original Equipment
Date of Application: Jan 27, 2021
Equipment Note: MOBILE PHONE
Frequency Range: 2402.00000000 - 2480.00000000
Company: MAXWEST COMMUNICATION LIMITED
Country: Hong Kong
