2ASQA696119WIRELESS BOOMBOX

BCB119 INSTRUCTION MANUAL BLUETOOTH CD BOOMBOX 1.0 PLEASE READ BEFORE OPERATING THIS EQUIPMENT IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product ís enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera-ture accompanying the appliance. This product utilizes a Class 1 laser to read Compact Discs. This laser Compact Disc Player is equipped with safety switches to avoid exposure when the CD door is open and the safety interlocks are defeated. Invisible laser radiation is present when the CD Player’s lid is open and the system’s interlock has failed or been defeated. It is very important that you avoid direct exposure to the laser beam at all times. Please do not attempt to defeat or bypass the safety switches . FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna. l Increase the separation between the equipment and receiver. l Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. l Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The equipment should be installed and operated with minimum distance 20cm between the radiator & your body. PRECAUTIONS FOR UNIT OPERATING THE PLAYER ON AC POWER • Insert one end of the supplied power cord into the AC IN jack located at the rear of the unit, and the other end into the wall outlet. PLACEMENT • Put the unit where ventilation is good enough to prevent overheating. • Never put the unit in direct sunlight or near heat sources. • Put the unit horizontally, never put any heavy object on the unit. • To protect the pickup, do not put the unit where there is much dust. If there is dust on the pickup, use a cleaning disc to clean it. • Refer to the operation instructions of the cleaning disc you bought. CONDENSATION Moisture will appear on the pickup lens in the following cases: • The unit is suddenly moved from a cold place to a warm place. • The unit is put in a room with a heater, or in cold air from an air - conditioner. • Use the unit in a humid place. In these cases, the unit cannot work. Unload the disc and leave the unit on for about one hour evaporates the water. CLEANING • Use soft cloth with a little neutral detergent to wipe the cabinet, panel and controls. Never use abra sive paper, polishing powder or solvent like alcohol and gasoline. 1 PRECAUTIONS FOR DISCS CARING FOR COMPACT DISCS • Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. • Do not attach adhesive tape, stickers, etc. to the compact disc label. • Clean the compact disc periodically with a soft, lint-free, dry cloth. Never use detergents or abrasive cleaners to clean the compact disc. If necessary, use a CD cleaning kit. • If a compact disc skips or gets stuck on a section of the compact disc, it is probably dirty or damaged (scratched). • When cleaning the compact disc, wipe in straight lines from the center of the compact disc to the outer edge of the compact disc. Never wipe in circular motions. B E N Z E N E C L E A N E R COMPACT • This unit is designed to play only compact discs bearing the identification logo as shown here. Other compact discs may not confirm to the CD standard and may not DIGITAL play properly. • Compact discs should be stored in their cases after each use to avoid damage. • Do not expose compact discs to direct sunlight, high humidity, high temperature, or dust, etc. Prolonged exposure or extreme temperatures can warp the compact disc. • Do not stick or write anything on either side of the compact disc. Sharp writing instruments, or may The ink damage the surface. AUDIO 2 INTRODUCTION Front View Side View Rear View Top View Bottom View 3 LOCATION OF CONTROLS 1. SPEAKER 9. LINE IN 2. TUNE-/SKIP/SEARCH (BACKWARD) 10. SOURCE SWITCH 3. STOP 11. VOLUME 4. REPEAT 12. HANDLE 5. DISPLAY 13. DC IN 6. PROGRAM 14. CD DOOR 7. PLAY/PAUSE 15. OPEN 8. TUNE+/SKIP/SEARCH (FORWARD) 16. BATTERY DOOR CONNECTING THE POWER AC POWER OPERATION Plug the included AC adapter into the standard AC power outlet to power the unit. Connect small end to DC INPUT jack of main unit. After adapter connection, Slide the Source switch to CD / BT/LINE IN / RADIO mode position to turn on the unit. The power indicator is lighted. BATTERY OPERATION  Before installing batteries (not included), ensure that the unit is …
