2ASQW-C-001DRental houses (rooms) smart lock

目录 1.产品参数、产品组成...................1 2.安装说明.....................................2-3 3 产品使用说明 ...............................3 4设置操作...............................................4-6 6售后保修...............................................7 第1部分：产品参数简介 品名：智能锁芯 型号：C-001D 安全级别：顶级 适应门类型：防盗门、木门、玻璃门 适应门厚度：40mm----100mm 静电防护：15KV 电源输入：3.6--5V 电流：工作电流〈135mA 待机电流〈10uA 工作温度：-20----70°C 耐按压：10万次 电池类型：7号电池 第2部分：产品组成 产品设置： 使用说明： 请在进行以下操作前确保手机蓝牙已打开，并且手 机与门锁在合理的距离范围内，建议在5米内进行 操作 1、APP连接： 在应用市场搜索“涂鸦”APP并下载 打开APP根据提示注册，在主页点击右上角“+”图 标 1.1、手动添加：点击左侧的“安防传感—门锁（蓝 牙）-确认已听到语音播报”，同时按设备上的 开启设备端蓝牙，等待几秒后，出现设备名称，点 击连接。 1.2、自动发现：点击上方“自动发现”，确保锁已 正常供电，同时按设备上的开启设备端蓝牙, 等待几秒后，出现设备名，点击连接。 2、指纹管理 2.1、添加指纹：点击主页设备名，进入管理界面， 点击“设置-指纹管理-右上角+号-添加指纹”，选 择用户，点击“开始采集”，根据提示录入3次指 纹，录入成功后弹出“指纹命名”，输入名称，添 加成功。 2.2、删除指纹：点击主页设备，进入管理界面，点 击“指纹-指纹管理”，点击已录入指纹右侧图标删 除。 3、密码管理 3.1、添加密码：点击主页设备后，进入管理界面， 点击“设置-密码管理-右上角+号添加密码”，选择 用户，根据页面提示输入密码、昵称，点击右上角 保存，添加成功。 3.2、删除密码：点击主页设备后，进入管理界面， 点击“设置-密码管理”，点击右侧图标删除。 4、成员管理 4.1、成员管理页面—两种不同的成员 4.1.1、家庭成员——该类成员与app中家庭组的用 户保持一致；在app家庭组中新增用户，在门锁成 员中也会对应的多出现一位家庭成员。同理，在门 锁家庭成员中新增一位家庭成员，在app的家庭组 中也会出现该成员。注：删除家庭成员只能在app 的家庭成员管理中进行操作。 4.1.2、其他成员——指仅在门锁里出现的用户，不 是app家庭组的用户。添加、删除这类用户，不会 对app家庭组里的成员产生影响。 4.2、成员管理——其他成员管理 4.2.1、有效期：管理员可以决定其他成员 的使用有效期长度。可以设置为永久有效，也可以 设置指定的开始时间—结束时间 4.2.2、开门方式。管理员可以决定该成员具备的开 门方式的权限类型；管理员如果关闭该成员的所有 开门权限，则该用户无法再通过app维护自己的开 门方式，只能使用已有的开门方式 4.2.3、创建一个其他成员后，管理员可以通过“分 享”操作，将该成员与app的某个用户建立关联。 到了该用户的指定结束时间，该用户的app会自动 失去该设备。 5、恢复出厂设置 点击主页设备，进入管理界面，点击右上角图标， 进入界面后，往下拉找到恢复出厂设置，点击即可 5.1、当手机app与门锁进行蓝牙连接状态时，使用 恢复出厂设置操作。门锁本地的所有的开门方式都 会被删除，门锁恢复到刚出厂时候的默认状态，其 他用户可以通过app重新添加该门锁。 5.2、当手机未与门锁进行蓝牙连接状态，在门锁上 对门锁进行恢复出厂设置操作。门锁上的开门方式 仍然保留不受影响。 6、门锁语言切换： 打开APP，点击主页设备，进入管理界面，点击“设 置-门锁语言”，切换语言。 7、开门操作： 按键盘上任意键一次，点亮键盘灯后，输入密码 +，验证通过，门锁开，蓝灯亮，开门时间后， 门锁关，蓝灯灭。 按指纹，验证通过，门锁开，蓝灯亮，开门时间后， 门锁关，蓝灯灭。 打开APP主页，选择设备后，进入管理界面，点击 “手机开门-确定”，开锁成功。 打开APP主页,选择设备后，进入管理界面，左滑切 换到“动态密码”界面，点击“点击获取”，生成 动态密码，动态密码生成后5分钟内有效。在锁上 按键输入8位数字+，开锁成功。 8、开门记录查询 打开APP主页，选择设备进入管理界面，点击下方 “开门记录”，查看开门记录。 9、低电量报警: 电量低于3.6v发出语音提示：电量不足请更换电 池。 10、输入错误锁定: 连续5次输入指纹错误，(密码三次)，系统报警， 非法操作系统已锁定，系统锁定3分钟不能操作。 11、按键灭灯： 按键后，灯亮十秒无操作自动退出操作系统，灯灭。 按返回键，退出系统，灯即灭。 售后保修： 一、售后保修： 1、7天无理由退换货：自产品售出7天内，产品在 不影响2次销售情况下可选择无条件退换货。 2、15天换货期：自产品售出15大内，产品不影响 2次销售情况下可进行同款产品换货。 3、在三包有效期内，保修两次如出现仍不能正常使 用的产品，凭修理记录和证明，由销售人员为消费 者免费调换同型号同规格的产品或退货。 4、产品保修期l年. 5、售后邮费：保修期间产品邮寄费用由各自承担寄 出费用。 二、不属于保修范围： l、因操作不当、失误造成产品损坏，经检测属实. 产品维修人员按人工成本、零件成本收取相应的费 用。 2、因不可抗拒因素：雷击(正面袭击导致设备烧毁、 变形)浸水(长时间浸泡水中经检测出现产品毁坏)。 3、无法提供有效订单、收据、发票凭证的保修者. 4、超过保修期、以及保修期内人为不可抗拒损坏产 品需更换零配件、需对应收取人工服务费加零配件 费用。 产品售后保修： 产品型号： 出厂编号： 购买日期： 顾客姓名： 顾客电话： 通信地址： 维修记录 维修日期故障原因维修内容维修人员签字 Part1:Introductiontoproductparameters Name:Smartlockcylinder Model:C-001D Securitylevel:toplevel Adapttodoortype:securitydoor,woodendoor, glassdoor Adapttothedoorthickness:40mm----100mm Electrostaticprotection:15KV Powerinput:3.6--5V Current:Operatingcurrent<135mA Standbycurrent<10uA Workingtemperature:-20----70°C Resistancetopressure:100,000times Part2:productcomposition Productsettings: Instructionsforuse: PleasemakesurethatthemobilephoneBlueto othisturnedonbeforethefollowingoperations, andthemobilephoneandthedoorlockare withinareasonabledistance.Itisrecommended tooperatewithin5meters. 1,APPconnection: Searchfor"tuya"appintheappmarketanddo wnload Opentheappandfollowthepromptstoregister. Clickonthe"+"iconintheupperrightcornero fthehomepage. 1.1.Manuallyadd:Click“SecuritySensing—Door Lock(Bluetooth)-Confirmthatyouhaveheardt hevoicebroadcast”ontheleft.Pressthebutton onthedevicetoturnonthedevicesideBlu etooth,Afterwaitingforafewseconds,thedev icenameappearsandclickConnect. 1.2,automaticdiscovery:Clickonthe"automatic discovery"above,toensurethatthelockhasbe enpowerednormally,Pressthebuttononthe devicetoturnonthedevicesideBluetooth,w aitafewseconds,thedevicenameappears,click ontheconnection. 2,fingerprintmanagement 2.1.Addfingerprint:Clickthehomedevicename, enterthemanagementinterface,click“Settings-fi ngerprintmanagement-upperrightcorner+number- addfingerprint”,selecttheuser,click“Starttoco llect”,enter3fingerprintsaccordingtotheprom pt,popupaftersuccessfulentry"Fingerprintna ming",enterthename,andaddsuccessfully. 2.2.Deletethefingerprint:Clickthehomedevice, enterthemanagementinterface,click“Fingerpri nt-fingerprintmanagement”,clicktheicononthe rightsideofthefingerprintyouhavedeleted. 3,passwordmanagement 3.1.Addpassword:Afterclickingthehomedevic e,enterthemanagementinterface,click“Settings -PasswordManagement-Addthepasswordinth eupperrightcorner+No.”,selecttheuser,ente rthepasswordandnicknameaccordingtothepr omptonthepage,clickSaveintheupperright corner,andaddsuccessfully. 3.2.Deletepassword:Afterclickingthehomedev ice,enterthemanagementinterface,click“Settin gs-PasswordManagement”,clicktheicononthe righttodelete. 4,membermanagement 4.1,membermanagementpage-twodifferentm embers 4.1.1.Familymembers-Thesemembersarecons istentwiththeusersofthefamilygroupinthe app;newusersareaddedtotheappfamilygro up,andafamilymemberisalsopresentinthe doorlockmembers.Inthesameway,afamilym emberisaddedtothefamilymemberofthedo orlock,andthememberwillalsoappearinthe familygroupoftheapp.Note:Deletingafamily membercanonlybedoneinthefamilymembe rmanagementoftheapp. 4.1.2.Othermembers-referstouserswhoappe aronlyinthedoorlock,notusersoftheappfa milygroup.Addinganddeletingsuchuserswilln otaffectthemembersoftheappfamilygroup. 4.2,membermanagement-othermembermana gement 4.2.1.Validityperiod:theadministratorcandecid eothermembers Thelengthofuseofthevalidityperiod.Canbe settobepermanentorsettothespecifiedstart time-endtime 4.2.2,openthedoor.Theadministratorcandeter minethetypeofpermissionthatthememberha stoopenthedoor;iftheadministratorclosesal ltheopeningrightsofthemember,theusercan nolongermaintainthedooropeningmodethro ughtheapp,andcanonlyusetheexistingdoor openingmode. 4.2.3.Aftercreatinganothermember,theadminis tratorcanassociatethememberwithauseroft heappthroughthe“Share”operation.Atthesp ecifiedendtimeoftheuser,theuser'sappwill automaticallylosethedevice. 5,restorefactorysettings Clickthehomedevice,enterthemanag…
