2ASRB-M08FA4 Portable Printer

A4便携打印机 A4 portable printer 快速入门指南 Quick Start Guide 01包装清单 Package Contents 打印机*1个 1xPrinter 电源线*1条 1x Data Cable 绒布袋*1个 1x Flannel Bag 说明书*1本 1x Quick Start Guide 02 机器说明 Printer Components Power Button Power Indicator Cover Release Latches Reset Button Power Socket 03指示灯状态说明 名称 状态 功能说明 电源指示灯 红灯亮 缺纸/开盖/高温 红灯闪 电量不足 绿灯亮 正常状态 绿灯闪 充电中 03 Indicator Light Guide Name Status Description Power Indicator Lit (Red) Out of paper/ Cover is open/ Overheat Blinking (Red) Low power Lit (Green) Normal Blinking (Green) Charging 04按钮功能 (电源)按钮功能 操作 开启打印机 按住此按钮约3秒钟，直到电源指示灯亮起 打印二维码 双击打印二维码，可手机app扫描二维码，连接机器 关闭打印机 按住此按钮约3秒钟，直到电源指示灯熄灭 04 Button Function (Power) Button Function Operation Turn on the printer Press and hold the button for around 3 seconds until the power indicator light turns on. Print QR code Double-press the button to print QR code. You can scan the QR code using the App on the phone and connect to the printer. Turn off the printer Press and hold the button for around 3 seconds until the power indicator light turns off. 05 Precautions 1. Please use 5V⎓2A input for charging, and it is recommended to use mobile phone power adapter for charging. 2. Please connect the USB cable to the power adapter before charging，Please gently insert or unplug the charging cable when charging, to prevent excessive force from damaging the port. 3. After the charging is completed, please unplug the charging cable in time. 4. In order to avoid danger, do not use or charge in the environment of high temperature, high humidity, heavy smoke and dust, such as in bathroom, steam room, near to open flame, etc. 5. Improper charging may cause damage to the print head. 6. Do not touch the print head to prevent scalding caused by overheating. 7. The tearing blade is sharp, please be careful to avoid touching it by mistake. 8. If the machine is malfunctioning, insert the reset hole to restart the machine. 06 Battery warning instructions * It is forbidden to disassemble, hit, squeeze the battery, or throw it into fire; * If severe swelling occurs, please do not reuse it; * Do not place in a high temperature environment, and it is strictly prohibited to use the battery after soaking in water; * There is a danger of explosion if the battery is replaced by the wrong type. Be sure to dispose of the used battery according to the instructions; * If consumers use a power adapter for power supply, they should purchase a power adapter that meets the requirements of corresponding safety standards or a power adapter with CCC certification. 07操作指南 Instruction Guide 7.1应用程序安装 Install App (1) 下载app 请在手机应用市场中搜索“Phomemo”，下载软件app (1) Download the App Please search for “Phomeno” on your phone’s App market and download the App. (2) 机器连接app Connect the printer to the App 方法一：打开手机蓝牙，打开Phomemo APP，点击Phomemo APP主界面右上角图标，在 下拉列表中选择M08F进行连接。 备注：安卓系统需要开启定位，并允许App获取相关权限。 方法二：双击机器电源按钮打印二维码，打开Phomemo APP，点击Phomemo APP主界面 右上角图标，在添加设备页，点击扫描连接，扫描二维码连接机器 Method 1: Turn on your phone’s Bluetooth and open your Phomeno App. Press the button on the top right of your Phomeno App home page and select M08F from the list. Note: Android system needs to enable positioning and allow app to obtain relevant permissions. Method 2: Double-press the printer’s power button to print a QR code. Open your Phomeno App and press the button on the top right of your Phomeno App home page. On the selection page, press scan and scan the QR code to connect to the printer. 7.2 耗材安装与更换 Install and change the printer’s consumable （1）耗材安装方法 Installing Consumable 用双手握住纸张，使其保持平直，然后小心地将纸张插入打印机的进纸槽中，直到卷轴将其 拉入最佳开始位置。为了实现最佳打印效果，请使用原厂Phomemo纸张。 Use two hands to hold the paper and make sure it is straight and aligned. Insert the paper carefully into the printer’s feeder until the roller pulls the paper to its optimal position. To get the best printing quality, please use original Phomeno papers. Power button Paper feed direction Printing paper Paper feed direction 提示： Hint: ①纸张的短边必须与进纸槽口平行。 ②纸张仅有一面可打印，检查纸张，印有“This side should face up”字样为非打印面，应朝上 安装。 (1) The paper must be inserted aligned to the paper feeder. (2) The paper can only be printed on one side, please check the paper. The side printed with “This side should face up” is the non-printable side and should be installed with that side faced up. （2）耗材更换方法 Changing Consumable 1. 您可以在app应用程序中将纸张设置为【单张纸】、【折叠A4纸】 2. 按照上述耗材安装方法，安装对应耗材规格。 1. You can set the paper as “Single paper” or “Fanfold A4 paper”in the App. 2. Refer to the instructions on“Installing Consumable”to install the relevant consumables. 注意事项：Note: 1. 当需要取出打印纸时，需同时按下PUSH键，机器上盖轻轻弹开，取出纸张。 PUSH Button 2. 当使用【折叠A4纸】时，打印完文件，需沿着穿孔虚线，撕下纸张。 1. When you need to take out the printing paper, press the PUSH buttons simultaneously to open the printer cover and take out the paper. 2. When using “Fanfold A4 paper”, after printing your documents, tear along the perforation lines. 08 官方打印纸类型 Official printing paper type 普通热敏纸：不含双酚-A，在室内常温干燥无阳光直射环境下，字迹可保存时长7/10年。 书写速干热敏纸：不含双酚-A，可手写且油墨速干的热敏纸，在室内常温干燥无阳光直射 环境下，字迹可保存时长10年。 *上述打印纸为印先森官方专用耗材，是印先森的专用纸张。 *若您因未使用官方专用耗材而引起打印机故障，则无法享受三包政策。 Normal thermal paper: Does not contain Bisphenol-A. The printed texts can last for 7 to 10 years if stored in a dry condition at room temperature without direct sunray. Writable Quick-drying thermal paper: Thermal paper that does not contain Bisphenol-A, can be written on, and dries ink quickly. The printed texts can last up to 10 years if stored in a dry condition at room temperature without direct sunray. *The printing papers mentioned above are official Mr.In printing papers. *Any issues with your printer arising from using non-official printing papers will not be covered under our warranty policy. 09售后支持 After-sales Service 9.1 Warranty description 100% warranty within 1 year * Although the product has undergone strict testing and quality inspection, accidents may occur during transportation, resulting in damages to the machine. If there is any problem with the printer, please contact us through the following methods. We have …

Text truncated - open the document above for the full version.

Zhuhai Quin Technology Co., Ltd. Model difference statement Product Name: A4 Portable Printer Model N o.: M08F, M08FS, M08 pro, M08A, M08AS, T08F, T08FS, T08A, T08AS, M08E, M08ES We (Zhuhai Quin Technology Co., Ltd., ROOM 201 2ND FLOOR, 3RD FLOOR, BLOCK 2, NO.1 CUIZHU 4TH STREET, QIANSHAN, XIANGZHOU DISTRICT, ZHUHAI CITY.) hereby state that all the models are the same circuit and RF module, except the model name, appearance color, silk screen pattern. Signature: Name / Chloe Xu Title: product manager Tel: 0756-8699759 Email: [email protected] Date: 11.8.2021

C5266091_X10_Ed.1 1/1 Zhuhai Quin Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 11/8/2021 Subject: Request for Confidentiality FCC ID: 2ASRB-M08F To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Chloe Xu Date: 11/8/2021 Title: product manager

Page 1 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] APPENDIX 1- EUT PHOTO Model: M08F Photo 1 Photo 2 Page 2 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 Page 3 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6 ----End of Report----

Label Location

Page 1 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] APPENDIX 1- EUT PHOTO Model: M08F Photo 1 Photo 2 Page 2 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 Page 3 of 3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6 ----End of Report---- BT & BLE ANT

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi210907013-04E3 Date of issue: Nov. 08, 2021 Applicant: Zhuhai Quin Technology Co., Ltd. Product name: A4 Portable Printer Model(s): M08F, M08FS, M08 pro, M08A, M08AS, T08F, T08FS, T08A, T08AS, M08E, M08ES FCC ID: 2ASRB-M08F Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6- Report No.: MTi210907013-04E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi210907013-04E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] TEST RESULT CERTIFICATION Applicant’s name .......... Zhuhai Quin Technology Co., Ltd. Address ........................ ROOM 201 2ND FLOOR, 3RD FLOOR, BLOCK 2, NO.1 CUIZHU 4TH STREET, QIANSHAN, XIANGZHOU DISTRICT, ZHUHAI CITY, CHINA Manufacturer's Name ... Zhuhai Quin Technology Co., Ltd. Address ........................ ROOM 201 2ND FLOOR, 3RD FLOOR, BLOCK 2, NO.1 CUIZHU 4TH STREET, QIANSHAN, XIANGZHOU DISTRICT, ZHUHAI CITY, CHINA Product description Product name ................. A4 Portable Printer Trademark ................... N/A Model Name ................ M08F Serial Model ................. M08FS, M08 pro, M08A, M08AS, T08F, T08FS, T08A, T08AS, M08E, M08ES Standards..................... N/A Test procedure ............. KDB 447498 D01 v06 Date of Test Date (s) of performance of tests............. : Oct. 22, 2021 ~Nov. 02, 2021 Test Result ............................................. : Pass This device described above has been tested by Shenzhen Microtest Co., Ltd. and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Testing Engineer : (Cindy Qin) Technical Manager : (Leon Chen) Authorized Signatory : (Tom Xue) - Page 4 of 6- Report No.: MTi210907013-04E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi210907013-04E3 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The…
