2ASU7JJ-JP-LTGarage Door Wireless Keypad

Determine your garage door opener type has Smart/Learn Button or DIP Switch, they are located on motor unit or external receiver. Our Universal Keyless Entry Keypad can programmed the Chamberlain, Sears Craftsman, Liftmaster, Mechanic, Do It, Genie Intellicode, Overhead Door, Stanely, Wayne Dalton, Linear etc major brand garage door openers.It has 2 channels can control up 2 garage door independently. Universal Garage Door Wireless Keypad JP-LT Manual V3.0 DETERMINE GARAGE DOOR OPENER TYPES: Proceed with instructions according to your garage door opener type. NOTE: Factory set PIN Code 1111# for 1st channel, 2222# for 2nd channel. If you want to change the factory set PIN code before programming, please go to next page "Change an Existing PIN Code". Opener TYPE 1 Chamberlain, LiftMaster, Sears Craftsman, Master Mechanic, Do It, Stanley, Genie Intellicode, Overhead Door, Wayne Dalton and Linear etc garage door openers with: Smart/Learn Button . Learn Button Learn LED Opener TYPE 2 Chamberlain, LiftMaster, Genie, Sears Craftsman, Master Mechanic, Do It, Moore-O-Matic and Linear etc garage door openers with: DIP Switches . 2 Position DIP Switch 3 Position DIP Switch OR Programming TYPE 2 1. Press and hold the and button at the same time for enter into program model. * # 2. Press button 1# OR 2# of your choice. NOTE “1#” mean enter program for 1st channel, “2#” mean enter program for 2nd channel. 123 456 789 0# 123 456 789 0# 1 123 456 789 0# 2 3. Enter your opener ID _ _ end up with #. * For example program the opener type “Chamberlain 8 DIP Switch 310MHz” corresponding the opener ID is 14, so enter 14#.(Determine your opener ID using the Brand List chart 2.) OR Fig.1 Fig.2 4. Enter the Keypad button for match your existing openers. 5. Enter a 4-digit factory set PIN Code 1111# OR 2222# of your choice. opener 2 position DIP switches opener 3 position DIP switches Leave the middle switch locations blank. For some old garage door opener/receiver that using the “DIP switches” system has 2 position or 3 position with switches number between 1-12. If your existing opener/receiver with 3 position switches, you MUST set them in “ ” or “ ” location first,do not use the “0” position. +- Chamberlain Chamberlain Genie Linear Multi code Chamberlain Stanley Multi code Genie Linear Moore-O-Matic Chamberlain Type/Dip Switch Opener IDBrand 9 DIP Switch 390MHz 1990-1992 9 DIP Switch 315 MHz 1983-1989 12 DIP Switch 390MHz 1985 10 DIP Switch 300MHz 8 DIP Switch 390MHz 10 DIP Switch 310MHz 9 DIP Switch 390MHz 8 DIP Switch 310MHz 7 DIP Switch 390MHz 10 11 12 13 14 15 16 17 18 Type/Dip SwitchOpener IDBrand 3 Chart 2 If your opener with 2 Position DIP Switches,the DIP switch is in the “ ” position place a 2, “ ” position place a 8, end with button # . Note the numerical value in order of the DIP switch locations. Then the garage door opener will activate. +- Such as program opener with 2 Position 12 DIP Switch “ON-OFF-OFF-OFF- ON-ON-ON-OFF-OFF-OFF-OFF-OFF”,corresponding press the button “2-8-8-8 -2-2-2-8-8-8-8-8”.(Fig.1) * If your opener with 3 Position DIP Switch,just leave the middle switch locations blank,then proceed as above. (Fig.2) NOTE: For Genie and Overhead Door Opener is special,you should press the PIN code twice. Such as press your PIN Code 1 time _ _ _ _#, then press again _ _ _ _#. NOTE: Factory set PIN code 1111# for 1st channel, 2222# for 2nd channel. 6. To test,enter the PIN Code with # again. Then the garage door opener will activate. * For safety, please go to next page "Change an Existing PIN Code" after programming. * The DIP switch locations and the keypad button MUST be match "On/ "=2, "Off/ "=8. + - Programming TYPE 1 Brand Linear Chamberlain Chamberlain Chamberlain Genie Overhead Door Genie Overhead Door Stanley Chamberlain Wayne Dalton Type/Learn Button MegaCode 318MHz 1997-Current Red/Orange button 390MHz 1997-2005 Purple button 315MHz 2005-Current Green button 390MHz 1993-1996 Intellicode 315MHz 1995-Current Intellicode 390MHz 2005-Current Security code 310MHz 1998-Current Yellow button 310/315/390MHz 2011-Current Rolling code 372.5MHz 1999-Current Opener ID 01 02 03 04 05 06 07 08 09 1. Press and hold the and button at the same time for enter into program model. * # NOTE: “1#” mean enter program for 1st channel, “2#” mean enter program for 2nd channel. 3. Enter your opener ID _ _ end up with #. Determine your opener ID using the Brand List chart 1. * For example program the opener type “Chamberlain green button” corresponding the opener ID is 04, so enter 04#. 2. Press button 1# OR 2# of your choice. 4. Press and release the Learn Button on the garage door opener within 1 minute. 5. Enter a 4-digit factory set PIN Code 1111# OR 2222# of your choice. 6. To test,enter the PIN Code with # again. Then the garage door opener will activate. * To program another channel,please repeat above steps with a new PIN Code for different opener. 123 456 789 0# 1 123 456 789 0# 2 The Learn LED will light on within 30 seconds... Learn Button 123 456 789 0# _ _ _ _ PIN Code # 123 456 789 0# 456 * NOTE: For Genie and Overhead Door Opener are special,you should press the PIN code twice. Such as press your existing PIN Code 1 time _ _ _ _#, then press again _ _ _ _#. Chart 1 3 NOTE: Factory set PIN code 1111# for 1st channel, 2222# for 2nd channel. * For safety, please go to next page "Change an Existing PIN Code" after programming. Please read instructions thoroughly BEFORE beginning. Start with garage door CLOSED. Install the battery and program the keypad prior to installation. NOTE: Your motor unit and/or remote control may look different. If you get something wrong when program or entry PIN Code and can not proceed with any operation, you could reset the keypad. Remove the battery cover and you will see a Reset Button. Press and hold the reset button for about 5s a beep sound to confirm the keypad has been reset successfully. Now the keypad has restore Factory Set model with PIN Code 1111# for 1st ch…

Text truncated - open the document above for the full version.

Giant Alarm System Co., Ltd Model Difference Product Name: Garage Door Wireless Keypad Model Number: JJ-JP-LT, RGR915 FCC Identifier: 2ASU7JJ-JP-LT All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature Client’s name / title: De Feng Pan / Manager Contact information: No.37 Yangguang Road, Optoelectronic Information Park, Daxiamei Town, Nan'An, Fujian, China

Giant Alarm System Co., Ltd 1/1 Letter of Authorization Company: Giant Alarm System Co., Ltd Address: No.37 Yangguang Road, Optoelectronic Information Park, Daxiamei Town, Nan'An, Fujian, China Product Name: Garage Door Wireless Keypad Model Number: JJ-JP-LT, RGR915 FCC Identifier: 2ASU7JJ-JP-LT We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: De Feng Pan Date: 2021-03-10 Title: Manager Signature of applicant:

Giant Alarm System Co., Ltd 1/1 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-03-10 Subject: Request for Confidentiality FCC ID: 2ASU7JJ-JP-LT To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual No ☐ Internal Photos No ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: De Feng Pan Title: Manager

Model: JJ-JP-LT

Size:17*10.5mm M/N: JJ-JP-LT FCC ID: 2ASU7JJ-JP-LT Label location

Antenna location Model: JJ-JP-LT

Global United Technology Services Co., Ltd. Report No.: GTS202102000084F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 34 + TEST REPORT Applicant: Giant Alarm System Co., Ltd Address of Applicant: No.37 Yangguang Road, Optoelectronic Information Park, Daxiamei Town, Nan'An, Fujian, China Manufacturer: Giant Alarm System Co., Ltd Address of Manufacturer: No.37 Yangguang Road, Optoelectronic Information Park, Daxiamei Town, Nan'An, Fujian, China Equipment Under Test (EUT) Product Name: Garage Door Wireless Keypad Model No.: JJ-JP-LT RGR915 Trade Mark: N/A FCC ID: 2ASU7JJ-JP-LT Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231 Date of sample receipt: Feb. 22, 2021 Date of Test: Feb. 22, 2021 - Mar. 03, 2021 Date of report issued: Mar. 03, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202102000084F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 34 2 Version Version No. Date Description 00 Mar. 03, 2021 Original Prepared By: Date: Mar. 03, 2021 Project Engineer Check By: Date: Mar. 03, 2021 Reviewer Report No.: GTS202102000084F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 34 3 Contents Page 1 COVER PAGE .............................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................6 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................6 5.4 DEVIATION FROM STANDARDS ..............................................................................................................6 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................6 5.6 TEST FACILITY ....................................................................................................................................6 5.7 TEST LOCATION ..................................................................................................................................6 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 RADIATED EMISSION METHOD ............................................................................................................12 7.3.1 Spurious emissions .....................................................................................................................14 7.4 20DB OCCUPY BANDWIDTH ...............................................................................................................21 7.5 CALCULATION OF AVERAGE FACTOR .......................................................................................23 7.6 DWELL TIME ..................................................................................................................................26 8 TEST SETUP PHOTO .............................................................................................................................28 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................29 Report No.: GTS202102000084F01 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 34 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203 Pass AC Power Line Conducted Emission 15.207 N/A Fundamental &Radiated Spurious Emission Measurement 15…

Text truncated - open the document above for the full version.

Measurement Photos Model: JJ-JP-LT
