2AT37STYLITE500BGAN Class 2 Mobile User Equipment

Chengdu Spaceon Technology Co., Ltd.
BGAN Class 2 Mobile User Equipment - FCC ID 2AT37STYLITE500 - Chengdu Spaceon Technology Co., Ltd.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Mar 30, 2020
Application Purpose
Original Equipment
Date of Application
Mar 26, 2020
Equipment Note
BGAN Class 2 Mobile User Equipment
Frequency Range
1626.50000000 - 1660.50000000
Company
Chengdu Spaceon Technology Co., Ltd.
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Portable BGAN Terminal STYLITE 500 Datasheet Chengdu Spaceon Technology Co., Ltd. 2 Product Description STYLITE 500 is a portable broadband terminal, developed for land applications, which based on Inmarsat I-4 satellite communication system. It can provide data service up to 464kbps, and support BGAN IP voice, SMS services, GPS position. With RJ45 wired access and Wi-Fi wireless access available, it can realize multiple users to access to Public Switched Telephone Network (PSTN), Cellular Network, Internet and Mobile Internet. STYLITE 500 is highly integrated, compact and easy to use. It is suitable for the establishment of temporary offices, outdoor communications, and emergency communications. It makes outdoor activities safer and more secure. What it is  Land portable broadband terminal for satellite communications  High speed internet access, support standard IP and streaming IP  BGAN IP voice call  SMS and Email  GNSS service, timing and positioning  Wire LAN and Wi-Fi connection, multiple user sharing of network resource  Web server, iOS APP, Android APP for user interface Features  Standard IP data, downlink 464kbps, uplink 448kbps  Streaming IP data, support 32kbps, 64kbps, 128kbps streaming  BGAN IP voice call, built-in SIP server  SMS / Email sending and receiving  GNSS service, support GPS, GLONASS and BeiDou  PPPoE dial-up Internet access  Data connection ON / OFF switch  Built-in Firewall, support MAC / IP / Application filtering  Built-in Web console, Remote Access for diagnostic, configuration, management  Smartphone application, support iOS APP and Android APP  Integrated DHCP / NAT routing  System settings backup and recovery  Traffic management, traffic threshold configurable, threshold alarm  Wire LAN (RJ45) and Wi-Fi connection, Wi-Fi coverage 60 meters  Global coverage (except for the poles)  Protection Grade IP65  Shock Resistance IK04 Appearance Composition STYLITE 500 is composed of  Host Unit  Battery  Adapter Interface 【1】 Charging Indicator LED 【2】 Power Switch 【3】 Power / Battery Indicator LED 【4】 Positioning Indicator LED 【5】 Signal Strength Indicator LED 【6】 Satellite Pointing Key 【7】 RJ45 LAN Interface 【8】 DC Power Interface 【9】 Elevation Indication 【10】 Battery Lock 【11】 Compass 【12】 Buzzer 5 Dimension Dimension of the terminal: 228mm x 217mm x 41.3mm Technical Specifications Frequency Receiving frequency 1518MHz~1559MHz Transmitting frequency range 1626.5MHz~1660.5MHz Coverage Service coverage Angle: 5° ~ 90° Azimuth: 360° Receiver G/T ≥ -13.5dB/K Transmitter EIRP -6.34dBW Service Standard IP Downlink 464kbps, Uplink 448kbps Streaming IP 32 kbps / 64 kbps / 128 kbps Voice BGAN IP voice SMS 160 Latin characters Environmental Conditions Operating temperature -20°C ~ +55°C Storage temperature -30°C ~ +80°C Relative humidity 95%, non-condensing (+40°C) Protection grade IP65 Shock Resistance IK04 Power Supply Battery 6Ah @ 11.1V, 66Wh Adapter 19VDC Data / Call duration 4h Standby 48h Interface LAN port 1 RJ45 SIM Card Slot 1 SIM slot Wi-Fi Built-in, Cover radius 60m FCCCaution Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2) thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay causeundesiredoperation. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor compliancecouldvoidtheuser'sauthoritytooperatetheequipment. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation. Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference toradiocommunications.However,thereisnoguaranteethatinterferencewillnot occurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe followingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe receiverisconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith minimumdistance20cmbetweentheradiator&yourbody.

Cover Letter(s)

Chengdu Spaceon Technology Co., Ltd. LETTER OF AGENCY 2019-08-19 Element Materials Technology 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yours faithfully Chengdu Spaceon Technology Co., Ltd. Signature Wendy Rao

Cover Letter(s)

Chengdu Spaceon Technology Co., Ltd. Long Term Confidentiality Request Letter 2019/8/19 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: BGAN Class 2 Mobile User Equipment Trademark: N/A FCC ID: 2AT37STYLITE500 MODEL : Stylite 500 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - BOM - PCB Layout required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Wendy Rao /Manager Contact information / address: No.88, Xinye Road, Scientific Industry Park, Chengdu Hi-tech Industry Zone

External Photos

External Photos

ID Label/Location Info

60*25mm Label Location Model: Stylite 500 FCC ID: 2AT37STYLITE500 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interfer ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Internal Photos Satellite antenna WIFI antenna

RF Exposure Info

Maximum Permissible Exposure (MPE) & Exposure evaluation FCC ID: 2AT37STYLITE500 Applied procedures / limit Equation from page 18 of OET Bulletin 65, Edition 97-01 Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna π = 3.1416 The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 f/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Technologies: Maximum Power (dBm) BGAN Class 2 Mobile User Equipment l 23.66 Prediction: minimum safety distance Max Output Power ( dBm) Antenna Gain(dBi) Limit (mW/cm 2 ) Minimum safety distance during operation / cm 23.66 11 1.0 80 Target power W/ tolerance (dBm) Max tune up power tolerance (dBm) Output power to antenna (mW) Antenna Gain(dBi) Power Density at R=80cm (mW/cm 2 ) Limit (mW/c m 2 ) Result 23.66 24 251.19 11 (12.59) 0.03932 1.0 Pass

Test Report

Page 2 of 30 Report No.: 190611020RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com Version Version No. Date Description V1.0 July 26, 2019 Original Page 3 of 30 Report No.: 190611020RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com CONTENTS 1. GENERAL INFORMATION ....................................................................................................................................... 4 1.1 CLIENT INFORMATION ........................................................................................................................................ 4 1.2 EUT INFORMATION ............................................................................................................................................ 4 1.3 PRODUCT SPECIFICATION SUBJECTIVE TO THIS STANDARD ................................................................................. 4 1.4 DESCRIPTION OF SUPPORT UNITS ...................................................................................................................... 4 1.5 TEST LOCATION ................................................................................................................................................. 5 1.6 TEST FACILITY ................................................................................................................................................... 5 1.7 DEVIATION FROM STANDARDS ............................................................................................................................ 5 1.8 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................. 5 1.9 OTHER INFORMATION REQUESTED BY THE CUSTOMER ........................................................................................ 5 1.10 MEASUREMENT UNCERTAINTY ........................................................................................................................... 6 2. TEST SUMMARY ...................................................................................................................................................... 7 3. EQUIPMENT LIST .................................................................................................................................................... 8 4. TEST CONFIGURATION .......................................................................................................................................... 9 4.1 ENVIRONMENTAL CONDITIONS FOR TESTING ........................................................................................................ 9 4.1.1 NORMAL OR EXTREME TEST CONDITIONS ............................................................................................... 9 4.1.2 RECORD OF NORMAL ENVIRONMENT....................................................................................................... 9 4.2 TEST CHANNELS ............................................................................................................................................... 9 4.3 EUT TEST STATUS ............................................................................................................................................ 9 4.4 TEST SETUP .................................................................................................................................................... 10 4.4.1 FOR RADIATED EMISSIONS TEST SETUP ................................................................................................ 10 4.4.2 FOR CONDUCTED RF TEST SETUP ........................................................................................................ 11 4.5 SYSTEM TEST CONFIGURATION ........................................................................................................................ 11 5. RADIO TECHNICAL REQUIREMENTS SPECIFICATION .................................................................................... 12 5.1 REFERENCE DOCUMENTS FOR TESTING ............................................................................................................ 12 5.2 OCCUPIED BANDWIDTH .................................................................................................................................... 12 5.3 FREQUENCY TOLERANCE ................................................................................................................................. 16 5.4 SPURIOUS EMISSIONS AT ANTENNA TERMINALS ................................................................................................ 17 5.5 RADIATED SPURIOUS EMISSIONS ...................................................................................................................... 23 5.6 EQUIVALENT ISOTROPIC RADIATED POWER ...................................................................................................... 24 5.7 LIMITS ON EMISSIONS FROM MOBILE EARTH STATIONS FOR PROTECTION OF AERONAUTICAL RADIO NAVIGATION- SATELLITE SERVICE ................................................................................................................................................... 25 APPENDIX 1 PHOTOS OF TEST SETUP ..................................................................................................................... 30 APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS ................................................................................. 30 Page 4 of 30 Report No.: 190611020RFC-1 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng…

Text truncated - open the document above for the full version.

Test Report

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 1 of 46 FCC Part 15C Test Report FCC ID: 2AT37STYLITE500 Product Name: BGAN Class 2 Mobile User Equipment Trademark: N/A Model Name : Stylite 500 Prepared For : Chengdu Spaceon Technology Co., Ltd. Address : No.88, Xinye Road, Scientific Industry Park, Chengdu Hi-tech Industry Zone Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Jun. 28, 2019 to Jun. 30, 2019 Date of Report : Jul. 30, 2019 Report No.: BCTC-FY190603030E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 2 of 46 TEST RESULT CERTIFICATION Applicant’s name ............... Chengdu Spaceon Technology Co., Ltd. Address ............................... No.88, Xinye Road, Scientific Industry Park, Chengdu Hi-tech Industry Zone Manufacture's Name .......... Chengdu Spaceon Technology Co., Ltd. Address ............................... No.88, Xinye Road, Scientific Industry Park, Chengdu Hi-tech Industry Zone Product description Product name ......................... BGAN Class 2 Mobile User Equipment Trademark ............................... N/A Model and/or type reference ............................ Stylite 500 Standards ........................... FCC Part15.247 ANSI C63.10:2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fang Zhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 3 of 46 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 12 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 RADIATED EMISSION LIMITS 15 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 16 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.2.8 TEST RESULTS (1GHZ~25GHZ) 21 3.3 RADIATED BAND EMISSION MEASUREMENT 22 3.3.1 TEST REQUIREMENT: 22 3.3.2 TEST PROCEDURE 22 3.3.3 DEVIATION FROM TEST STANDARD 23 3.3.4 TEST SETUP 23 3.3.5 EUT OPERATING CONDITIONS 23 4 . POWER SPECTRAL DENSITY TEST 28 4.1 APPLIED PROCEDURES / LIMIT 28 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 4 of 46 Table of Contents Page 4.1.1 TEST PROCEDURE 28 4.1.2 DEVIATION FROM STANDARD 28 4.1.3 TEST SETUP 28 4.1.4 EUT OPERATION CONDITIONS 28 4.1.5 TEST RESULTS 29 5 . BANDWIDTH TEST 31 5.1 APPLIED PROCEDURES / LIMIT 31 5.1.1 TEST PROCEDURE 31 5.1.2 DEVIATION FROM STANDARD 31 5.1.3 TEST SETUP 31 5.1.4 EUT OPERATION CONDITIONS 31 5.1.5 TEST RESULTS 32 6 . PEAK OUTPUT POWER TEST 34 6.1 APPLIED PROCEDURES/LIMIT 34 6.1.1 TEST PROCEDURE 34 6.1.2 DEVIATION FROM STANDARD 34 6.1.3 TEST SETUP 34 6.1.4 EUT OPERATION CONDITIONS 34 6.1.5 TEST RESULTS 35 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 36 7.1 APPLICABLE STANDARD 36 7.2 TEST PROCEDURE 36 7.3 DEVIATION FROM STANDARD 36 7.4 TEST SETUP 36 7.5 EUT OPERATION CONDITIONS 36 7.6 TEST RESULT 36 8 . DUTY CYCLE OF TEST SIGNAL 41 8.1 STANDARD REQUIREMENT 41 8.2 FORMULA: 41 9 . ANTENNA REQUIREMENT 42 9.1 STANDARD REQUIREMENT 42 9.2 EUT ANTENNA 42 10 . EUT TEST PHOTO 43 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 5 of 46 Table of Contents Page 11 . EUT PHOTO 45 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 6 of 46 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (d) Radiated Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Restricted Band of Operation PASS 15.247 (d) Band Edge (Out of Band Emissions) PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC-FY190603030E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.:A.0 Page 7 of 46 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add. : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Test Firm Registration Number: 712850 Test site MRA number: CN1212 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied …

Text truncated - open the document above for the full version.

Test Setup Photos

Page 1 of 1 FCC ID: 2AT37STYLITE500 Shenzhen UnionTrust Quality and Technology Co., Ltd. Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China Tel: +86-755-28230888 Fax: +86-755-28230886 E-mail: [email protected] Http://www.uttlab.com APPENDIX 1 PHOTOS OF TEST SETUP Radiated emission Test Setup (30 MHz~1 GHz) Radiated emission Test Setup (Above 1 GHz)

Test Setup Photos

Shenzhen BCTC Testing Co., Ltd. Conducted emissions Shenzhen BCTC Testing Co., Ltd. Radiated Measurement Photos

Contact Information

Applicant

Wendy Rao
[email protected]+8618328322474Fax: +8618328322474

Test Firm

Shenzhen BCTC Testing Co., Ltd.Alan Mei
[email protected]+8675536882589

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
6251.63 GHz - 1.66 GHz70.15 mW174KD1D10 ppm
Confidentiality
Long Term
Grant Notes
Output Power listed is EIRP. The Antenna installation and operating configurations of this transmitter, including antenna gain and cable loss must satisfy MPE Categorical Exclusion Requirements of§2.1091. The antenna used for this transmitter must be installed to provide a separation distance of at least 80 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter except as documented in this application. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
