2AT7E-OLAFUS-04SKBluetooth Speaker

shen zhen shi zhi hui duo ke ji you xian gong si Add: qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Date: 2022-2-23 FCC ID: 2AT7E-OLAFUS-04SK Dear Sir/Madam, We, shen zhen shi zhi hui duo ke ji you xian gong si Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Bluetooth Speaker Model no.: OLAFUS-04SK, A SPEAKER04, A SPEAKER05, OLAFUS-02SK, OLAFUS-03SK, A SPEAKER08, A SPEAKER09 Sincerely, Name/Title： Luis huang/N/A Company: shen zhen shi zhi hui duo ke ji you xian gong si Address: qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Phone: +86 18029157990 Fax: +86 0755-26995865 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2022-2-23> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AT7E-OLAFUS-04SK OLAFUS-04SK For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Luis huang/N/A Company: shen zhen shi zhi hui duo ke ji you xian gong si Address: qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Phone: +86 18029157990 Fax: +86 0755-26995865 E-Mail: [email protected]

shen zhen shi zhi hui duo ke ji you xian gong si qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2022-2-23 To whom it may concern: We, shen zhen shi zhi hui duo ke ji you xian gong si the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AT7E-OLAFUS-04SK including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Luis huang/N/A Company: shen zhen shi zhi hui duo ke ji you xian gong si Address: qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Phone: +86 18029157990 Fax: +86 0755-26995865 E-Mail: [email protected]

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 External Photos of the EUT Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 Fig. 3 Fig. 4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig. 7 Fig. 8

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 LABEL AND LOCATION (Size: L4.0cm x 4.0cm) Label Location Bluetooth Speaker Model: OLAFUS-04SK FCC ID: 2AT7E-OLAFUS-04SK

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Internal Photos of the EUT Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 Fig. 3 Fig. 4 BT Antenna Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig. 7 Fig. 8

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 4 FCC RF Exposure Evaluation 1. Product Information FCC ID : 2AT7E‐OLAFUS‐04SK Product name : Bluetooth Speaker Test Model : OLAFUS‐04SK Additional Model No. : A SPEAKER04, A SPEAKER05, OLAFUS‐02SK, OLAFUS‐03SK, A SPEAKER08, A SPEAKER09 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additionalmodelsweretested Power supply : Input: DC 5V, 1A, 7W DC 3.7V by Rechargeable Li‐ion Battery, 1400mAh Bluetooth : 2402MHz ~ 2480MHz Channel Number : 79 channels for Bluetooth V5.0(DSS) Channel Spacing : 1MHz for Bluetooth V5.0 (DSS) Modulation Type : GFSK, π/4‐DQPSK, 8‐DPSKfor Bluetooth V5.0(DSS) Bluetooth Version : V5.0 Antenna Type : PCB Antenna Antenna Gain : 2.0dBi(Max.) Hardware Version : V3.1 Software Version : 74AE Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 4 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1‐g head or body and 10‐g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source‐based time‐averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune‐up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two‐way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune‐up tolerance, mW)/ (min. test separaƟon distance, mm)] · [√f (GHz)] ≤ 3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune‐up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 4 4. Conducted Power Results <BT> Mode Channel Frequency(MHz) Max Conducted Power (dBm) GFSK 0 2402 ‐0.15 39 2441 0.32 78 2480 0.05 π/4DQPSK 0 2402 ‐0.55 39 2441 0.07 78 2480 ‐0.16 8DPSK 0 2402 ‐0.31 39 2441 0.18 78 2480 ‐0.…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 1 / 48 Appendix A RF Test Data for BT (Conducted Measurement) Product Name: Bluetooth Speaker Test Model: OLAFUS-04SK Environmental Conditions Temperature: 23.5  C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Monkey Li Supervised by: Li Huan Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 2 / 48 A.1 20dB Emission Bandwidth Test Result TestMode Antenna Channel 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 1.032 2401.463 2402.495 --- --- 2441 1.020 2440.469 2441.489 --- --- 2480 1.047 2479.454 2480.501 --- --- 2DH5 Ant1 2402 1.293 2401.355 2402.648 --- --- 2441 1.290 2440.358 2441.648 --- --- 2480 1.287 2479.358 2480.645 --- --- 3DH5 Ant1 2402 1.311 2401.337 2402.648 --- --- 2441 1.290 2440.346 2441.636 --- --- 2480 1.290 2479.343 2480.633 --- --- Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 3 / 48 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 4 / 48 2DH5_Ant1_2402 2DH5_Ant1_2441 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 5 / 48 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 6 / 48 3DH5_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 7 / 48 A.2 Maximum peak conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict DH5 Ant1 2402 -0.15 ≤20.97 PASS 2441 0.32 ≤20.97 PASS 2480 0.05 ≤20.97 PASS 2DH5 Ant1 2402 -0.55 ≤20.97 PASS 2441 0.07 ≤20.97 PASS 2480 -0.16 ≤20.97 PASS 3DH5 Ant1 2402 -0.31 ≤20.97 PASS 2441 0.18 ≤20.97 PASS 2480 -0.06 ≤20.97 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 8 / 48 Test Graphs DH5_Ant1_2402 DH5_Ant1_2441 DH5_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 9 / 48 2DH5_Ant1_2402 2DH5_Ant1_2441 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 10 / 48 2DH5_Ant1_2480 3DH5_Ant1_2402 3DH5_Ant1_2441 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 11 / 48 3DH5_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 12 / 48 A.3 Carrier frequency separation Test Result TestMode Antenna Channel Result[MHz] Limit[MHz] Verdict DH5 Ant1 Hop 0.82 ≥0.698 PASS 2DH5 Ant1 Hop 1.158 ≥0.862 PASS 3DH5 Ant1 Hop 1.092 ≥0.874 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 13 / 48 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 14 / 48 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 15 / 48 A.4 Time of occupancy Test Result TestMode Antenna Channel BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH5 Ant1 Hop 2.88 106.67 0.307 ≤0.4 PASS 2DH5 Ant1 Hop 2.88 106.67 0.308 ≤0.4 PASS 3DH5 Ant1 Hop 2.89 106.67 0.308 ≤0.4 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 16 / 48 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 17 / 48 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 18 / 48 A.5 Number of hopping channels Test Result TestMode Antenna Channel Result[Num] Limit[Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 19 / 48 Test Graphs DH5_Ant1_Hop 2DH5_Ant1_Hop 3DH5_Ant1_Hop Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 20 / 48 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 21 / 48 A.6 Band edge measurements Test Result TestMode Antenna ChName Channel RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -0.96 -48.83 ≤-20.96 PASS High 2480 -0.57 -47.91 ≤-20.57 PASS Low Hop_2402 -1.86 -49.09 ≤-21.86 PASS High Hop_2480 -0.71 -48.04 ≤-20.71 PASS 2DH5 Ant1 Low 2402 -1.83 -48.3 ≤-21.83 PASS High 2480 -1.57 -47.95 ≤-21.57 PASS Low Hop_2402 -2.35 -48.74 ≤-22.35 PASS High Hop_2480 -2.03 -46.96 ≤-22.03 PASS 3DH5 Ant1 Low 2402 -1.88 -48.17 ≤-21.88 PASS High 2480 -1.71 -47.59 ≤-21.71 PASS Low Hop_2402 -4.17 -49.49 ≤-24.17 PASS High Hop_2480 -1.82 -47.71 ≤-21.82 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 22 / 48 Test Graphs DH5_Ant1_Low_2402 DH5_Ant1_High_2480 DH5_Ant1_Low_Hop_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 23 / 48 DH5_Ant1_High_Hop_2480 2DH5_Ant1_Low_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 24 / 48 2DH5_Ant1_High_2480 2DH5_Ant1_Low_Hop_2402 2DH5_Ant1_High_Hop_2480

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 25 / 48 3DH5_Ant1_Low_2402 3DH5_Ant1_High_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 26 / 48 3DH5_Ant1_Low_Hop_2402 3DH5_Ant1_High_Hop_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 27 / 48 A.7 Conducted Spurious Emission Test Result TestMode Antenna Channel FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 Reference -0.96 -0.96 --- PASS 30~1000 -0.96 -60.82 ≤-20.96 PASS 1000~26500 -0.96 -45.62 ≤-20.96 PASS 2441 Reference -0.52 -0.52 --- PASS 30~1000 -0.52 -60.19 ≤-20.52 PASS 1000~26500 -0.52 -46.25 ≤-20.52 PASS 2480 Reference -0.66 -0.66 --- PASS 30~1000 -0.66 -56.09 ≤-20.66 PASS 1000~26500 -0.66 -46.17 ≤-20.66 PASS 2DH5 Ant1 2402 Reference -1.87 -1.87 --- PASS 30~1000 -1.87 -60.23 ≤-21.87 PASS 1000~26500 -1.87 -45.8 ≤-21.87 PASS 2441 Reference -1.69 -1.69 --- PASS 30~1000 -1.69 -60.22 ≤-21.69 PASS 1000~26500 -1.69 -46.23 ≤-21.69 PASS 2480 Reference -1.57 -1.57 --- PASS 30~1000 -1.57 -60.33 ≤-21.57 PASS 1000~26500 -1.57 -46.04 ≤-21.57 PASS 3DH5 Ant1 2402 Reference -1.82 -1.82 --- PASS 30~1000 -1.82 -60.76 ≤-21.82 PASS 1000~26500 -1.82 -45.31 ≤-21.82 PASS 2441 Reference -1.32 -1.32 --- PASS 30~1000 -1.32 -60.31 ≤-21.32 PASS 1000~26500 -1.32 -45.87 ≤-21.32 PASS 2480 Reference -1.84 -1.84 --- PASS 30~1000 -1.84 -60.67 ≤-21.84 PASS 1000~26500 -1.84 -45.99 ≤-21.84 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 28 / 48 Test Graphs DH5_Ant1_2402_0~Reference DH5_Ant1_2402_30~1000 DH5_Ant1_2402_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 29 / 48 DH5_Ant1_2441_0~Reference DH5_Ant1_2441_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 30 / 48 DH5_Ant1_2441_1000~26500 DH5_Ant1_2480_0~Reference DH5_Ant1_2480_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 31 / 48 DH5_Ant1_2480_1000~26500 2DH5_Ant1_2402_0~Reference Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 32 / 48 2DH5_Ant1_2402_30~1000 2DH5_Ant1_2402_1000~26500 2DH5_Ant1_2441_0~Reference Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 33 / 48 2DH5_Ant1_2441_30~1000 2DH5_Ant1_2441_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 34 / 48 2DH5_Ant1_2480_0~Reference 2DH5_Ant1_2480_30~1000 2DH5_Ant1_2480_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 35 / 48 3DH5_Ant1_2402_0~Reference 3DH5_Ant1_2402_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 36 / 48 3DH5_Ant1_2402_1000~26500 3DH5_Ant1_2441_0~Reference 3DH5_Ant1_2441_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 37 / 48 3DH5_Ant1_2441_1000~26500 3DH5_Ant1_2480_0~Reference Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 38 / 48 3DH5_Ant1_2480_30~1000 3DH5_Ant1_2480_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 39 / 48 A.8 Emissions in Restricted Bands Test Result TestMode Antenna ChName Channel Detector Freq. [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict DH5 Ant1 Low 2402 AV 2310.000-48.3 ≤-41.2046.90 ≤54 PASS AV 2383.370-47.73 ≤-41.2047.47 ≤54 PASS AV 2390.000-47.88 ≤-41.2047.32 ≤54 PASS Peak 2310.000-38.1 ≤-21.2057.10 ≤74 PASS Peak 2310.605-36.65 ≤-21.2058.55 ≤74 PASS Peak 2390.000-37.81 ≤-21.2057.39 ≤74 PASS High 2480 AV 2483.500-47.21 ≤-41.2047.99 ≤54 PASS AV 2490.800-47.18 ≤-41.2048.02 ≤54 PASS AV 2500.000-47.32 ≤-41.2047.88 ≤54 PASS Peak 2483.500-37.79 ≤-21.2057.41 ≤74 PASS Peak 2495.280-36.3 ≤-21.2058.90 ≤74 PASS Peak 2500.000-37.74 ≤-21.2057.46 ≤74 PASS Low Hop_24 02 Peak 2310.000-38.57 ≤-21.2056.63 ≤74 PASS Peak 2349.455-37.2 ≤-21.2058.00 ≤74 PASS Peak 2390.000-38.42 ≤-21.2056.78 ≤74 PASS High Hop_24 80 Peak 2483.500-37.99 ≤-21.2057.21 ≤74 PASS Peak 2486.800-36.05 ≤-21.2059.15 ≤74 PASS Peak 2500.000-37.99 ≤-21.2057.21 ≤74 PASS 2DH5 Ant1 Low 2402 AV 2310.000-48.26 ≤-41.2046.94 ≤54 PASS AV 2386.520-47.79 ≤-41.2047.41 ≤54 PASS AV 2390.000-47.95 ≤-41.2047.25 ≤54 PASS Peak 2310.000-38.7 ≤-21.2056.50 ≤74 PASS Peak 2387.885-36.48 ≤-21.2058.72 ≤74 PASS Peak 2390.000-37.59 ≤-21.2057.61 ≤74 PASS High 2480 AV 2483.500-47.25 ≤-41.2047.95 ≤54 PASS AV 2486.960-47.09 ≤-41.2048.11 ≤54 PASS AV 2500.000-47.26 ≤-41.2047.94 ≤54 PASS Peak 2483.500-37.59 ≤-21.2057.61 ≤74 PASS Peak 2496.800-35.78 ≤-21.2059.42 ≤74 PASS Peak 2500.000-38.42 ≤-21.2056.78 ≤74 PASS Low Hop_24 02 Peak 2310.000-39.1 ≤-21.2056.10 ≤74 PASS Peak 2321.000-37.07 ≤-21.2058.13 ≤74 PASS Peak 2390.000-38.62 ≤-21.2056.58 ≤74 PASS High Hop_24 80 Peak 2483.500-38.34 ≤-21.2056.86 ≤74 PASS Peak 2494.960-35.95 ≤-21.2059.25 ≤74 PASS Peak 2500.000-38.46 ≤-21.2056.74 ≤74 PASS 3DH5 Ant1 Low 2402 AV 2310.000-48.27 ≤-41.2046.93 ≤54 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E‐OLAFUS‐04SK Report No.: LCS220111159AEA 40 / 48 AV 2372.135-47.71 ≤-41.2047.49 ≤54 PASS AV 2390.000-47.75 ≤-41.2047.45 ≤54 PASS Peak 2310.000-38.88 ≤-21.2056.32 ≤74 PASS Peak 2383.790-37.13 ≤-21.2058.07 ≤74 PASS Peak 2390.000-38.99 ≤-21.2056.21 ≤74 PASS High 2480 AV 2483.500-47.26 ≤-41.2047.94 ≤54 PASS AV 2497.680-47.16 ≤-41.2048.04 ≤54 PASS AV 2500.000-47.34 ≤-41.2047.86 ≤54 PASS Peak 2483.500-38.45 ≤-21.2056.75 ≤74 PASS Peak 2490.560-36.32 ≤-21.2058.88 ≤74 PASS Peak 2500.000-37.84 ≤-21.2057.36 ≤74 PASS Low Hop_24 02 Peak 2310.000-38.85 ≤-21.2056.35 ≤74 PASS Peak 2…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK Report No.: LCS220111159AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 36 FCC TEST REPORT FOR shen zhen shi zhi hui duo ke ji you xian gong si Bluetooth Speaker Test Model: OLAFUS-04SK Additional Model No.: Please Refer to Page 6 Prepared for : shen zhen shi zhi hui duo ke ji you xian gong si Address : qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : February 14, 2022 Number of tested samples : 2 Sample No. : 220111159A-1, 220111159A-2 Serial number : Prototype Date of Test : February 14, 2022 ~ February 18, 2022 Date of Report : February 21, 2022 Scan code to check authenticity Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK Report No.: LCS220111159AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 36 FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ....................... : LCS220111159AEA Date of Issue ......................................... : February 21, 2022 Testing Laboratory Name ................. : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ................................................. : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ................ : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ............................... : shen zhen shi zhi hui duo ke ji you xian gong si Address ................................................. : qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Test Specification Standard ............................................... : FCC CFR 47 PART 15 C (15.247) Test Report Form No. .......................... : LCSEMC-1.0 TRF Originator ..................................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .......................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ........................ : Bluetooth Speaker Trade Mark ........................................... : Olafus Test Model ........................................... : OLAFUS-04SK Ratings ................................................. : Input: DC 5V, 1A, 7W DC 3.7V by Rechargeable Li-ion Battery, 1400mAh Result ................................................. : Positive Compiled by: Supervised by: Approved by: Ray Yang/ Administrator Jin Wang/ Technique principal Gavin Liang / Manager Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK Report No.: LCS220111159AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 36 FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS220111159AEA February 21, 2022 Date of issue Test Model.............................. : OLAFUS-04SK EUT......................................... : Bluetooth Speaker Applicant............................... : shen zhen shi zhi hui duo ke ji you xian gong si Address................................... : qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Telephone............................... : / Fax.......................................... : / Manufacturer......................... : shen zhen shi zhi hui duo ke ji you xian gong si Address................................... : qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Telephone............................... : / Fax.......................................... : / Factory................................... : shen zhen shi zhi hui duo ke ji you xian gong si Address................................... : qian wan yi lu yi hao A dong 201 shi, qian hai shen gang he zuo qu Shen zhen, 518000 China Telephone............................... : / Fax.......................................... : / Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK Report No.: LCS220111159AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 36 Revision History Revision Issue Date Revision Content Revised By 000 February 21, 2022 Initial Issue -- Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK Report No.: LCS220111159AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 36 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..................................................................................................... 6 1.1 Description of…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK _______________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AT7E-OLAFUS-04SK _______________________________________________________________________________________________ This report shall …
