2AT8X-FALCONIIBluetooth earphone

2 Thanks for purchasing NOBLE’s Falcon 2 Bluetooth 5.2 True Wireless Earbuds. Please carefully read this instruction manual before using your new Falcon 2 earbuds. Noble Falcon earbuds x 1 pairs Instruction Manual x 1 Storage bag x1 3 Multifunction button (MFB) Earbuds LED light Microphone LED light Charging port Charging case 2 3 EN EN 2 Ear tips x 3 USB charging cable x 1 Packing List Product Overview 4 (The white indicator light will blink for one second to indicate that the earbuds are in a “power on” state.) To manually turn the earbuds on, press the MFB button lightly to boot up. 5 5 EN EN 4 Power On Power Off 4 5 7 EN EN 6 Pairing Procedure ll connect automatically each time they are booted up. Pairing 1.Remove your two earbuds from the charging case. They will power on automatically, and will enter pairing mode, with orange a 2.Enable Bluetooth on your smartphone, and search for “NOBLE Falcon_L/R” in available Bluetooth devices. Once found, click “NOBLE Falcon_L/R” to initiate the pairing. ttings will be completed. NOBLE Falcon 2 Pairing a new device Repeat above steps Model MUSIC Phone Siri Volume Function Play Pause Next Track Previous Track Answer Call Hang Up Reject Call Enable Disable Up + Down - - Single Click or Put in Charging Case Single Click Single Click Single Click Three Click Double Click Double Click Three Click Press 1 Second Press 1 Second Press 1 Second - - - - - - - - LR How to Pair Button Operation 4 5 9 EN EN 8 ·Declarations and Warnings Disconnect previous devices before pairing a new device. ·WARNING! Long-term exposure to high noise volumes may cause permanent hearing loss. · Do not use the NOBLE Falcon earbuds in locations prohibiting the use of electronic equipment. · Consult your physician prior to using your NOBLE Falcon earbuds if you have a pacemaker or other electrical medical device. · This package contains small parts, which may pose a hazard to small children. or serious injury. ·Any disassembly of the NOBLE Falcon, or attempt to replace or repair the NOBLE Falcon by an unauthorized person, will void the NOBLE Falcon’s warranty. ·This product is not designed for use in water, keep product away from water and liquids. Failure to do so may cause permanent damage to the product. ·FCC Statement ·Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. ·This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ·-- Reorient or relocate the receiving antenna. ·-- Increase the separation between the equipment and receiver. ·-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ·-- Consult the dealer or an experienced radio/TV technician for help ·This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 8 Battery Indicator All LED On Case Charging ChargingChargingWhite LED ONOrange LED ON Fully ChargedFully Charged Earbuds Charging Charging Declarations and Warning 3 2 11 JP JP10 x 1x 1 x1 3 2 13 JP JP 12 x 3 x 1 4 5 15 JP JP 14 NOBLE Falcon 2 4 5 17 JP JP 16 8 4 5 19 JP JP 18 JP 20 21 JP 0570-057067 4 5 23 JP JP 22 8 4 5 25 JP JP 24 8 4 JP 26 8 24

22020-09-27 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Jim Moulton Title: Manager Applicant Company: Noble HiFi. LLC

Noble HiFi. LLC 2020-09-27 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AT8X-FALCONII Product Name: Bluetooth earphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Jim Moulton Title: Manager Company: Noble HiFi. LLC

FCC ID: 2AT8X-FALCONII Product: Bluetooth earphone s Model No.: Falcon II The device have left and right earphone , left and right earphone are electrically identical . <Signature> Name: Jim Moulton Title: Manager Company: Noble HiFi. LLC

Noble HiFi. LLC 2020-09-27 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongce Testing Lab. / 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Noble HiFi. LLC / 109 State Hwy. 110 S, Whitehouse, Texas 75791, United States (Applicant Name and address) <Signature> Name: Jim Moulton Title: Manager Applicant Company: Noble HiFi. LLC

Page 1 of 4 Appendix B: Photographs of EUT Product: Bluetooth earphone Model: Falcon II External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: Falcon II Label: Size: L*W=32.3*20mm Location 5mm

Page 1 of 4 Appendix B: Photographs of EUT Product: Bluetooth earphone Model: Falcon II Internal Photos Page 2 of 4 Antenna Page 3 of 4 Page 4 of 4

RF exposure evaluation FCC ID: 2AT8X-FALCONII §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  For EDR+BDR: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 8.96 8±1 9 7.94 5 2.50 3.0 Result: Base on the calculation value, No SAR measurement is required.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AT8X-FALCONII Product: Bluetooth earphone Model No.: Falcon II Additional Model No.: N/A Trade Mark: NOBLE Report No.: TCT200828E001 Issued Date: Sep. 10, 2020 Issued for: Noble HiFi. LLC 109 State Hwy. 110 S, Whitehouse, Texas 75791, United States Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT200828E001 Page 2 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 18 6.5. Carrier Frequencies Separation ......................................................................... 23 6.6. Hopping Channel Number .................................................................................. 28 6.7. Dwell Time ............................................................................................................ 31 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 36 6.9. Conducted Band Edge Measurement ................................................................ 37 6.10. Conducted Spurious Emission Measurement ................................................. 41 6.11. Radiated Spurious Emission Measurement .................................................... 45 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT200828E001 Page 3 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Bluetooth earphone Model No.: Falcon II Additional Model No.: N/A Trade Mark: NOBLE Applicant: Noble HiFi. LLC Address: 109 State Hwy. 110 S, Whitehouse, Texas 75791, United States Manufacturer: SHENZHEN SHI KISB ELECTRONIC CO., LTD. Address: F4, 5, BlockB, F3, Building A, Shanghe Industrial Park, Nanchang Village, Hangcheng Avenue, Xixiang Town, Bao'an District, Shenzhen City, Guangdong Province, China. Date of Test: Aug. 31, 2020 – Sep. 09, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Sep. 09, 2020 Rleo Reviewed By: Date: Sep. 10, 2020 Beryl Zhao Approved By: Date: Sep. 10, 2020 Tomsin Report No.: TCT200828E001 Page 4 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT200828E001 Page 5 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: Bluetooth earphone Model No.: Falcon II Additional Model No.: N/A Trade Mark: NOBLE Bluetooth Version: V5.2 Operation Frequency: 2402MHz~2480MHz Transfer Rate: 1/2/3 Mbits/s Number of Channel: 79 Modulation Type: GFSK, π/4-DQPSK, 8DPSK Modulation Technology: FHSS Ant…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Bluetooth earphone Model: Falcon II Radiated Emission Page 2 of 2 Conducted Emission
