2AT9B-AV-1327W-99Car Audio

QUICK START GUIDE AV-1327W-99 Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. Media Receiver with Wireless and Wired CarPlay™ and Android Auto™ featuring a 7" digital TFT Display Installation Wiring Diagram - Inputs/Outputs Main Menu Tuner Operation x 2 Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATC mini style fuse located on the power connector. Wiring Notes: Subwoofer output The Subwoofer preamp audio output (Blue jacket with Black RCA) is active in all audio modes. Rear camera input A rear view camera (not included) can be used with the Camera input. SiriusXM For more information on how to install the SiriusXM Connect Vehicle tuner, consult the installation guide included with the tuner(SiriusXM connect tuner and subscription sold separely). In main menu, press the desired icon to enter the corresponding mode: Radio/Android Auto/ CarPlay/USB/Bluetooth/AV In/Settings. 1235 9 87 11 10 12 www.maxmade.cn Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen. China 1327W-99 Main Menu Current Mode Seek down Radio frequency EQ Seek up Keypad button DX Auto Store button AM FM Preset Station List 1 2 3 4 5 6 7 8 9 10 11 Control Locations The radio display features the following functions and displays: Home VOL+ VOICE COMMAND BUTTON VOL- 1 2 3 4 5 2 1 3 4 5 Wired & Wireless Android Auto™ Operation Wired connection 1. Connect an Android Auto™ compatible device to this unit via USB. 2. Press the Android Auto icon. The Android Auto home screen appears. Wireless connection Before using Android Auto wirelessly, turn on the Bluetooth/Wifi function on the Android device. 1. Press icon on the main menu; 2. Press "” to confirm to use wireless Android Auto; 3. Press "”icon to search phone device. The available devices appear on the list; 4. Find the desired device on the screen and press "Pair"; 5. A pass key will be displayed on the screen; 6. The same key appears on the Android device, press "Pair" and then press "Allow" for the popups; 7. Press "” on the screen to confirm to connect; The unit configures the connection then starts the application. Tip: Press "” icon. Displays Android Auto device list. This icon appears Only When Android Auto is connected and two or more devices can be used as Android Auto Source. Note: Works for CarPlay and Android Auto only. Power/Mute 4 6 12 USB Operation From the main menu, touch the USB icon on the main screen. Main Menu Current Mode Indicator Audio button Video button Keypad Repeat Random Track Down Play/Pause Track Up EQ 1 2 3 4 5 6 7 8 9 10 1 23 6 5 General Operation From the Main Menu screen, select Setup to access the Settings menu and select from eight categories represented by the icons on the top of the screen: General, Audio, Display, Others. Select the category, and adjust any of the available options using the touch screen. SiriusXM ® Satellite Radio Operation From the main menu, touch the SXM icon on the main screen. Main Menu Band Program Information Search Preset Channel List Additional Options Preset Buttons Direct Channel Down Channel Up Tune / Track Down Play / Pause Tune / Track Up 1 2 3 4 5 6 7 8 9 10 11 12 13 13 2564 8910111213 7 Audio Operation Press the "Settings" icon on the main menu screen to adjust Fader and Balance controls, Equalizer (8-Band Tone Control and 8 Presets EQ Settings). Wired & Wireless CarPlay Operation Wired connection 1. Connect an Apple CarPlay compatible device to this unit via USB. 2. Press the Apple CarPlay icon. The Apple CarPlay home screen appears. Wireless connection Before using Apple CarPlay wirelessly, turn on the Bluetooth/Wifi function on the Phone. 1. Press icon on the main menu; 2. Press "” to confirm to use wireless CarPlay; 3. Press "”icon to search phone device. The available devices appear on the list; 4. Find the desired device on the screen and press "Pair"; 5. A pass key will be displayed on the screen; 6. The same key appears on the iPhone, press "Pair" and then press "Allow" for the popups; 7. Press "” on the screen to confirm to connect; 8. Press "Use CarPlay" on the iPhone. The unit configures the connection then starts the application. Tip: Press "” icon. Displays CarPlay device list. This icon appears Only When CarPlay is connected and two or more devices can be used as CarPlay Source. 4 7 8 9 1011 11 Before using Bluetooth Before you can use a Bluetooth device to make hands-free calls or stream audio. it must be authenti- cated. This is also referred to as "pair" a device. Pairing a New Device The unit broadcasts the pairing signal constantly when no devices are currently connected. Complete the pairing sequence from your Bluetooth device. Refer to the owner's manual for your device for more details. The device name is "BT AUDIO". The unit can be in any mode of operation when pair- ing is performed. On certain phones, pairing may need to be done more than once. Connect The head unit will automatically connect to the last connected device when the connect feature is set to Auto connect On. If the connect feature is set to Auto Connect Off, the head unit will not automati- cally connect to any device. Bluetooth Phone From the main menu. touch the Bluetooth on the screen. Bluetooth icon will appear anytime a Bluetooth device is connected. Dialing a Number Press to display keypad and dial a number. Making and Ending a Call Press to connect a call, and press to end a call. Streaming Audio Pressto play or pause the music. Press to skip to the previous track. Press to advance to the next track. study wheel control TSTEERING WHEEL KEY LEARNING allow you to learn factory fitted steering mounted audio controls. 1. Select Restudy from the wheel key s…

Text truncated - open the document above for the full version.

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: MAXMADE AUTO ELECTRONICS CO.,LTD. Grantee code: 2AT9B FCC ID: 2AT9B-AV-1327W-99 Contact Name: Chester Yang Address: Building 2,GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Telephone No: 13428922936 Fax No: +86-0755-2319 9626 Email: [email protected] i. [MAXMADE AUTO ELECTRONICS CO.,LTD.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [MAXMADE AUTO ELECTRONICS CO.,LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [MAXMADE AUTO ELECTRONICS CO.,LTD.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2023/05/11 Applicant’s Name: Chester Yang Title: Director Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091 X10 Ed.1 MAXMADE AUTO ELECTRONICS CO.,LTD. Office of Engineering Technolo gy Federal Communicati。nsCommission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022/09/28 Subject: R equest for Confidentiality FCC ID；也，T9B-AV-132 7 W-99 To Whom It May c 。 ncern, Pu「suant to the provisi。ns of Sections 0.457 and 0.459 of Commission's rules ( 4 7 C F R0.457, 0.459), we are陀 questingth e Commission to withhold th e fol l owi 『， g attachment ( s) as confidential document from public disclosure. Exhibits Long-Term Short-Term Confidentiality Confidentialitv ID Label/L民ation N。 No Attestation Statement No No External Photos No 因 Block Diaaram 囚 口 Schemati臼 l:J 口 Test Reoort No No 丁estSetuo Phot，臼 No 国 User ’ s Manual 口因 Internal阶，otos 口囚 Parts List I Tune Up 口口 RF Exoosure Info 口口 Ooeratlonal Descrlotion 囚 口 Cove「Le忧er(s) No No SDR S。先wareI Securitv Info 吕 t· ·· ． ，．’kyat－「－H ’l ttEUL’’ · ·SE · I · － In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. Above mention ed docu ment contains detailed system and equipme nt description are considered as prop 「 ie阳叩infor mation in operation of the equipment .有，e public d i sclosur e of above document s might be ha r mf u l to our comp any and would g ive competitor an unfair advantage in the market. It is o ur understa nding t hat all measurement test repo此s, FCC ID label format and correspond ent during certification review process cannot be granted as confide ntial documents a nd those i nformation wi l l be available for public review 。 nee the grant of equipme nt auth 。 rization Is issued. Sincerely, cJ � 问 Signature: Name: Chester Yang Title: Director 一 囚 口

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 92 of 99 16. Photos of the EUT Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 93 of 99 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 94 of 99

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 95 of 99 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 96 of 99 BT/WIFI ANT. Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 97 of 99 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 98 of 99 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E01 Page 99 of 99 END OF REPORT

Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 1 of 8 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Equipment under Test : Car Audio Model No. : AV-1327W-99 Trade Mark : N/A FCC ID : 2AT9B-AV-1327W-99 Manufacturer : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Report No.: DDT-R22070625-2E04 Issued Date: Sep. 27, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 2 of 8 Table of Contents Test report declares.......................................................................................................3 1. General Information ....................................................................................................... 5 1.1. Description of equipment ............................................................................................... 5 1.2. Assess laboratory ........................................................................................................... 6 2. RF Exposure Evaluation ................................................................................................ 7 2.1. Requirement ................................................................................................................... 7 2.2. Calculation method ........................................................................................................ 7 2.3. Estimation result ............................................................................................................. 8 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 3 of 8 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd. and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd. is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-R22070625-2E04 Date of Receipt: Jul. 11, 2022 Date of Test: Jul. 11, 2022 ~ Sep. 27, 2022 Prepared By: Approved By: ____________________ ______________________ Johnny Wang/Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Equipment under Test : Car Audio Model No. : AV-1327W-99 Trade mark : N/A Manufacturer : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue Sep. 27, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 5 of 8 1. General Information 1.1. Description of equipment EUT* Name : Car Audio Model Number : AV-1327W-99 EUT function description : Please reference user manual of this device Power Supply : DC 12V Radio Specification : Bluetooth V4.2 IEEE 802.11b/g/n IEEE 802.11a/n/ac Operation Frequency : BT: 2402 MHz - 2480 MHz IEEE 802.11b: 2412MHz—2462MHz IEEE 802.11g: 2412MHz—2462MHz IEEE 802.11n HT20: 2412MHz—2462MHz IEEE 802.11n HT40: 2422MHz—2452MHz IEEE 802.11a: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11n HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT20: 5180MHz-5240MHz, 5745MHz-5825MHz IEEE 802.11ac HT40: 5190MHz-5230MHz, 5755MHz-5755MHz IEEE 802.11ac HT80: 5210MHz, 5775MHz Modulation : GFSK, /4-DQPSK, 8DPSK IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11a: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11ac: OFDM (256QAM, 64QAM, 16QAM, QPSK, BPSK) Data Rate : BT: 1 Mbps, 2 Mbps, 3 Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps IEEE 802.11n HT20: up to 72.2 Mbps IEEE 802.11n HT40: up to 150 Mbps IEEE 802.11a: up to 54 Mbps IEEE 802.11ac HT20: up to 86.6 Mbps IEEE 802.11ac HT40: up to 200 Mbps IEEE 802.11ac HT80: up to 433.3 Mbps Antenna Gain : BT: FPC antenna, maximum PK gain: 6.42 dBi 2.4G WIFI: FPC antenna, maximum PK gain: 6.42 dBi 5G WIFI: FPC antenna, maximum PK gain: 7.12 dBi Sample Number : S22070625-01 for conductive S22070625-02 for radiation Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page 6 of 8 1.2. Assess laboratory Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808. Tel.: +86-0769-38826678, http://www.dgddt.com, Email: [email protected]. CNAS Accreditation No. L6451; A2LA Accreditation Number: 3870.01 FCC Designation Number: CN1182, Test Firm Registration Number: 540522 Innovation, Science and Economic Development Canada Site Registration Number: 10288A Conformity Assessment Body identifier: CN0048 VCCI facility registration number: C-20087, T-20088, R-20123, R-20155, G-20118 Dongguan Dongdian Testing Service Co., Ltd. Report No.:DDT-R22070625-2E04 Page…

Text truncated - open the document above for the full version.

深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 1 页 承认书 厂商： 深圳市承拓电子有限公司 原厂名称： FPC-2.4/5.8G天线 原厂料号： 01010E04001 原厂规格： 2.4/5.8G-FPC0015-1.37YX 黑 -C13-150 文档编号制 作 品质工程复核签章 20230110-001 日期 客户： 麦思美 客户名称：深圳市麦思美汽车电子有限公司 客户料号：2-WX01-0150-01-YX-0 客户规格： WIFI/BT 天线 文档编号承认人日期签章 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 2 页 产品参 考图片 注：承认书一式三份，供应商存档一份，客户存档二份。 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 3 页 产品规格书 PRODUCTSPECIFICATION Customer:shenzhenChengtuoElectronicCo.,LTD Customer’spartnumber:01010E04001 Productdescription:2.4/5.8GANTENNA(Pastetype) UniLink’spartnumber:2.4/5.8G-FPC0015-1.37YX黑-C13-150 IssueDate:2023-01-10 Note:2400-2500/5150-5850 CustomerUse Customer'sauthorized signature Remarks Fullapproved Conditional approved Rejected 承拓电子 Tel:86-755-89368800 Fax:86-755-89368100 Website:www.kontec.com.cn 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 4 页 一、产品技术指标（PRODUCTTECHNICALSPECIFICATION） 电性能指标 ElectricalSpecifications 频率范围 FrequencyRange(MHz)2400-2500/5150-5850 机械指标 MechanicalSpecifications 天线长度AntennaLength(mm)42.3*15.3±0.5mm 电缆长度Cable(mm)150±5mm 连接器型号ConnectTypeIPEX 固定方式 Mounting 粘贴式 Pastetype 线材颜色 ColorofCable 黑色 Black 工作温度（ OperatingTemperature ） -30 °C～ +70 °C 工作湿度（%）0%-95% 贮藏温度（StoringTemperature）-35°C～+75°C 贮藏湿度（%）0%-95% 二、测试数据 (testdata) ： 1. 驻波测试 (Standingwavetest) ： 测试仪器 (testinstrument) ：罗德与施瓦茨 ZVB8(ROHDE&SCHWARZZVB8) 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 5 页 测试数据(testdata)： 2．OTA测试(OTAtest)： 测试设备(testequipment)：24探头球型微波暗测试室(Testroom) 测试仪器(testinstrument)：5071B，CMW500，E4438C 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 6 页 测试数据(testingdataset)： 2.4G: 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 7 页 5.8G: 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 8 页 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 9 页 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 10 页 深 圳 市 承 拓 电 子 有 限 公 司 承拓电子 www.kontec.com.cn 第 11 页 3D 注：测试数据以我司实验室为准(The test data shall be subject to our laboratory)。 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 12 页 三、安装位置示意图(installationsite)： 深圳市承拓电子有限公司 承拓电子 www.kontec.com.cn 第 13 页

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 1 of 101 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Equipment under Test : Car Audio Model No. : AV-1327W-99 Trade Mark : N/A FCC ID : 2AT9B-AV-1327W-99 Manufacturer : MAXMADE AUTO ELECTRONICS CO.,LTD. Address : Building 2, GIEC Industrial Park, Puzai Road, Pingdi, Longgang District, Shenzhen, China Report No.: DDT-R22070625-2E02 Issued Date: Sep. 27, 2022 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 2 of 101 TABLE OF CONTENTS Test report declares.........................................................................................................4 1. Summary of test results ................................................................................................. 6 2. General test information ................................................................................................. 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 7 2.3. Assistant equipment used for test .................................................................................. 7 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Deviations of test standard............................................................................................. 8 2.6. Test environment conditions .......................................................................................... 8 2.7. Test laboratory ............................................................................................................... 9 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment used during test ......................................................................................... 10 4. 6dB Bandwidth and 99% Bandwidth ............................................................................ 11 4.1. Block diagram of test setup .......................................................................................... 11 4.2. Limits ............................................................................................................................ 11 4.3. Test Procedure ............................................................................................................. 11 4.4. Test Result ................................................................................................................... 12 4.5. original test data ........................................................................................................... 13 5. Duty Cycle .................................................................................................................... 22 5.1. Block diagram of test setup .......................................................................................... 22 5.2. Limit .............................................................................................................................. 22 5.3. Test procedure ............................................................................................................. 22 5.4. Test result ..................................................................................................................... 23 5.5. Original test data .......................................................................................................... 23 6. Conducted Output Power ............................................................................................. 28 6.1. Block diagram of test setup .......................................................................................... 28 6.2. Limits ............................................................................................................................ 28 6.3. Test Procedure ............................................................................................................. 28 6.4. Test Result ................................................................................................................... 28 7. Power Spectral Density ................................................................................................ 29 7.1. Block diagram of test setup .......................................................................................... 29 7.2. Limits ............................................................................................................................ 29 7.3. Test Procedure ............................................................................................................. 29 7.4. Test Result ................................................................................................................... 29 7.5. original test data ........................................................................................................... 30 8. Band Edge Compliance (Conducted Method) ............................................................. 35 8.1. Block diagram of test setup .......................................................................................... 35 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 3 of 101 8.2. Limits ............................................................................................................................ 35 8.3. Test procedure ..................…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 40 of 101 9.4. Test Result EUT Set Mode CH or Frequency Result (dBm) EUT Set Mode CH or Frequency Result Result (dBm) 11b CH1 Pass 11n HT 20 CH1 Pass CH6 Pass CH6 Pass CH11 Pass CH11 Pass 11g CH1 Pass 11n HT 40 CH3 Pass CH6 Pass CH6 Pass CH11 Pass CH9 Pass 9.5. original test data 11B_Ant1_2412_0~Reference 11B_Ant1_2412_30~1000 11B_Ant1_2412_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 41 of 101 11B_Ant1_2437_0~Reference 11B_Ant1_2437_30~1000 11B_Ant1_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 42 of 101 11B_Ant1_2462_0~Reference 11B_Ant1_2462_30~1000 11B_Ant1_2462_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 43 of 101 11G_Ant1_2412_0~Reference 11G_Ant1_2412_30~1000 11G_Ant1_2412_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 44 of 101 11G_Ant1_2437_0~Reference 11G_Ant1_2437_30~1000 11G_Ant1_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 45 of 101 11G_Ant1_2462_0~Reference 11G_Ant1_2462_30~1000 11G_Ant1_2462_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 46 of 101 11N20SISO_Ant1_2412_0~Reference 11N20SISO_Ant1_2412_30~1000 11N20SISO_Ant1_2412_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 47 of 101 11N20SISO_Ant1_2437_0~Reference 11N20SISO_Ant1_2437_30~1000 11N20SISO_Ant1_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 48 of 101 11N20SISO_Ant1_2462_0~Reference 11N20SISO_Ant1_2462_30~1000 11N20SISO_Ant1_2462_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 49 of 101 11N40SISO_Ant1_2422_0~Reference 11N40SISO_Ant1_2422_30~1000 11N40SISO_Ant1_2422_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 50 of 101 11N40SISO_Ant1_2437_0~Reference 11N40SISO_Ant1_2437_30~1000 11N40SISO_Ant1_2437_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 51 of 101 11N40SISO_Ant1_2452_0~Reference 11N40SISO_Ant1_2452_30~1000 11N40SISO_Ant1_2452_1000~26500 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 52 of 101 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 53 of 101 10. Radiated Spurious Emissions 10.1. Block diagram of test setup In 3 m Anechoic Chamber, test setup diagram for 9 kHz - 30 MHz: In 3 m Anechoic Chamber, test setup diagram for 30 MHz - 1 GHz: Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 54 of 101 In 3 m Anechoic Chamber, test setup diagram for frequency above 1 GHz: Note: For harmonic emissions test an appropriate high pass filter was inserted in the input port of AMP. 10.2. Limit (1) FCC 15.205 Restricted frequency band MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 1 0.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.1772&4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.2072&4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 108-121.94 1718.8-1722.2 13.25-13.4 6.31175-6.31225 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 ( 2 ) 13.36-13.41 1 Until February 1, 1999, this restricted band shall be 0.490-0.510 MHz. 2 Above 38.6 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R22070625-2E02 Page 55 of 101 (2) FCC 15.209 Limit FREQUENCY MHz DISTANCE Meters FIELD STRENGTHS LIMIT V/m dB(V)/m 0.009 ~ 0.490 300 2400/F(kHz) 67.6-20log(F) 0.490 ~ 1.705 30 24000/F(kHz) 87.6-20log(F) 1.705 ~ 30.0 30 30 29.54 30 ~ 88 3 100 40.0 88 ~ 216 3 150 43.5 216 ~ 960 3 200 46.0 960 ~ 1000 3 500 54.0 Above 1000 3 74.0 dB(V)/m (Peak) 54.0 dB(V)/m (Average) Note: (1) The emission limits shown in the above table are based on measurements employing a CISPR QP detector except for the frequency bands 9 - 90 kHz, 110 - 490 kHz and above 1000 MHz. Radiated emissions limits in these three bands are based on measurements employing an average detector. (2) At frequencies below 30 MHz, measurement may be performed at a distance closer than that specified, and the limit at closer measurement distance can be extrapolated by below formula: Limit 3m (dBuV/m) = Limit 30m (dBuV/m) + 40Log(30m/3m) (3) Limit for this EUT The emissions appearing within 15.205 restricted frequency bands shall not exceed the limits shown in 15.209, all the other emissions shall be at least 20 dB below the fundamental emissions or comply with 15.209 limits. 10.3. Test Procedure (1) EUT height should be 0.8 m for below 1 GHz at a semi‐anechoic chamber while EUT height should be 1.5 m for above 1 GHz at full chamber or semi‐anechoic chamber ground with absorbers. (2) The antenna used as below table. Test frequency range Test antenna used Measuring dista…
