2ATB5-T301ERemote Control Transmitter

REMOTE CONTROL OPERATING INSTRUCTIONS Install a 12V battery into the remote control. To prevent damage to the remote control, remove the battery if not used for long periods of time. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user isencouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. This equipment complies with FCC's RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna(s) must not be co-located or conjunction with any other antenna or transmitter. WARNING: Do not short-circuit, disassemble, heat up, connect improperly, or dispose of used batteries in fire. Do not recharge or mix batteries with used or other battery types. Immediately remove used batteries.  澳

Tarzan Technology Co.,Ltd Date:October 11, 2022 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:2ATB5-T301E Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematic.pdf Block Diagram.pdf Operational Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Tarzan Technology Co.,Ltd Signature Andy Lee/Manager Typed name and Title

Tarzan Technology Co.,Ltd FCC ID:2ATB5-T301E POWER OF ATTORNEY Date: October 11, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Testing Group (Foshan) Co., Ltd. (Dara Zhou) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Testing Group (Foshan) Co., Ltd. (Dara Zhou) on our behalf shall have the same effect as acts of our own. This authorization expires on October 11, 2023 . This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Tarzan Technology Co.,Ltd are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Tarzan Technology Co.,Ltd Signature Andy Lee/Manager Typed name and Title

Model: T301E Page 1 of 3 Picture 1 Picture 2 Model: T301E Page 2 of 3 Picture 3 Picture 4 Model: T301E Page 3 of 3 Picture 5 Picture 6

Model: T301E Page 1 of 3 Picture 1 Picture 2 Model: T301E Page 2 of 3 Picture 3 Picture 4 Model: T301E Page 3 of 3 Picture 5

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Page 1 of 25 WT-510-201-12-A TEST REPORT Reference No. .................... : WTF22F08175303W FCC ID ................................ : 2ATB5-T301E Applicant ............................ : Tarzan Technology Co.,Ltd Address .............................. : 2F, Build 4, No 111 Jintong Rd, Tangxia Town, Pengjiang District, Jiangmen Guangdong, China Manufacturer .................... : The same as above Address .............................. : The same as above Product Name .................... : Remote Control Transmitter Model No. ........................... : T301E Test specification .............. : FCC CFR47 Part 15 Subpart C (Section 15.231):2020 Date of Receipt sample .... : 2022-09-06 Date of Test ....................... : 2022-09-08 to 2022-09-23 Date of Issue ...................... : 2022-10-18 Test Report Form No. ....... : WEW-15231A-01A Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Foshan) Co., Ltd. Address: No.13-19, 2/F., 2nd Building, Sunlink International Machinery City, Chencun, Shunde District, Foshan, Guangdong, China Tel:+86-757-23811398 Fax:+86-757-23811381 E-mail:[email protected] Tested by: Approved by: Kyrie Yun Danny Zhou Reference No.: WTF22F08175303W Page 2 of 25 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 1 Revision History Test Report No. Date of Issue Description Status WTF22F08175303W 2022-10-18 Original Valid Reference No.: WTF22F08175303W Page 3 of 25 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 2 Contents Page 1 REVISION HISTORY ................................................................................................................................. 2 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ....................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 3.2 TECHNICAL CHARACTERISTICS OF EUT ........................................................................................... 4 3.3 STANDARDS APPLICABLE FOR TESTING ............................................................................................ 4 3.4 TEST FACILITY ................................................................................................................................ 5 3.5 SUBCONTRACTED ........................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................ 5 3.7 DISCLAIMER .................................................................................................................................... 5 4 EUT SETUP AND TEST MODE ................................................................................................................ 6 5 EQUIPMENT USED DURING TEST ......................................................................................................... 7 5.1 EQUIPMENT LIST ............................................................................................................................. 7 5.2 TEST SOFTWARE ............................................................................................................................ 8 5.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ......................................................................... 8 5.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 8 6 SUMMARY OF TEST RESULT ................................................................................................................ 9 6.1 ANTENNA REQUIREMENT ............................................................................................................... 10 6.2 RADIATED SPURIOUS EMISSIONS ................................................................................................... 11 6.3 20DB BANDWIDTH ......................................................................................................................... 15 6.4 TRANSMISSION TIME ..................................................................................................................... 16 6.5 DUTY CYCLE ................................................................................................................................. 17 7 PHOTOGRAPHS TEST SETUP ............................................................................................................. 19 7.1 PHOTOGRAPHS - RADIATED EMISSION TEST SETUP ........................................................................ 19 8 PHOTOGRAPHS - CONSTRUCTIONAL DETAILS ............................................................................... 20 8.1 EUT - EXTERNAL PHOTOS ............................................................................................................. 20 8.2 EUT - INTERNAL PHOTOS .............................................................................................................. 23 Reference No.: WTF22F08175303W Page 4 of 25 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn WT-510-201-12-A 3 General Information 3.1 General Description of E.U.T Product Name ............................... : Remote Control Transmitter Model No. ..................................... : T301E Model…
