CMP item#: AWC1058 Description: Module, 5W Qi Wireless Charger, USB-C In This document is proprietary & confidential. Do not copy or distribute without consent. Revision: 100 Date: 08/21/2019 Product Description The Ubio Labs AWC1058 is a compact, wireless charging module for AirPods. It derives its power from a compatible USB-C receptacle capable of supplying power and will keep your AirPods charged and ready. Product Description Component - Product Requirements Document Industrial Design Component - Product Requirements Document CMP#: AWC1058SG Apple Dark Space Gray Apple White Accent USB-C Input Logo AirPods Surface Bottom Gasket Qi/Power LED Indicator Part Color / Material / Finish Notes Bottom / Gasket Apple White / ABS / YS20019 AirPods Surface Apple White / ABS / Gloss Qi Center Apple White / ABS / Gloss Deboss 0.1mm Accent Apple Dark Space Gray Light Blast / ABS / Paint Logo Clear/ Pad Print / Gloss Industrial Designer: Ken Jasinski STP File Name: AWC1058 Qi USB-C in_REV100.STEP Qi center Industrial Design Component - Product Requirements Document CMP#: AWC1058SG - AL Apple Dark Space Gray Apple White Accent USB-C Input Logo AirPods Surface Bottom Qi center Gasket Qi/Power LED Indicator Part Color / Material / Finish Notes Bottom / Gasket Apple White / ABS / YS20019 AirPods Surface Apple White / ABS / Gloss Qi Center Apple White / ABS / Gloss Deboss 0.1mm Accent Apple Dark Space Gray / Aluminum / Light Blast Logo Clear/ Pad Print / Gloss Industrial Designer: Ken Jasinski STP File Name: AWC1058 Qi USB-C in_REV100.STEP Industrial Design Component - Product Requirements Document CMP#: AWC1058NA Part Color / Material / Finish Notes Bottom / Gasket Apple White / ABS / YS20019 AirPods Surface Apple White / ABS / Gloss Qi Center Apple White / ABS / Gloss Deboss 0.1mm Accent Natural Aluminum Light Blast / ABS / Paint Logo Clear/ Pad Print / Gloss Industrial Designer: Ken Jasinski STP File Name: AWC1058 Qi USB-C in_REV100.STEP Accent USB-C Input Logo AirPods Surface Bottom Apple White Qi center Gasket Natural Aluminum Light Blast Qi/Power LED Indicator Accent USB-C Input Logo AirPods Surface Bottom Qi center Gasket Industrial Design Component - Product Requirements Document CMP#: AWC1058NA - AL Apple White Natural Aluminum Light Blast Qi/Power LED Indicator Part Color / Material / Finish Notes Bottom / Gasket Apple White / ABS / YS20019 AirPods Surface Apple White / ABS / Gloss Qi Center Apple White / ABS / Gloss Deboss 0.1mm Accent Natural Aluminum / Aluminum / Light Blast Logo Clear/ Pad Print / Gloss Industrial Designer: Ken Jasinski STP File Name: AWC1058 Qi USB-C in_REV100.STEP Industrial Design Component - Product Requirements Document CMP#: AWC1058 Silkscreen Part Color / Material / Finish Notes Logo Clear/ Pad Print / Gloss Industrial Designer: Ken Jasinski .PDF File Name: AWC1058 Pad Print_Logo_REV100 Regulatory marking provided later – Please include in Quote Logo Qi/Power LED Indicator Functionality Condition LED Status Functionality Device Charging, Charged Illuminates white No device, not charging Not illuminated Fault Foreign Object Detection Illuminates amber for fault due to foreign object detection Input Power Illuminates white for 1 second at power up and then turns off if no device detected Functional Requirements A.USB-C Input: The USB-C Input is used to provide power to the wireless charging module. Plugging the module into a compatible USB-C receptacle will automatically power up the module and remain on as long as the module is plugged in. B.Qi Coil: The Qi coil placed behind the top cover will allow charging of wireless AirPods case immediately upon placement on the coil location. This will initiate the Qi/Power Indicator functionality. C.Qi/Power LED Indicator: The Qi/Power Indicator is a dual color White/Amber LED. It shall illuminate as described in the table above. Component - Product Requirements Document C A B ON OFF Product Platform Overview Component - Product Requirements Document USB-C Input Power •5V, 2.4A, 12W •USB-C Current •Fault Tolerant, Protection, Detection Wireless Charge Module Common Computing Platform (CCP) A.Platform Based Design: Platform Based Design: The AirPlugs product family shall be designed such that it is modular in nature for Hardware, Software, Mechanical functionality, design reusability and platformization. All adjustable variables such as time delays, duty cycles, frequencies etc. shall be software controlled to reduce impact to hardware in anticipation of standards and specification changes in the future. B.USB-C Current Platform: This platform accepts USB-C input from a compatible USB-C device. All end-user facing I/O’s, onboard I/O’s, interfaces and functionality pertaining to this platform shall be designed to comply with the applicable USB and MFi specifications. C.Indicator Platform: This platform provides the Indicator User Interface (UI) capability. All end-user facing I/O’s, onboard I/O’s, interfaces and functionality pertaining to this platform shall be designed to comply with the indicator functionality described here within this document. D.Wireless Charge Module Common Computing Platform (CCP): This platform provides the control logic and communication capabilities. All software functions, interfaces and libraries should be modular to align with hardware functionality and vice-versa. For example, USB-C Current I/O Platform Hardware and Software are modular and go together. Standard software development tools and common hardware chipsets shall be used to ensure ease of development and debugging. E.Qi Wireless Platform: This platform provides Qi Wireless Charging capability. All end-user facing I/O’s, onboard I/O’s, interfaces and functionality pertaining to this platform shall be designed to comply with the applicable Qi and MFi specifications. F.Mechanical Parts and Tooling: The AirPlugs product family shall use common tooling and mechanical parts in order to reduce unique parts count and tooling. USB-C Current Plat…
