2ATGY-AWC1100Wireless Charging Stand

User Manual and Safety Instructions LED Charge Indicator Wireless Pad Features Qi Wireless Surface SAVE THESE INSTRUCTIONS Warranty At Ubio Labs we are dedicated to designing and manufacturing products with superior performance and 100% customer satisfaction. All of our products come with a 1 year limited warranty from date of purchase. www.ubiolabs.com [email protected] 1-866-642-4428 (Monday - Friday 9am - 4pm PST) 2821 Northup Way, Suite 250 Bellevue, WA 98004 DO NOT RETURN TO THE STORE Our customer service team is here to help. WARNING - When using this product, basic precautions should always be followed, including the following: a) Read all manufacturers instructions before using this product. b) To reduce the risk of injury, close supervision is necessary when the product is used near children. c) Do not put ngers or hands into the product. d) Do not expose wireless pad to moisture, rain, or snow. e) Use of a power supply or charger not recommended or sold by wireless pad manufacturer may result in a risk of re or injury to persons. f) Do not use the wireless pad in excess of its output rating. Overloaded outputs above rating may result in a risk of re or injury to persons. Important Safety Instructions NOTE: This equipment has been tested and found to comply with the limits for a wireless power charger, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the product. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Model: CHG1151 Input: AC 110-240V, 50-60 Hz Output: 37.5W 15V / 2.5A DC-DC Dimensions: 2.28 x 2.28 x 1.06inches Weight: 4.1 oz. Technical Specifications Wall Adapter Features At Ubio Labs, we are always improving our products’ features and functionality, we reserve the right to change specications at any time without notice. Technical Specifications Model: AWC1100 Input: 37.5W 15V / 2.5A DC Output: Wireless：15W Qi / 10W / 7.5W / 5W USBA: 5V 2.4A Compatibility: Apple, Android, other devices with wireless charging Charge Indicator: White/amber LED indicator Dimensions: 2.2 x 2.2 x 4.2 inches W eight: 10 oz. g) Do not disassemble the wireless pad. Take it to a qualied service person when service or repairs are required. Incorrect reassembly may result in a risk of re or injury to persons. h) Do not expose the wireless pad to re or excessive temperature. Exposure to re or temperature above 122°F may cause explosion. The wireless pad’s working temperature is ≤104°F. i) Have service performed by a qualied repair person using only identical replacement parts. This will ensure that the safety of the product is maintained. Wireless Charging Stand DC Power In Your wireless pad is designed to provide optimal power delivery for your wireless device: 10W Qi certified fast charging for Samsung Note9, S9+, S9, Note8, S8+, S8, S7 Edge, S7, S6 Edge, S7, S6 Edge, S6, Note5, LG G6, LGV30, Sony Xperia XZ2 • 7.5W Apple wireless charging for iPhoneX , iPhoneX Max , iPhoneX, iPhone X, iPhone 8, iPhone 8 Plus • 5W charging for other compatible wireless charging devices User Manual AWC1100 USBA Power out Folding Wall Prongs 6 Ft. Cable FCC COMPLIANCE STATEMENT: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC WARNING This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device The distance between user and products should be no less than 10cm. ADVERTENCIA IC Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes : (1) Cet appareil ne doit pas causer d'interférences. (2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement indésirable de l'appareil. Cet émetteur ne doit pas être co-localisées ou opérant en conjonction avec une autre antenne ou transmetteur.Pour se conformer aux exigences d'exposition aux radiofréquences, une distance minimale de 10cm doit être maintenue entre le corps de …
