2ATIH-SW1PSmartWatch

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Aukey Technology Co., Ltd. Address: Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Phone: +86-755-33620645 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. FCC ID: 2ATIH-SW1P If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-06-29 Name / Title: Jiaguang Zhou / Manager Company: Aukey Technology Co., Ltd. Address: Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Phone: +86-755-33620645 Fax: +86-755-33620645 E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2ATIH-SW1P SW-1P We, applicant Company Name: Aukey Technology Co., Ltd. Address: Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Phone: +86-755-33620645 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-06-29 Name / Title: Jiaguang Zhou / Manager Company: Aukey Technology Co., Ltd. Address: Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Phone: +86-755-33620645 Fax: +86-755-33620645 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2ATIH-SW1P SW-1P For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-06-29 Name / Title: Jiaguang Zhou / Manager Company: Aukey Technology Co., Ltd. Address: Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Phone: +86-755-33620645 Fax: +86-755-33620645 E-Mail: [email protected]

FCC ID: 2ATIH-SW1P Fig. 1 Fig. 2 FCC ID: 2ATIH-SW1P Fig. 3 Fig. 4 FCC ID: 2ATIH-SW1P Fig. 5 Fig. 6 FCC ID: 2ATIH-SW1P Fig. 7

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L 3.607cm x 2.579cm) Label Location

FCC ID: 2ATIH-SW1P Fig. 1 Fig. 2 FCC ID: 2ATIH-SW1P Fig. 3 Fig. 4 Antenna FCC ID: 2ATIH-SW1P Fig. 5 Fig. 6 FCC ID: 2ATIH-SW1P Fig. 7

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No. .................... : FCC ID. ............................................ : GTS20221201014-1-9 2ATIH-SW1P Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Dec.27, 2022 Representative Laboratory Name : Shenzhen Global Test Service Co.,Ltd. Address ............................................. : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Aukey Technology Co., Ltd. Address ............................................. : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Test specification .......................... : Standard ........................................... : 47CFR §1.1310 47CFR §2.1093 KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : SmartWatch Trade Mark ....................................... : AUKEY Manufacturer ..................................... : Aukey Technology Co., Ltd. Model/Type reference ....................... : SW-1P Listed Models ................................... : N/A Exposure category ............................ : General population/uncontrolled environment EUT Type .......................................... : Portable Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.8V by battery Recharged by DC 5.0V Result ................................................ : PASS Report No.: GTS20221201014-1-9 Page 2 of 10 T E S T R E P O R T Test Report No. : GTS20221201014-1-9 Dec.27, 2022 ______________________________________________________________________________________________ Date of issue Equipment under Test : SmartWatch Model /Type : SW-1P Listed model : N/A Applicant : Aukey Technology Co., Ltd. Address : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Manufacturer : Aukey Technology Co., Ltd. Address : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20221201014-1-9 Page 3 of 10 Contents 1. S U M M A R Y .................................................................................. 4 1.1. EUT configuration ....................................................................................................................................... 4 1.2. Product Description .................................................................................................................................... 4 2. T E S T E N V I R O N M E N T ................................................................... 5 2.1. Address of the test laboratory ................................................................................................................... 5 2.2. Test Facility .................................................................................................................................................. 5 2.3. Environmental conditions .......................................................................................................................... 5 2.4. Statement of the measurement uncertainty ............................................................................................. 5 3 . M E T H O D O F M E A S U R EM E N T ......................................................... 6 3.1. Applicable Standard .................................................................................................................................... 6 3.2. Evaluation Method and Limit...................................................................................................................... 6 4. C O N D U C T E D P O W E R R E S U L T S ...................................................... 7 5. M A NU F A C T U R I N G T O L E R A N C E ...................................................... 8 6 . E V A L U A T I O N R E S U L TS ................................................................ 9 6.1. Standalone Evaluation ................................................................................................................................ 9 7. C O N C L U S I O N ............................................................................ 10 Report No.: GTS20221201014-1-9 Page 4 of 10 1. S U M M A R Y 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Adapter Length (m) : 0.4m Shield : Non-Shielded Detachabl…

Text truncated - open the document above for the full version.

BT Audio Antenna Report 1.Gain and Efficiency Frequency (MHz) Gain (dBi) Efficiency （ dB ） Efficiency （ % ） 2400 1.99 -6.73 21.23 2410 1 -6.48 22.5 2420 1.06 -6.41 22.85 2430 0.35 -5.64 27.26 2440 0.81 -6.04 24.9 2450 0.61 -5.72 26.79 24600.9-6.01 25.06 2470 0.72 -5.8 26.33 2480 1.07 -6.21 23.94 2490 1.37 -6.41 22.84 2. Passive pattern Input impedance: 3. Radiation Pattern 3D: 2.402G 2.441Ghz 2.480Ghz 趼 揭 杅 載蜊囀 梓暮

Case No. : GTS20221201014-1-8 Ambient Condition: 25 °C, 45 %RH, Atmos100.1Kpa, Test Date: 2022.12.12 Test Engineer: Jenny zeng Appendix B.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE Ant1 2402 0.628 2401.664 2402.292 0.5 PASS 2440 0.504 2439.652 2440.156 0.5 PASS 2480 0.616 2479.688 2480.304 0.5 PASS Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 Appendix B.2: Occupied Channel Bandwidth Test Result TestMode Antenna Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE Ant1 2402 1.0096 2401.492 2402.502 --- --- 2440 1.0120 2439.490 2440.502 --- --- 2480 1.0188 2479.487 2480.506 --- --- Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 Appendix B.3: Maximum conducted output power Test Result Peak TestMode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict BLE Ant1 2402 2.5 ≤30 PASS 2440 4.68 ≤30 PASS 2480 3.81 ≤30 PASS Appendix B.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3kHz] Limit[dBm/3kHz] Verdict BLE Ant1 2402 -7.8 ≤8.00 PASS 2440 -5.74 ≤8.00 PASS 2480 -6.26 ≤8.00 PASS Test Graphs BLE_Ant1_2402 BLE_Ant1_2440 BLE_Ant1_2480 Appendix B.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 Low 2402 2.49 -37.72 ≤-17.51 PASS High 2480 3.85 -46.09 ≤-16.15 PASS Test Graphs BLE_Ant1_Low_2402 BLE_Ant1_High_2480 Appendix B.6: Conducted Spurious Emission Test Result TestMode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE Ant1 2402 Reference 2.24 2.24 --- PASS 30~1000 2.24 -60.21 ≤-17.76 PASS 1000~26500 2.24 -46.46 ≤-17.76 PASS 2440 Reference 4.49 4.49 --- PASS 30~1000 4.49 -60.06 ≤-15.51 PASS 1000~26500 4.49 -46.59 ≤-15.51 PASS 2480 Reference 3.63 3.63 --- PASS 30~1000 3.63 -60.8 ≤-16.37 PASS 1000~26500 3.63 -46.73 ≤-16.37 PASS Test Graphs BLE_Ant1_2402_0~Reference BLE_Ant1_2402_30~1000 BLE_Ant1_2402_1000~26500 BLE_Ant1_2440_0~Reference BLE_Ant1_2440_30~1000 BLE_Ant1_2440_1000~26500 BLE_Ant1_2480_0~Reference BLE_Ant1_2480_30~1000 BLE_Ant1_2480_1000~26500

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID............................................. : GTS20221201014-1-8 2ATIH-SW1P Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Dec.27, 2022 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ............................ : Aukey Technology Co., Ltd. Address ............................................ : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Test specification ........................... : Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : SmartWatch Trade Mark ....................................... : AUKEY Manufacturer .................................... : Aukey Technology Co., Ltd. Model/Type reference ...................... : SW-1P Listed Models .................................. : N/A Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.8V by battery Recharged by DC 5.0V Result ............................................... : PASS Report No.: GTS20221201014-1-8 Page 2 of 24 T E S T R E P O R T Test Report No. : GTS20221201014-1-8 Dec.27, 2022 ______________________________________________________________________________________________ Date of issue Equipment under Test : SmartWatch Model /Type : SW-1P Listed model : N/A Applicant : Aukey Technology Co., Ltd. Address : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Manufacturer : Aukey Technology Co., Ltd. Address : Room 102, Building P09, South China City Electronic trading center, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20221201014-1-8 Page 3 of 24 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 6 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 6 2.5. EUT operation mode .............................................................................................................................. 6 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. EUT Exercise Software .......................................................................................................................... 7 2.8. Special Accessories ............................................................................................................................... 7 2.9. External I/O Cable .................................................................................................................................. 7 2.10. Related Submittal(s) / Grant (s) ........................................................................................................... 7 2.11. Modifications ........................................................................................................................................ 7 3. TEST ENVIRONMENT ..................................................................................................................................... 8 3.1. Address of the test laboratory ................................................................................................................ 8 3.2. Test Facility ............................................................................................................................................ 8 3.3. Environmental conditio…

Text truncated - open the document above for the full version.

FCC ID: 2ATIH-SW1P _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2ATIH-SW1P _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig. 3
