2ATJW-BM-RXCD02baby monitor

720P/1080P USER MANUAL V3.5 01 02 USER MANUAL 03 0405 0706 0908 1011 1213 1415 1617 1918 20 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

(Shenzhen Dayunlinks Co., ltd) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ATJW-BM-RXCD02 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ( Henry Zhang) Rev 11/20/07

Bulk Unlimited Corp Model Difference 2020-10-11 EUT NAME: baby monitor FCC ID: 2 AT J W-BM-RXCD02 MODEL : BM-5APD101 BM-5APD102,BM-5APD201,BM-5APD202,BD-5A10,BD-5A20,BC-PD10,BC- PD20,BM-5ACD101,BM-5ACD102,BM-5ACD201,BM-5ACD202,BC-CD10,BC- CD20,BM-5AEA101,BM-5AEA102,BM-5AEA201,BM-5AEA202,BC-EA10,BC- EA20,BM-5AMP101,BM-5AMP102,BM-5AMP201,BM-5AMP202,BC-MP10,BC- MP20,BM-5AJQGA101,BM-5AJQGA102,BM-5AJQGA201,BM-5AJQGA202,BC- JQGA10,BC-JQGA20,BM-5AJQGB101,BM-5AJQGB102,BM-5AJQGB201,BM- 5AJQGB202,BC-JQGB10,BC-JQGB20,BM-5AJQGC101,BM-5AJQGC102,BM- 5AJQGC201,BM-5AJQGC202,BC-JQGC10,BC-JQGC20,BM-5AXD101,BM- 5AXD102,BM-5AXD201,BM-5AXD202,BC-XD10,BC-XD20,BM-5AYS101,BM- 5AYS102,BM-5AYS201,BM-5AYS202,BC-YS10,BC-YS20,BM-5AATM101,BM- 5AATM102,BM-5AATM201,BM-5AATM202,BC-ATM10,BC-ATM20,BM- 5AATMB101,BM-5AATMB102,BM-5AATMB201,BM-5AATMB202,BC-ATMB10,BC- ATMB20,BM-5AXG101,BM-5AXG102,BM-5AXG201,BM-5AXG202,BC-XG10,BC- XG20,BD-5B10,BD-5B20,BM-RXPD02,BM-RXCD02,BM-XG10,BM-XG20,BM- RXPD02,BM-RXCD02,BM-RXMP02,BM-RXEA02,BM-5PD101,BM-5PD102,BM- 5CD101,BM-5PD102,BM-5MP101,BM-5MP102,BM-5EA101,BM-5EA102,BM- 5BG101,BM-5BG102,BM-5PD201,BM-5PD202,BM-5CD201,BM-5PD202,BM- 5MP201,BM-5MP202,BM-5EA201,BM-5EA202,BM-5BG201,BM-5BG202,BD- BG10,BD-BG20,DE-168,EY-168,DE-188,EY-188,P8-720P,P8- 1080P,HM136,H13C,BM1003,BC1003,babycare,HM570A,HM570A-1,V65- 2US,V65-US,V65,V65-1,V65-2,V65-UK,BM101,BM201,AW- BM50,DY720,DY720TX,HM570A,BD-5A20TX,BD-5A10TX,V65-CAM,P8-100,P8- 200 All the model are the same circuit and RF module, except model names. . Regards Sincerely Client’s signature Client’s name / title : Henry Zhang/ CEO Contact information / address: 30th Park West Zhangbei Yuanhu Road Longcheng Street Longgang District Shenzhen City, 518000, GuangDong Province, China

(Shenzhen Dayunlinks Co., ltd) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for FCC ID: 2ATJW-BM-RXCD02 To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, ( Henry Zhang)

External Photos

Label & label location Size:40*20mm baby monitor FCC ID: 2 AT J W-BM-RXCD02 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2 AT J W-BM-RXCD02 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. = max possible output power (PK,conducted)：8±1dbm 0dBi logarithmic terms convert t o numeric result is nearly 1 9dbm=7.94mW 2410MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=7.94/5*√2.410 =2.47≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Modulation Frequency (MHz) Output Power (dBm) Max Antenna Gain (dBi) GFSK 2410 8.55 0 GFSK 2441.5 8.35 0 GFSK 2477 8.69 0 2441.5MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 7.94/5*√2.441 5=2.48≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. 2477MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=7.94/5*√2.477 =2.50≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

No.：BCTC/RF-EMC-005 Page 1 of 45 Edition：A.1 TEST REPORT Report No.: BCTC2009001273E Applicant: Shenzhen Dayunlinks Co., ltd Product Name: baby monitor Model/Type Ref.: BM-5APD101 Tested Date: Sep. 15, 2020 to Sep. 25, 2020 Issued Date: Sep. 25, 2020 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2009001273E No.：BCTC/RF-EMC-005 Page 2 of 45 Edition：A.1 FCC ID : 2ATJW-BM-RXCD02 The test report is effective only with both signature and specialized stamp.This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full.The tested sample(s) and the sample information are provided by the client. Product Name: baby monitor Trademark: N/A Model/Type Ref.: Refer to section 4.1 Prepared For: Shenzhen Dayunlinks Co., ltd Address: 30th Park West Zhangbei Yuanhu Road Longcheng Street Longgang District Shenzhen City, 518000, GuangDong Province, China Manufacturer: Shenzhen Dayunlinks Co., ltd Address: 30th Park West Zhangbei Yuanhu Road Longcheng Street Longgang District Shenzhen City, 518000, GuangDong Province, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Sample Received Date: Sep. 15, 2020 Sample tested Date: Sep. 15, 2020 to Sep. 25, 2020 Issue Date: Sep. 25, 2020 Report No.: BCTC2009001273E Test Standards FCC Part15.247 ANSI C63.10-2013 Test Results PASS Compiled by: Reviewed by: Approved by: Sam zeng Eric Yang Zero Zhou/Manager Report No.: BCTC2009001273E No.：BCTC/RF-EMC-005 Page 3 of 45 Edition：A.1 TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................ 5 2. TEST SUMMARY ..................................................... 6 3. MEASUREMENT UNCERTAINTY ....................................... 7 4. PRODUCT INFORMATION AND TEST SETUP ........................... 8 4.1 Product Information ..................................................... 8 4.2 Test Setup Configuration ................................................ 9 4.3 Support Equipment ..................................................... 9 4.4 Channel List .......................................................... 10 4.5 Test Mode ............................................................ 10 4.6 Table of parameters of text software setting ............................... 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 12 6. CONDUCTED EMISSIONS ............................................ 14 6.1 Block Diagram Of Test Setup ........................................... 14 6.2 Limit ................................................................. 14 6.3 Test procedure ........................................................ 14 6.4 EUT operating Conditions .............................................. 14 6.5 Test Result ........................................................... 15 7. RADIATED EMISSIONS .............................................. 17 7.1 Block Diagram Of Test Setup ........................................... 17 7.2 Limit ................................................................. 18 7.3 Test procedure ........................................................ 19 7.4 EUT operating Conditions .............................................. 20 7.5 Test Result ........................................................... 21 8. RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION .......................................................... 25 8.1 Block Diagram Of Test Setup ........................................... 25 8.2 Limit ................................................................. 25 8.3 Test procedure ........................................................ 26 8.4 EUT operating Conditions .............................................. 26 8.5 Test Result ........................................................... 27 9. POWER SPECTRAL DENSITY TEST ................................... 28 9.1 Block Diagram Of Test Setup ........................................... 28 9.2 Limit ................................................................. 28 9.3 Test procedure ........................................................ 28 9.4 EUT operating Conditions .............................................. 28 9.5 Test Result ........................................................... 29 10. BANDWIDTH TEST .................................................. 31 10.1 Block Diagram Of Test Setup .......................................... 31 10.2 Limit ................................................................ 31 Report No.: BCTC2009001273E No.：BCTC/RF-EMC-005 Page 4 of 45 Edition：A.1 10.3 Test procedure ....................................................... 31 10.4 EUT operating Conditions ............................................. 31 10.5 Test Result .......................................................... 32 11. PEAK OUTPUT POWER TEST ........................................ 34 11.1 Block Diagram Of Test Setup .......................................... 34 11.2 Limit ................................................................ 34 11.3 Test procedure ....................................................... 34 11.4 EUT operating Conditions ............................................. 34 11.5 Test Result .......................................................... 35 12. 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE ................... 36 12.1 Block Diagram Of Test Setup .......................................... 36 12.2 Limit ................................................................ 36 12.3 Test procedure ....................................................... 36 12.4 EUT operating Conditions .................…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2009001273E 1. EUT TEST SETUP PHOTOGRAPHS Spurious emissions Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 1 of 2 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2009001273E Conducted emissions ※※※※※ END OF REPORT ※※※※※ Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 2 of 2
