FOR ITEM: V80031PDQ-NOC SKU#2102247 SMART WATCH \ TRUE WIRELESS EARPHONES BUNDLE INTRODUCTION 1. Thank you for purchasing the Vivitar Active Life Smart Watch and True Wireless Earphones Bundle, item V80031PDQ-NOC. You can use your device to track steps, distance and calories. In order to get the best results, please read this manual first before using your device. FEATURES Smart Watch (SMRTW20-BLK) -Answer or dial calls directly from the watch connected to a smartphone via Bluetooth®. -Built-in heart rate sensor that supports heart rate & sleep quality monitoring. -Activity tracker has various sport modes to record your fitness data. -Compatible with smartphones that use iOS 8.0/Android OS 4.4 or above. -Notifications from the smartphone will show up on the watch’s display for convenience. True Wireless Earphones (V40088W-NOC) -Automatic pairing for easy set-up -Up to 3.5 hours playtime -Comfort fit -Answer calls PACKAGE CONTENTS -Bluetooth Smart Watch -True Wireless Earphones Bundle -Charging Clip with Attached USB Cable -User’s Manual with Warranty Information ATTENTION ! This device is not a substitute for medical devices. Always consult a physician for medical advice. A QUICK LOOK 2. When wearing your smart watch, make sure that the band is tight enough so that the sensor is making contact with your skin, but not so tight that it is uncomfortable. SMARTWATCH SPECIFICATIONS -Screen: 1.59” TFT -Battery: 3.7V, 180mAh Lithium Polymer Battery -Bluetooth Version: Bluetooth 5.0 -Charging Time: ~1.5 Hours -Working Time: ~3 Days* -Compatibility: Android 5.0 and Higher, iOS 9.0 and Higher *Working time may vary depending on product usage. DISPLAY SCREEN POWER BUTTON SMART WATCH CHARGING 3. To charge your activity tracker, follow the steps below: 1. Take o¥ your smart watch and fit the back of the head onto the charging clip. Make sure to connect the charging contacts. 2. Slide the USB plug into a USB port on your computer, or a suitable DC 5V, 1A USB charging adapter. 3. Once fully charged, the battery status indicator on the display screen will go from empty to full. EMPTYFULL -When connecting to USB port, make sure plug is inserted correctly. -If charging icon does not appear, make sure that the charging clip is fitted properly. ! WARNING NOTE: Smart Watch Features may not be accessible while device is charging. Bluetooth may not connect while battery is insu¦cient. APP INSTALLATION 4. In order to use your smart watch, you will first need to download the FitPro App, which is available on the Google Play Store and on the iPhone App Store. OR iPhoneAndroid Install FitPro App App BLUETOOTH SETUP 5. To use your smart watch with your smartphone, you will first need to setup a Bluetooth connection between both devices. To do so, follow the steps below: 1. Press the power button on the side of your smart watch to turn it on. 3. Open the FitPro software application on your phone and create an account. 4. If the app’s home page opens, press the “Set” icon to access device binding options. 2. Make sure that your phone’s Bluetooth is turned on. BLUETOOTH SETUP 6. 5. View if your smartphone is paired with your smart watch. If not, press here to connect. The app will automatically list any nearby Bluetooth devices. Select your watch “SMRTW20” to bind it with the app. 6. When the Bluetooth pairing dialog appears, press “Pair”. “SMRTW20” “SMRTW20” 7. Open your phone’s Bluetooth setting’s menu and select the device named “SMRTW20” to connect. Note that you will now have two SMRTW20 Bluetooth connections. One connection sends data between your watch and your phone, the other connection is for audio. USER SETUP 7. In order to get the best possible results when using the FitPro App, enter your personal data before using. To do so, follow the steps below. 1. Press the “Me” icon in the lower right hand corner of the screen. 2. In the user settings menu you can explore the following settings: Personal Information: Change Avatar and Nickname. Input your Sex, Age, Height, Weight, and Target settings. Change the units of measurement for Height and Weight. Change Password: Change your FitPro account password. About Us: QR code that leads to the FitPro app in the app store. Feedback: If you have concerns about your smart watch, FitPro app or connecting your device, send feedback. ACTIVITY 8. When you open the FitPro software application, the main activity panel will appear, showing your distance traveled, calories and goal status for the day. Press each panel to get a health rating, blood pressure or sleep measurements. Press the “Healthy habits” panel to manage and keep track of your healthy habits. Disclaimer: App is not a substitute for medical or health advice. For medical and health advice seek a medical professional. Press the top panel to get a more detailed report of your activity with daily, weekly and monthly tracking. Press the week and month buttons at the bottom for an average reading of steps, distance and calories. ACTIVITY 9. To log and track your physical activity, press the sports icon. TRACK ACTIVITY 10. Choose a type of activity to track. Tap to view distance stats for all sessions. Press to start tracking your session. Sports Icon Displays total distance of session. Press the Setting icon to open the settings page. In order to access setting features, be sure to bind your device to smart watch. Remote Shutter: Turn on/o¥ smart watch camera feature. Find: Locates smart watch. Lift wrist to bright screen: Turn on/o¥ this feature. Device Reset: Resets data on smart watch. Remove: Remove smart watch connection. Other Settings: Access other settings. OTA upgrade: Upgrade app to latest software. SETTINGS 11. Displays device name and version number. Message Push Setting: Change notification settings. Do Not Disturb: Silence notifications that appear on smart watch. Alarm Setting: Set alarms. Sedentary Reminder: You can set reminders to be active when smart watch registers long resting periods. Press the …
