2ATNWK1ZNJDRobosen AI Base Lite

robosen AI base lite is an open platform based on artificial intelli- gence, with advanced automatic speech recognition and emotion- al interaction. It can give Robosen robot products more functions, such as intelligent voice user interface, emotional companionship and AI entertainment. It can identify your intentions in a more accurate way, let your hands free, and experience the fun things of AI entertainment. ( robosen AI base lite applies to most Robosen robot products) Pr oduct Name Model Main Unit Input Main Board Dimensions Weight Material Wireless Connection Control Method External Ports Microphone robosen AI base lite K1JD 12Vdc 1.5A MT8516 ABS 2.4G Wi-Fi, Bluetooth 4.2 Voice control, Mobile App, Button control DC power port, Micro USB port 6-Mic Circular Arra Power supplypowered by adapter MEET ROBOSEN AI BASE LITE PRODUCT SPECIFICATION ROBOSEN AI BASE LITE BUTTON'S FUNCTION DESCRIPTION ROBOSEN AI BASE LITE QUICK START GUIDE Please download the "Robosen AI "app before you start using the product. You can download it from APP Store or Google Play. APP DOWNLOAD QR CODE 201.5*201.5*54.5mm (7.93*7.93*2.15in) 456g(16.09oz) 1 2 3 4 5 Volume Up Mode/Next Button Mic Button Wake Button Volume Down Button Mic Button Action Short press Long press Short press Quick double click Short press Short press Hold for 3s Short press Long press Function Volume increases by scale Volume increases continuously Next action/song Ground mode/Base mode Turn off microphone/Turn on microphone Voice command Wi-Fi configuration Volume decreases by scale Volume decreases continuously Volume Up Volume Down Wake Button Mode/Next Button 2.Connect the power supply to the robots Plug one end of the robot power cord into the DC charging port on the top of the robosen AI base lite, and connect the other end to the robot charging port. 2. After downloading the app, register and log in to your account. Then follow the instructions in the app. * It is recommended to use the latest version of IOS and Android system. 1. On the main interface of the app, click "Add Base" to make the configuration of robot and Wi-Fi. 2. After connecting the base, the app will automatically search for robots or other devices for you. * Our app does not support 5G Wi-Fi yet, please choose a 2.4G Wi-Fi network for connecting our device. 2. Double-click the mode/next button to enter the ground mode. The ringlight will turn yellow. Please take the robot off the base. In this mode, the robot can do various cool actions on the ground. 1. You can place the robot on the base, and the ringlight is green. In this mode, you can experience the various voice interactions of the robosen AI base lite and the robot. You can say "Robosen", "Hey, Robosen" to wake the robosen AI base lite, and start your journey of exploration. You can also say "Hey k-one" to wake AI Interstellar scout k-one. For more product features, please visit Robosen official website: www.robosen.com 1.Connect the power supply to the robosen AI base lite Connect one end of the power adapter to the DC charging port at the bottom of the robosen AI base lite, and the other end to the power socket. At this time, the blue light of the ring lights up, indicating that the startup is successful. * You can switch between the two modes by using the app. POWER ON ROBOT MODE DOWNLOAD THE APP START THE CONVERSATION CONFIGURE THE NETWORK AND CONNECT THE ROBOT 1. Scan the QR code, or download the "Robosen AI" app from the app store, and follow the instructions in the app to configure the network and connect to the robot. Make sure that both your device and the robot can connect with the Wi-Fi or mobile hotspot. 1 1 1 1 2 2 2

This de vic e complies with part 15 of the FCC Rules. Oper ation is subject to the follo wing tw o conditions: (1) this de vic e may no t cause harmful int erf er enc e, and (2) this de vic e mus t ac cep t any int erf er enc e rec eiv ed, including int erf er enc e tha t may cause undesired operation. Any changes or modifications not e xpr essly approved by the party r esponsible for c ompliance c ould void the user's authority to operate the equipment. NO TE: This equipment has been tes ted and found to comply with the limit s for a Class B digit al de vic e, pur suant to Part 15 of the FCC Rules. These limit s ar e designed to pr ovide reasonable pr otec tion ag ains t harmful int erf er enc e in a residential ins talla tion. This equipment gener ates, uses and can radia te radio fr equency ener gy and, if no t ins talled and used in accor danc e with the ins truc tions, may cause harmful int erf er enc e to radio communications. Ho wever , ther e is no guarant ee that int erf er enc e will not oc cur in a particular installa tion. If this equipment does cause harmful int erf er enc e to radio or tele vision rec ep tion, which can be de termined by turning the equipment off and on, the user is enc our ag ed to tr y to corr ec t the int erf er enc e by one or mor e of the follo wing measur es: -- R eorient or reloc ate the rec eiving antenna. -- Increase the separ ation betw een the equipment and rec eiv er . -- Connect the equipment into an outlet on a circuit differ ent fr om that t o which the rec eiv er is connected. -- Consult the dealer or an experienced r adio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be ins talled and oper ated with minimum distanc e be tw een 20cm the radiator your body: Use only the supplied antenna. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 [Robosen Robotics (ShenZhen) Co., Ltd.] Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both [Robosen Robotics, Inc.] (“Agent”) and [Robosen Robotics (ShenZhen) Co., Ltd.]] (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I [Johnny] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Robosen Robotics (ShenZhen) Co., Ltd. Contact Name : Johnny Address : A3703, Bldg 11, Shenzhen Bay ECO-Tech Park, No.16, Gaoxin South Science and Tech Rd., Nanshan Dist. Shenzhen, Guangdong, China Telephone No : +86 13418584460 Email : [email protected] FCC ID : 2ATNWK1ZNJD Applicant FRN : 0028566222 Signature: ____________________________ Date: _____2023.03.01_______________________________ I [Sean Tang] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated above. Agent Company Name : Robosen Robotics, Inc. Contact Name : Sean Tang Address : 15025 Proctor Ave #113, City of Industry, CA 91746, USA Telephone No : (800)298-1623 Email : [email protected] Agent FRN : 0033505744 Signature: ________ ____________ Date: _____2023.03.01_______________________________

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 [Robosen Robotics (ShenZhen) Co., Ltd.] Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: [Robosen Robotics (ShenZhen) Co., Ltd.] FCC ID: [2ATNWK1ZNJD] To whom it may concern, [Robosen Robotics (ShenZhen) Co., Ltd.](“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant [is not] identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] [Johnny LYU] [CPO] [Robosen Robotics (ShenZhen) Co., Ltd.] [3/15/2023]

CPO

CPO

RF Chip RF Antenna

INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a Robosen AI Base Lite with Bluetooth 4.2 BLE (Single-mode) function operating in 2402-2480MHz, 2.4G WIFI function operating in 2412-2462MHz. The EUT is powered by DC 12V. The micro-USB port of the device is only used for upgrading firmware. For more detail information pls. refer to the user manual. 2.4GHz WiFi: Antenna Type: Integral Antenna Antenna Gain: 0.18dBi Modulation Type: CCK, BPSK, QPSK, 16QAM, 64QAM The normal radiated output power (e.i.r.p) is: 19.18dBm (tolerance: +/-3dB). The normal conducted output power is 19.0dBm (tolerance: +/-3dB). The maximum conducted output power for the EUT is 21.0dBm in the frequency 2.412GHz 802.11n-HT20 mode which is within the production variation. The minimum conducted output power for the EUT is 18.0dBm in the frequency 2.462GHz 802.11b mode which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting devices is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, According to the KDB 447498 and OET 65, the simple calculation as below: The source-based time averaged maximum radiated power = 19.18dBm+3dB= 22.18dBm = 165.2mW At the distance (R) of 20cm to 40cm and in 0.3 GHz to 6 GHz, MPE Exclusion Threshold Level: The MPE limit is 3060mW for general population and uncontrolled exposure in the 2.4GHz frequency range according to FCC Part 1.1307. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. Note: EIRP is higher than ERP, thus EIRP is compared with the Exclusion Threshold. FCC ID: 2ATNWK1ZNJD Bluetooth: Antenna Type: Integral Antenna Antenna Gain: 0.18dBi Modulation Type: GFSK The normal radiated output power (e.i.r.p) is: 5.18dBm (tolerance: +/-2dB). The normal conducted output power is 5dBm (tolerance: +/-2dB). The maximum conducted output power for the EUT is 6.54dBm in the frequency 2.480GHz which is within the production variation. The minimum conducted output power for the EUT is 5.93dBm in the frequency 2.402GHz which is within the production variation. According to FCC Part 2.1091, this unlicensed transmitting devices is categorically excluded from routine environmental evaluation for RF exposure prior to equipment authorization or use, According to the KDB 447498 and OET 65, the simple calculation as below: The source-based time averaged maximum radiated power = 5.18dBm+2dB= 7.18dBm = 5.22mW At the distance (R) of 20cm to 40cm and in 0.3 GHz to 6 GHz, MPE Exclusion Threshold Level: The MPE limit is 3060mW for general population and uncontrolled exposure in the 2.4GHz frequency range according to FCC Part 1.1307. As the measured power density at 20cm from the transmitter is lower than the MPE limit, the compliance to the MPE limit can be ensured by indicating the minimum 20cm separation between the transmitter's radiating structure and body of the user or nearby persons. Note: EIRP is higher than ERP, thus EIRP is compared with the Exclusion Threshold. FCC ID: 2ATNWK1ZNJD For Simultaneous Transmission: Total exposure ratio = 165.2/3060+5.22/3060=0.056<1 According to KDB 447498 D04, the device with multiple RF sources can be exempted from the requirements of RF exposure testing. FCC ID: 2ATNWK1ZNJD
