2ATPO-PB01-02BT Model

PB-02 specifications V 1.0 Copyrigh t © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 1 PB-02 Specifications Version V1.0 Copyright ©2020 PB-02 specifications V 1.0 Copyrigh t © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 2 Disclaimer and copyright notice The information in this article, including the URL address for reference, is subject to change without notice.The Documentation is provided "as is" without any warranty, including any warranties of merchantability, fitness for a particular purpose, or non-infringement, and any warranties mentioned in the proposal, specification or sample. This document is not responsible for any infringement of any patent rights arising out of the use of the information in this document. No license, express or implied, by estoppel or otherwise, is hereby granted. The test data obtained in this paper are all obtained by Ai-Thinker laboratory , and the actual results may be slightly different.The Wi-Fi alliance membership mark is owned by the WiFi alliance. All trade mark names, trademarks and registered trademarks mentioned herein are the property of their respective owners and are hereby declared. The final interpretation right is owned by Shenzhen Ai-Thinker Technology Co., Ltd. Note The contents of this manual may be changed due to the version upgrade of the product or other reasons. Shenzhen Ai-Thinker Technology Co., Ltd. reserves the right to modify the contents of this manual without any notice. This manual is only used as a guide, and Shenzhen Ai-Thinker Technology Co., Ltd. makes every effort to provide accurate information in this manual, but Shenzhen Ai-Thinker Technology Co., Ltd. does not ensure that the contents of the manual are completely true.All statements and information in this manual,and the recommendations do not constitute for any warranty, express or implied. PB-02 specifications V 1.0 Copyrigh t © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 3 Document development / revision / revocation resume Version Date Development/revision Developme nt Approval V1.0 2020.05.29 Initial development Xie Yiji PB-02 specifications V 1.0 Copyrigh t © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 4 Contents 1、Product Overview ..................................................................................................................................... 5 2、Electrical parameters ........................................................................................................................... 7 3、Appearance dimensions ........................................................................................................................... 9 4、Definition of pins ............................................................................................................................... 10 5、 Schematic diagrams ............................................................................................................................. 12 6、Design guidance ..................................................................................................................................... 12 7、Packaging information ......................................................................................................................... 16 8、 Contact us ............................................................................................................................................. 16 PB-02 specifications V 1.0 C opyright © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 5 1、Product Overview PB-02 is a BLE 5.0 low-power Bluetooth module based on PHY6212 chip; supports SIGMesh.. PHY6212 is equipped with ARM® Cortex™-M0 32-bit processor, 138KB SRAM, ultra-low power consumption,high performance and wireless multi-mode characteristics,, supports BLE functions of security, applications and wireless updates. PB-02 module has the function of Bluetooth mesh networking; the communication between devices through peer-to-peer network, using Bluetooth broadcast for communication, can ensure timely response in the case of multiple devices. It is mainly used in intelligent lamp control, wearable smart device, retail payment and other Internet of things fields; it can meet the requirements of low power consumption, low delay, low cost wireless data communication. Characteristics  1.1 mm spacing SMD-20 package  6 channels PWM output  The antenna adopts PCB onboard antenna; at the same time, half hole pad and antenna hole are reserved. The half-hole pad can guide the antenna to the motherboard, and the antenna hole can be directly welded to the spring antenna.  Brightness (duty cycle) adjustment range 5%-100%  Factory default cool and warm color 50%  PWM output frequency 1KHz  Features with Nightlight  Switching Color Temperature with Wall Switching PB-02 specifications V 1.0 C opyright © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 6 Main parameters Table 1 main parameter descriptions Model PB-02 Dimensions 12.2*18.6*2.3(±0.2) MM Package SMD-20 Wireless Standards Bluetooth 5.0 Frequency range 2400~2483.5 MHz Maximum transmit power Maximum dBm 10 Receiving sensitivity -93±2 dBm Interface GPIO/PWM/SPI/ADC Operating temperature -40°C ~ 85 °C Storage environment -40°C~125°C,<90% Powersupply range Supply voltage 2.7 V ~3.6 V, supply current ≥50 mA Power consumption Deep sleep mode :0.7 uA (IO wake-up) Dormancy mode :2 uA (RTC wake-up) RX mode :7 mA TX (10dBm):25mA PB-02 specifications V 1.0 C opyright © Shenzhen Ai-Thinker Technology Co.,Ltd All Rights Reserved 2020 7 2、Electrical parameters Electrical characteristics PB-02 module is electrostatic sensitive equipment, when handling need to take special precautions Absolute maximum rating Any more than the following absolute maximum values can cause module damage Power consumption Name Typical values Units Emission power consumption (10 dBm) 25 mA Receiving Power 7 mA Light Sleep 2 uA…

Text truncated - open the document above for the full version.

Shenzhen Ai-Thinker Technology Co., Ltd Family models difference declaration Product:BT Model Model: PB-02, PB-01 Difference declaration: All models are the same circuit and RF module, PB-02 has its own onboard antenna, PB-01 his used with external antenna Regards, Signature Name: guan ning Date: 2020/12/08

C5266091_X8_Ed.1 1/1 Letter of Authorization < Shenzhen Ai-Thinker Technology Co., Ltd > Company: Shenzhen Ai-Thinker Technology Co., Ltd Address: 410, Block C, Huafeng Smart Innovation Port, Gushu 2nd Road, Gushu Community, Xixiang Street, Baoan District, Shenzhen China Product Name: BT Model Model Number(s): PB-02, PB-01 Product Description: BT Model We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: guan ning Date: 2020/12/08 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 < Shenzhen Ai-Thinker Technology Co., Ltd > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/12/08 Subject: Request for Confidentiality FCC ID: 2ATPO-PB01-02 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No Block Diagram ☐ Schematics ☐ Test Report No No Test Setup Photos No User’s Manual ☐ NOTE 1 Internal Photos ☐ NOTE 1 Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, C5266091_X10_Ed.2 1/1 Signature: Name: guan ning Title: Manager

Shenzhen Ai-Thinker Technology Co., Ltd FCC – Modular Approval Request Rev 2.0 Modular Transmitter Approval Request Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD21046 Company name: Shenzhen Ai-Thinker Technology Co., Ltd FCC ID: 2ATPO-PB01-02 Gentlemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Equip Auth Guide v02’. FCC ID: 2ATPO-PB01-02 has been examined against the following requirements. Requirement per 15.212 and KDB 996369 D01 Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Yes,the products have a shield, Physical components and tuning capacitor(s) are assembly to the module and located internal to the shield. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Yes,The modulehas buffered modulation/data inputs. The module must contain power supply regulation on the module Yes,The modular transmitter has its own power supply regulation. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Yes,The module contains a permanently attached PCB antenna. The module must demonstrate compliance in a stand-alone configuration Yes, The modulecompliance in a stand- alone configuration. The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labeling requirements) Yes.The module has its permanently affixed FCC ID labeland the FCC ID label is laser engraved on the shield. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee The module complies with all specific rules applicable to the transmitter. The module must comply with RF exposure requirements Yes. We provided an MPE report to show the modulecomply with RF exposure requirements. Name: guan ning Date: Dec. 08. 2020 Title: Manager Signature of applicant:

S20092702205 Model: PB-02 Photo 1 Photo 2 PB-02 S20092702205 Model: PB-02 Photo 3 PB-02 Photo 4 PB-01 S20092702205 Model: PB-02 Photo 5 PB-01

Label location

S20092702205 Model: PB-02 Photo 1 PB-02 Photo 2 PB-02 S20092702205 Model: PB-02 Photo 3 PB-02 Photo 4 PB-02 BT ANT S20092702205 Model: PB-02 Photo 5 PB-01 Photo 6 PB-01 BT ANT

FCC ID: 2ATPO-PB01-02 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. MAX OUTPUT POWER BLE Condition Mode Frequency (MHz) Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE-1M 2402 -3.36 30 Pass NVNT BLE-1M 2440 -2.31 30 Pass NVNT BLE-1M 2480 -3.95 30 Pass NVNT BLE-2M 2402 -3.45 30 Pass NVNT BLE-2M 2440 -2.40 30 Pass NVNT BLE-2M 2480 -4.05 30 Pass Measurement Result Operation Frequency: 2402-2480MHz Power density limited: 1mW/ cm 2 Antenna Type: PCB Antenna Antenna gain:1.5 dBi R=20cm BLE: conducted power Evaluation result Power density Limits (dBm)(mW)(dBi)Numeric 2402 -3.4-3±1-2 0.6311.501.410.00021 2440 -2.3-3±1-2 0.6311.501.410.00021 2480 -4.0-3±1-2 0.6311.501.410.00021 (mW/cm2 ) Channel Freq. (MHz) modulation Tune-up power (dBm) (dBm) GFSK (mW/cm2) Antenna Gain Max tune-up power Conclusion: For the max result : 0.0002≤ 1.0 for Max Power Density, compliance RF exposure. Signature: Date: 2020-12-08 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

Report No.: S20092702205001 Version.1.3 Page 1 of 59 RADIO TEST REPORT FCC ID: 2ATPO-PB01-02 Product: BT Model Trade Mark: B&T, Model No.: PB-02 Family Model: PB-01 Report No.: S20092702205001 Issue Date: 20 Nov.2020 Prepared for Shenzhen Ai-Thinker Technology Co., Ltd 410, Block C, Huafeng Smart Innovation Port, Gushu 2nd Road, Gushu Community, Xixiang Street, Baoan District, Shenzhen China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District Shenzhen, Guangdong, China Tel:400-800-6106 , 0755-3699-5508 Website:http://www.ntek.org.cn Report No.: S20092702205001 Version.1.3 Page 2 of 59 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 SUMMARY OF TEST RESULTS ......................................................................................................................... 4 3 FACILITIES AND ACCREDITATIONS ............................................................................................................. 5 3.1 FACILITIES..................................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 5 3.3 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 6 5 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................... 9 6.2 SUPPORT EQUIPMENT............................................................................................................................... 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS .............................................................................................. 11 7 TEST REQUIREMENTS .................................................................................................................................... 13 7.1 CONDUCTED EMISSIONS TEST ............................................................................................................... 13 7.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 16 7.3 6DB BANDWIDTH ....................................................................................................................................... 28 7.4 DUTY CYCLE ............................................................................................................................................... 29 7.5 PEAK OUTPUT POWER .............................................................................................................................. 30 7.6 POWER SPECTRAL DENSITY ................................................................................................................... 31 7.7 CONDUCTED BAND EDGE MEASUREMENT......................................................................................... 33 7.8 SPURIOUS RF CONDUCTED EMISSIONS................................................................................................ 34 7.9 ANTENNA APPLICATION .......................................................................................................................... 35 8 TEST RESULTS ................................................................................................................................................... 36 8.1 MAXIMUM CONDUCTED OUTPUT POWER........................................................................................... 36 8.2 OCCUPIED CHANNEL BANDWIDTH ....................................................................................................... 40 8.3 MAXIMUM POWER SPECTRAL DENSITY LEVEL ................................................................................. 44 8.4 BAND EDGE ................................................................................................................................................. 48 8.5 CONDUCTED RF SPURIOUS EMISSION .................................................................................................. 53 Report No.: S20092702205001 Version.1.3 Page 3 of 59 1 TEST RESULT CERTIFICATION Applicant’s name ......................... : Shenzhen Ai-Thinker Technology Co., Ltd Address ....................................... : 410, Block C, Huafeng Smart Innovation Port, Gushu 2nd Road, Gushu Community, Xixiang Street, Baoan District, Shenzhen China Manufacturer's Name .................. : Shenzhen Ai-Thinker Technology Co., Ltd Address ....................................... : 410, Block C, Huafeng Smart Innovation Port, Gushu 2nd Road, Gushu Community, Xixiang Street, Baoan District, Shenzhen China Product description Product name .............................. : BT Model Model and/or type reference ...... : PB-02 Family Model ............................... : PB-01 Measurement Procedure Used: APPLICABLE STANDARDS APPLICABLE STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C ANSI C63.10-2013 KDB 558074 D01 15.247 Meas Guidance v05r02 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report.…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
