TB-02 Specification V1.0 Copyright © 2019Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved I TB-02Specification Version V1.0 Copyright©2019 TB-02 Specification V1.0 Copyright © 2019Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved II Disclaimer and Copyright Notice The information in this article, including URL addresses for reference, is subject to change without notice. This document is provided "as is" without warranty of any kind, including any warranty of merchantability, fitness for a particular purpose, or non-infringement, and any warranty of any proposal, specification, or sample mentioned elsewhere. No liability is assumed in this document, including any infringement of any patent rights arising out of the use of the information in this document. No license is granted by estoppel or otherwise in this document, either express or implied. The test data obtained in this article are all obtained from the testing performed by Anxinke Labs. Actual results may vary slightly. The Bluetooth Alliance member logo is owned by the Bluetooth Alliance. All trademark names, trademarks and registered trademarks mentioned in this article are the property of their respective owners and are hereby declared. The final interpretation right belongs to Shenzhen Anxinke Technology Co., Ltd. Pay attention The contents of this manual may be changed due to product version upgrades or other reasons. Shenzhen Anxinke Technology Co., Ltd. reserves the right to modify the contents of this manual without any notice or prompt. This manual is only used as a guide. Shenzhen Anxin Ke Technology Co., Ltd. makes every effort to provide accurate information in this manual, but Shenzhen An Xin Ke Technology Co., Ltd. does not ensure that the content of the manual is completely error-free. All statements and information in this manual And recommendations do not constitute any express or implied warranty. TB-02 Specification V1.0 Copyright © 2019Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved III Document development/revision/revocation resume Version Date Revised content Maker Approve V1.0 2019.11.25 First developed Yiji Xie TB-02 Specification V1.0 Copyright © 2019Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved IV CONTENT 1.INTRODUCTION .............................................................................................................................................. V 2.SPECIFICATION .............................................................................................................................................. VII 3.DIMENSION ................................................................................................................................................. VIII 4.PIN DEFINITION ............................................................................................................................................. IX 5.SCHEMATIC .................................................................................................................................................... XI 6.DESIGN GUIDE ............................................................................................................................................... XI 7.REFLOW PROFILE ......................................................................................................................................... XIV 8.PACKAGING .................................................................................................................................................. IXV 9.CONTACT US ................................................................................................................................................ IXV TB-02 Specification V1.0 Copyright © 2019 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved V 1.INTRODUCTION The TB-02 intelligent lighting module is a Bluetooth module based on the TLSR8253F512 chip and compatible with BT 5.0 low-power Tmall Genie Mesh. This module supports the Bluetooth module directly controlled by Tmall Genie and has a Bluetooth mesh networking function. Peer-to-peer network communication, using Bluetooth broadcast for communication, can ensure timely response in the case of multiple devices. It is mainly used in intelligent light control, which can meet the requirements of low power consumption, low latency, and short-range wireless data communication. Features  Can be directly controlled by Tmall Elf without a gateway  1.6mm pitch pin vertical solder DIP18 package  6 PWM outputs  With on-board antenna, no need to design antenna  Brightness (duty cycle) adjustment range 5% -100%  Factory default 50% duty cycle for cool and warm colors  PWM output power 1KHz  With night light function  With wall switch to switch color temperature function TB-02 Specification V1.0 Copyright © 2019 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved VI LIST 1 Main Parameters Model Name TB-02 Size 18.0*18.0*2.8(±0.2)MM Wireless Standard Bluetooth V5.0 Frequency Range 2400 ~ 2483.5MHz Output Power 10dBm Max Sensitivity -93.2dBm Interface GPIO/PWM/SPI/ADC Work Temperature -20°C ~ 70 °C Store Temperature -40 °C ~ 125 °C , < 90%RH Voltage Range Voltage 2.7V ~ 3.6V, Current≥50mA Power Deep Sleep Mode：0.8uA Sleep Mode：1.8uA TX：12.62mA Transmission distance 80m ~ 150m TB-02 Specification V1.0 Copyright © 2019 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved VII 2.SPECIFICATION Electrical characteristics Absolute Maximum Rating Any exceeding the following absolute maximum ratings may cause damage to TLSR8253F512 RF Specification Sensitivity Item Min Typical Max Unit Sensitivity -92dBm -91dBm -90dBm dBm Item Min Typical Max Unit Voltage 2.7 3.3 3.6 V I/O Voltage (VCCIO) -0.3 - 3.6 V Work Temperature -20 - +70 °C Store Temperature -40 - +125 °C TB-02 Specification V1.0 Copyright © 2019 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved VIII 3.DIMENSION TB-02 Specification V1.0 Copyright © 2…

Text truncated - open the document above for the full version.

Photo 1 Photo 2 TB-02 Photo 3 TB-02 Photo 4 TB-03F Photo 5 TB-03F Photo 6 TB-04 Photo 7 TB-04

Photo 1 TB-02 Photo 2 TB-02 ANT Photo 3 TB-03F Photo 4 TB-03F ANT Photo 5 TB-04 Photo 6 TB-04 Photo 7 TB-04 ANT

version01 Shenzhen Ai-Thinker Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: TB-02, TB-03F, TB-04 FCC ID: 2ATPO-TB02 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for antenna type(s) described below: GFSK Model No. of antenna: N/A TB-02 Type of antenna: PCB Antenna Gain：2dBi TB-03F Type of antenna:PCB Antenna Gain：2dBi TB-04 Type of antenna: FPCB Antenna Gain：2dBi permanently attached Frequency range: 2402-2480MHz MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Ai-Thinker Technology Co., Ltd Address: 410, Block C, Huafeng Smart Innovation Port, Gushu 2nd Road, Gushu Community, Xixiang Street, Baoan District, Shenzhen, China City: Shenzhen ZIP / Postal code: Country: China Place: guan ning/manager Date: 2021/05/17 Signature:

FCC ID: 2ATPO-TB02 RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method E (V/m) ＝ d GP**30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 *377 **30 D GP From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Measurement Result Operation Frequency: BT: 2402-2480MHz Power density limited: 1mW/ cm 2 Antenna Type: PCB Antenna Antenna gain: 2dBi, R=20cm conducted power Evaluation result Power density Limits (dBm)(mW)(dBi)Numeric 2402 8.88 8±19 7.9432.001.580.00251 2440 8.51 8±19 7.9432.001.580.00251 2480 7.39 8±19 7.9432.001.580.00251 Channel Freq. (MHz) modulation Tune-up power (dBm) (dBm) BLE (mW/cm2 )(mW/cm2) Antenna Gain Max tune-up power Conclusion: For the max result : 0.0025≤ 1.0 for Max Power Density, compliance RF exposure.. Signature: Date: 2021-05-24 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.
