2ATV9TMY03GPS Tracker

pg. 1 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved. TMY03 IoT Wireless Device User Manual 1 Product Introduction TMY03 is an IOT intelligent wireless communication terminal that includes 4G (LTE Cat M1 and NB1) with 2G(GPRS) fallback. TMY03 is built-in a rechargeable lithium battery. TMY03 is with ultra-low power consumption, long battery life that is widely used in the field of tracking valuable assets. More details are as follows: • Support global LTE Cat M1, NB1 and GPRS network global frequency band. • Support terminal parameters configuration through SMS. • Support TCP/IP, UDP connection. • Support SSL/TLS encryption transmission protocol. • Support GPS/BDS/Galilleo/GLONASS/LBS position. • Built-in a rechargeable lithium battery. • IP65 rating for waterproof capability. • Easy installation without wires. 2 Function ➢ Location: The user can query the latest reported location of the targeted assets through mobile app or cloud service platform. ➢ Data Reporting: The user can set the reporting interval through platform. The device will connect the platform server to upload the location information according to the pre-configured reporting interval. The device report data every 24 hours by default. ➢ Battery Level Detection: The device will upload the low battery power alarm to platform when the battery power is less than 20%. ➢ Tamper Alarm: TMY03 has a built-in optical sensor. When the device is removed after installation, the optical sensor can be activated immediately and report the tamper alarm to platform. ➢ Wake-up Feature: The user can modify the schedule of the wake-up times of the device on the Platform to wake-up the device and report data at a fixed time. pg. 2 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved. ➢ Tracking: The user can set tracking time parameters through platform to realize real-time tracking of assets ➢ Working Mode: TMY03 has four working modes: Refresh Mode, Vibration Mode, Flight Mode, and Continuous working mode. ⚫ Refresh Mode: The device will wake up from the sleep state and report the data according fixed report interval. ⚫ Vibration Mode: The device will wake up from static state if continuous vibration/motion is detected by accelerator, report the data according to the preset reporting interval until the device stops moving for more than a certain working time. ⚫ Flight Mode: When the accelerometer detects that the device is in flight state (continuous motion), it will shut down the communication module until the device is in static state, returns to the timing report state. ⚫ Continuous working mode: Continuous working mode is needed when the device needs to be active all the time and upload the location data according to the user preconfigured interval. 3 Use Scenario TMY03 is mainly for overseas markets, especially countries and regions that have stopped 2G service. The terminal is mainly used for daily position monitoring of valuable assets (such as vending machines, automobiles, mobile devices, etc.) and tracking of the transportation process of valuables. The terminal is generally installed inside the valuable assets or on the transport tray, pallet and loading box. pg. 3 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved. 4 Device Installation Guidance The device parameters need to set and relevant information need to register on the platform before installation. Regarding parameter setting and platform data entry, please refer to the platform operation manual or consult our customer service personnel. 4.1 Get Started To use the device, the user needs to open the top cover, insert the SIM card correctly, turn the power on, and install the device. The user can open the top cover by hand. There are two LED indicators under the cover: the blue LED shows the GPS status, and the green LED shows the cellular connectivity status. Please review the following diagram (need update the diagram) for the different LED combinations. Terminology: Fast blinking: The indicator light flashes 3-5 times in 1s. Slow blinking: The indicator light flashes one times in 2s. GPRS green LED Off: Module off Slow blink: GPRS connecting Fast blink: GPRS connected Solid on: platform connected GPS blue LED Off: Module off Slow blink: GPS locating Solid on: GPS located pg. 4 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved. 4.2 SIM Card Installation Open the SIM card holder cover, insert the SIM card into the SIM card holder. Ensure that the SIM card is properly placed. Close the SIM card cover. Please take note of the ICCID of the SIM card, and make sure that the SIM card has an active subscription for the required cellular connectivity. 4.3 Device Power Up After the SIM card is installed, move the power switch to the ON position. When the blue LED starts blinking, the device is powered on. 4.4 Device Installation Close the top cover after the device is powered up. Peel one side of the supplied 3M double sided tape and place it in the white square area in the bottom of the device (optical sensor side). Peel the other side of the tape and place and press down the TMY03 firmly over a clean flat surface area so that the 3M tape holds the TMY03 in place. If the device is removed, the optical sensor can be activated immediately and trigger tamper alarm. Notes: ⚫ The ideal installation direction of the terminal is that the top cover is facing the sky. To prevent the GNSS positioning signal from being blocked and unable to be located, it must be ensured that no metal barrier pg. 5 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved. above the top cover. If the terminal cannot be installed face up due to the limitation of the installation environment, the top cover can also be installed in the horizontal direction. ⚫ The installation position of the device shall be in the position without radio signal shielding. The installation surface shall be kept clean and free of oil and dust, which will affect the installation firmness. ⚫ During the installat…

Text truncated - open the document above for the full version.

ThingsMatrix Inc. 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 Statement and explanations The host TMY03(FCC ID : 2ATV9TMY03) is a new product with one certified module(module Quectel BG96(Module FCC ID:XMR201707BG96).) integrated. This module is a single modular and it was integrated into the host that not any effect on RF performance. And considering the antenna is designed for the host (TMY03 ) when the module is integrated in the host , we have performed MPE for the host and the ERP/EIRP and RSE re-tested. Please refer to the lab test results accordingly. Should you have any question or comment regarding this matter , Please have my best attention. Sincerely yours print name: Huitao Liu Email: [email protected] Telephone Number: 4047915958 Title: VP Signature: .

Rev 11/20/07 ThingsMatrix Inc. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ATV9TMY03 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (Block Diagram, Schematics, Operational Description, Parts List, Tune Up Info) (1.Block Diagram.pdf; 4.MB_P4_sch.pdf; 3.Operation Description.pdf; 2.BOM.pdf; 8. Tuneup.pdf;) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for a period of 45days: Exhibit Type File Name (External Photos, Internal Photos, Test Setup Photos, Manual) (Appendix A.1-External Photos.pdf; Appendix A.2-Internal Photos.pdf; Appendix A.3-Test setup.pdf; User Manual.pdf;) Sincerely, print name: Huitao Liu Email: [email protected] Telephone Number: 4047915958 Title: VP

RF_160, Issue 04 ThingsMatrix Inc. Declaration of Authorization We Name: ThingsMatrix Inc. Address: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 City: Austin Country: United States Declare that: Name Representative of agent: Jim Huang Agent Company name: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No.1 Workshop, M-10, Middle Section, Science & Technology Park, City: Shenzhen Country China is authorized to apply for Certification of the following product(s): Product description: GPS Tracker FCC ID: 2ATV9TMY03 Type designation: TMY03 Trademark: ThingsMatrix on our behalf. print name: Huitao Liu Email: [email protected] Telephone Number: 4047915958 Title: VP Signature: .

FEDERAL COMMUNICATIONS COMMISSION Supplier’s Declaration of Conformity (SDoC) Equipment: GPS Tracker Trademark(s) and Model(s): ThingsMatrix TMY03 Manufacturer: ThingsMatrix Inc. FCC ID in case other parts of this equipment are subject to certification: 2ATV9TMY03 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number: ZR/2019/C000301 Issue date: 2019-12-30 The following manufacturer/importer/entity (located in the USA) is responsible for this declaration: Company name: ThingsMatrix Inc. Name/Title (legal representative): Huitao Liu Address: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 Phone: 4047915958 E-mail: [email protected] Date:2020-1-10 Signature: FCC

Justification letter This letter is to explain the reason for adjusting the voltage. Because the previous Operational description & User manual voltage was incorrectly filled, not the actual voltage, this statement was issued to revise the report and Operational description / User manual. Operational description update page 1 and page 3 Voltage information User manual update page 5 Voltage information ZR2019C000302-FCC RF TEST REPORT update page 9 Voltage information Name: ThingsMatrix Inc. Address: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 Product description: GPS Tracker Type designation: TMY03 Trademark: ThingsMatrix on our behalf. print name: Huitao Liu Email: [email protected] Telephone Number: 4047915958 Title: VP Signature: .

Page 1 of 3 1 Photographs - EUT Constructional Details Model No.(EUT): TMY03 FCC ID: 2ATV9TMY03 Page 2 of 3 Page 3 of 3

Label location

pg. 1 Copyright © 2019 ThingsMatrix Inc., All Rights Reserved.

Page 1 of 6 1 Photographs - EUT Constructional Details Model No.(EUT): TMY03 FCC ID: 2ATV9TMY03 Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2019/C000303 Page: 1 of 7 Authorized Signature: Derek Yang Wireless Laboratory Manager Cover PRF Exposure Evaluation Report Application No.: ZR/2019/C0003 Applicant: ThingsMatrix Inc. Address of Applicant: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 Manufacturer: ThingsMatrix Inc. Address of Manufacturer: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 EUT Description: GPS Tracker Model No.: TMY03 Trade Mark: ThingsMatrix FCC ID: 2ATV9TMY03 Standards: 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 Date of Receipt: 2019/12/7 Date of Test: 2019/12/7 to 2020/1/6 Date of Issue: 2020/1/6 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2019/C000303 Page: 2 of 7 1 Version Revision Record Version Chapter Date Modifier Remark 00 2020/1/6 Original Authorized for issue by: 2020/1/6 Mike Hu /Project Engineer 2020/1/6 David Chen /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2019/C000303 Page: 3 of 7 Contents 1 VERSION ................................................................................................................................................................. 2 2 GENERAL INFORMATION .................................................................................................................................. 4 2.1 CLIENT INFORMATION ..................................................................................................................................... 4 2.2 TEST LOCATION .............................................................................................................................................. 4 2.3 TEST FACILITY ................................................................................................................................................. 4 2.4 GENERAL DESCRIPTION OF EUT .................................................................................................................... 5 3 RF EXPOSURE EVALUATION ........................................................................................................................... 6 3.1 RF EXPOSURE COMPLIANCE REQUIREMENT ................................................................................................. 6 3.1.1 Limits .......................................................................................................................................................... 6 3.1.2 Test Procedure ......................................................................................................................................... 6 3.1.3 EUT RF Exposure Evaluation ................................................................................................................ 7 3.1.4 Exposure calculations for multiple sources .......................................................................................... 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2019/C000303 Page: 4 of 7 2 General Information 2.1 Client Information Applicant: ThingsMatrix Inc. Address of Applicant: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 Manufacturer: ThingsMatrix Inc. Address of Manufacturer: 9442 North Capital of Texas Hwy,Plaza One, Suite 500,Austin, TX 78759 2.2 Test Location Company: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China Post code: 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 E-mail: [email protected] 2.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L2929) CNAS has accredited SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab to ISO/IEC 17025:2005 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Industry Canada (IC) Two 3m Semi-anechoic chambers and the 10m Semi-anechoic chamber of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab have been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 4620C-1, 4620C-2, 4620C-3. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2019/C000303 Page: 5 of 7 2.4 General Description of EUT EUT Description: GPS Tracker Model No.: TMY03 Trade Mark: ThingsMatrix Hardware Version: TMY03V01 Software Version: TMY03V01.191230 Antenna Gain: GSM 850: -0.16dBi; GSM1900: 0.41dBi; NB1 Band 2: 0.41dBi; NB1 Band 5: -0.16dBi; NB1 Band 12: -0.25dBi; NB1 Band 13: -0.23dBi; NB1 Band 26: -0.22dBi; CatM1 Band 2: 0.41dBi; CatM1 Band 4: 0.45dBi; CatM1 Band 5: -0.16dBi; CatM1 Band 12: -0.25dBi; CatM1 Band 13: -0.23dBi; CatM1 Ban…

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd. FCC ID XMR201707BG96 Product Quectel BG96 Brand Quectel Model BG96 Report No. RXA1706-0199RF05 Issue Date August 29, 2017 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2017)/ FCC CFR 47 Part 22H (2017). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Jiangpeng Lan Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 FCC RF Test Report Report No: RXA1706-0199RF05 TA Technology (Shanghai) Co., Ltd. TA-MB-04-001R Page 2 of 45 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ...................................................................................................................................... 4 1.1. Notes of the Test Report ............................................................................................................... 4 1.2. Test facility ..................................................................................................................................... 4 1.3. Testing Location ............................................................................................................................ 5 2. General Description of Equipment under Test ....................................................................................... 6 3. Applied Standards .................................................................................................................................. 7 4. Test Configuration .................................................................................................................................. 8 5. Test Case Results .................................................................................................................................. 9 5.1. RF Power Output ........................................................................................................................... 9 5.2. Effective Radiated Power ............................................................................................................ 11 5.3. Occupied Bandwidth ................................................................................................................... 14 5.4. Band Edge Compliance ............................................................................................................... 22 5.5. Peak-to-Average Power Ratio (PAPR) ....................................................................................... 27 5.6. Frequency Stability ...................................................................................................................... 29 5.7. Spurious Emissions at Antenna Terminals ................................................................................. 33 5.8. Radiates Spurious Emission ....................................................................................................... 36 6. Main Test Instruments ......................................................................................................................... 42 ANNEX A: EUT Appearance and Test Setup .............................................................................................. 43 A.1 EUT Appearance ......................................................................................................................... 43 A.2 Test Setup .................................................................................................................................... 45 FCC RF Test Report Report No: RXA1706-0199RF05 TA Technology (Shanghai) Co., Ltd. TA-MB-04-001R Page 3 of 45 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results No. Test Type Clause in FCC rules Verdict 1 RF power output 2.1046 PASS 2 Effective Radiated Power 22.913(a)(2) PASS 3 Occupied Bandwidth 2.1049 PASS 4 Band Edge Compliance 2.1051 / 22.917(a) PASS 5 Peak-to-Average Power Ratio 22.913(d)/ KDB 971168 D01(5.7) PASS 6 Frequency Stability 2.1055 / 22.355 PASS 7 Spurious Emissions at Antenna Terminals 2.1051 / 22.917(a) PASS 8 Radiates Spurious Emission 2.1053 / 22.917 (a) PASS Date of Testing: August 4, 2017 ~ August 18, 2017 Note: PASS: The EUT complies with the essential requirements in the standard. FAIL: The EUT does not comply with the essential requirements in the standard. FCC RF Test Report Report No: RXA1706-0199RF05 TA Technology (Shanghai) Co., Ltd. TA-MB-04-001R Page 4 of 45 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. This report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. 1.2. Test facility CNAS (accreditation number: L2264) TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS). FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform…

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd. FCC ID XMR201707BG96 Product Quectel BG96 Brand Quectel Model BG96 Report No. RXA1706-0199RF06 Issue Date August 29, 2017 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2017)/ FCC CFR 47 Part 24E (2017). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Jiangpeng Lan Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 FCC RF Test Report Report No: RXA1706-0199RF06 TA Technology (Shanghai) Co., Ltd. TA-MB-04-002R Page 2 of 37 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ...................................................................................................................................... 4 1.1. Notes of the test report .................................................................................................................. 4 1.2. Test facility ..................................................................................................................................... 4 1.3. Testing Location ............................................................................................................................ 5 2. General Description of Equipment under Test ....................................................................................... 6 3. Applied Standards .................................................................................................................................. 7 4. Test Configuration .................................................................................................................................. 8 5. Test Case Results .................................................................................................................................. 9 5.1. RF Power Output ........................................................................................................................... 9 5.2. Effective Isotropic Radiated Power ............................................................................................. 11 5.3. Occupied Bandwidth ................................................................................................................... 14 5.4. Band Edge Compliance ............................................................................................................... 19 5.5. Peak-to-Average Power Ratio (PAPR) ....................................................................................... 22 5.6. Frequency Stability ...................................................................................................................... 24 5.7. Spurious Emissions at Antenna Terminals ................................................................................. 27 5.8. Radiates Spurious Emission ....................................................................................................... 30 6. Main Test Instruments ......................................................................................................................... 34 ANNEX A: EUT Appearance and Test Setup .............................................................................................. 35 A.1 EUT Appearance ......................................................................................................................... 35 A.2 Test Setup .................................................................................................................................... 37 FCC RF Test Report Report No: RXA1706-0199RF06 TA Technology (Shanghai) Co., Ltd. TA-MB-04-002R Page 3 of 37 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. Summary of measurement results No. Test Case Clause in FCC rules Verdict 1 RF power output 2.1046 PASS 2 Effective Isotropic Radiated power 24.232(c) PASS 3 Occupied Bandwidth 2.1049 PASS 4 Band Edge Compliance 2.1051 /24.238(a) PASS 5 Peak-to-Average Power Ratio 24.232/KDB 971168 D01(5.7) PASS 6 Frequency Stability 2.1055 / 24.235 PASS 7 Spurious Emissions at Antenna Terminals 2.1051 / 24.238(a) PASS 8 Radiates Spurious Emission 2.1053 / 24.238(a) PASS Date of Testing: August 4, 2017 ~ August 18, 2017 Note: PASS: The EUT complies with the essential requirements in the standard. FAIL: The EUT does not comply with the essential requirements in the standard. FCC RF Test Report Report No: RXA1706-0199RF06 TA Technology (Shanghai) Co., Ltd. TA-MB-04-002R Page 4 of 37 This report shall not be reproduced except in full, without the written approval of TA Technology (Shanghai) Co., Ltd. 1. Test Laboratory 1.1. Notes of the test report This report shall not be reproduced in full or partial, without the written approval of TA technology (shanghai) co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein .Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. This report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. 1.2. Test facility CNAS (accreditation number: L2264) TA Technology (Shanghai) Co., Ltd. has obtained the accreditation of China National Accreditation Service for Conformity Assessment (CNAS). FCC (Designation number: CN1179, Test Firm Registration Number: 446626) TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform …

Text truncated - open the document above for the full version.

RF TEST REPORT Applicant Quectel Wireless Solutions Co., Ltd. FCC ID XMR201707BG96 Product Quectel BG96 Brand Quectel Model BG96 Report No. RXA1706-0199RF07 Issue Date August 29, 2017 TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 2 (2017)/ FCC CFR47 Part 27C (2017). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Performed by: Jiangpeng Lan Approved by: Kai Xu TA Technology (Shanghai) Co., Ltd. No.145, Jintang Rd, Tangzhen Industry Park, Pudong Shanghai, China TEL: +86‐021‐50791141/2/3 FAX: +86‐021‐50791141/2/3‐8000 FCC RF Test Report Report No: RXA1706-0199RF07 TA Technology (Shanghai) Co., Ltd. TA-MB-0…

Text truncated - open the document above for the full version.
