ELEVATE YOUR PLAY Wireless Effects Pedal Controller Guide BEYOND THE BOARD What’s Included Controller + Attachment SystemCharging Cable Dock 01 01 TABLE OF CONTENTS 02 AIRPATCH DOCK 03 PAIRING YOUR AIRPATCH 04 AIRPATCH CONTROLLER 05 CHARGING YOUR CONTROLLER 06 CONTROLLER ATTACHMENT 07 MAKING IT YOUR OWN 08 MODE SELECTION 09 PREPARE FOR LAUNCH 10&11 FLIGHT MODES 12 AIRPATCH SPECIFICATIONS 13 STAY PATCHED IN Table of Contents Airpatch Dock Select the eff ects pedals you want to use with your Airpatch and connect them between the Send and Return jacks on the Airpatch Dock. (See Figure A.1 for connection example.) The audio source connects to the Input jack while the rest of your audio signal chain connects to the Airpatch Output. Ensure all pedals between your Airpatch Send and Return are powered ON and engaged. For the 9V connection, use a standard 2.1mm center negative barrel connector ONLY. Power supply is not included. 02 Airpatch Dock 03 Pairing Your irpatch Use your Airpatch Dock Button—with the Airpatch Sonic Bars—to cycle through modes and pair your Controller. Hold the Dock Button down for 3 seconds until the Dock’s LED starts blinking. Press your Airpatch Controller once to pair it. The Dock’s LED will then stop blinking and remain ON. 04 Airpatch Controller When you press your Airpatch Controller, the surface will fl ash white. When the LED fl ashes red, your battery is low (~1 hour remaining). If the light does not fl ash at all, your battery is depleted and your Controller must be charged. 05 Charging Your Controller Charge your Airpatch Controller with the magnetic USB cable provided and a standard 5V USB power supply. The magnetic charging connector is designed to fi t one way only so look for the light to appear red indicating your Controller is charging. It will turn white once it’s complete (~45 minutes). Remove the charging cable once your battery is full. 06 Controller ttachment Your Airpatch includes a Mounting Plate with a release lever and a removable, fi nish-friendly adhesive pad, allowing you to quickly and easily attach and detach your Airpatch from a variety of instrument surfaces and positions. Simply peel off the white fi lm from the Mounting Plate’s adhesive pad to expose the permanent adhesive and carefully stick it to the bottom of the Mounting Plate. The clear side is fi nish-friendly adhesive. Peel off the clear fi lm and secure the Mounting Plate to your instrument. The adhesive is strong but removable and reusable. 07 Making It Your Own When connecting your eff ects pedals, Airpatch enables endless combinations. Ever wish you could control your favorite eff ects right on your instrument? What about getting more out of your go-to pedals? Your Airpatch makes it possible. Airpatch encourages freedom of movement and expression. Experiment by placing the Airpatch Controller in diff erent locations on your instrument until you fi nd the position that’s most comfortable and best suited to your playing style. Airpatch uses medium-pressure silicone switches to avoid accidental eff ects switching. The areas to the left and right of the grip bars require slightly less pressure to activate while the center of the Controller Button requires slightly more pressure to engage. 08 Mode Selection Dock Button Flight Mode Latch Momentary Reverse Momentary LED Color Description Simply press the Airpatch Dock Button located in the left side of the Dock to switch Flight Modes. The three-color LED will indicate which Flight Mode you’re in. Press the Airpatch Controller to activate pedals; press again to turn them off . You can connect multiple pedals in your eff ects loop! With responsive control, your eff ects are activated by pressing and holding the Airpatch Controller. Your eff ects default to ON. The eff ects loop is bypassed for as long as the Airpatch Controller is pressed and held. Mode Selection InstrumentAmp out out in in 09 Prepare for Launch Figure A.1 — Airpatching Your Effects Pedals 10 Flight Modes Tone Tacks Get more out of your pedals with wireless control and unique switching features. Lead Button Distortion/Boost + Latch Mode — Use your Airpatch to launch into your lead section. Add a modulation to your effects loop and activate multiple pedals at once. Tremolo/Stutter Button Tremolo Pedal + Momentary Mode — Press and hold Tremolo/Stutter for accents and dramatic note and chord holds. This is a great modulation when combined with distortion outside of your effects loop. Delay Trail Delay + Momentary/Latch Mode — Your Airpatch will continue to send your audio signal into the delay pedal even when it’s bypassed, preserving your delay trails. Dial in long delay times and use your Airpatch to bring in the ambient delay trail during phrases and chords. 11 PitchButton Pitch Shifter + Latch/Momentary Mode — Incorporate new and unprecedented harmonies and octaves into your soundscapes. Your Airpatch’s Momentary Mode acts like new notes for your instrument when combined with pitch eff ects. Three-wayKillswitch Momentary Mode — Leave your eff ects loop blank or directly connect your eff ects Send to the Return with just one patch cable. No pedals necessary. This provides you with two killswitch options. Use a distortion pedal in your Airpatch eff ects loop and a second distortion outside of your eff ects loop to stack other-worldly tones when switched rapidly. 12 Airpatch Specifications • 2.4 GHz wireless signal, similar to other low latency wireless guitar transmitters. • Noiseless switching circuit. • 9V center negative barrel connector — compatible with standard pedal board power systems. (Power supply not included.) • Over 50 feet of range (line of sight). • Long-lasting battery life Controller that lasts for multiple performances on a single charge. • USB charging cable for Airpatch Controller with magnetic connection. • Estimated 45-minute charging time. • Wireless controller LED indicator blinks white when button is activated. LED indicator blinks red notifyin…
Text truncated - open the document above for the full version.
SCS-F018: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Website: https://www.cps.bureauveritas.com/ Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 Updated References and Contact info 6.0 7.0 Aug-30-2020 SCS-F018: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 7.0 (Algorhythm Technologies Inc. DBA Aviate Audio) (2020-11-13) To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____( Algorhythm Technologies Inc. DBA Aviate Audio) _____ hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AU4S-716 Product Description: Airpatch Model: 716 Sincerely, Client’s signature Client’s name / title Alexander Schwartz, VP of Engineering Contact information / address : 1576 Sweethome Rd Suite 217C, Amherst, New York, United States
SCS-F019: Confidentiality Request Letter Page 1 of 3 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Website: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 3 Rev 7.0 (Algorhythm Technologies Inc. DBA Aviate Audio) (2020-11-13) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: 2AU4S-716 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, SCS-F019: Confidentiality Request Letter Page 3 of 3 Rev 7.0 Client’s signature: Client’s name & title: VP of Engineering Contact information / address: 1576 Sweethome Rd Suite 217C, Amherst, New York, United States
Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:28 of 34 6.2 EUT Constructional Details Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:29 of 34 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:30 of 34
2cm 0.5cm
Label Location
Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 Test Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No. : CQASZ20201100032EX-01 Applicant: Algorhythm Technologies Inc. DBA Aviate Audio Address of Applicant: 1576 Sweethome Rd Suite 217C, Amherst, New York, United States Equipment Under Test (EUT): Product: Airpatch Model No.: 716 Brand Name: N/A FCC ID: 2AU4S-716 Standards: 47 CFR Part 15, Subpart C Date of Test: 2020-11-03 to 2020-11-10 Date of Issue: 2020-11-11 Test Result : PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By: (Daisy Qin) Reviewed By: (Aaron Ma) Approved By: ( Jack Ai) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:2 of 33 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20201100032EX-01 Rev.01 Initial report 2020-11-11 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:3 of 33 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203 ANSI C63.10 (2013) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2013) PASS Field Strength of the Fundamental Signal 47 CFR Part 15, Subpart C Section 15.249 (a) ANSI C63.10 (2013) PASS Spurious Emissions 47 CFR Part 15, Subpart C Section 15.249 (a)/15.209 ANSI C63.10 (2013) PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.249(a)/15.205 ANSI C63.10 (2013) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.215 (c) ANSI C63.10 (2013) PASS Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20201100032EX-01 Page:4 of 33 3 Contents Page 1 VERSION .................................................................................................................................................................. 2 2 TEST SUMMARY .................................................................................................................................................... 3 3 CONTENTS .............................................................................................................................................................. 4 4 GENERAL INFORMATION .................................................................................................................................... 5 4.1 CLIENT INFORMATION ............................................................................................................................................. 5 4.2 GENERAL DESCRIPTION OF EUT ............................................................................................................................. 5 4.3 TEST ENVIRONMENT AND MODE ............................................................................................................................ 7 4.4 DESCRIPTION OF SUPPORT UNITS ............................................................................................................................ 7 4.1 TEST LOCATION ...................................................................................................................................................... 7 4.2 TEST FACILITY ........................................................................................................................................................ 7 4.3 STATEMENT OF THE MEASUREMENT UNCERTAINTY ................................................................................................ 8 4.4 DEVIATION FROM STANDARDS ................................................................................................................................ 8 4.5 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 8 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER .......................................................................................... 8 4.7 EQUIPMENT LIST ..................................................................................................................................................... 9 5 TEST RESULTS AND MEASUREMENT DATA ............................................................................................... 10 5.1 ANTENNA REQUIREMENT ..................................................................................................................................... 10 5.2 CONDUCTED EMISSIONS ....................................................................................................................................... 11 5.3 RADIATED EMISSION ............................................................................................................................................. 15 5.4 20DB BANDWIDTH ................................................................................................................................................ 23 6 PHOTOGRAPHS ................................................................................................................................................... 25 6.1 RADIATED EMISSION TEST SETUP ......................................................................................................................... 25 6.1 CONDUCTED EMISSION TEST SETUP ..................................................................................................................... 26 6.2 EUT CONSTRUCTIONAL DETAILS .....................................................................................…
