2AU4T-TC10Smart Car Holder with Charging & WiFi
Shanghai TUGE Data Technologies Co., Ltd.
Click to zoom
Application Details
- Equipment Class
- PCB - PCS Licensed Transmitter
- Date of Grant
- Sep 11, 2025
- Application Purpose
- Original Equipment
- Equipment Note
- Smart Car Holder with Charging & WiFi
- Frequency Range
- 699.70000000 - 715.30000000
- Country
- China
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
If you need to modify the SSID, Password of WiFi , your mobile phone or computer need to access the devices' WiFi hotspot, then login 192.168.100.1 with web browser . The default login user name: admin, default login password:admin. Quick Troubleshooting This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body .
