2AU99-LP167Wireless charging

User Manual Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE： This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. RF exposure compliance statement: This device has been evaluated to meet the general RF exposure requirement Product electrical performance 1. Power adapter specifications: DC12V ± 0.5V @ 1.25A 2. DC3.5 wire output: DC12V ± 0.5V @ 0.75A 3. Rated current: <0.7A (DC wire output is not connected to any products) 4. No-load power consumption: <0.3W 5. Buck chip output efficiency:> 85% 6. Overall efficiency:> 65% 7. Input voltage ripple / noise: <300mVp-p 8. TX coil power supply: DC5.5V ± 0.5V 9. TX transmit power: 5W 10. TX transmitting frequency: 125kHz 11. TX transmitting distance:> 3mm 12. Foreign object detection FOD: Yes, the minimum can detect 1 yuan coin (center position of the coil) 13. Maximum case temperature: <50 °C 14. Working environment temperature: <45 °C Indication LED lighting method 1. Power-on start: After the red and green flashes, turn to standby green light 2. Standby / charging is over: green light is always on 3. Charging: red light is on 4. Fault / Exception: Red light flashes

Shenzhen Letsolar Technology Co.LTD Agent Authorization Company: Shenzhen Letsolar Technology Co.LTD Address: Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Product Name: Wireless charging Model Number(s): LP167 Product Description:Wireless charging We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters c oncerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: Dec. 25, 2019 Signature: Name: LiuDi Title: manager Company: Shenzhen Letsolar Technology Co.LTD

Shenzhen Letsolar Technology Co.LTD Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Tel: +86-755-82556336/13632615951 Email: [email protected] Dec. 25, 2019 FCC ID: 2AU99-LP167 Model Number: LP167 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern, We, Shenzhen Letsolar Technology Co.LTD hereby declare that our product (Wireless charging) Model Number: LP167 will conduct FCC compliance testing, the sDOC part in recognized test lab. (Shenzhen HUAK Testing Technology Co., Ltd.). The product conforms KDB 680106 D01 V03 Clause 5 b) as follows; Requirements of KDB 680106 D01 Yes / No Description Power transfer frequency is less than 1 MHz Yes The device operate in the frequency range 115.0 KHz - 205.0 KHz Output power from each primary coil is less than 15 watts Yes The maximum output power of the primary coil is 5W. The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils. Yes The transfer system includes single coil that is able to detect receiver device. Client device is placed directly in contact with the transmitter. Yes Client device is placed directly in contact with the transmitter. Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes Mobile exposure conditions only The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are Yes The EUT H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are Shenzhen Letsolar Technology Co.LTD Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Tel: +86-755-82556336/13632615951 Email: [email protected] demonstrated to be less than 50% of the MPE limit. demonstrated to be less than 50% of the MPE limit. Please contact me if you have any question. Sincerely, Name: LiuDi Company: Shenzhen Letsolar Technology Co.LTD Address: Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Tel: +86-755-82556336/13632615951 Email: [email protected]

Shenzhen Letsolar Technology Co.LTD Date: Dec. 25, 2019 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2AU99-LP167 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: LiuDi Title: manager

SIZE: 25*60mm Wireless charging Model No.: LP167 FCC ID: 2AU99-LP167 FCC Statement: This device complies with part 15 of the fcc rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Loop coil antenna

Page 1 of 8 Report No.: HK1912063127-02E FCC TEST REPORT Test report On Behalf of Shenzhen Letsolar Technology Co.LTD For Wireless charging Model No.: LP167 FCC ID: 2AU99-LP167 Prepared for : Shenzhen Letsolar Technology Co.LTD Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Nov. 21, 2019 ~Nov. 27, 2019 Date of Report: Nov. 27, 2019 Report Number: HK1912063127-02E Page 2 of 8 Report No.: HK1912063127-02E Note: 1.For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 125 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. SUMMARY OF TEST RESULTS 2.1 Test procedures according to the technical standards: FCC KDB680106 D01 RF Exposure Wireless Charging Apps v03 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB680106 D01v03 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 All emissions,radiated(<30M)(9KHz-30MHz) ±2.45dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 3 of 8 Report No.: HK1912063127-02E 2.3 Test Instruments Description Brand Model No. Frequency Range Calibrated Date Calibrated Until Broadband Field Meter NARDA NBM-550 - Dec. 27, 2018 Dec. 26, 2019 Magnetic Field Meter NARDA ELT-400 1 – 400kHz Dec. 27, 2018 Dec. 26, 2019 Magnetic Probe NARDA HF-3061 300kHz – 30MHz Dec. 27, 2018 Dec. 26, 2019 Magnetic Probe NARDA HF-0191 27 – 1000MHz Dec. 27, 2018 Dec. 26, 2019 Broadband Field Meter NARDA NBM-550 - Dec. 27, 2018 Dec. 26, 2019 Electric Field Meter COMBINOVA EFM 200 5Hz – 400kHz Dec. 27, 2018 Dec. 26, 2019 E-Field Probe NARDA EF-0391 100kHz – 3GHz Dec. 27, 2018 Dec. 26, 2019 E-Field Probe NARDA EF-6091 100MHz – 60GHz Dec. 27, 2018 Dec. 26, 2019 NOTE: 1. The calibration interval of the above test instruments is 12 months . Page 4 of 8 Report No.: HK1912063127-02E 3. MAXIMUM PERMISSIBLE EXPOSURE 3.1 MAXIMUM PERMISSIBLE EXPOSURE Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-30061.4 0.163 1.0 6 300-1500F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-30027.5 0.073 0.2 30 300-1500F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applic able limit, see FCC 1.1310, 680106 D01 RF Exposure W ireless Charging Apps v03 Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 0.815A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 5 of 8 Report No.: HK1912063127-02E 4. TEST PROCEDURE a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 TEST SETUP 4.2 RESULT OF MAXIMUM PERMISSIBLE EXPOSURE Page 6 of 8 Report No.: HK1912063127-02E For Full load mode: E-Field Stre ngth at 15 cm fro m the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 2.05 1.59 1.25 2.08 1.62 614 H-Field Strength at 15 cm fro m the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.180.210.140.210.04 0.815 For Half Load mode: E- Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 1.33 1.83 0.64 1.53 1.80 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.11 0.270.25 0.190.14 0.815 Page 7 of 8 Report No.: HK1912063127-02E For No load mode: E-Field Strength at 15 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (V/m) 0.125 2.18 1.25 1.26 1.52 1.86 614 H-Field Strength at 15 cm from the edges surrounding the EUT (A/m) Frequency Range (MHz) Test Position A Test Position B Test Position C Test Position D Test Position E Limits Test (A/m) 0.125 0.25 0.10 0.14 0.260.31 0.815 Remark: According KDB 680106 D01 RF Exposure Wireless Charging App v03, section 5, b). The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous tr…

Text truncated - open the document above for the full version.

Page 1 of 24 Report No.: HK1912063127-E Prepared for : Shenzhen Letsolar Technology Co.LTD Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1F, B2 Building, Junfeng Zhongcheng Zhizao Innovation Park, Fuhai Street, Bao'an District, Shenzhen City, China Date of Test: Nov. 30, 2019 ~ Dec. 13, 2019 Date of Report: Dec. 13, 2019 Report Number: HK1912063127-E TEST REPORT FCC PART 15 SUBPART C Test report On Behalf of Shenzhen Letsolar Technology Co.LTD For Wireless charging Model No.: LP167 FCC ID: 2AU99-LP167 Page 2 of 24 Report No.: HK1912063127-E TEST RESULT CERTIFICATION Applicant’s name .................. : Shenzhen Letsolar Technology Co.LTD Address ................................... : Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Manufacture's Name............. : Shenzhen Letsolar Technology Co.LTD Address ................................... : Building D, Sanlian Industrial, Songbai Road, Shiyan Sub-district Office, Bao’an District, Shenzhen City, China Product description Trade Mark ................................ : N/A Product name ........................... : Wireless charging Model and/or type reference . : LP167 Standards............................... : 47 CFR FCC Part 15 Subpart C This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test .............................................. : Date (s) of performance of tests .............. : Nov. 30, 2019 ~ Dec. 13, 2019 Date of Issue............................................. : Dec. 13, 2019 Test Result ................................................. : Pass Prepared by: Project Engineer Reviewed by: Project Supervisor Approved by: Technical Director Page 3 of 24 Report No.: HK1912063127-E Table of Contents Page 1. SUMMARY .................................................................................................................................................................. 4 1.1. TEST STANDARDS ................................................................................................................................................ 4 1.2. TEST DESCRIPTION ................................................................................................................................................... 4 1.3. TEST FACILITY ......................................................................................................................................................... 5 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ........................................................................................................... 5 2. GENERAL INFORMATION ............................................................................................................................................ 6 2.1. ENVIRONMENTAL CONDITIONS.................................................................................................................................... 6 2.2. GENERAL DESCRIPTION OF EUT.................................................................................................................................. 6 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY ...................................................................................................... 6 2.4. RELATED SUBMITTAL(S) / GRANT (S)............................................................................................................................ 6 2.5. MODIFICATIONS ...................................................................................................................................................... 6 2.6. DESCRIPTION OF TEST SETUP .............................................................................................................................. 6 2.7. DESCRIPTION OF SUPPORT UNITS ................................................................................................................................ 7 2.8. EQUIPMENTS USED DURING THE TEST .......................................................................................................................... 7 3. TEST CONDITIONS AND RESULTS ................................................................................................................................ 8 3.1. CONDUCTED EMISSIONS TEST .................................................................................................................................... 8 3.2. 20DB BANDWIDTH ................................................................................................................................................ 11 3.3. RADIATED EMISSIONS ............................................................................................................................................. 12 3.4. ANTENNA REQUIREMENT ................................................................................................................................. 16 4. TEST SETUP PHOTOS OF THE EUT ............................................................................................................................. 17 5. PHOTOS OF THE EUT ................................................................................................................................................ 19 Page 4 of 24 Report No.: HK1912063127-E 1. SUMMARY 1.1. TEST STANDARDS The tests were performed according to following standards: ANSI C63.10: 2013 : American National Standard for Testing Unlicensed Wireless Devices ANSI C63.4: 2014: –American National Standard for Me…

Text truncated - open the document above for the full version.

Below 30MHz 30MHz-1000MHz Conducted Emission
