2AUFO-LE401BElectronic Earmuff

1 3 2 4 5 6 7 8 LE 401B USER MANUAL 1. Padded Headband 2. Battery Compartment 3. Guide Arms 4. Power / Volume Controls 5. LED “ON” Indicator Light 6. Microphones 7. Auxiliary Input Jack 8. Auxiliary Device Patch Cable 1. Diadema Acolchada 2. Compartimento de Batería 3. Brazos Guía 4. Encendido/Controles de Volumen 5. Indicador de Luz LED “Encendido” 6. Micrófonos 7. Conector para Entrada Auxiliar 8. Cable de Conexión para el Dispositivo Auxiliar 1. Serre-Tête Rembourré 2. Compartiment des Piles 3. Bras de Guidage 4. Commandes d’Alimentation / Volume 5. Voyant Lumineux de Marche 6. Microphone 7. Entrée Auxiliaire 8. Câble de Raccordement d’Appareil Externe BATTERY INSTALLATION install before use inside the left ear cup (the ear cup WITHOUT the Power / Volume Control knob). 1. The LE401B earmuff requires 2AAA size Alkaline batteries. The battery tray is The foam is cut and can be opened for battery installation. 2. Unit will not operate unless batteries are installed with correct polarity. Locate the “+” and “–” molded into the battery tray. Place the positive end of the battery at the end of the tray nearest to the “+”. The second battery is placed opposite to the first. 3. Installing the batteries over the ribbon will allow the user to remove the batter- ies by pulling on the loose end of the ribbon. 4. After installation of batteries, return foam to original position. 5. Without placing the ear muffs on head, check for correct battery installation by turning the Power / Volume Control knob to verify that the LED “ON” Indicator Light lights when the switch is in the “ON” position. VOLUME KNOB 1. Identify the Power / Volume Control knob. 2. Turn on and adjust the volume control by rotating the knobs from back to front until the desired volume is achieved. It is important to increase the volume control very gradually to avoid sudden increase in sound. When not in use, turn the knob counter-clockwise until you hear a ‘click’. This indicates the power to the electronics in the earmuff has been turned off. FITTING INSTRUCTIONS 1. For best results, it is important that the ear muff is fitted and worn properly. Maximum attenuation will only be achieved if the HPD is properly fitted. 2. Before ear muff is fitted to head, grasp ear cup with one hand, and headband with the other. Slide the ear cup gently away from the headband. The wire headband frame will extend from the guide arms about one inch. 3. Place ear muff on head, and gently collapse the headband frame into the guide arms until the headband rests on top of the wearer’s head and the ear cups completely cover the wearer’s ears. 4. The ear cup with the Power / Volume Control knob should be worn on over the wearer’s right ear. OPERATING INSTRUCTIONS 1. After installation of batteries and fitting, gently twist Power / Volume Control knob. There is slight resistance on the knob when unit is in “OFF” position. A click indicates unit is “on” and visible light from the LED verifies. 2. Increase volume gradually until sounds from surroundings can be heard. 3. Amplification of surroundings is interrupted when there are bursts or impulse noises at unsafe levels. AUXILIARY INPUT OPERATION 1. Use the accessory patch cable included with the unit. 2. Plug one end of the cable into the Auxiliary Jack on the ear muffs and the other end of the cable into the auxiliary device or smart phone. 3. Turn the ear muff Volume Control knob to “ON” position, but leave volume at minimum setting. 4. Turn on the music, radio or audio source from the external device. Use the volume control on the external device to adjust levels to your preference. 5. While Auxiliary device is plugged in and turned on, ear muffs will provide sound from your auxiliary device but will not amplify or let the wearer hear their surroundings. INSTALACIÓN DE LAS PILAS instale antes de usar 1. Las orejeras R-3200 funcionan con dos pilas alcalinas AAA. La bandeja de la batería está dentro de la Copa de la oreja izquierda (sin el poder / perilla de Control de volumen). La espuma se corta y se puede abrir para la instalación de la batería. 2. La unidad no funcionará si las baterías no están instaladas en la polaridad correcta. Ubique los “+” y “–” moldeados en la bandeja de la batería. Coloque la punta positiva de la batería en la parte final de la bandeja lo más cercano al “+”. La segunda batería se coloca opuesta a la primera. 3. Colocar las pilas sobre la cinta le permitirá al usuario quitar las pilas tirando del extremo de la cinta que está suelto. 4. Luego de colocar las pilas, vuelva a ubicar la espuma en la posición original. 5. Sin poner las orejeras en la cabeza, compruebe para la instalación correcta de la batería apagando / perilla de Control de volumen para verificar que la luz del indicador LED “ON” se enciende cuando el interruptor está en la posición “ON”. PERILLA PARA EL VOLUMEN 1. Identifique la Perilla para el Volumen. 2. Encienda y gire cada perilla en sentido de las manecillas del reloj hasta alcanzar el volumen deseado. Es importante incrementar el volumen gradualmente para evitar que el sonido incrementeabruptamente. Cuando el aparato no esté en uso, gire las perillas hasta que oiga un ‘clic’. Esto indica que la orejera ha sido apagada. INSTRUCCIONES DE AJUSTE 1. Para obtener los mejores resultados, es importante que las orejeras estén bien colocadas y se utilicen en forma correcta. 2. Antes de ajustar las orejeras a la cabeza, tome un auricular con una mano y la vincha con la otra. Separe con cuidado el vincha quede colocada en la cabeza de la persona que las va a usar y los auriculares cubran completamente sus orejas. 4. auricular de la vincha. El marco de la vincha con interior de alambre se separará del soporte-guía aproximadamente una pulgada (más de 2.5 cm). 3.Coloque las orejeras sobre la cabeza y con cuidado achique la vincha para que ingrese en el soporte-guía hasta que la El auricular que tiene la perilla de encendido y volumen debe utilizarse sobre la oreja derech…

Text truncated - open the document above for the full version.

Wenzhou Only Electronics Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Wenzhou Only Electronics Co., Ltd Address: No.23 Building, Gexiang High-tech Industrial Zone, Ruian City, Zhejiang Province, China Product Name: Electronic Earmuff FCCID: 2AUFO-LE401B Model(s): LE401B, R3200ECS, R3200ECS-WM, R3400ECS, R3700ECS, CAB3200ECS, CAB3220ECS 2.911(d)(5)(i) EquipmentType We, [Wenzhou Only Electronics Co., Ltd] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Helen Qian Date: Aug. 25, 2023 Title: Manager Company name: Wenzhou Only Electronics Co., Ltd Signature: NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Wenzhou Only Electronics Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Wenzhou Only Electronics Co., Ltd Address: No.23 Building, Gexiang High-tech Industrial Zone, Ruian City, Zhejiang Province, China Product Name: Power Strip FCCID: 2AUFO-LE401B Model(s): LE401B, R3200ECS, R3200ECS-WM, R3400ECS, R3700ECS, CAB3200ECS, CAB3220ECS 2.911(d)(5)(ii) Applicant filing We, [Wenzhou Only Electronics Co., Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Helen Qian Date: Aug. 25, 2023 Title: Manager Company name: Wenzhou Only Electronics Co., Ltd Signature: NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

WenzhouOnlyElectronicsCo.,Ltd 2.911(d)(7)USAAgentv1.4 Section2.911(d)(7)USA Agentfor Serviceof Process Companyname:WenzhouOnly ElectronicsCo., Ltd Address:No.23Building,GexiangHigh-techIndustrialZone, Ruian City, ZhejiangProvince, China ProductName:ElectronicEarmuff FCCID:2AUFO-LE401B Model(s):LE401B,R3200ECS,R3200ECS-WM,R3400ECS,R3700ECS,CAB3200ECS, CAB3220ECS 2.911(d)(7)USADesignatedAgentforServiceof Process We, [Wenzhou Only Electronics Co., Ltd](“the applicant”) designate [USA MEIHUA TRADING INC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicantconsent:We acknowledgeourconsentto acceptserviceof processin the UnitedStatesfor mattersrelatedto the applicableequipment,and at the physicalU.S. addressand emailaddressof the designatedagentand acknowledgeour acceptanceof our obligationto maintainan agent for serviceof processin the United Statesfor no less than one year after eitherwe the granteehave permanently terminatedall marketingand importationof the applicableequipmentwithin the U.S., or at the conclusionof any Commission-relatedadministrativeor judicialproceeding involvingthe equipment,whicheveris later. Agentobligation:We acknowledgeourobligationto acceptserviceof processin the UnitedStatesfor mattersrelatedto the applicableequipmentat our physicalU.S. addressand email addressforno less than one year after eitherthe granteehas permanentlyterminatedall marketingand importationof the applicableequipment withinthe U.S., or at the conclusionof any Commission-relatedadministrativeor judicialproceedinginvolvingthe equipment,whicheveris later.

Wenzhou Only Electronics Co., Ltd Agent Authorization Company: Wenzhou Only Electronics Co., Ltd Address: No.23 Building, Gexiang High-tech Industrial Zone, Ruian City, Zhejiang Province, China Product Name: Electronic Earmuff Model Number(s): LE401B, R3200ECS, R3200ECS-WM, R3400ECS, R3700ECS, CAB3200ECS, CAB3220ECS Product Description: Electronic Earmuff We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Aug. 25, 2023 Name: Helen Qian Title: Manager Company: Wenzhou Only Electronics Co., Ltd

Wenzhou Only Electronics Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Aug. 25, 2023 Subject; Request for Confidentiality FCC ID: 2AUFO-LE401B To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Helen Qian Title: Manager

Wenzhou Only Electronics Co., Ltd Model Difference Declaration To Whom It May Concern, We, Wenzhou Only Electronics Co., Ltd (Electronic Earmuff); Model Number: LE401B, R3200ECS, R3200ECS-WM, R3400ECS, R3700ECS, CAB3200ECS, CAB3220ECS Model Difference: All model’s the function, software and electric circuit are the same, only with a product model named different. Test sample model: LE401B. Please contact me if you have any question. Signature: Date: Aug. 25, 2023 Name: Helen Qian Title: Manager

Annex A External Photos Report No.: HK2307273313-E Page 1 of 3 Report No.: HK2307273313-E Page 2 of 3 Report No.: HK2307273313-E Page 3 of 3

FCC ID LABEL: Ca. 8mm x 10mm label location FCC ID: 2AUFO‐LE401B

Annex B Internal Photo Report No.: HK2307273313-E Page 1 of 6 Report No.: HK2307273313-E Page 2 of 6 Antenna Report No.: HK2307273313-E Page 3 of 6 Report No.: HK2307273313-E Page 4 of 6 Report No.: HK2307273313-E Page 5 of 6 Report No.: HK2307273313-E Page 6 of 6

FCC RF Exposure EUT Description: Electronic Earmuff Model No.: LE401B FCC ID: 2AUFO-LE401B 1. Limits According to KDB 447498 D01 General RF Exposure Guidance v01 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)]≤3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, Where: Result=P/D*√F F= the RF channel transmit frequency in GHz P=Maximum turn‐up power in mw D=Min. test separation distance in mm 2. Test Result of RF Exposure Evaluation Output power (dBm) Tune Up Power (dBm) Max Tune Up power dBm/mW Min test separati on distance mm Result Limit SAR Test Exclusion EDR 0.86 0±1(1) 1.26 5 0.38393 3.0 Pass Note: PK Output power= conducted power. Conducted power see the test report HK2307273313-E, antenna gain=1.2dBi Per KDB 447498 D01, when the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. The test exclusion threshold is 0.38393 which is<= 3, SAR testing is not required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f (GHz)] f(GHz) is the RF channel transmit frequency in GHz Distance=5mm

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(dBm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.2 (Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4(XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to ch ange without prior notice Antenna Layout & module on the system board Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane
